– 1 –

THERMAL PRINTER

TSP600 SERIES

USER’S MANUAL

–2 –

Federal Communications Commission

Radio Frequency Interference

Statement

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the

FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is

operated in a commercial environment. This equipment generates, uses and can radiate radio frequency energy and, if not

installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be

required to correct the interference at his own expense.

For compliance with the Federal Noise Interference Standard, this equipment requires a shielded cable.

This statement will be applied only for the printers marketed in U.S.A.

Statement of

The Canadian Department of Communications

Radio Interference Regulations

This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus set out in the

Radio Interference Regulations of the Canadian Department of Communications.

Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables aux appareils numériques de la

classe Aprescrites dans le Règlement sur le brouillage radioélectrique édictépar le ministère des Communications du Canada.

The above statement applies only to printers marketed in Canada.

Manufacturer’s Declaration of Conformity

EC Council Directive 89/336/EEC of 3 May 1989

This product has been designed and manufactured in accordance with the International Standards EN 61000-6-3/10.2001

and EN 55024/09.98 following the provisions of the Electro Magnetic Compatibility Directive of the European Communi-

ties as of May 1989.

EC Council Directive 73/23/EEC and 93/68/EEC of 22 July 1993

This product has been designed and manufactured in accordance with the International Standards EN 60950 following the

provisions of the Low Voltage Directive of the European Communities as of July 1993.

The above statement applies only to printers marketed in EU.

Trademark acknowledgments

TSP600: Star Micronics Co., Ltd.

ESC/POS: Seiko Epson Corporation

Notice

sion is forbidden.

•The contents of this manual are subject to change without notice.

•All efforts have been made to ensure the accuracy of the contents of this manual at the time of going to press. How-

ever, should any errors be detected, STAR would greatly appreciate being informed of them.

•The above notwithstanding, STAR can assume no responsibility for any errors in this manual.

–3 –

Safety Information

Important!

Make sure that the printer is turned off and unplugged from the AC outlet and that the computer is

turned off before making connections.

Important!

Donotconnectatelephonelineintotheperipheraldriveconnector.Failuretoobservethismayresult

in damage to the printer.

Also, for safety purposes, do not connect wiring to the external drive connector if there is a chance

it may carry peripheral voltage.

–4 –

Unpacking

Choosing a place for the printer

Before actually unpacking the printer, you should take a few minutes to think about where

you plan to use it. Remember the following points when doing this.

✓Choose a firm, level surface where the printer will not be exposed to vibration.

✓The power outlet you plan to connect to for power should be nearby and unobstructed.

✓Make sure that the printer is close enough to your host computer for you to connect the

two.

✓Make sure that the printer is not exposed to direct sunlight.

✓Make sure that the printer is well away from heaters and other sources of extreme heat.

✓Make sure that the surrounding area is clean, dry, and free of dust.

✓Make sure that the printer is connected to a reliable power outlet. It should not be on the

same electric circuit as copiers, refrigerators, or other appliances that cause power spikes.

✓Make sure that the room where you are using the printer is not too humid.

✓Printer

✓User’s manual

✓Roll paper

✓Ferrite core(Parallel interface model only)

✓Fastener(Parallel interface model only)

Roll paper Ferrite core

Fastener

Printer

User’s manual

–5 –

Consumable Parts

When consumable parts have run out, use those specified in the table below. Make sure that the

AC adapter specified in the table is used.

Use of consumable parts orAC adapter which are not specified in the table may result in damage

to the printer, fire or electric shock.

(1) Roll paper specification

Thermal paper

Thickness: 65~85 µm

Width: 79.5±0.5 mm (57.5±0.5 mm when the optional paper roller holder is used)

Outer roll diameter: ø90 mm or less

Core outer/inner diameter

Paper thickness Core outer Core inner

65~85 µmø18±1 mm ø12±1 mm

Printed surface: Outer edge of roll

Tail end handling: Do not use paste or glue to secure the roll paper or its core.

Do not fold the tail end of the paper.

(2) Recommended paper

Mitsubishi Paper Mills Limited

P220AG (normal type paper), 65 µm (thickness)

HP220A (high image stability paper), 65 µm (thickness)

HP220AB-1 (high image stability paper), 75 µm (thickness)

P220AB (normal type paper, card ticket), 85 µm (thickness)

PB670 (2 color paper: Red & Black), 75 µm (thickness)

PB770 (2 color paper: Blue & Black), 75 µm (thickness)

Oji Paper Co., Ltd.

PD150R (normal type paper), 75 µm (thickness)

PD160R (high image stability paper), 65/75 µm (thickness)

PD750R (2 color paper: Red & Black), 75 µm (thickness)

PD700R (2 color paper: Blue & Black), 75 µm (thickness)

Nippon Paper Industries

TF50KS-E2C (normal type paper), 65 µm (thickness)

Kanzaki Specialty Papers Inc. (KSP)

P320RB (2 color paper: Red & Black), 65 µm (thickness)

P320BB (2 color paper: Blue & Black), 65 µm (thickness)

Depending on the type and thickness of the paper, it may be necessary to change the settings for

printing darkness. To change the darkness settings, use the printing darkness settings command

<ESC><RS> ‘d’n. Refer to the separate programmer’s manual for details.

