StarTech.com InfoSafe SAT3510U2B Manuel utilisateur

SATA Hard Drive Enclosure

SAT3510U2B Instruction Manual

Actual product may vary from photo

3.5" USB 2.0 SATA HDD Enclosure with One Button Backup

FFCCCCCCoommpplliiaanncceeSSttaatteemmeenntt

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses and can

radiate radio frequency energy and, if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

UUsseeooffTTrraaddeemmaarrkkss,,RReeggiisstteerreeddTTrraaddeemmaarrkkss,,aannddootthheerrPPrrootteecctteeddNNaammeessaannddSSyymmbboollss

This manual may make reference to trademarks, registered trademarks, and other protected names

and/or symbols of third-party companies not related in any way to StarTech.com. Where they occur

these references are for illustrative purposes only and do not represent an endorsement of a

product or service by StarTech.com, or an endorsement of the product(s) to which this manual

applies by the third-party company in question. Regardless of any direct acknowledgement

elsewhere in the body of this document, StarTech.com hereby acknowledges that all trademarks,

registered trademarks, service marks, and other protected names and/or symbols contained in this

manual and related documents are the property of their respective holders.

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Hard Drive Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Software Utility Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Driver Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Connecting SAT3510U2B to the host computer . . . . . . . . . . . . . . . . .7

Using the Backup4all software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Disconnecting SAT3510U2B from the host computer . . . . . . . . . . . . . . . . . .8

Instruction Manual

TTaabblleeooffCCoonntteennttss

Instruction Manual

Thank you for purchasing a StarTech.com 3.5" USB 2.0 SATA HDD Enclosure with One

Button Backup. The perfect solution for high-speed data backups, SAT3510U2B supports

high capacity hard drives to maximize storage capability, while housing the drive in a

lighweight enclosure, and features a built-in cooling fan to keep the drive running at

optimal temperatures.

IInnttrroodduuccttiioonn

•Supports almost any Universal fitting for 3.5" SATA I/II hard drives

Features

BBeeffoorreeyyoouubbeeggiinn

System requirements:

•3.5” SATA hard drive

Package contents:

•1 x Enclosure

This package should contain:

•Lightweight, durable aluminum finish with built-in cooling fan

•Power and data transfer LEDs offer simple monitoring of drive activity

•Works with High Capacity HDD’s - Supports 750 GB’s

•Host computer with an available USB port. Operating system requirement: Windows

98SE/ME/2000/XP/VISTA/Mac OS 9x and up

•1 x Power Adapter

•1 x Driver / Software utility CD

•1 x Instruction Manual

•1 x Stand

•1 x Screw kit

•1 x USB Cable

•1 x Backup4all User Guide

Instruction Manual

IInnssttaallllaattiioonn

WARNING: Hard drives require careful handling, especially when being

transported. If you are not careful with your hard disk, lost data may result.

Always handle your hard drive and storage device with caution.

WARNING: Do not disconnect any cables or power sources while the hard drive

is active. This can result in data loss and possible damage to the hard drive.

WARNING: Hard drives, like all computer equipment can also be severely

damaged by static electricity. Be sure that you are properly grounded before

opening your computer case or touching any components. StarTech.com

recommends that you wear an anti-static strap when installing any computer

equipment. If an antistatic strap is unavailable, discharge yourself of any static

electricity build-up by touching a large grounded metal surface (such as the

computer case) for several seconds.

1. Unscrew the enclosure and remove

the rear panel cover. Pull the tray

out of the enclosure:

2. Place the 3.5” SATA drive in the tray,

with the hard drive SATA connector

facing the SATA connections

provided by the drive tray:

Hard Drive Installation

Rear Panel Cover

Instruction Manual

3. With the hard drive connected to the

tray (using the SATA connection),

turn the tray over and place it on a

flat, stable surface, exposing the

base of the tray. Attach the drive to

the enclosure tray, using the screw

kit provided:

4. Once the drive has been secured to

the drive tray, insert the tray (with

drive) into the enclosure:

5. Secure the tray in the enclosure using the

screws removed in step #1.

The hard drive has now been installed in the enclosure. Please proceed to software

installation, as detailed in the following section.

Instruction Manual

Software Utility Installation

1. Insert the Backup4All CD into the CD/DVD-ROM drive. Locate and double-click on

the file titled Autorun.exe. (d:\Autorun.exe, where d:\ is the CD/DVD-ROM drive letter

designation).

To use the One Button Backup feature, the accompanying Backup4all software must be

installed on the host computer:

2. When the Software Installer window

appears, click on Install:

3. Select OTB Software:

4. Select the preferred language for installation

and click OK.

5. When the Welcome to Backup4all setup

Wizard screen appears, please click Next.

Instruction Manual

6. Click on Next if you wish to install the

software in the default directory. If you wish

to specify a destination other than the default

location for the software, please click on

browse, and specify an alternate installation

path.

7. Select the languages you wish to use with

the Backup4all interface and click Next.

8. Select the default language that will be used

with the Backup4all interface, and click Next.

9. When you receive a message indicating that

the Backup4all Setup Wizard has finished

installation, select Launch Backup4all3 and

click on Finish.

10. When the Backup4all utility is first launched, you

will be asked to register the software. Enter the

registration key in the text box provided, then click

Close to conclude the software installation. The key

can be found on the CD sleeve containing the

Backup4all software (24 character alphanumeric

code)

Instruction Manual

11. To access the Backup4all utility, click on the

Backup4all icon, located on the desktop. In

the window that appears, click on Tools, then

Options. Select One Touch Backup in the left

pane, and ensure that there is a checkmark

next to Enable “One Touch Backup” support.

This feature is now enabled.

Driver Installation

Please note that if you are using Windows 98/98SE, you are required to install the

necessary drivers, prior to usage. If you are using Windows ME, 2000, XP or higher, no

driver installation is required, as the operating system will automatically install the

necessary files. As such, if you are using Windows ME or above, please advance to

Connecting SAT3510U2B to the host computer.

Windows 98/98SE users:

1. Ensure the Backup4All CD is present in the CD/DVD-ROM drive. Locate and double-

click on the file titled Autorun.exe (d:\Autorun.exe, where d:\ is the CD/DVD-

ROM drive letter designation).

2. When the Software Installer window

appears, click on Install:

3. Select 98/ME Driver for SATA:

Instruction Manual

4. Click Next, then Finish to complete driver installation.

Once the drivers have been installed, the host computer is ready to use SAT3510U2B.

Connecting SAT3510U2B to the host computer

1. Connect the power adapter (included) to the drive enclosure, using the power port on

the rear panel of the enclosure (marked DC12V). Connect the remaining end of the

power adapter to an available power outlet.

2. Insert the type ‘b’ connector provided by the USB cable (included) into the port

marked USB 2.0 on the rear panel of the drive enclosure. Insert the remaining (type

‘a’) connector into an available USB port on the host computer.

3. One the rear panel of the enclosure, move the Fan Switch to the ON position.

4. Power the drive enclosure by pressing the side of the remaining switch marked with a

dot.

Please note: SAT3510U2B features an ON/OFF switch that controls the

internal cooling fan. Please note that to ensure the best possible operating

environment for the installed hard drive and reduce the risk of damage to the

drive, the fan should be left in the ON position. This feature is intended for

temporary use only, as necessary to quiet environments.

Using the Backup4all software

For explicit instructions on how to use the Backup4all software that was packaged with

SAT3510U2B, please see the Backup4all User Guide.
