SAT2510U2REM

2.5 SATA External HDD Enclosure w/

3.5/5.25 Front Drive Bay

*actual product may vary from photos

Instruction Manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there

is no guarantee that interference will not occur in a particular installation. If this equipment

does cause harmful interference to radio or television reception, which can be determined by

turning the equipment o and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver

is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other Protected Names and

Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not

represent an endorsement of a product or service by StarTech.com, or an endorsement of the

product(s) to which this manual applies by the third-party company in question. Regardless

of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby

acknowledges that all trademarks, registered trademarks, service marks, and other protected

names and/or symbols contained in this manual and related documents are the property of

their respective holders.

Instruction Manual

Table of Contents

Introduction ...........................................................................................1

Features ........................................................................................................................................................ 1

Package Contents ..................................................................................................................................... 1

System Requirements.............................................................................................................................. 1

Installation ..............................................................................................2

Installing the hard drive in the drive enclosure ............................................................................. 3

Installing the drive bay in the computer .......................................................................................... 4

Connecting the Drive Enclosure - Removable storage................................................................ 5

Removing the Drive Enclosure - Removable storage................................................................... 5

Connecting the Drive Enclosure - Standalone ............................................................................... 6

Removing the Drive Enclosure - Standalone .................................................................................. 6

Specications..........................................................................................7

Technical Support ..................................................................................8

Warranty Information............................................................................8

Instruction Manual

Introduction

Thank you for purchasing a StarTech.com 3.5” Bay Removable 2.5” SATA Drive

Enclosure. This product oers versatile functionality, acting as either an internal

desktop removable drive enclosure, or an external drive enclosure. Ideal for entry-level

servers, network attached storage systems or applications requiring data transport

from one location to another, SAT2510U2REM is the perfect solution for data mobility.

Features

• Hot swappable plug and play operation

• Easy add-on storage for home or oce usage

• Desktop application - Insert & Remove 2.5” drive enclosure with SATA hard drive at

the push of a button

• Portable (External) application - Instantly connect the enclosure to a host computer

or notebook as external storage, via USB 2.0 connection

Package Contents

• 2.5” SATA hard drive enclosure

• 3.5” Drive bay

• 5.25” Drive bracket

• USB 2.0 Cable

• SATA cable

• 5V DC Cable

• 4 pin power cable

• Users Manual

• Screw Kit

System Requirements

• (Internal use) Any computer with available 5.25” drive bay & SATA motherboard

connection

• (External use) Any desktop or notebook with an available USB port

Instruction Manual

Installation

WARNING: Hard drives require careful handling, especially when being transported. If

you are not careful with your hard disk, lost data may result. Always handle your hard

drive and storage device with caution.

WARNING: Hard drives, like all computer equipment can also be severely damaged

by static electricity. Be sure that you are properly grounded before opening your

computer case or touching any components. StarTech.com recommends that you

wear an anti-static strap when installing any computer equipment. If an antistatic strap

is unavailable, discharge yourself of any static electricity build-up by touching a large

grounded metal surface (such as the computer case) for several seconds.

WARNING: Do not disconnect any cables or power sources while the hard drive is

active. This can result in data loss and possible damage to the hard drive.

Drive Enclosure

Drive Bay Bracket

Drive Bay

Instruction Manual

Installing the hard drive in the drive enclosure

1. Remove the two screws from the rear panel of the Drive Enclosure. Remove the rear

panel of the Drive Enclosure.

2. Remove the circuit board from the drive enclosure.

3. Attach the 2.5”SATA hard drive to the circuit board, and fasten it to the board using

drive mounting screws.

4. Once the hard drive has been secured on the circuit board, replace the circuit board

(with hard drive attached) in the drive enclosure. Fasten the rear panel of the drive

enclosure to the enclosure, using the screws that were removed in step #1.

Instruction Manual

Installing the drive bay in the computer

Please note that the SAT2510U2REM drive bay can be installed into either a 3.5” or a

5.25” drive bay slot on the host computer, using the included 5.25”Drive Bay Bracket.

If you wish to install the Drive Bay directly into the drive bay slot provided by the host

computer, please skip steps 1 and 2 in the instructions that follow:

1. Insert the Drive Bay into the 5.25”bracket provided, ensuring that the holes located

on the sides of the drive bay are aligned with the holes in the sides of the bracket.

