AN3127

Application note

CEC networking

using STM32F100xx value line microcontrollers

Introduction

STM32F100xx value line microcontrollers feature a high-definition multimedia interface

consumer electronics control (HDMI™-CEC) controller peripheral that supports the HDMI-

CEC v1.3a protocol. The HDMI-CEC controller provides a hardware support of this protocol,

and it supports the whole set of features offered with CEC devices.

This application note describes the CEC protocol software and hardware implementation

based on the HDMI-CEC controller. A real application example is also provided to illustrate

the software implementation.

www.st.com

Contents AN3127

2/36 Doc ID 16896 Rev 2

Contents

1 High-definition multimedia interface, consumer

electronics control (HDMI-CEC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

1.1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

1.2 Frame description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

1.3 Bit timing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

1.4 Device connectivity and addressing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

1.4.1 CEC communication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

1.4.2 Enhanced DDC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

1.4.3 Hot plug detect (HPD) signal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

1.4.4 Physical address discovery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

1.4.5 Discovery algorithm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

1.4.6 Logical addressing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

1.4.7 Logical address allocation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

1.5 STM32F100xx’s HDMI-CEC controller . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

1.5.1 Main features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

1.5.2 HDMI-CEC advanced features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

2 Hardware environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

2.1 HDMI connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

2.1.1 I2C bus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

2.2 Hardware connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

3 Firmware description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

3.1 Package directories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

3.2 Firmware architecture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

4 Value line evaluation board CEC demonstration . . . . . . . . . . . . . . . . . 27

4.1 CEC demonstration overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

4.2 Device type selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

4.3 Physical address discovery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

4.4 Logical address allocation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

4.5 Checking the connected devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

4.6 Displaying CEC send/receive information on the LCD . . . . . . . . . . . . . . . 30

AN3127 Contents

Doc ID 16896 Rev 2 3/36

4.6.1 Receive information subscreen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

4.6.2 Send information subscreen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

5 Conclusion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

6 Revision history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

List of tables AN3127

4/36 Doc ID 16896 Rev 2

List of tables

Table 1. Logical addresses. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Table 2. HDMI connector pinout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Table 3. STM32F100xx and HDMI-CEC connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Table 4. High-level functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Table 5. Document revision history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

AN3127 List of figures

Doc ID 16896 Rev 2 5/36

List of figures

Figure 1. CEC frame format. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Figure 2. Message structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Figure 3. Blocks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Figure 4. Bit timings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Figure 5. Follower acknowledge (ACK) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Figure 6. CEC and DDC line connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Figure 7. Addresses within a HDMI cluster . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Figure 8. Physical address discovery algorithm. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Figure 9. System exits Stop mode when data reception starts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Figure 10. HDMI cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Figure 11. Application schematic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Figure 12. Electrical schematic proposal for STM32100B-EVAL. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Figure 13. Electrical schematic proposal for STM32100E-EVAL. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Figure 14. Example of a hardware connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Figure 15. Package directory structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Figure 16. Firmware architecture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Figure 17. CEC demonstration flowchart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Figure 18. Device type selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Figure 19. Physical and logical addresses display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Figure 20. CEC menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Figure 21. Receive flowchart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Figure 22. Receive information subscreen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Figure 23. Send flowchart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Figure 24. Select CEC command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

AN3127

6/36 Doc ID 16896 Rev 2

Glossary of terms

Broadcast message: a message sent to logical address 15 that all devices are expected to

receive.

Destination: the target device for a CEC message.

Follower: a device that has just received a CEC message and is required to respond to it.

Initiator: the device that is sending, or has just sent, a CEC message and, if appropriate, is

waiting for a follower to respond.

Logical address: a unique address assigned to each device.

Menu-providing device: a non-display device that may render a menu on TV.

Playback device: a device that has the ability to play media, like a DVD player.

Recording device: a device that has the ability to record a source such as an internal tuner

or an external connection.

Source device: a device that is currently providing an AV stream via HDMI.

Tuner device: a device that contains a tuner, e.g. an STB (set-top box) or a recording

device.

TV: a device with a HDMI input that has the ability to display the input HDMI signal.

Generally it has no HDMI output.

CEC: consumer electronics control.

DDC: display data channel.

E-DDC: enhanced display data channel.

EDID: extended display identification data.

E-EDID: enhanced extended display identification data.

HDMI: high-definition multimedia Interface.

(HDMI) source: a device with a HDMI output.

