JPEG VIEWER

– For RM-NX7000

Operating Instructions

Table of Contents

Overview ................................................................................................................. 3

JPEG files to be used ................................................................................................. 3

Transferring JPEG VIEWER to the RM-NX7000 ................................................ 4

Using JPEG VIEWER ............................................................................................. 6

Showing JPEG files by slide show (SLIDE SHOW) .............................................. 6

Selecting JPEG files to show (LIST DISPLAY).......................................................9

Setting the screen saver ............................................................................................ 9

Troubleshooting .................................................................................................... 11

Overview

JPEG VIEWER is an application to view JPEG files in a “Memory Stick,” and

create a screen saver on the RM-NX7000 remote control.

JPEG files to be used

The following JPEG file specifications are required to run RM-NX7000:

•Memory capacity for start-up: 5 MB*or more

• Format: JFIF (JPEG File Interchange Format) compliance

Non support for Progressive JPEG and Multi-scan JPEG files

•Pixel count: 3,264 ×2,448 pixels, 2,448 ×3,264 pixels or lower

•File size: 5 MB or less

(Viewable file size varies depending on the free space on your

RM-NX7000)

•File name: English one-byte characters and symbols below

! # $ % & ’ ( ) + – . ; = @ [ ] ^ _ { } ˜

•Maximum file name: Up to 32 characters (not including a file extension)

•File extension: jpg, jfi, jif, jpe, jpeg, jfif

•Directory name: English one-byte characters and symbols below

! # $ % & ’ ( ) + – . ; = @ [ ] ^ _ { } ˜

•Maximum directory tree: UP to 128 characters by the full pathname of

directories (including drive name and path separator)

•Viewable file/directory number: 4,000 files/directories in “Memory

Stick”

•Maximum file/directory number: 8,000 files/directories in “Memory

Stick”

If files/directories are over 8,000, the application will not work properly.

Design and specifications are subject to change without notice.

*If 5 MB of memory is not available, the message appears shown below:

“The Remote Commander memory is insufficient. Quit JPEG Viewer.”

Transferring JPEG VIEWER to the RM-NX7000

You need to download the latest kernel for the RM-NX7000 to your

computer to use JPEG VIEWER.

Consult the NAVITUS Web site (http://www.sony.com/nxremotesupport)

about how to download the kernel.

After downloading the latest kernel to your computer, use “NAVITUS

Design” to transfer it to the Remote Commander by connecting the Remote

Commander to the computer with the USB cable.

Before connecting the Remote Commander to the computer with the USB

cable, set the Remote Commander to the recovery mode.

Step 1: Set the Remote Commander to the RECOVERY

mode

1Press the [SET] key for 2 seconds or longer in

the Home display.

The Set display appears.

2Press the [SYSTEM] key.

The System display appears.

3Press the [RECOVERY] key for 2 seconds or

longer.

The confirmation display for the transition to the recovery mode

appears.

4Press the [YES] key.

After restarting, the Remote Commander enters the recovery mode.

Step 2: Connect

1Connect your Remote Commander to your

computer with the USB cable.

Notes

•Before connecting the Remote Commander to your computer, be sure to

connect the supplied AC power adaptor to the Remote Commander.

• Do not disconnect the USB cable from your computer, until kernel transfer

and Remote Commander update are complete, as a malfunction may occur.

•Do not connect several Remote Commanders to your computer at the same

time, as you will not be able to transfer the kernel to the Remote

Commander. Connect only the RM-NX7000.

Transferring JPEG VIEWER to the RM-NX7000

Step 3: Transfer the kernel from NAVITUS Design

1Close any currently open project files on

NAVITUS Design.

2Click “Tools” of the menu bar, then select

“Update Kernel for NX7000.”

The “Update Kernel for NX7000” dialog box appears.

3Click of “Look in,” then select the folder that

contains the kernel.

4Select the kernel file, and click “Select.”

Transfer of the kernel to the Remote Commander starts. When

transfer is complete, a message dialog box appears.

Note

After you click “Select,” an error message will appear if:

•You select a file other than the kernel file for the RM-NX7000.

•The data capacity of the kernel is larger than the memory capacity of the

Remote Commander.

•The version of the kernel you are transferring is the same as, or older than

that of the Remote Commander.

