StarTech.com ST121HDBT5 Manuel utilisateur

Manual Revision: 03/11/2014

For the most up-to-date information, please visit: www.startech.com

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

ST121HDBT5

HDMI over Cat 5/6 Extender w/ Serial & IR –

330ft (100m)

*actual product may vary from photos

Instruction Manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there

is no guarantee that interference will not occur in a particular installation. If this equipment

does cause harmful interference to radio or television reception, which can be determined by

turning the equipment o and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver

is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not

represent an endorsement of a product or service by StarTech.com, or an endorsement of the

product(s) to which this manual applies by the third-party company in question. Regardless

of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby

acknowledges that all trademarks, registered trademarks, service marks, and other protected

names and/or symbols contained in this manual and related documents are the property of

their respective holders.

Instruction Manual

Table of Contents

Product Diagram ....................................................................................1

Front View - Transmitter / Receiver Unit............................................................................................ 1

Rear View - Transmitter/Receiver Unit ............................................................................................... 1

Introduction............................................................................................2

Packaging Contents ................................................................................................................................. 2

System Requirements.............................................................................................................................. 2

Preparing Your Site ................................................................................3

Installation ..............................................................................................3

Hardware Installation .............................................................................................................................. 3

Specications..........................................................................................5

Technical Support ..................................................................................6

Warranty Information............................................................................6

Instruction Manual

Product Diagram

Front View - Transmitter / Receiver Unit

Rear View - Transmitter/Receiver Unit

Link LEDs Status

(Power)

LED

Power jack

Grounding

Bolt

Link (RJ-45

Connector)

IR out portIR in port

HDMI out port

Serial in port

Serial out port

LAN Ports 1, 2,

and 3

IR out

port

IR in

port

HDMI in port

Instruction Manual

Introduction

Packaging Contents

• 1 x HDMI extender

• 1 x HDMI receiver

• 2 x Mounting brackets

• 1 x IR sensor kit (Transmitter cable \ Receiver cable)

• 1 x CAT5 Cable

• 2 x Foot pad set

• 1 x Power Adapter

• 2 x Grounding Wire

• 1 x Instruction Manual

System Requirements

• HDMI® enabled video source device (i.e. computer, Blu-ray Player)

• HDMI® enabled display device (i.e. television, projector)

• Available AC electrical outlet for either the transmitter or receiver

• 2x HDMI® Cables (for video source to transmitter, and receiver to display)

Instruction Manual

Preparing Your Site

1. Determine where the local video source (i.e. computer, Blu-ray Player) will be

located and set up the device.

2. Determine where the remote display will be located and place/ mount the display

appropriately.

Note: This HDMI extender kit features Power over cable, allowing both the

transmitter and Receiver to be powered from a single power source that connects

to either the transmitter or receiver unit. Please ensure that unit you’ve chosen to

power is situated near an available AC electrical outlet. Make sure all devices are

turned o before beginning installation.

Before you begin Hardware Installation ensure both Transmitter and Receiver are

properly grounded.

Installation

Hardware Installation

1. Install Transmitter Unit

a) Position the Transmitter Unit near the video source (i.e. Computer, Blu-ray Player).

b) Connect an HDMI® cable from the video source device (i.e. computer, Blu-ray Player)

to the HDMI® in port on the Transmitter Unit.

c) (Optional) If you’ve chosen to connect the power adapter to the transmitter unit,

connect the power adapter from the power adapter port to an available wall outlet.

d) (Optional) If using the Extender to extend up to three 10/100 Network signal(s),

connect up to three Ethernet cable(s) from the Network gateway to the LAN Port(s)

on the Transmitter Unit.

e) (Optional) If using the Extender kit to transmit an infrared (IR) device signal, and

the device receiving the IR signal is on the Receiver side. Connect the IR Transmitter

Cable to the IR-RX port on the Transmitter Unit, and position the extended IR sensor

directly in front of the video source’s IR sensor. Check the manual of your video

source device for the IR sensor location. If the device receiving the IR signal is on

the Transmitter side, and connect the IR Transmitter Cable to the IR-TX port, and

position the IR sensor where the remote control will point.

f) (Optional) If using the Extender kit to transmit a serial signal. Connect a serial cable

(not included) from the serial in port on the Transmitter unit to the serial port on the

local device.

