Sony SDX-D550V Manuel

SDX-D550V/D450V/D250V/2-546-779-02(1)

SDX-D550V/D450V/D250V

AIT Drive Unit

2-546-779-02(1)

Operator’s Guide –––––––––page 2

取扱説明書

–––––––––––––––30

ページ

Mode d’emploi –––––––––––page 61

Benutzerhandbuch –––––––Seite 89

Guía del operador ––––––––página 117

–––––––––––––––––145

–––––––––––––––––171

2Safety Regulations

Safety Regulations

Owner’s Record

The model and serial numbers are located on the bottom. Record the serial

number in the space provided below.

Refer to them whenever you call upon your dealer regarding this product.

Model No. Serial No.

________________________ __________________________________

Information

WARNING

To prevent fire or shock hazard, do not expose the

unit to rain or moisture.

To avoid electrical shock, do not open the cabinet.

Refer servicing to qualified personnel only.

Model No. for Regulatory Compliance

Your SDX-D550V is assigned a Model No.: ATDEA3 for regulatory

compliance certifications.

Your SDX-D450V and SDX-D250V are assigned a Model No.: ATDEA2 for

regulatory compliance certifications.

The number is indicated on the model number label on your drive along with

the rated voltage and current.

For the customers in the USA

You are cautioned that any changes or modifications not expressly approved

in this manual could void your authority to operate this equipment.

If you have any questions about this product, please refer to Sony contact in

the instruction manual.

DECLARATION OF CONFORMITY

Trade Name: SONY

Model: ATDEA2, ATDEA3

Responsible Party: Sony Electronics Inc.

Address: 16450 W. Bernardo Dr., San Diego,

CA 92127 U.S.A.

Telephone number: 858-942-2230

This device complies with part 15 of the FCC Rules. Operation is subject to

the following two conditions:

(1) This device may not cause harmful interference.

(2) This device must accept any interference received, including

interference that may cause undesired operation.

Safety Regulations 3

WARNING

Note: This equipment has been tested and found to comply with the limits

for a Class B digital device, pursuant to Part 15 of the FCC Rules. These

limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates, uses and

can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not

occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and receiver.

•Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

•Consult the dealer or an experienced radio/TV technician for help.

This device requires shielded interface cables to comply with FCC emission

limits.

CAUTION

The mains plug on this equipment must be used to disconnect mains power.

Please ensure that the socket outlet is installed near the equipment and shall

be easily accessible.

ACHTUNG

Zur Trennung vom Netz ist der Netzstecker aus der Steckdose zu ziehen,

welche sich in der Nähe des Gerätes befinden muß und leicht zugänglich

sein soll.

Hinweis: Der höchste Schalldruckpegel beträgt 70 dB (A) oder weniger

gemäß ISO 7779

NOTICE

Use the power cord set approved by the appropriate testing organization for

the specific countries where this unit is to be used.

HINWEIS

Die 3-adrige Geräteanschlußleitung muß Typ H05VV-F oder H05VVH2-F

sein und nach DIN VDE 0625 geprüft sein. Der Stecker und die

Gerätesteckdose müssen nach DIN VDE 0620 bzw DIN VDE 0625 geprüft

sein. Der Leitungsquerschnitt kann 0,5 mm2betragen wenn die

Anschlußleitung eine Länge von 2 m nicht überschreitet. Anderenfalls muß

der Leitungsquerschnitt mindestens 0,75 mm2betragen.

English

4Safety Regulations

Für Kunden in Deutschland

Diese Ausrüstung erfüllt die Europäischen EMC-Bestimmungen für die

Verwendung in folgender/folgenden Umgebung(en):

– Wohngegenden

– Gewerbegebiete

– Leichtindustriegebiete

(Diese Ausrüstung erfüllt die Bestimmungen der Norm EN 55022, Klasse

B.)

Safety Regulations 5

IMPORTANT SAFEGUARDS

For your protection, please read these safety

instructions completely before operating the

appliance, and keep this manual for future

reference.

Carefully observe all warnings, precautions and

instructions on the appliance, or the one described

in the operating instructions and adhere to them.

USE

Power Sources – This unit should be operated

only from the type of power source indicated on

the marking label. If you are not sure of the type

of electrical power, consult your dealer or local

power company.

For the unit with a three-wire grounding type

ac plug:

If you are unable to insert the plug into the outlet,

contact your electrician to have a suitable plug

installed. Do not defeat the safety purpose of the

grounding plug.