(HDMI) sink: a device with a HDMI input.

AN3127 High-definition multimedia interface, consumer electronics control (HDMI-CEC)

Doc ID 16896 Rev 2 7/36

1 High-definition multimedia interface, consumer

electronics control (HDMI-CEC)

1.1 Introduction

Consumer electronics control (CEC) is the appendix supplement 1 to the HDMI (high-

definition multimedia interface) standard.

It is a protocol that provides high-level control functions between all of the various

audiovisual products in a given environment. It is specified to operate at low speeds with

minimum processing and memory overhead.

For more details, refer to the high-definition multimedia interface specification available from

www.hdmi.org.

1.2 Frame description

The CEC bus is a single-wire protocol that can connect up to 10 audiovisual devices through

standard HDMI cabling.

All transactions on the CEC line consist of an initiator and one or more followers. The

initiator is responsible for sending the message structure and the data. The follower is the

recipient of any data and is responsible for setting any acknowledgement bits.

A message is conveyed in a single frame that consists of a start bit followed by a header

block and, optionally, an opcode and a variable number of operand blocks. Figure 1 shows a

CEC frame format.

Figure 1. CEC frame format

Figure 2. Message structure

Start bit

01101101 0-

EOM ACKInitiator Destination

Header block

Header block Databock 1 Datablock n

10 bits10 bits10 bits

Initiator address = 0x6

Destination address = 0xD

Example of Header block:

11100101 0 -

EOM ACK

Data

Data block

Data= 0xE5

Example of Datablock:

ai15931

3TART

HIGH (EADER /PCODE /PERAND /PERAND

TOOPERANDS

HIGH

IMPEDANCE BIT IMPEDANCE

AI

High-definition multimedia interface, consumer electronics control (HDMI-CEC) AN3127

8/36 Doc ID 16896 Rev 2

Figure 3. Blocks

All these blocks are made of an 8-bit payload (most significant bit transmitted first) followed

by an end-of-message (EOM) bit and an acknowledge (ACK) bit.

The EOM bit is set in the last block of a message and kept cleared in all others. If a message

contains additional blocks after the EOM, these blocks should be ignored. The EOM bit may

be set in the header block to “ping” other devices and make sure that they are active.

The acknowledge bit is always brought to high impedance by the initiator. It can therefore be

driven low by either the follower that has read its own address in the header, or the follower

that needs to reject a broadcast message.

The header consists of the source logical address field, and the destination logical address

field. Note that the address 0xF is specially used for broadcast messages.

1.3 Bit timing

The format of the start bit is unique and identifies the start of a message. It should be

validated by its low duration and its total duration.

All remaining data bits in the message, after the start bit, have a consistent timing. The high-

to-low transition at the end of the data bit is the start of the next data bit except for the final

bit where the CEC line remains high.

Figure 4 shows the timings of the start bit and the different data bits.

Figure 4. Bit timings

%/- !#+



$%34).!4)/.;=).)4)!4/2;=

(EADERBLOCK

%/- !#+



$!4!;=

/PCODE/PERANDBLOCK

AI

3TARTBIT

HIGHIMPEDANCE

LOWIMPEDANCE

MSMS

MSMS

$ATABIT

HIGHIMPEDANCE

LOWIMPEDANCE

MSMS

MSMS

).)4)!4/2LOGICAL

$ATABIT

HIGHIMPEDANCE

LOWIMPEDANCE

MSMS

MSMS

).)4)!4/2LOGICAL

AI

AN3127 High-definition multimedia interface, consumer electronics control (HDMI-CEC)

Doc ID 16896 Rev 2 9/36

CEC Figure 5 shows an example bit with both initiator and follower where the follower may

assert the bit to logical 0 to acknowledge a data block. The initiator outputs a logical 1, thus

allowing the follower to change the CEC state by pulling the control line low for the duration

of the safe sample period.

Figure 5. Follower acknowledge (ACK)

1.4 Device connectivity and addressing

1.4.1 CEC communication

By definition the HDMI system architecture consists of sources and sinks. A given device

may have one or more HDMI input(s) and output(s). Each HDMI input on the device should

follow all the rules for a HDMI sink and each HDMI output should follow all the rules for a

HDMI source.

The DDC is used for configuration and status exchange between a single source and a

single sink. The optional CEC protocol provides high-level control functions between all of

the various audiovisual products in a user’s environment.

