StarTech.com HSB320SATBK Manuel utilisateur

Trayless SATA Multi-Drive Bay

HSB320SATBK

HSB430SATBK

Instruction Manual

3 Drive Trayless SATA Hot-Swap Enclosure

4 Drive Trayless SATA Hot-Swap Enclosure

***HSB430SATBK shown

Actual Product may vary from photo

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the

user is encouraged to try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use

Trademarks,

Registered

Trademarks,

and

other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and

do not represent an endorsement of a product or service by StarTech.com, or an

endorsement of the product(s) to which this manual applies by the third-party company in

question. Regardless of any direct acknowledgement elsewhere in the body of this

document, StarTech.com hereby acknowledges that all trademarks, registered

trademarks, service marks, and other protected names and/or symbols contained in this

manual and related documents are the property of their respective holders.

Table of Contents

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Hardware Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Instruction Manual

Introduction

Thank you for purchasing a StarTech.com Multi-Drive Trayless SATA Hot Swap

Enclosure. This product allows you to install multiple hard drives in seconds, without

having to fasten the drive to the enclosure or the host computer.

Features

• Innovative design requires no internal tray (caddy)

• Trayless design offers improved air circulation and heat dissipation for optimized drive

performance

• 10000+ Insertion rating - drive tray is designed to withstand the friction created by

removing and re-inserting the drive tray more than 10000x

• Fits all 3.5” Serial ATA hard drives

• Internal rubber cushioning helps eliminate vibration and damage to the hard disk

Before

You

Begin

HSB320SATBK System Requirements

• Two successive, available 5.25” drive bays

• Pentium-based computer running Windows 2000/XP/2003 Server or Mac OS 9.0 or

higher

• Four available LP4 (4-pin) power connectors

• Three available SATA ports

HSB430SATBK System Requirements

• Three successive, available 5.25” drive bays

• Pentium-based computer running Windows 2000/XP/2003 Server or Mac OS 9.0 or

higher

• Five available LP4 (4-pin) power connectors

• Four available SATA ports

Contents

• 5.25" Trayless SATA Hot Swap Drive Bay (1)

• Instruction Manual (1)

• Mounting screws (8)

• TX4 + SATA Power LP4 Y-cable (x3 - HSB320SATBK x4 - HSB430SATBK)

• SATA data cable (HSB320SATBK) (3)

• SATA data cable (HSB430SATBK) (4)

Instruction Manual

Hardware

Guide

Instruction Manual

Rear Panel

SATA Power connector

SATA Data connector

Front Panel

Power LED indicator

Activity LED indicator

Front door spring lock

***HSB430SATBK shown

LED

Indicator

connections

for fan and

HDD activity

Installation

To ensure a quick and easy installation, please read through this section before

attempting to install this device.

WARNING: Hard drives require careful handling, especially when being transported. If

you are not careful with your hard disk, it may result in lost data. Always handle your

hard drive with caution.

WARNING: Hard drives, like all computer equipment can also be severely damaged by

static electricity. Be sure that you are properly grounded before opening your computer

case or touching any components. StarTech.com recommends that you wear an anti-

static strap when installing any computer equipment. If an anti-static strap is unavailable,

discharge yourself of any static electricity build-up by touching a large grounded metal

surface (such as the computer case) for several seconds.

WARNING: Do not bump, jar, or drop the device. Do not disconnect any cables or power

sources while the hard drive is active. This can result in data loss and possible damage

to the hard drive. Always make sure that your hard drive is fully spun down before

removing the device.

NOTE: Prior to installation, please ensure that the cover from both sides of the computer

case have been removed, as you would in order to install a conventional hard drive. For

further instruction on how to complete this step, please consult the documentation that

accompanied your computer at the time of purchase.

Prior to opening your computer case, please remove all power to the computer, as well

as all power connected to the computer peripherally.

1. Remove the covers of two (HSB320SATBK) or three (HSB430SATBK) successive

drive bays (i.e. adjacent to one another).

2. Insert the Multi-Drive Enclosure into the bays made accessible in Step #1, and gently

push it inward until the mounting holes located on the side panels of the enclosure are

aligned with the holes provided by the drive bays:

Instruction Manual

3. Using the mounting screws provided, secure the Multi-Drive Enclosure to the drive

bays:

Connecting the Multi-Drive Enclosure to the motherboard/power

1. a. Attach one end of a SATA data cable (provided) to a SATA port on the motherboard.

Connect the remaining SATA connectors provided by the cable to the topmost

data port located on the rear panel of the Multi-Drive Enclosure.

b. Connect the LP4/TX-4/SATA Power Y-cable to an available LP4 power connector as

provided by the computer power supply.

c. Connect the SATA Power connector provided by the Y-cable to the topmost SATA

power port. Similarly, connect the TX4 connector to the corresponding port, as

shown below.

2. Repeat steps 1a. - 1c. for each remaining drive bay/hard drive being installed.

Instruction Manual

Loading hard drives in the Multi-Drive Enclosure

Please note: If you are using third-party RAID software, please ensure that each drive is

configured properly, prior to insertion.

1. Gently pull the spring lock to open the front door of the drive bay:

2. Position the hard drive so that the drive connectors are facing towards the exposed

drive bay, and the hard drive label is facing upward. Gently insert the hard drive into

the bay, until the front door of the bay begins to close.

3. Press the front door closed, until the spring lock is secured. Please note: The front

door will not close securely, if the hard drive is not properly positioned. If you have

difficulty closing the door, please do not attempt to force it closed, as this can cause

damage to the hard drive connectors, as well as the connectors located inside the

Multi-Drive Enclosure. lease remove the drive from the enclosure and verify that the

drive is properly positioned:

4. Repeat steps 1-3 for each hard drive being installed.

Unloading hard drives in the Multi-Drive Enclosure

Please note: Removing a hard drive from the enclosure while the drive is busy, can

result in lost data. To ensure the drive is not active when you remove it from the

enclosure, please disable the drive from within the Windows Device Manager or the

RAID software being used.

1. Open the front panel of the drive bay from which you wish to remove the hard drive:

2. Remove the hard drive from the bay.

3. Close the front door, to prevent dust particles from entering the drive bay. Once the

door clicks closed, the bay is secure:

Instruction Manual

Specifications

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commitment to provide

industry-leading solutions. If you ever need help with your product, visit

www.startech.com/support and access our comprehensive selection of online tools,

documentation, and downloads.

Warranty Information

This product is backed by a one-year warranty. In addition, StarTech.com warrants its

products against defects in materials and workmanship for the periods noted, following

the initial date of purchase. During this period, the products may be returned for repair, or

replacement with equivalent products at our discretion. The warranty covers parts and

labor costs only. StarTech.com does not warrant its products from defects or damages

arising from misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their

officers, directors, employees or agents) for any damages (whether direct or indirect,

special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business,

or any pecuniary loss, arising out of or related to the use of the product exceed the

actual price paid for the product.

Some states do not allow the exclusion or limitation of incidental or consequential

damages. If such laws apply, the limitations or exclusions contained in this statement

may not apply to you.

Instruction Manual

Bus Type Serial ATA

Connectors

Serial ATA data

Serial ATA power

Activity LED

Power supply LP4 x 1 - Fan Power

Data Transfer Rate (Max) 3.0 Gb/s (max)

OS Support Windows 2000, XP, 2003 Server

Mac OS 9.0 or above

Operating temperature 0 - 55°C

Storage temperature 0 - 55°C

Dimensions HSB430SATBK: 146 x 127 x 194 mm

HSB320SATBK: 146 x 85 x 194 mm