AC Power cord:

The AC power cord should have appropriate safety

approvals or marking for the country in which the

equipment will be used. Consult your dealer or

local power company.

Cleaning – Unplug the unit from the wall outlet

before cleaning or polishing it. Do not use liquid

cleaners or aerosol cleaners.

Use a cloth lightly dampened with water for

cleaning the exterior of the unit.

Object and Liquid Entry – Never push objects of

any kind into the unit through openings as they

may touch dangerous voltage points or short out

parts that could result in a fire or electric shock.

Never spill liquid of any kind on the unit.

6Safety Regulations

INSTALLATION

Water and Moisture – Do not use power-line

operated units near water - for example, near a

bathtub, washbowl, kitchen sink, or laundry tub, in

a wet basement, or near a swimming pool, etc.

Power-Cord Protection – Route the power cord

so that it is not likely to be walked on or pinched

by items placed upon or against them, paying

particular attention to the plugs, receptacles, and

the point where the cord exits from the appliance.

Accessories – Do not place the unit on an unstable

cart, stand, tripod, bracket, or table. The unit may

fall, causing serious injury to a child or an adult,

and serious damage to the unit. Use only a cart

stand tripod, bracket, or table recommended by the

manufacturer.

Ventilation – The slots and openings in the

cabinet are provided for necessary ventilation. To

ensure reliable operation of the unit, and to protect

it from overheating, these slots and openings must

never be blocked or covered.

•Never cover the slots and openings with a cloth

or other materials.

•Never block the slots and openings by placing

the unit on a bed, sofa, rug or other similar

surface.

•Never place the unit in a confined space, such as

a bookcase, or built-in cabinet, unless proper

ventilation is provided.

SERVICE

Damage Requiring Service – Unplug the unit

from the wall outlet and refer servicing to qualified

service personnel under the following conditions:

•When the power cord or plug is damaged or

frayed.

•If liquid has been spilled or objects have fallen

into the unit.

•If the unit has been exposed to rain or water.

•If the unit has been subject to excessive shock by

being dropped, or the cabinet has been damaged.

•If the unit does not operate normally when

following the operating instructions. Adjust

only those controls that are specified in the

operating instructions. Improper adjustment of

other controls may result in damage and will

often require extensive work by a qualified

technician to restore the unit to normal

operation.

• When the unit exhibits a distinct change in

performance - this indicates a need for service.

Servicing – Do not attempt to service the unit

yourself as opening or removing covers may

expose you to dangerous voltage or other hazards.

Refer to all servicing to qualified service

personnel.

Table of Contents 7

Table of Contents

Part 1.

Introduction

How to Use this Guide ...................................................................... 8

About AIT Drives ............................................................................... 9

Features .................................................................................................... 9

Useable Cartridges ................................................................................. 10

System Components .............................................................................. 10

Part Names and Functions ............................................................. 11

Front Panel ............................................................................................. 11

Rear Panel .............................................................................................. 12

Part 2.

Preparation

Supplied Items................................................................................. 13

Interconnections ............................................................................. 13

SCSI ID Setting ................................................................................ 14

Option Switches (DIP Switch) ........................................................ 14

Part 3.

Operation

How to use the AIT Drive ................................................................ 17

Cartridge Removal ................................................................................. 18

Attaching the Dust Cover ............................................................... 19

WORM Function .............................................................................. 21

Part 4.

Care and

Maintenance

Taking Care of the Drive ................................................................. 23

Safety Considerations ............................................................................ 23

Avoiding Damage .................................................................................. 23

Taking Care of Cartridges .............................................................. 25

Use Precautions ..................................................................................... 25

Storage Precautions ............................................................................... 25

Head Cleaning ................................................................................. 26

How to Clean ......................................................................................... 26

Appendix Specifications (SDX-D550V) ........................................................... 27

Specifications (SDX-D450V) ........................................................... 28

Specifications (SDX-D250V) ........................................................... 29

8How to Use this Guide

How to Use this Guide

This Guide describes the AIT Drive Unit SDX-D550V/SDX-D450V/SDX-

D250V, and how to take care of it. Please read it carefully before using the

unit, and keep it handy for future reference.

The Guide consists of four parts, plus the specifications. Refer to the parts

that relate to your use of the drive.

Part 1 describes the features of the drive, its system components, and the

name and function of each part.