Figure 6. CEC and DDC line connections

HIGHIMPEDANCE

LOWIMPEDANCE

HIGHIMPEDANCE

LOWIMPEDANCE

AI

MS

MS

MS

MSMAX

$ATABITINITIATORLOGICAL

$ATABITFOLLOWERLOGICAL

High-definition multimedia interface, consumer electronics control (HDMI-CEC) AN3127

10/36 Doc ID 16896 Rev 2

Figure 7. Addresses within a HDMI cluster

1.4.2 Enhanced DDC

The enhanced DDC described in this section is defined in VESA “ENHANCED DISPLAY

DATA CHANNEL STANDARD Version 1 (September 2, 1999)”. All sinks are required to

support these enhanced DDC features. If the E-EDID structure of a sink is longer than 256

bytes, it should support the segment pointer.

Timing

Data is synchronized with the SCL signal and timing should comply with the Standard Mode

of the I2C specification (100 kHz maximum clock rate).

The I2C bus is a standard two-wire (clock and data) serial databus protocol. Refer to the I2C

specification for details.

Note that a HDMI sink may hold off the DDC transaction by stretching the SCL line during

the SCL-low period following the Acknowledge bit as permitted by the I2C specification. All

HDMI sources should delay the DDC transaction while the SCL line is being held low.

Data transfer protocols

The source should use I2C commands to read information from a sink’s E-EDID with a slave

address.

In Enhanced DDC, a segment pointer is used to address the E-EDID outside the 256 bytes

normally addressable by the 0xA0/0xA1 addresses. The Enhanced DDC protocol sets the

segment pointer before the remainder of the DDC command.

Autres manuels pour STM32F100 Series

Table des matières

Autres manuels ST Microcontrôleur

ST VIP-M07SPI-ADIS Manuel utilisateur

ST STM32H74xI/G Manuel utilisateur

ST STM32L0x3 Manuel utilisateur

ST SPC56A Series Manuel utilisateur

ST STEVAL-STWINBX1 Manuel utilisateur

ST PSD4256G6V Manuel utilisateur

ST UM2140 Manuel utilisateur

ST STM32G4 Series Manuel utilisateur

ST STM32 Nucleo Manuel utilisateur

ST STM32F103 series Instructions d'installation et d'utilisation

ST STM32Cube Manuel utilisateur

ST STM32F2 Series Manuel utilisateur

ST STM32H7 3 Series Instructions d'installation et d'utilisation

ST STM32F20 Series Instructions d'installation et d'utilisation

ST STM32G0 1 Series Manuel utilisateur

ST STM32 Nucleo Manuel utilisateur

ST STM32F31xx Manuel utilisateur

ST STM8AF Series Manuel utilisateur

ST STM32F74 Series Manuel utilisateur

ST UM2975 Manuel utilisateur

ST STM32F103ZE Manuel utilisateur

ST STM32U585 Series Manuel utilisateur

ST STM32WL5 Series Manuel utilisateur

ST UM2334 Manuel utilisateur

Manuels Microcontrôleur populaires d'autres marques

AMS

AMS AS7261 Demo Kit Manuel utilisateur

Novatek

Novatek NT6861 Manuel utilisateur

Espressif Systems

Espressif Systems ESP8266 SDK Guide de configuration

Nuvoton

Nuvoton ISD61S00 ChipCorder Mode d’emploi

STMicrolectronics

STMicrolectronics ST7 Assembler Linker Manuel utilisateur

Texas Instruments

Texas Instruments Chipcon CC2420DK Manuel utilisateur

Lantronix

Lantronix Intrinsyc Open-Q 865XR SOM Manuel utilisateur

NEC

NEC 78GK0S/K 1+ Series Instructions d'installation et d'utilisation

Mikroe

Mikroe SEMITECH N-PLC Click Instructions d'installation et d'utilisation

Intel

Intel Agilex Manuel utilisateur

Cypress

Cypress CY4607 HX2VL Manuel utilisateur

DIGITAL-LOGIC

DIGITAL-LOGIC MICROSPACE Manuel utilisateur

Texas Instruments

Texas Instruments TMS320F2837 D Series Manuel utilisateur

CYPRES

CYPRES CY14NVSRAMKIT-001 Manuel utilisateur

Texas Instruments

Texas Instruments INA-DUAL-2AMP-EVM Manuel utilisateur

Espressif Systems

Espressif Systems ESP8266EX Mode d'emploi

Abov

Abov AC33M8128L Manuel utilisateur

Laird

Laird BL654PA Manuel utilisateur