2. Fasten the Drive Bay to the Bracket, using the screws provided. To ensure proper

attachment to the Bracket, secure the Drive Bay to the Bracket both on the sides and

on the bottom of the Bracket.

3. Power down the computer.

4. Remove the cover of the host computer drive bay slot into which you wish to install

the Drive Bay and Enclosure, as well as the side panels of the computer case. If you

require further instruction on this step, please consult the documentation that

accompanied your computer or computer case at the time of purchase.

5. Insert the Drive Bay into an available 3.5” or 5.25” drive bay slot as appropriate,

through the opening at the front of the case provided following step 3. Please

ensure proper alignment of screw holes in the Drive Bay and drive bay slot.

6. Secure the Drive Bay to the drive bay slot, using the screws provided. To ensure

proper attachment to the drive bay slot, secure the Drive Bay to the drive bay slot on

both sides of the bay slot.

7. Connect an available LP4 (4 pin) power connector (provided by computer power

supply) to the 4 pin power connector, located on the rear panel of the Drive Bay.

Ensure Proper Alignment

Instruction Manual

8. Connect one end of the SATA cable provided to the SATA port located on the rear

panel of the Drive Bay. Connect the remaining end of the SATA cable to an available

SATA connector as provided by the computer motherboard.

9. Once the Drive Bay has been installed in the computer, replace the side panels of

the computer casing (removed in step 3).

Connecting the Drive Enclosure - Removable storage

Once the Drive Bay has been installed in the computer, you can use the Drive Enclosure

as ejectable (removable) storage. Please note that when inserting or removing the

Drive Enclosure, the computer must be powered down in order to avoid data loss or

damage to the drive.

1. Power down the host computer

2. Insert the Drive Enclosure into the Drive Bay. The Eject button will pop out,

indicating that the Drive Enclosure is rmly connected.

3. Restore power to the computer. Once the operating system is fully loaded and has

detected the presence of the drive, any necessary software will install automatically,

4. Restore power to the computer. If you are using a Windows operating system, any

necessary software will install automatically, once the operating system is fully

loaded and has detected the presence of the drive,

5. The drive is now ready for use and will be available in My Computer, designated

(typically) with a drive letter subsequent to those assigned to stationary

(permanent) hard drives.

Removing the Drive Enclosure - Removable storage

To remove the Drive Enclosure from the host computer when inserted in the Drive Bay:

1. Power down the host computer

2. Press the eject button located next to the drive bay insertion slot

3. Remove the drive enclosure from the bay

4. Restore power to the computer

Instruction Manual

Connecting the Drive Enclosure - Standalone

To connect the Drive Enclosure to the host computer, for use as standalone storage:

1. Insert the small connector (USB Mini-B) into the USB Mini-B port located on the rear

panel of the Drive Enclosure. Insert the remaining end (USB type A) connector into

an available USB port on the host computer.

2. Insert the cylindrical connector provided by the power adapter into the power port

on the rear panel of the Drive Enclosure. Connect the remaining end of the power

adapter to an available power outlet.

3. Once the Drive Enclosure is connected via USB and powered, the drive will be

accessible to the host computer. If you are using a Windows operating system,

please wait a few moments, to allow the operating system to automatically install

the necessary les; once the les have successfully installed, the drive will be

available in My Computer, designated (typically) with a drive letter subsequent to

those assigned to stationary (permanent) hard drives.

Removing the Drive Enclosure - Standalone

When connected to the host computer as standalone storage, you will not need to

power down the computer in order to remove the drive enclosure. Please note that

removing the drive while in operation may cause data loss or damage to the drive. To

avoid this, please use the Safely Remove Hardware wizard, which is prompted by

clicking on the wizard icon located near the clock in the bottom right corner (typically)

of the Windows desktop.