Part 2 describes the necessary connections between the drive and the host

computer. If other SCSI devices are being used, you may need to change the

SCSI ID setting. Read this part if you are installing the drive.

Part 3 describes how to use the drive, including how to turn it on, and how

to insert and remove cartridges. Read this part if you are going to operate the

drive.

Part 4 describes how to take care of the drive and cartridges, and how to

clean the drive heads. Read this part before using the drive.

Appendix provides the major specifications of the SDX-D550V/SDX-

D450V/SDX-D250V.

Part 1. Introduction 9

Part 1. Introduction

About AIT Drives

The SDX-D550V is an external AIT drive unit that uses data cartridges

conforming to the AIT-2 Turbo format. The SDX-D450V is an external AIT

drive unit that uses data cartridges conforming to the AIT-1 Turbo format.

The SDX-D250V is an external AIT drive unit that uses data cartridges

conforming to the AIT-E Turbo format.

The SDX-D550V supports the AIT-E Turbo, AIT-1, AIT-1 Turbo, AIT-2 and

AIT-2 Turbo formats. The SDX-D450V supports the AIT-E Turbo, AIT-1

and AIT-1 Turbo formats. The SDX-D250V only supports the AIT-E Turbo

format.

Features

The AIT Drive Unit SDX-D550V has the following features:

• Supports reading and writing to data cartridges conforming to the AIT-E

Turbo, AIT-1, AIT-1 Turbo, AIT-2 and AIT-2 Turbo formats.

•Read After Write Function and third-level error correction code guarantee

high data reliability.

•Data compression provides 208 gigabytes of storage on 186 m tape-length

AIT-2 Turbo data cartridge.*1

The native capacity is 80 gigabytes of storage on 186 m tape-length AIT-2

Turbo data cartridge.

• Stored data is automatically checked for compression.

•Ultra 160 Wide SCSI LVD/SE interface is fully supported for host

computer access.

The AIT Drive Unit SDX-D450V has the following features:

• Supports reading and writing to data cartridges conforming to the AIT-E

Turbo, AIT-1 and AIT-1 Turbo formats.

•Read After Write Function and third-level error correction code guarantee

high data reliability.

•Data compression provides 104 gigabytes of storage on 186 m tape-length

AIT-1 Turbo data cartridge.*1

The native capacity is 40 gigabytes of storage on 186 m tape-length AIT-1

Turbo data cartridge.

• Stored data is automatically checked for compression.

•Wide Ultra SCSI LVD/SE interface is fully supported for host computer

access.

*1 This is assuming 2.6:1 compression ratio.

The degree of data compression attained while recording data varies according to system

environment and data type.

10 Part 1. Introduction

The AIT Drive Unit SDX-D250V has the following features:

• Supports reading and writing to data cartridges conforming to the AIT-E

Turbo format.

•Read After Write Function and third-level error correction code guarantee

high data reliability.

•Data compression provides 52 gigabytes of storage on 98 m tape-length

AIT-E Turbo data cartridge.*1

The native capacity is 20 gigabytes of storage on 98 m tape-length AIT-E

Turbo data cartridge.

• Stored data is automatically checked for compression.

•Wide Ultra SCSI LVD/SE interface is fully supported for host computer

access.

*1 This is assuming 2.6:1 compression ratio.

The degree of data compression attained while recording data varies according to system

environment and data type.

Useable Cartridges

Data cartridges used with the the SDX-D550V can be used with data

cartridges marked with AIT-E Turbo, AIT-1 Turbo, AIT-2 Turbo, AIT-1 or

AIT-2 logo. The SDX-D450V must be marked with AIT-E Turbo, AIT-1

Turbo or AIT-1 logo. The SDX-D250V can be used with data cartridges

marked with the AIT-E Turbo logo.

AIT-E Turbo LOGO AIT-1 Turbo LOGO AIT-2 Turbo LOGO AIT-1 LOGO AIT-2 LOGO

Caution

•Be sure to use only the cartridges designed specifically for AIT.

•Do not use anything but AIT cartridges with this system, as doing so can

damage the AIT drive. Although commercially available 8mm videotapes

resemble AIT cartridges in appearance, they have entirely different

specifications and cannot be used.

System Components

The SDX-D550V/SDX-D450V/SDX-D250V connects to the host computer

via on Ultra Wide LVD/SE SCSI interface.

SDX-D550V

SDX-D450V

SDX-D250V

Host Computer

Peripheral Devices Terminator
