SV565UTP

KVM Console Extender over Cat5 UTP

*actual product may vary from photos

Instruction Manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there

is no guarantee that interference will not occur in a particular installation. If this equipment

does cause harmful interference to radio or television reception, which can be determined by

turning the equipment o and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver

is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other Protected Names and

Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not

represent an endorsement of a product or service by StarTech.com, or an endorsement of the

product(s) to which this manual applies by the third-party company in question. Regardless

of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby

acknowledges that all trademarks, registered trademarks, service marks, and other protected

names and/or symbols contained in this manual and related documents are the property of

their respective holders.

Instruction Manual

Table of Contents

Introduction............................................................................................1

Packaging Contents ................................................................................................................................. 1

System Requirements.............................................................................................................................. 1

Installation ..............................................................................................2

Front View.................................................................................................................................................... 2

Rear View...................................................................................................................................................... 3

Hardware Installation .............................................................................................................................. 4

Driver Installation...................................................................................................................................... 4

Conguration..........................................................................................5

Serial Data Link .......................................................................................................................................... 5

Automatic Calibration Button and Light .......................................................................................... 5

Manual Calibration and Settings Menu ............................................................................................ 5

Commands .................................................................................................................................................. 6

Transmitter Unit specic commands ................................................................................................. 6

Image Quality............................................................................................................................................. 7

Firmware Upgrade.................................................................................................................................... 7

Troubleshooting.....................................................................................8

Specications..........................................................................................10

Technical Support ..................................................................................11

Warranty Information............................................................................11

Instruction Manual

Introduction

Packaging Contents

• SV565UTP Host Unit

• SV565UTP Remote Unit

• Instruction Manual

• Power Adapter

• Set of rubber mounting feet

System Requirements

• Integrated KVM cable for the host and remote computers (not provided) StarTech.

com ID:SVECONx (PS/2), SVECONUSx (USB)

• Standard 104-key PS/2 keyboard

• Standard 3-button PS/2 mouse

• VGA capable display

Instruction Manual

Installation

This product is composed of two dierent units: the Host Unit and

the Remote Unit. The Host Unit takes input controls from a computer

(using a PS/2 or USB integrated KVM cable) and allows access to

them via the Remote Unit over Category 5 UTP cable. The remote

computer also connects to the Remote Unit using an integrated KVM

cable (again, either PS/2 or USB) and allows the user at the remote

site to control that computer or the host computer using keyboard

hotkey commands.

A PS/2 mouse and keyboard and a VGA monitor are connected to the

Remote Unit (the console). You can also connect console peripherals

to the Host Unit if you need direct as well as remote access to that

computer.

Preparing Your Site

Before you can install the the product, you need to prepare your site.

1. Determine where the host computer will be located and set up the computer.

2. Determine where the console devices (mouse, keyboard, monitor) will be located

and place them appropriately

3. If you are using surface cabling, ensure you have enough Category 5 unshielded

twisted pair (UTP) network cabling to connect the Host Unit to the Remote Unit’s

location, and that each end is terminated with RJ-45 connector.

4. If you are using premisses cabling, ensure that the category 5 unshielded twisted

pair (UTP) network cabling between the Host Unit and the Remote Unit has been

properly terminated in a wall outlet in each location and there is a patch cable long

enough to connect the Remote Unit and the Host Unit to their respective outlets

Instruction Manual

Installing the Host Unit

1. Place the Host Unit near the computer.

2. Switch o the computer and disconnect any existing VGA and input connections.

3. Using a StarTech.com integrated KVM cable (see page 8 for part numbers), connect

the end of the cable that has two (USB) or three (PS/2) connectors to the VGA Out

connector and the USB or mouse and keyboard PS/2 connectors on the computer

as appropriate (The PS/2 version of the cable is color coded.) Connect the opposite

end of the cable with a single connector to the gray coded connector marked

COMPUTER on the Host Unit of the KVM extender.

4. If you wish to have console access to the host computer, connect a PS/2 mouse,

keyboard and VGA monitor indicators marked as CONSOLE on the Host Unit.

5. Connect the UTP cable connection for the Remote Unit to the NETWORK RJ-45

connector on the Host Unit. Connect the opposite end to a terminated wall outlet (if

you are using premises cabling).

