StarTech.com 110VDSLEXT Manuel utilisateur

VDSL Ethernet LAN Extender

10/100 VDSL Ethernet

LAN Extender Kit

110VDSLEXT

110VDSLEXTGB

110VDSLEXTEU

Instruction Manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide rea-

sonable protection against harmful interference in a residential installation. This equip-

ment generates, uses and can radiate radio frequency energy and, if not installed and

used in accordance with the instructions, may cause harmful interference to radio com-

munications. However, there is no guarantee that interference will not occur in a particu-

lar installation. If this equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.•

Increase the separation between the equipment and receiver.•

Connect the equipment into an outlet on a circuit different from that to which the receiver•

is connected.

Consult the dealer or an experienced radio/TV technician for help.•

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and

do not represent an endorsement of a product or service by StarTech.com, or an en-

dorsement of the product(s) to which this manual applies by the third-party company in

question. Regardless of any direct acknowledgement elsewhere in the body of this doc-

ument, StarTech.com hereby acknowledges that all trademarks, registered trademarks,

service marks, and other protected names and/or symbols contained in this manual and

related documents are the property of their respective holders.

Table of Contents

Installation....................................................................... 1

Operation......................................................................... 1

LED Displays...........................................................................1

DIP Switch Settings.................................................................2

Connector Architecture ...............................................................5

Speciﬁcations.................................................................. 6

Technical Support........................................................... 7

Warranty Information...................................................... 7

Installation

Package Contents

1 x Extender•

1 x Receiver•

2 x RJ-45 to VDSL Cable•

1 x Instruction Manual•

2 x Power Adapter•

Hardware Installation

To install the 110VDSLEXT, all four of the DIP switches must be in1.

the upwards (OFF) position.

Plug the DC power adapter into the port on the rear panel of the2.

unit, and then into an available AC outlet.

Plug in an RJ45 Ethernet cable to the RJ45 port on the 110VD-3.

SLEXT.

Plug a phone cable into the VDSL port of the 110VDSLEXT.4.

Operation

LED Displays

LAN LED Display

LED Blinking ON OFF

1Activity Link up Link down

2100 Mbps 10 Mbps

3Full duplex Half duplex

VDSL LED Display

DIP Switch Settings

The 110VDSLEXT has a 4-position DIP switch for conﬁguration of

Side, Channel, Rate Limit, and SNR.

Pin 1 - CO, CPE Switch

OFF: If Pin 1 is in the OFF position, the 110VDSLEXT will operate in

Central Ofﬁce (CO) mode.

ON: If Pin 1 is in the ON position, the 110VDSLEXT will operate in

Customer Premise Equipment (CPE) mode.

Pin 2 - Interleave Noise Protection

LED Blinking ON OFF

1Activity Device

Power On

Device Power Off

2-CPE Mode CO Mode

3Slowly: Idle

Quickly: Training Linked Ofﬂine

OFF: If Pin 2 is in the OFF position, the 110VDSLEXT will operate in

Interleave mode, with communication protection for up to 250ms of

impulse noise with latency less than 6 ms

ON: If Pin 2 is in the ON position, the 110VDSLEXT will operate in Fast

mode, with direct data transmissions having less than 1ms of latency.

Pin 3 - Band Plan

OFF: If Pin 3 is in the OFF position, the 110VDSLEXT will operate in

Symmetric mode, with both downstream and upstream transmissions

operating on the G.997 band plan.

ON: If Pin 3 is in the ON position, the 110VDSLEXT will operate in

Asymmetric mode, with asymmetric short range transmissions operat-

ing at the highest available line rate.

Pin 4 - General Protection

OFF: If Pin 4 is in the OFF position, the 110VDSLEXT will operate with

a SNR ratio up to 9 dB.

ON: If Pin 4 is in the ON position, the 110VDSLEXT will operate with a

SNR ratio of 6 dB.

Connector Architecture

Ethernet Port

VDSL Port

Pin Number Assignment (MDI-X)

1RX+; Receive data +

2RX-; Receive data -

3TX+; Transmit data +

4Not used

5Not used

6TX-; Transmit Data -

7Not used

8Not used

Pin Number Assignment (MDI-X)

1Not used

2Not used

3Not used

4ANALOG Input/Output

5ANALOG Input/Output

6Not used

7Not used

8Not used

Specications

LAN Interface

RJ-45 connector

Complies with IEEE

802.3/802.3u/802.3x

10/100 Base-T Auto-Negotiation,

Auto-MDI/MDI-X

VDSL Interface

RJ-45 connector

DMT Encoding

Complies with ITU-T

G993.1/993.2

On-board surge protection

DIP Switch 4 position

LED

LAN: ACT/LNK, 10/100 Mbps,

Half/Full Duplex

VDSL: Power On/Off, CO/CPE,

Idle/Trained/Link

Power Supply DC single 12 Volt over 35mm DC

jack

Power Consumption 4.2 Watt maximum

Dimensions 95.5 x 69.4 x 22mm

Technical Support

StarTech.com’s lifetime technical support is an integral part of our com-

mit-ment to provide industry-leading solutions. If you ever need help

with your product, visit www.startech.com/support and access our com-

prehensive selection of online tools, documentation, and downloads.

Warranty Information

This product is backed by a one year warranty.

In addition, StarTech.com warrants its products against defects in

materials and workmanship for the periods noted, following the initial

date of purchase. During this period, the products may be returned for

repair, or replacement with equivalent products at our discretion. The

warranty covers parts and labor costs only. StarTech.com does not war-

rant its products from defects or damages arising from misuse, abuse,

alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com

USA LLP (or their ofﬁcers, directors, employees or agents) for any dam-

ages (whether direct or indirect, special, punitive, incidental, consequen-

tial, or otherwise), loss of proﬁts, loss of business, or any pecuniary loss,

arising out of or related to the use of the product exceed the actual price

paid for the product. Some states do not allow the exclusion or limitation

of incidental or consequential damages. If such laws apply, the limita-

tions or exclusions contained in this statement may not apply to you.
