ST STM32 ODE Manuel utilisateur

Version 1.1 (Jan. 30, 2017)

Quick Start Guide

STM32 ODE Function Pack for connecting 6LoWPAN IoT Nodes to

smartphone through a BLE interface

(FP-NET-6LPBLE1)

Quick Start Guide Contents 2

FP-NET-6LPBLE1: STM32 ODE Function Pack for connecting 6LoWPAN

IoT Nodes to smartphone through a BLE interface

Hardware and Software overview

Setup & Demo Examples

Documents & Related Resources

STM32 Open Development Environment: Overview

Bluetooth Low Energy Expansion Board (X-NUCLEO-IDB05A1)

Hardware Overview (1/3) 3

Hardware Description

•The X-NUCLEO-IDB05A1 is a Bluetooth Low Energy

(BLE) evaluation and development board system,

designed around ST’s SPBTLE-RF Bluetooth Low

Energy module based on BlueNRG-MS.

•The BlueNRG-MS processor hosted in the SPBTLE-RF

module communicates with the STM32 Nucleo developer

board host microcontroller though an SPI link available

on the Arduino UNO R3 connector.

Key Products on board

SPBTLE-RF

Bluetooth Low Energy, FCC and IC certified, module

based on Bluetooth® Low Energy wireless network

processor BlueNRG-MS, BLE4.2 compliant.

SPBTLE-RF integrates a BALF-NRG-01D3 balun and

a chip antenna. It embeds 32 MHz and 32.768 kHz

crystal oscillators for the BlueNRG-MS.

M95640-R

64-Kbit serial SPI bus EEPROM with high-speed clock

interface

Latest info available at www.st.com

X-NUCLEO-IDB05A1

Sub-1 GHz RF expansion boards

Hardware Overview (2/3) 4

SPSGRF-868 or

SPSGRF-915 (*)

X-NUCLEO-IDS01A4/5 Hardware description

•The X-NUCLEO-IDS01A4, X-NUCLEO-IDS01A5

are evaluation boards based on the SPIRIT1 RF

modules SPSGRF-868 and SPSGRF-915

•The SPIRIT1 module communicates with the

STM32 Nucleo developer board host

microcontroller though an SPI link available on the

Arduino UNO R3 connector.

EEPROM

Arduino UNO R3 connector

Key products on board

SPSGRF

Sub-GHz (868 or 915 MHz) low power

programmable RF transceiver modules

SPIRIT1

Low data-rate, low-power sub-1GHz transceiver)

module

M95640-R

64 Kbit SPI bus EEPROM with high-speed clock

Latest info available at www.st.com

X-NUCLEO-IDS01A4

X-NUCLEO-IDS01A5

(*) Identification of the operating frequency of the X-NUCLEO-IDS01Ax (x=4 or 5)

is performed through two resistors (R14 and R15).

LPS25HB

HTS221

Key Product on board

LSM6DS0: MEMS 3D accelerometer (±2/±4/±8 g) + 3D gyroscope

(±245/±500/±2000 dps)

LIS3MDL: MEMS 3D magnetometer (±4/ ±8/ ±12/ 16 gauss)

LPS25HB: MEMS pressure sensor, 260-1260 hPa absolute digital

output barometer

HTS221: capacitive digital relative humidity and temperature

DIL 24-pin: socket available for additional MEMS adapters and

other sensors

DIL 24-pin

Motion MEMS and environmental sensors expansion board

Hardware Overview (3/3) 5

X-NUCLEO-IKS01A1 Hardware Description

•The X-NUCLEO-IKS01A1 is a motion MEMS and environmental sensor

evaluation board system.

•It is compatible with the Arduino UNO R3 connector layout, and is

designed around ST’s latest sensors.

Arduino UNO R3 connector

ST morpho connector**

** Connector for the STM32 Nucleo Board

LSM6DS0

LIS3MDL

Latest info available at www.st.com

X-NUCLEO-IKS01A1

Key Features

•The X-NUCLEO-IKS01A1 is a motion MEMS and environmental sensor

evaluation board system.