–6 –

Connecting the Optional AC Adapter

Note: Before connecting/disconnecting theAC adapter, make sure that power to the printer and

all the devices connected to the printer is turned off.Also make sure the power cable plug

is disconnected from the AC outlet.

(1)Connect the AC adapter to the power cable.

Note: Use only the standard AC adapter and power cable.

(2)Connect AC adapter to the connector on the printer.

(3)Insert the power cable plug into an AC outlet.

Control Panel

1POWER lamp (Green LED)

Lights when the power is ON

2ERROR lamp (Red LED)

Indicates various errors in combination with

POWER lamp

3FEED button

Press the FEED button to feed roll paper.

3FEED button

2ERROR lamp (Red LED)

1POWER lamp (Green LED)

Important!

When disconnecting the cable, take hold of the cable

connectorto pull it out.Releasingthelockmakesit easy to

disconnect the connector.

Pulling the cable excessively could cause damage to the

connector.

–7 –

Loading the Roll Paper

Be sure to use roll paper that matches the printer’s specification.

When using a paper roll with an 57.5 mm width, install the optional paper roll holder.

Push the Cover open lever, and open the printer cover.

Cover open lever

Roll paper

Removing Paper Jam

If a paper jam occurs, clear it as described below.

(1)Set the power switch to off to turn off power to the printer.

(2)Pull the lever toward you to open the printer cover.

If the printer cover will not open on auto cutter models, it means that the auto cutter is not at the

homeposition.Inthiscase,returntheautocuttertothehomepositionbyfollowingtheinstructions

provided in next section. Then open the printer cover after the paper jam has been removed.

(3)Remove the jammed paper.

Note: Take care not to damage the printer when removing the jammed paper.

Since it is easy to damage the thermal head in particular, take care not to touch it.

(4)Position the roll paper straight and close the printer cover gently.

Note 1: Make sure that the paper is positioned straight. If the printer cover is closed with the

paper skewed, a paper jam may result.

Note 2: Lock the printer cover by pressing down on the sides. Do not try to close it by pressing

down on the center. The cover may not lock properly.

(5)Set the power switch to on to turn on power to the printer. Make sure that the ERROR LED is

not lit.

Note: While the ERROR LED is lit, the printer will not accept any commands such as the print

command, so make sure that the printer cover is locked properly.

While observing the direction of the roll, set the paper roll into the hollow, and pull on the leading

edge of the paper toward you.

–8 –

Cleaning theThermal Head

To remove blackish dust collected on the surface of the thermal head, wipe it with Isopropyl

alcohol (IPA).

Note: Thethermalheadiseasytodamage,socleanitgentlywithasoftcloth.Takesufficientcare

not to scratch it when cleaning it.

Releasing a Locked Cutter (Auto Cutter Mode only)

If the auto cutter locks up or fails to cut the paper, follow the steps below.

Caution

Since working on the cutter may be dangerous, be sure to turn off the printer first.

(1)Set the power switch to OFF to turn off the printer.

(2)Slide off the front cover to reveal the auto cutter.

(3)Remove any jammed paper.

Note: Be careful not to damage the printer while removing any jammed paper.

Since the thermal print head is particularly sensitive, be sure not to touch it.

(4)Ifthecutter’smovingbladeisprotruding,useaPhillipsscrewdrivertoturnthePhillip-headscrew

and return the moving blade to its home position.

When the check window is completely white, the moving blade is at its home position.

Note 1:Do not apply extreme pressure to the moving blade.

Note 2:If the moving blade is protruding too much, the printer cover cannot be opened. Trying

to open the printer cover may damage the cutter.

(5)Open the printer cover, remove any jammed paper, and then re-install the paper roll.

(6)Install the front cover, and then set the power switch to ON.

Auto cutter

Front cover

Moving blade

–9 –

No. 1

DIP-SW1

2345678

No. 1

DIP-SW2

2 3 4

Dip Switch Settings - Parallel InterfaceType

DIP-SW 1

Switch 1-1 Command emulation

ON Star Mode

OFF ESC/POS Mode

All factory settings for DIP switch on the auto cutter model are set at on.

Switch 1-3 on the tear bar model is set at off, and the others are set at on.

(1) Star mode

Switch

Function ON OFF

1-1 Command emulation Always ON

1-2

Should not be changed (Should be set to on)

1-3 Auto cutter Valid Invalid

1-4 Sensor adjustment Invalid Valid

1-5 Pin #31 (INIT) reset signal Valid Invalid

1-6 Handshaking conditions Offline or receive Receive buffer full

(conditions for BUSY) buffer full

1-7 Automatic status back function Invalid Valid

1-8 Should not be changed (Should be set to on)

(2) ESC/POS mode

Switch

Function ON OFF

1-1 Command emulation Always OFF

1-2 Graphic adjustment 203 DPI 180 DPI

1-3 Auto cutter Valid Invalid

1-4 Sensor adjustment Invalid Valid

1-5 Pin #31 (INIT) reset signal Valid Invalid

1-6 Handshaking conditions Offline or receive Receive buffer full

(conditions for BUSY) buffer full

1-7 Automatic status back function Invalid Valid

1-8 Should not be changed (Should be set to on)

DIP-SW 2

Switch

Function ON OFF

2-1

2-2 Always ON Should be set to on

2-3

2-4

OFF

–10 –

Dip Switch Settings - Serial Interface Type

No. 1

DIP-SW1

2345678

No. 1

DIP-SW2

2 3 4

DIP-SW 1

Switch 1-1 Command emulation

ON Star Mode

OFF ESC/POS Mode

All factory settings for DIP switch on the auto cutter model are set at on.

