Sony RMT-P1BT Guide de référence

Help Guide

Remote Commander

RMT-P1BT

Use this Help Guide when you have issues or questions on how to use your Remote Commander.

Supported camera models

Identifying the parts

Preparations

Unpacking

Inserting the battery

Connecting the Remote Commander and a camera with the Bluetooth® function

Preventing unintentional operations

Shooting

Shooting a still image

Shooting a video

Adjusting the camera focus

Zooming the camera

Indicator activities

Activating the camera's C1 or AF-ON function

About this unit

Notes on use

Specifications

Trademarks

Troubleshooting

The Remote Commander fails to work.

Help Guide

Remote Commander

RMT-P1BT

Supported camera models

This unit is Remote Commander which is compatible with the Bluetooth function.

For the camera models that can connect to the unit, visit the following website.

https://www.sony.net/dics/p1bt/

Help Guide

Remote Commander

RMT-P1BT

Identifying the parts

About the built-in Bluetooth antenna

The Remote Commander is equipped with a built-in Bluetooth antenna at the section shown in the following illustration.

When you operate the Remote Commander, keep your hand away from the section to prevent a possible Bluetooth

connection failure.

Indicator

Indicates the camera's operational state in accordance with the Remote Commander operation.

Focus/Zoom button

Adjusts the camera focus or zooms in/out the camera. Slide the Remote Commander's ZOOM/FOCUS switch to the

position suitable for your purpose. For details, see Adjusting the camera focus or Zooming the camera.

Shutter-release/REC button

Shoots a still image or starts recording a video with the camera. Slide the Remote Commander's MOVIE/STILL

switch to the position suitable for your purpose. For details, see Shooting a still image or Shooting a video.

AF-ON button*

C1 button*

Strap holder6.

ZOOM/FOCUS switch7.

MOVIE/STILL switch8.

LOCK switch9.

Battery cover10.

Activates the function assigned to the C1 or AF-ON button on the camera. For details about the camera's settings, refer to the operating

instructions supplied with your camera.

Related Topic

Activating the camera's C1 or AF-ON function

Preventing unintentional operations

Inserting the battery

Supported camera models

Connecting the Remote Commander and a camera with the Bluetooth® function

Indicator activities

Help Guide

Remote Commander

RMT-P1BT

Unpacking

If you find anything missing, please contact your dealer.

The number in the parentheses indicates the quantity.

Remote Commander (1)

Lithium coin cell battery (CR2032) (1)

Set of printed documentation

Help Guide

Remote Commander

RMT-P1BT

Inserting the battery

Insert the supplied lithium coin cell battery (CR2032) into the battery chamber of the Remote Commander.

Place a coin, or similar object, into the groove of the battery cover on the back of the Remote Commander,

and then turn the battery cover to “OPEN.”

Remove the battery cover and insert the supplied lithium coin cell battery.

Insert the battery so that the + terminal is facing upward.

(+ on the battery chamber indicates the direction of the battery.)

Turn the battery cover until you reach “CLOSE.”

Help Guide

Remote Commander

RMT-P1BT

Connecting the Remote Commander and a camera with the Bluetooth® function

Connect the Remote Commander and a camera with the Bluetooth function.

Before connecting the Remote Commander and a camera with the Bluetooth function, you must pair them together

(device registration).

Note

The following is an example of a procedure for Sony Interchangeable Lens Digital Cameras and Sony digital still cameras.

Before you start, check that the Remote Commander’s LOCK switch is in the position to the opposite of “LOCK.”

Note

If pairing fails, the Remote Commander's indicator flashes rapidly. If this happens, redo the procedure from the beginning.

On the camera, select MENU → (network) → [Bluetooth Settings] → [Bluetooth Function] → [On].

On the camera, select MENU → (network) → [Bluetooth Rmt Ctrl] → [On].

If the pairing screen appears on the camera's screen, proceed to step .

On the camera, select MENU → (network) → [Bluetooth Settings] → [Pairing].

On the Remote Commander, press and hold the Shutter-release/REC button ( ) and the Focus/Zoom

button (either the + button ( ) or the - button ( )) at the same time for at least 7 seconds.

When a confirmation message appears on the camera's screen, select [OK].

appears and pairing begins.

When pairing is complete, [Paired.] appears.

In the following situations, pair the Remote Commander and the camera again.

When using the Remote Commander to operate a different camera (After having connected the Remote Commander with a

different camera, you also must pair the Remote Commander and the original camera again when connecting to the original

camera.)

When the camera's network settings have been reset

If the Remote Commander is not used for a period of time during a Bluetooth connection, (no Bluetooth connection) may

appear on the camera’s screen.

Help Guide

Remote Commander

RMT-P1BT

Preventing unintentional operations

You can disable all the buttons on the Remote Commander in order to prevent unintentional operations while you carry it

around.

Slide the LOCK switch to the “LOCK” position.

To enable the buttons, slide the LOCK switch to the position to the opposite of “LOCK.”