•All sensor sensors are connected on a single I²C bus

•Sensor I²C address selection

•Each sensor has separate power supply lines allowing power

consumption measurement

•Sensor disconnection (disconnect the I²C bus as well as the power

supply)

•Interrupt and DRDY signals from sensors

•DIL24 socket (Compatible to STEVAL-MKI***V* MEMS adapter boards,

i.e. STEVAL-MKI160V1)

OPTIONAL

BLE & 6LoWPAN software (FP-NET-6LPBLE1)

Software Overview 6

FP-NET-6LPBLE1 Software Description

FP-NET-6LPBLE1 is an STM32 ODE Function Pack. This

package provides application layer bridging functionality to

connect a 6LoWPAN network made of SPIRIT1 based sub-1

GHz RF communication sensor nodes to a device in a BLE

network, such as a smartphone or tablet, allowing the control of

the sensor nodes by an app. This package allows jumpstarting

end-to-end IoT development so user can save time in the

integration of the different basic functions needed to have a

6LoWPAN node connected to smart phone using BLE interface.

Key features

•Firmware package with Contiki 6LoWPAN protocol stack 3.x

and related applications running on a STM32 Nucleo board

equipped with sub-1 GHz RF,BLE connectivity and optionally,

a sensors expansion board. Middleware library with BLE and

Contiki 6LoWPAN protocol stack 3.x.

•Sample application to connect a Border Router to sensor node

using 6LoWPAN mesh network technology and display mesh

network tree and sensors data on android phone.

•Example implementation available for X-NUCLEO-IDS01A4 or

X-NUCLEO-IDS01A5 and X-NUCLEO-IDB05A1 boards

connected to a NUCLEO-F401RE board and sensor board X-

NUCLEO-IKS01A1.

•Easy portability across different MCU families.

FP-NET-6LPBLE1

Latest info available at www.st.com

Overall Software Architecture

Quick Start Guide Contents 7

FP-NET-6LPBLE1: STM32 ODE Function Pack for connecting 6LoWPAN

IoT Nodes to Smartphone through a BLE Interface

Hardware and Software overview

Setup & Demo Examples

Documents & Related Resources

STM32 Open Development Environment: Overview

Setup & Demo Examples

H/W prerequisites 8

Mini USB Cable

•1x Sub-1GHz RF expansion board

(X-NUCLEO-IDS01A4 or X-NUCLEO-IDS01A5)

•1x Bluetooth Low Energy Expansion Board

(X-NUCLEO-IDB05A1)

•1x STM32 Nucleo development board (NUCLEO-F401RE)

•1x BLE-enabledAndroid™ device

•1x PC with Windows 7, 8 or 10

•1x USB type A to Mini-B USB cable

X-NUCLEO-IDB05A1 X-NUCLEO-IKS01A1X-NUCLEO-IDS01A4

X-NUCLEO-IDS01A5

NUCLEO-F401RE

Setup & Demo Examples

S/W prerequisites 9

•STSW-LINK009

•ST-LINK/V2-1 USB driver

•STSW-LINK007

•ST-LINK/V2-1 firmware upgrade

•FP-NET-6LPBLE1

•Copy the zip file content into a folder on your PC

•The package will contain source code example (Keil, IAR, System Workbench for STM32 for

NUCLEO-F401RE

•Binary files for Border Router and Sensor Node application

•Border Router : Applications/STM32_Nucleo_BorderRouter/Binary/STM32F401RE-Nucleo/ STM32F401RE-

Nucleo_BorderRouter.bin

•Sensor Node : Applications/STM32_Nucleo_SensorNode/Binary/STM32F401RE-Nucleo/ STM32F401RE-

Nucleo_SensorNode.bin

FP-NET-6LPBLE1

Bluetooth low energy & 6LoWPAN software 10

Download &

unpack

www.st.com/stm32ode-fp

www.st.com

FP-NET-6LPBLE1

Select

FP-NET-6LPBLE1 package structure

Docs

Application example

Compile / Flash and Run the project

BSP, HAL and drivers

Android™ smartphone application

Sub-GHz 6LoWPAN

BLE