To remove the Drive Enclosure from the host computer:

1. Remove the USB connection between the Drive Enclosure and the computer.

2. Remove the power adapter from the Drive Enclosure.

Safely Remove Hardware

Instruction Manual

Specications

Form Factor Internal Mount: 5.25” drive bay or 3.5”

drive bay

Connectors

3.5” Internal Bay:

External to Host - 4 pin power input 7

pin SATA

Internal to HD enclosure - 7 pin and 15

pin SATA

2.5” HD Enclosure:

External ports - USB 2.0 mini B

DC 5V power to USB

Internal - 7 pin and 15 pin SATA

Power Adapter External Use - 5V DC to USB 2.0

Cables

SATA to SATA

USB Mini B to USB Type A

4 pin power to LP4

5V DC to USB 2.0

Maximum Data Transfer Rate Internal data transfer rate: up to 1.5Gb/s

External use: Up to 480Mbps (USB)

Regulatory Certications FCC, CE, RoHS

Chipset JMicron 20336

OS Support

Windows / 2000 / XP / Vista / 7 /

MAC OS 9.x or higher

Linux 2.4.1.0 or above

Dimensions

2.5” Enclosure - 131 x 77 x 14mm

(LxWxH)

3.5” Bay - 15 x 100 x 25mm

(LxWxH)

5.25” Bracket - 138 x 144 x 40mm

(LxWxH)

Weight 0.5 kg

Table des matières

Autres manuels StarTech.com Enceinte

StarTech.com

StarTech.com S352BU33RER Manuel utilisateur

StarTech.com

StarTech.com InfoSafe SAT2510BU2B Manuel utilisateur

StarTech.com

StarTech.com UNI2510U2V Manuel utilisateur

StarTech.com

StarTech.com RK1219WALL Manuel utilisateur

StarTech.com

StarTech.com S3510SMU33 Manuel du système

StarTech.com

StarTech.com ESATCASE2 Manuel utilisateur

StarTech.com

StarTech.com USB2SLSATINT Manuel utilisateur

StarTech.com

StarTech.com S352BU313R Manuel utilisateur

StarTech.com

StarTech.com INFOSAFE IDE2510U2 Manuel utilisateur

StarTech.com

StarTech.com SAT3520UERGB Manuel utilisateur

StarTech.com

StarTech.com HSB13SATSASB Manuel utilisateur

StarTech.com

StarTech.com SAT3510U2REM Manuel utilisateur

StarTech.com

StarTech.com S354UFER Manuel utilisateur

StarTech.com

StarTech.com 2TBT3-PCIE-ENCLOSURE Manuel utilisateur

StarTech.com

StarTech.com INFOSAFE IDE2510U2 Manuel utilisateur

StarTech.com

StarTech.com SLSODDU33B Manuel utilisateur

StarTech.com

StarTech.com RK1232WALHM Manuel utilisateur

StarTech.com

StarTech.com M2E1BRU31C Manuel utilisateur

StarTech.com

StarTech.com S251BU31REM Manuel utilisateur

StarTech.com

StarTech.com S251BU31C3CB Manuel utilisateur

StarTech.com

StarTech.com SATSAS225ODD Manuel utilisateur

StarTech.com

StarTech.com MADE EASY HSB110SATBK Manuel utilisateur

StarTech.com

StarTech.com S3510BMU33 Manuel utilisateur

StarTech.com

StarTech.com IDE1810U2Z Manuel utilisateur

Manuels Enceinte populaires d'autres marques

SilentiumPC

SilentiumPC Armis AR5 Manuel

Pulsar

Pulsar 17/TRP80/DSPR Manuel utilisateur

Thermaltake

Thermaltake V150 TG Manuel utilisateur

MSI

MSI MPG SEKIRA 500X Manuel utilisateur

Antec

Antec Dark fleet DF-10 Manuel utilisateur

Nexans

Nexans WTC05 Manuel utilisateur

Peavey

Peavey DS 1502 Manuel utilisateur

D-Link

D-Link ShareCenter Pro DNS-1550-04 Manuel utilisateur

Rosewill

Rosewill RX82-U(JBOD) Manuel utilisateur

QNAP

QNAP SAS JBOD CLI 1.0 Manuel utilisateur

GAMDIAS

GAMDIAS Talos P1 Manuel utilisateur

Auvs

Auvs KR615 Manuel utilisateur

Digitus

Digitus DA-71114 Manuel utilisateur

CommScope

CommScope FDH 3000 Manuel utilisateur

FS FHD-FWME4 Manuel utilisateur

JBL

JBL CS1215T Manuel utilisateur

Pulsar

Pulsar ARAD-S4 Manuel utilisateur

Pulsar

Pulsar AWO454 Manuel utilisateur
