StarTech.com IES61002POE Manuel utilisateur

Manual Revision: 11/13/2013

For the most up-to-date information, please visit: www.startech.com

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

IES61002POE

6 Port Unmanaged Gigabit Ethernet Switch

with 4 PoE+ Ports - 30W per port

*actual product may vary from photos

Instruction Manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class A digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there

is no guarantee that interference will not occur in a particular installation. If this equipment

does cause harmful interference to radio or television reception, which can be determined by

turning the equipment o and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver

is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not

represent an endorsement of a product or service by StarTech.com, or an endorsement of the

product(s) to which this manual applies by the third-party company in question. Regardless

of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby

acknowledges that all trademarks, registered trademarks, service marks, and other protected

names and/or symbols contained in this manual and related documents are the property of

their respective holders.

Instruction Manual

Table of Contents

Product Diagram ....................................................................................1

Introduction............................................................................................2

Packaging Contents ................................................................................................................................. 2

System Requirements.............................................................................................................................. 2

Terminal Block Power Connector.........................................................3

DIP Switch Conguration......................................................................3

LED Indicators.........................................................................................4

Installation ..............................................................................................4

DIN Rail / Wall Bracket Installation...................................................................................................... 4

Specications..........................................................................................5

Technical Support ..................................................................................6

Warranty Information............................................................................6

Instruction Manual

Product Diagram

Terminal

Block

Shielded RJ45

LAN Ports

DIP Switch

Shielded RJ45

LAN Ports

with PoE

Instruction Manual

Introduction

Packaging Contents

• 1 x 6 Port Gigabit Switch

• 1 x Terminal Block

• 1 x Wall Mount Bracket w/ Screws

• 1 x DIN Rail Bracket w/ Screws

• 1 x Instruction Manual

System Requirements

• RJ45 terminated Cat5 or higher Ethernet cabling

• 10/100/1000 Mbps compatible Ethernet network

• 20-57 VDC Power Supply

Instruction Manual

Terminal Block Power Connector

Power can be provided through the dual inputs from separate sources, if needed. One

electrical relay can be wired into an alarm circuit. The relay is connected as Normally

Closed (will open upon alarm condition).

DIP Switch Conguration

1. Alarm Enable: When ‘On’ this switch will disable alarm relay and fault LED if there is

a power failure in one supply. If only connecting to a single power source, place this

switch ‘On’ to disable alarm.

2. BSP: When‘On’ this switch will disable the broadcast storm protection feature which

is enabled by default.

Instruction Manual

LED Indicators

PWR1: This green LED will light if power is connected and active at the PWR1 terminal

connection.

PWR2: This green LED will light if power is connected and active at the PWR2 terminal

connection.

Fault: This amber LED will light if one of the power inputs has fault condition and as

long as DIP sw#1 is OFF.

100/1000: This dual color LED will light with amber color when the LAN connected

speed is 1000M, it will light with green color when the LAN speed is 100M and will

remain o if the connected speed is 10M.

LINK/ACT: This green LED will light when the LAN port has a link and will ash when

there is Ethernet trac.

PoE: These green LEDs will light when the LAN has successfully negotiated PoE and is

supplying output power to the remote connected PD device.

Installation

DIN Rail / Wall Bracket Installation

If you are mounting the IES61002POE product onto either a DIN Rail or to a wall, you

will rst need to attach the appropriate bracket(s) to the device as shown below.

Instruction Manual

Specications

Number of Ports 6 (4 PoE)

Supported Standards IEEE 802.3at, 802.3af, 802.3, 802.3u, 802.3ab,

802.3z, 802.3x

Connectors 6 x RJ45 Female (Shielded)

1 x 6-wire Terminal Block

LED Indicator(s) PWR1, PWR2, Fault, 100/1000, Link/Act, PoE

Maximum Data Transfer Rate 2 Gbps (Full-Duplex)

Compatible Networks 10/100/1000 Mbps

Auto MDIX Yes

Full Duplex Support Yes

Switching Architecture Store-and-Forward

Maximum Cable Length 330ft (100m)

Power Source Redundant 20 - 57VDC

Power Consumption 2.91A@48VDC, 139.6Watts (120W for PoE)

5.95A@24VDC, 142.9Watts (120W for PoE)

Enclosure Material Metal (IP30)

Operating Temperature 0°C to 60°C (32°F to 140°F)

Storage Temperature -40°C to 75°C (-40°F to 167°F)

Humidity 5~95% (Non-condensing)

Dimensions 135 x 106 x 62.5 mm

Weight 840 g

Instruction Manual

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commitment to

provide industry-leading solutions. If you ever need help with your product, visit

www.startech.com/support and access our comprehensive selection of online tools,

documentation, and downloads.

For the latest drivers/software, please visit www.startech.com/downloads

Warranty Information

This product is backed by a two year warranty.

In addition, StarTech.com warrants its products against defects in materials

and workmanship for the periods noted, following the initial date of purchase.

During this period, the products may be returned for repair, or replacement with

equivalent products at our discretion. The warranty covers parts and labor costs only.

StarTech.com does not warrant its products from defects or damages arising from

misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their

ocers, directors, employees or agents) for any damages (whether direct or indirect,

special, punitive, incidental, consequential, or otherwise), loss of prots, loss of business,

or any pecuniary loss, arising out of or related to the use of the product exceed the

actual price paid for the product. Some states do not allow the exclusion or limitation

of incidental or consequential damages. If such laws apply, the limitations or exclusions

contained in this statement may not apply to you.