UTP Cable

Host Computer

(KVM cable)

PS/2 keyboard/

mouse and VGA

console

Power

Connector

Instruction Manual

Installing the Remote Unit

1. Place the Remote Unit near the computer.

2. Switch o the computer and disconnect any existing VGA and input connections.

3. Using a StarTech.com integrated KVM cable (see page 8 for part numbers), connect

the end of the cable that has two (USB) or three (PS/2) connectors to the VGA Out

connector and the USB or mouse and keyboard PS/2 connectors on the computer

as appropriate (The PS/2 version of the cable is color coded.) Connect the opposite

end of the cable with a single connector to the gray coded connector marked

COMPUTER on the Remote Unit of the KVM extender.

4. Connect a PS/2 mouse, keyboard, and VGA monitor to the indicators marked as

CONSOLE on the Remote Unit.

5. Connect the UTP cable connection for Remote Unit to the NETWORK RJ-45

connector on the Remote Unit. Connect the opposite end to a terminated wall

outlet (if using premises cabling).

CAUTION: The UTP network cables that connect the Host and Remote Units carry

electrical current and should not be plugged in to other devices, as they may cause

damage. We strongly recommend marking the cables the cables you are using with

this product at both locations for easy identication.

UTP Cable

Host Computer

(KVM cable)

PS/2 keyboard/

mouse and VGA

console

Power

Connector

Instruction Manual

Driver Installation

No driver installation is required as the SV565UTP uses standard keyboard/mouse

drivers.

Video Compensation

Video Compensation allows the user to adjust the equalization on the Remote Unit to

optimize video performance based on the length of cable being used, as well as other

factors that may aect . There are ve segments of various lengths of CAT 5 cables from

which to chose; to achieve the best visibility, please refer to the section titled Keyboard

Shortcut Command Sequences, to adjust the video compensation.

First, note the length of CAT 5 cable you used. Then, use the hotkeys to adjust the video

compensation accordingly. You can use the hotkey sequence as outlined in the section

titled Keyboard Shortcut Command Sequences.

Instruction Manual

Using the SV565UTP KVM Extender

This section details how to use your KVM extender at both the host and remote

locations.

Using the Host Unit

The Host Unit performs two functions: it allows a user at the Remote Unit to assume

control of the computer on the Host Unit (Computer A), and it also permits the user

at the Host Unit to use Computer A. It has three modes that control which user may

access the system at a given time: Auto (the KVM extender looks for keyboard or

mouse activity from both Host and Remote and automatically accepts input from the

active console), Local (only the user seated at the Host Unit can access the system), and

Remote (only the user at the Remote Unit can access Computer A).

You can use either keyboard shortcuts (if there is a keyboard and mouse attached)

or the mode switch on the top of the Host Unit to control which user has access to

Computer A. By default, the Host Unit operates in Auto mode, and switches to the next

mode in the sequence each time the switch is pressed as follows:

Auto Local Remote

Having a keyboard and mouse attached to the console ports on the Host Unit is

recommended since it oers access to a number of extended features.

LED Indicators

Mode ‘A’ Indicator ‘B’ Indicator

Auto

(Auto senses activity) Flashing Flashing

Local

(User at Host Unit has control) ON OFF

Remote

(User at Remote Unit has control) OFF ON

Instruction Manual

Keyboard Shortcut Command Sequences

Standard Hotkey Hotkey with

Compatibility Mode Description

[Ctrl] - [Ctrl] - [T] [Ctrl] - [Ctrl] - [T]

Toggles control of

Computer A between

Auto, Local, Remote

modes

[Ctrl] - [Ctrl] - [Esc] [Ctrl] - [Ctrl] - [Esc] Cancels the hotkey

sequence

[Ctrl] - [Ctrl] - [Alt]+[E] [Ctrl] - [Ctrl] - [Alt]+[E]

Enables (2 beeps)

or disables (1 beep)

Compatibility Mode so

that the KVM extender

will work with a KVM

switch that also uses a

[Ctrl] hotkey sequence

[Ctrl] - [Ctrl] - [1] [Ctrl] - [Ctrl] - [E] - [1]