Instruction Manual

2. Install RJ45 terminated Cat5e/6 Ethernet Cable

a) Connect an RJ45 terminated Cat5e/6 Ethernet cable (not included) to the RJ45

connector on the Transmitter unit.

Note: If you are using surface cabling, ensure you have enough Category 5e

unshielded twisted pair (UTP) network cabling to connect the Host Unit to the

Remote Unit’s location, and that each end is terminated with a RJ45 connector. The

cabling should not go through any networking equipment (i.e. router, switch).

If you are using premises cabling, ensure that the Category 5 unshielded twisted

pair (UTP) network cabling between the Host Unit and the Remote Unit has been

properly terminated in a wall outlet in each location and there is a patch cable long

enough to connect the Remote Unit and the Host Unit to their respective outlets.

The cabling should not go through any networking equipment (i.e. router, switch).

b) Connect the other end of the Cat5e/6 cable run to the RJ45 connector on the

Receiver Unit.

3. Install Receiver Unit

a) Position the Receiver Unit near the video display (i.e. television, projector).

b) Connect the Display to the HDMI out port on the Receiver unit using an HDMI cable.

c) (Optional) If you’ve chosen to connect the power adapter to the Receiver unit,

connect the power adapter from the power adapter port to an available wall outlet.

d) (Optional) If using the Extender to extend up to three 10/100 Network signal(s),

connect up to three Ethernet cable(s) from the LAN Port(s) on the Receiver Unit to

RJ-45 port on your network device(s).

e) (Optional) If using the Extender kit to transmit an infrared (IR) device signal, and the

device receiving the IR signal is on the Transmitter side. Connect the IR Transmitter

Cable to the IR-TX port on the Receiver Unit, and position the IR sensor where the

remote control will point. If the device receiving the IR signal is on the Transmitter

side, and connect the IR Transmitter Cable to the IR-TX port, and position the

extended IR sensor directly in front of the video source’s IR sensor. Check the

manual of your video source device for the IR sensor location.

f) (Optional) If using the Extender kit to transmit a serial signal. Connect a serial cable

(not included) from the serial out port on the Receiver unit to the serial port on the

remote device.

4. Your source video image will now appear on the remote video display.

Instruction Manual

Specications

Local Unit Connectors

2x IrDA (Infrared; SIR/FIR)

1x HDMI (19 pin) Female

4x RJ-45 Female

1x RS232 (9 pin) Female

Remote Unit Connectors

2x IrDA (Infrared; SIR/FIR)

1x HDMI (19 pin) Female

4x RJ-45 Female

1x RS232 (9 pin) Male

Maximum Data Transfer Rate HDMI - 3.4Gbps

Max Distance 100 m / 330 ft

Maximum Digital Resolutions 1080p @ 60Hz, 48-bit

Wide Screen Supported Yes

Audio Specications Supports Dolby® TrueHD, DTS-HD MA

Instruction Manual

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commitment to

provide industry-leading solutions. If you ever need help with your product, visit

www.startech.com/support and access our comprehensive selection of online tools,

documentation, and downloads.

For the latest drivers/software, please visit www.startech.com/downloads

Warranty Information

This product is backed by a two year warranty.

In addition, StarTech.com warrants its products against defects in materials

and workmanship for the periods noted, following the initial date of purchase.

During this period, the products may be returned for repair, or replacement with

equivalent products at our discretion. The warranty covers parts and labor costs only.

StarTech.com does not warrant its products from defects or damages arising from

misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their

ocers, directors, employees or agents) for any damages (whether direct or indirect,

special, punitive, incidental, consequential, or otherwise), loss of prots, loss of business,

or any pecuniary loss, arising out of or related to the use of the product exceed the

actual price paid for the product. Some states do not allow the exclusion or limitation

of incidental or consequential damages. If such laws apply, the limitations or exclusions

contained in this statement may not apply to you.