•An error occurs while you are transferring the kernel (e.g., if you disconnect

the USB cable).

If you click “Back to file selection,” the display returns to the “Update Kernel

for NX7000” dialog box, and you can select the kernel file again. If you click

“Cancel update,” the updating is canceled.

5Click “OK.”

The Remote Commander starts to update the kernel. Wait until the

updating is complete.

6To finish the setting, follow the on-screen

instructions in the recovery mode.

When the recovery mode finishes, the Remote Commander is

restarted. If the Remote Commander is restarted, the system clock is

reset. After restarting, set the system clock again.

Note

If you are using Windows 2000 Professional, after transfer of the kernel to the Remote

Commander, the “Unsafe Removal of Device” dialog box appears. This is not an error.

Click “OK” to close the dialog box.

Using JPEG VIEWER – Showing JPEG files by slide show (SLIDE SHOW)

Using JPEG VIEWER

1Press the [APP] key for 2

seconds or longer in the

Home display.

The Application display appears.

2Press the (JPEG

VIEWER) icon.

The “Memory Stick” confirmation

display appears.

JPEG VIEWER MENU display will

appear .

Note

We do not guarantee the performance of the RM-NX7000 or the “Memory Stick,” if the

“Memory Stick” is removed while accessing data.

JPEG VIEWER has two menus, “SLIDE SHOW” and “LIST DISPLAY.”

“SLIDE SHOW” can show JPEG files automatically in the “Memory Stick” as

your setup. “LIST DISPLAY” can show JPEG files in the “Memory Stick”

according your selection.

Showing JPEG files by slide show (SLIDE SHOW)

1Press the [SLIDE SHOW]

key.

The setup display appears.

zTip

If you want to close the application

display, press the [EXIT] key in the

display to return to the Application

display.

Using JPEG VIEWER – Showing JPEG files by slide show (SLIDE SHOW)

2Press the [DIRECTORY

SELECT] key to select a

directory for the slide

show.

3Press the [v] or [V] key to

select the directory name

and then select the

Directory Select area to

confirm.

zTip

•Press and hold [v]/[V] to move to the

top/last page.

•You can change the list, in order from

latest/oldest date or alphabetically.

•Press the key to display the upper

directory.

4Press the [PLAY MODE]

key to change the play

mode.

The play mode display appears.

5Select the play mode.

•NEW DATE: Display files in order of

date.

•OLD DATE: Display files in order from

oldest date.

•Alphabet DATE: Display files

alphabetically.

•SHUFFLE: Display files randomly.

Using JPEG VIEWER – Showing JPEG files by slide show (SLIDE SHOW)

6Press the [EXIT] key to

confirm.

7Press the [EFFECT] key to

add effects to the files.

8Select an effect from the

display.

You can preview the effect in the

thumbnail.

9Press the [EXIT] key to

confirm.

10 Press the [START] key.

The slide show starts as set.

Using JPEG VIEWER – Selecting JPEG files to show (LIST DISPLAY)

To stop the slide show

Press the display panel.

If the error message “File pixel count is too high” appears.

The application has a pixel count limitation when showing a JPEG file. For

details, refer to “JPEG files to be used” on page 2.

Setting the screen saver

You can set the screen saver for RM-NX7000.

The screen saver will be activated by the following:

–The AC power adaptor is connected to the RM-NX7000.

–The screen saver set to ON.

–A“Memory Stick” is inserted into the RM-NX7000.

–The lock function is released.

Note

Do not remove the “Memory Stick” while the slide show or screen saver is activating

as the directory in the “Memory Stick” may be disrupted.

Using JPEG VIEWER – Selecting JPEG files to show (LIST DISPLAY)

Selecting JPEG files to show (LIST DISPLAY)

You can show a file to select it directly.

1Press the [LIST DISPLAY]

key.

The directory list in the “Memory

Stick” appears.

zTip

If you want to close the application

display, press the [EXIT] key to return to

the Application display.

2Select a file to show.

The selected file will be displayed.

■To show the file in the directory

Press the [v] or [V] key to select the directory name and then select a

file from the list.

zTip

•Press and hold [v]/[V] to move to the top/last page.

•You can change the list, in order from latest/oldest date or alphabetically.

•Press the key to display the upper directory.