Local Mode: Allows the

user at Host Unit exclusive

access to Computer

A; remote access from

Remote Unit is disabled

[Ctrl] - [Ctrl] - [2] [Ctrl] - [Ctrl] - [E] - [2]

Remote Mode: Allows

the console at Remote

Unit exclusive access to

Computer A; access to

Computer A from the

Host Unit is disabled

[Ctrl] - [Ctrl] - [3] [Ctrl] - [Ctrl] - [E] - [3] Auto Mode : Wait for

console activity

[Ctrl] - [Ctrl] - [F3] [Ctrl] - [Ctrl] - [E] - [F3]

Sets the interval of

inactivity in seconds that

the Host Unit will wait

before returning to Auto

Mode

[Ctrl] - [Ctrl] - [F4] [Ctrl] - [Ctrl] - [E] - [F4}

Adjusts the typematic rate

for improved keyboard

responsiveness

Autres manuels pour SV565UTP

Table des matières

Autres manuels StarTech.com Extenseur

StarTech.com

StarTech.com 110VDSLEXT Manuel utilisateur

StarTech.com

StarTech.com SV565UTPHDU Manuel utilisateur

StarTech.com

StarTech.com SV565LANDUA Manuel utilisateur

StarTech.com

StarTech.com ST12MHDLAN2K Manuel utilisateur

StarTech.com

StarTech.com ST121R Manuel utilisateur

StarTech.com

StarTech.com COMPUTPEXTA Manuel utilisateur

StarTech.com

StarTech.com SV565UTPDUA Manuel utilisateur

StarTech.com

StarTech.com USBthere USB110EXT Manuel utilisateur

StarTech.com

StarTech.com STDHVHDBT Manuel utilisateur

StarTech.com

StarTech.com USB2G4LEXT2 Manuel utilisateur

StarTech.com

StarTech.com ST121UTPMINI Manuel utilisateur

StarTech.com

StarTech.com USB2001EXTV Manuel utilisateur

StarTech.com

StarTech.com SV565HDIP Manuel utilisateur

StarTech.com

StarTech.com ST1218T Manuel utilisateur

StarTech.com

StarTech.com USBthere USB204EXTFIB Manuel utilisateur

StarTech.com

StarTech.com WIFI2HD2 Manuel utilisateur

StarTech.com

StarTech.com SV565UTPDUV Manuel utilisateur

StarTech.com

StarTech.com 4K70IC-EXTEND-HDMI Manuel utilisateur

StarTech.com

StarTech.com ST121WHD2 Manuel utilisateur

StarTech.com

StarTech.com IPUSB2HD3 Manuel utilisateur

StarTech.com

StarTech.com HDBOOST4K2 Manuel utilisateur

StarTech.com

StarTech.com USB110EXT2 Manuel utilisateur

StarTech.com

StarTech.com STUTPEALR Manuel utilisateur

StarTech.com

StarTech.com USBthere USB100EXT Manuel utilisateur

Manuels Extenseur populaires d'autres marques

SY HDBT-60T Manuel utilisateur

Appsys ProAudio

Appsys ProAudio ADX-16 Manuel utilisateur

Atlona

Atlona RS232 Manuel utilisateur

IDK

IDK OPF-TH1000-A Manuel utilisateur

Enable-IT

Enable-IT 824WP Manuel utilisateur

Worx

Worx Landroid RadioLink WA0864 Fiche technique

TP-Link

TP-Link TL-WA730RE Manuel utilisateur

Camplex

Camplex CMX-HDMI-SFPL Manuel utilisateur

SC&T

SC&T HE03-4K Manuel utilisateur

Marmitek

Marmitek MegaView70 Manuel utilisateur

Samsung

Samsung SCS-26UC4 Manuel utilisateur

Foxun

Foxun SX-GES24 Manuel utilisateur

MuxLab

MuxLab 500771 Manuel utilisateur

foxunhd

foxunhd SX-AEX01 Manuel utilisateur

TERK Technologies

TERK Technologies LFIRX2 Manuel utilisateur

Devolo

Devolo Audio Extender Manuel

Edimax

Edimax EW-7438RPn V2 Manuel utilisateur

Shinybow USA

Shinybow USA SB-6335T5 Manuel utilisateur