Hard-to-nd made easy. At StarTech.com, that isn’t a slogan. It’s a promise.

StarTech.com is your one-stop source for every connectivity part you need. From

the latest technology to legacy products — and all the parts that bridge the old and

new — we can help you nd the parts that connect your solutions.

We make it easy to locate the parts, and we quickly deliver them wherever they need

to go. Just talk to one of our tech advisors or visit our website. You’ll be connected to

the products you need in no time.

Visit www.startech.com for complete information on all StarTech.com products and

to access exclusive resources and time-saving tools.

StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology

parts. StarTech.com was founded in 1985 and has operations in the United States,

Canada, the United Kingdom and Taiwan servicing a worldwide market.

Table des matières

Autres manuels StarTech.com Extenseur

StarTech.com

StarTech.com ST124HDBT Manuel utilisateur

StarTech.com

StarTech.com ST121R Manuel utilisateur

StarTech.com

StarTech.com 110VDSLEXT Manuel utilisateur

StarTech.com

StarTech.com USBthere USB100EXT Manuel utilisateur

StarTech.com

StarTech.com 0065030863223 Manuel utilisateur

StarTech.com

StarTech.com HD202A Manuel utilisateur

StarTech.com

StarTech.com SV565UTP Manuel utilisateur

StarTech.com

StarTech.com ST121HD20FXA Manuel utilisateur

StarTech.com

StarTech.com ST121HDBTPW Manuel utilisateur

StarTech.com

StarTech.com WIFI2HD2 Manuel utilisateur

StarTech.com

StarTech.com ST121HDBTE Manuel utilisateur

StarTech.com

StarTech.com C15012-USB-EXTENDER Manuel utilisateur

StarTech.com

StarTech.com 410VDSLEXT Manuel utilisateur

StarTech.com

StarTech.com HDBOOST4K2 Manuel utilisateur

StarTech.com

StarTech.com SV565UTPUSA Manuel utilisateur

StarTech.com

StarTech.com ST121USBHD Manuel utilisateur

StarTech.com

StarTech.com HDBOOST4K Manuel utilisateur

StarTech.com

StarTech.com ST121HDFXA Manuel utilisateur

StarTech.com

StarTech.com ST121SHD50 Manuel utilisateur

StarTech.com

StarTech.com ST121HDBTE Manuel utilisateur

StarTech.com

StarTech.com USB3004EXT2 Manuel utilisateur

StarTech.com

StarTech.com ST121HDBTPW Manuel utilisateur

StarTech.com

StarTech.com USBthere USB221EXT Manuel utilisateur

StarTech.com

StarTech.com USBthere USB201EXT Manuel utilisateur

Manuels Extenseur populaires d'autres marques

SY HDBT-60T Manuel utilisateur

Appsys ProAudio

Appsys ProAudio ADX-16 Manuel utilisateur

Atlona

Atlona RS232 Manuel utilisateur

IDK

IDK OPF-TH1000-A Manuel utilisateur

Enable-IT

Enable-IT 824WP Manuel utilisateur

Worx

Worx Landroid RadioLink WA0864 Fiche technique

TP-Link

TP-Link TL-WA730RE Manuel utilisateur

Camplex

Camplex CMX-HDMI-SFPL Manuel utilisateur

SC&T

SC&T HE03-4K Manuel utilisateur

Marmitek

Marmitek MegaView70 Manuel utilisateur

Samsung

Samsung SCS-26UC4 Manuel utilisateur

Foxun

Foxun SX-GES24 Manuel utilisateur

MuxLab

MuxLab 500771 Manuel utilisateur

foxunhd

foxunhd SX-AEX01 Manuel utilisateur

TERK Technologies

TERK Technologies LFIRX2 Manuel utilisateur

Devolo

Devolo Audio Extender Manuel

Edimax

Edimax EW-7438RPn V2 Manuel utilisateur

Shinybow USA

Shinybow USA SB-6335T5 Manuel utilisateur