Switch 1-3 on the tear bar model is set at off, and the others are set at on.

(1) Star mode

Switch

Function ON OFF

1-1 Command emulation Always ON

1-2

Should not be changed (Should be set to on)

1-3 Auto cutter Valid Invalid

1-4 Sensor adjustment Invalid Valid

1-5 Should not be changed (Should be set to on)

1-6 Handshaking conditions Offline or receive Receive buffer full

(conditions for BUSY) buffer full

1-7 Automatic status back function Invalid Valid

1-8 Should not be changed (Should be set to on)

(2) ESC/POS mode

Switch

Function ON OFF

1-1 Command emulation Always OFF

1-2 Graphic Adjustment 203 DPI 180 DPI

1-3 Auto cutter Valid Invalid

1-4 Sensor adjustment Invalid Valid

1-5 Should not be changed (Should be set to on)

1-6 Handshaking conditions Offline or receive Receive buffer full

(conditions for BUSY) buffer full

1-7 Automatic status back function Invalid Valid

1-8 Should not be changed (Should be set to on)

DIP-SW 2

Switch

Function ON OFF

2-1

2-2 Always ON Should be set to on

2-3

2-4

OFF

Autres manuels pour TSP600 Series

Table des matières

Langues :

Autres manuels Star Micronics Imprimante

Star Micronics

Star Micronics LaserPrinter4 Manuel utilisateur

Star Micronics

Star Micronics TSP400 Series Manuel d'utilisation et d'entretien

Star Micronics

Star Micronics SM-T300I SERIES Manuel utilisateur

Star Micronics

Star Micronics NP-255 Instructions d'installation

Star Micronics

Star Micronics TSP600 Series Manuel utilisateur

Star Micronics

Star Micronics SLIP SP298 SERIES Manuel d'utilisation et d'entretien

Star Micronics

Star Micronics ND-10/15 Manuel utilisateur

Star Micronics

Star Micronics TSP1000 Series Instructions d'installation

Star Micronics

Star Micronics NX-1001 Manuel utilisateur

Star Micronics

Star Micronics TMP900 Manuel d'instructions d'installation

Star Micronics

Star Micronics XB-2425 Manuel utilisateur

Star Micronics

Star Micronics SM-T400I Series Manuel utilisateur

Star Micronics

Star Micronics NP-266 Instructions d'installation

Star Micronics

Star Micronics SP500 Series Manuel utilisateur

Star Micronics

Star Micronics LC-240 Manuel utilisateur

Star Micronics

Star Micronics TSP700 Series Instructions d'installation

Star Micronics

Star Micronics TSP700II Series Manuel utilisateur

Star Micronics

Star Micronics MULTI-FONT NX-1000II Manuel utilisateur

Star Micronics

Star Micronics PW2000-24 Manuel utilisateur

Star Micronics

Star Micronics TUP500 series Instructions d'installation

Star Micronics

Star Micronics SP320S series Manuel utilisateur

Star Micronics

Star Micronics NX-1000 Manuel utilisateur

Star Micronics

Star Micronics FVP-10U Manuel utilisateur

Star Micronics

Star Micronics SB-15 Manuel utilisateur

Manuels Imprimante populaires d'autres marques

Lexmark

Lexmark 1400 Series Manuel

Canon

Canon i70 Series Manuel utilisateur

Evolis

Evolis Elypso Manuel utilisateur

Kyocera

Kyocera FS-9530DN Manuel utilisateur

Canon

Canon LASER SHOT LBP-1210 Manuel utilisateur

Samsung

Samsung BIXOLON SRP-350plusF Manuel utilisateur

Canon

Canon PIXMA PRO-1 Series Manuel utilisateur

Canon

Canon PIXMA G3560 Guide de configuration

Dell

Dell Color Laser Printer 2130cn Manuel utilisateur

Tektronix

Tektronix Phaser 840 Manuel utilisateur

Epson

Epson ET-7750 Mode d'emploi

Canon

Canon CLBR 460ps Manuel utilisateur

Eltron

Eltron P210 Guide Manuel utilisateur

Ricoh

Ricoh MD-P1 Manuel utilisateur

Epson

Epson SC-F7100 series Manuel utilisateur

Epson

Epson Stylus C40UX Manuel utilisateur

Canon

Canon imagePASS-A2 Manuel utilisateur

Canon

Canon S820D Manuel utilisateur
