Sony VCT-D580RM Manuel utilisateur

VCT-D580RM

US Model

Canadian Model

AEP Model

SERVICE MANUAL

REMOTE CONTROL TRIPOD

Sony EMCS Co. 2006E1600-1

Published by DITechnical Support Department

9-929-888-11

Ref. No. Part No. Description

1 3-052-096-01 KNOB, ELEVATOR LOCK

2 3-053-093-01 KNOB, PAN LOCK

3 A-7007-793-A HEAD (A) BLOCK ASSY

4 3-052-094-01 SHOE, QUICK

5 3-052-097-01 KNOB, PAN HEAD ANGLE ADJUSTMENT

6 7-688-006-02 WASHER

7 A-7028-500-A BAR BLOCK ASSY, PAN

8 3-068-083-01 TRIPOD (MAIN)

3-068-084-01 CASE, CARRYING

3-068-088-01 MANUAL, INSTRUCTION

(JAPANESE, ENGLISH, FRENCH, GERMAN, SPANISH,

DUTCH, SWEDISH, ITALIAN, PORTUGUESE, RUSSIAN,

ARABIC, TRADITIONAL CHINESE, KOREAN)

PARTS LIST

SPECIFICATIONS NOTE: The mechanical parts with no reference number in the exploded

views are not supplied.

Ver.1.2 2006. 05

Sony EMCS Co.

SERVICE MANUAL

2004D1600-1

Published by DI Technical Support Section

9-929-888-82

SUPPLEMENT-1

File this supplement-1 with the Service Manual.

(PV04-001)

VCT-D580RM

Ver 1.1 2004. 04

VCT-D580RM

US Model

Canadian Model

AEP Model

• Addition of service part

PARTS LIST : Added portion : Changed portion

Page Before change After change

Ref. No. Part No. Description

9 1-696-933-81 CORD, CONNECTION

Ref. No. Part No. Description

Sony EMCS Co.

2006E1600-1

Published by DI Technical Support Department

9-929-888-84

SERVICE MANUAL

SUPPLEMENT-2

File this supplement-2 with the service manual and Supplement-1.

(PV06-004)

Ver.1.2 2006. 05

US Model

Canadian Model

AEP Model

Chinese Model

VCT-D580RM

Page

2-102-952-01 MANUAL, INSTRUCTION

(SIMPLIFIED CHINESE)(Chinese model)

Ref. No. Part No. DescriptionRef. No. Part No. Description

: Added portion

Before change After change

Page Before change After change

Ref. No. Part No. DescriptionRef. No. Part No. Description

19 1-696-933-81 CORD, CONNECTION 9 1-828-908-23 CORD WITH CONNECTOR

• Addition of service part (Chinese model)

SERVICE MANUAL (9-929-888-11)

• Change of service part

SUPPLEMENT-1 (9-929-888-82)

• Addition of Chinese model

• Change of service part

: Changed portion

Revision History

992988813.pdf

VCT-D580RM

Reverse

Ver.

1.0

1.1

1.2

Date

2001.05

2004.04

2006.05

History

Official Release

Supplement-1

Supplement-2

(PV06-004)

Contents

—

Addition of service part

Addition of Chinese model

Change of service part

S.M. Rev.

issued

—
