SOLTEK SL-75ERV Manuel utilisateur

The Soul Of Computer Technology

Mainboard

SL-75ERV User Manual V1.1

Product Model : SL-75ERV

Manual Revision : V1.1

Release Date : Januar 2002

• AMD Athlon ThunderbirdTM, DuronTM, and AthlonTM XP processors are trademarks of AMD

Corporation.

• V A, KT-266A, VT8366A and VT8233A are trademarks of V A Corporation.

his Users Guide & Technical Reference is to help system

manufacturers and end-users set up and install the mainboard.

Every effort has been made to ensure that the information in this

manual is accurate. Soltek Computer nc. is not responsible for printing or

clerical errors. nformation in this document is subject to change

without notice and does not represent a commitment on the part of

Soltek Computer nc.

No part of this manual may be reproduced, transmitted, translated

into any language in any form or by any means, electronic or

mechanical, including photocopying and recording, for any purpose

without the express written permission of Soltek Computer nc.

Companies and products mentioned in this manual are for identification

purpose only. Product names appearing in this manual may or may

not be registered trademarks or copyrights of their respective

companies.

Soltek Computer nc. provides this manual “As is “ without warranty

of any kind, either express or implied, including but not limited to the

implied warranties or conditions of merchantability or fitness for a

particular purpose. n no event shall Soltek Computer nc. be liable

for any loss or profits, loss of business, loss of use or data, interruption

of business, or for indirect, special, incidental, or consequential

damages of any kind, even if Soltek Computer nc. has been

advised of the possibility of such damages arising from any defect

or error in this manual or product.

NOTIC

SOLTEK AROUND THE WORLD

SOLT K COMPUT R INC.

Address : 7F, No. 306-3, Ta-Tung Rd, Sec.1, Hsi-Chih, Taipei-

Hsien, Taiwan, R.O.C.

Telephone : 886-2-2642-9060

Fax : 886-2-2642-9065

E-mail : [email protected]

Web site : http://www.soltek.com.tw

SOUL T CHNOLOGY UROP B.V.

Address : Hongkongstraat 55, 3047 BP Rotterdam. The Neth-

erlands

Telephone : 31-10-2457492

Fax : 31-10-2457493

E-mail : [email protected]

Web site : http://www.soultech-europe.com

SOLT K KOR A INC.

Address : 1002, Chungjin Bldg. 53-5 Wonhyo-Ro, 3-Ka,

Yongsan-Ku Seoul 140-113, Korea

Telephone : 82-2-32717400

Fax : 82-2-32717405

E-mail : [email protected]

75ERV

CONTENT

Chaper 1 Introduction ............................................................. 8

1-1 Mainboard Specification ............................................................ 9

1-1.1 Processor .......................................................................................... 9

1-1.2 Chipset .............................................................................................. 9

1-1.3 AWARD B OS V6.0 Supporting ......................................................... 9

1-1.4 Sound Controller ............................................................................... 9

1-1.5 Power Management .......................................................................... 9

1-1.6 Full Featured Accelerated Graphics Ports (AGP) Controller ........... 10

1-1.7 Multi- /O Function ............................................................................ 10

1-1.8 Expansion Slots .............................................................................. 10

1-1.9 Advanced High Performance SDR/DDR DRAM Controller ............. 10

1-1.10 Form Factor ................................................................................... 11

1-1.11 Hareware Monitoring ..................................................................... 11

1-2 Mainboard Layout .................................................................... 12

1-3 Chipset Diagram ...................................................................... 13

Chaper 2 Hardware Setup .................................................... 15

2-1 CPU nstallation ....................................................................... 16

2-2 Memory nstallation.................................................................. 17

2-3 HDD/FDD nstallation .............................................................. 19

2-4 Switch Setting For CPU Frequency And Voltage ..................... 21

2-4.1 nformation On AMD Socket 462 Processor (Model 4, 5 Products) ........ 21

2-4.2 nformation On AMD Socket 462 Processor (Model 6, 7 Products) ........ 22

2-4.3 Processor Core Voltage Select (By SW1 D P1-D P6) ..................... 23

2-4.4 CPU External Frequency Setting (By SW2) .................................... 24

2-5 Jumper Settings ....................................................................... 25

2-5.1 JP1 Power Lost Resume ................................................................. 26

Content

2-5.2 JBAT1 For Clear CMOS Data ......................................................... 26

2-6 Connectors Configurations ...................................................... 27

2-6.1 On Board FAN Connector (FAN1, FAN2, FAN3, FAN4) .................. 27

2-6.2 WOL1 Wake On LAN ...................................................................... 28

2-6.3 CD-ROM Audio Connector (JCD_ N1) ............................................ 28

2-6.4 Complex Header CON1 .................................................................. 29

2-6.5 ATX Power Supply Connector ......................................................... 30

2-6.6 Chassis Panel Connector ................................................................ 31

2-6.7 Communication And Networking Riser Slot (CNR) ......................... 32

2-6.8 USB Ports and USB Headers (Header USB 3) ............................... 33

2-6.9 PS/2 Mouse And PS/2 Keyboard .................................................... 33

Chaper 3 Software Setup...................................................... 35

3-1 Open up the Suport CD and choose Drivers and Utilities........ 36

3-2 Proceed to V A 4- n-1 Drivers nstallation ............................... 37

3-3 Proceed to AC’97 Audio Driver nstallation .............................. 39

3-4 Proceed to Hardware Monitor nstallation................................ 40

Chaper 4 BIOS Setup ............................................................ 43

4-1 What s B OS Setup ................................................................. 44

4-2 How To Run B OS Setup ......................................................... 44

4-3 What s CMOS ......................................................................... 44

4-4 What s POST .......................................................................... 44

4-5 B OS Upgrade ......................................................................... 45

4-5.1 Before Upgrading B OS .................................................................. 45

4-5.2 Upgrade Process ............................................................................ 45

4-6 B OS Setup --- CMOS Setup Utility ......................................... 49

4-6.1 CMOS Setup Utility ......................................................................... 49

4-6.2 Standard CMOS Setup ................................................................... 50

4-6.3 Advanced B OS Features ................................................................ 53

75ERV

4-6.4 Advanced Chipset Features ............................................................ 57

4-6.5 ntegrated Peripherals ..................................................................... 62

4-6.6 Power Management Setup .............................................................. 68

4-6.7 PNP / PC Configuration ................................................................. 74

4-6.8 SmartDOC Anti-Burn Shield ............................................................ 77

4-6.9 Frequency/Voltage Control .............................................................. 79

4-6.10 Load Optimized Defaults ............................................................... 81

4-6.11 Set Supervisor / User Password ................................................... 81

4-6.12 Save & Exit Setup ......................................................................... 82

4-6.13 Exit Without Saving ....................................................................... 82

Appendices ............................................................................ 84

Appendix-1 dentify B OS Version & B OS Part Number .............. 85

Appendix-2 dentifying Mainboard model Number ........................ 86

Appendix-3 Technical Terms .......................................................... 87

Content

Mainboard

====Support CD

====User’s Manual

====Bundled Bonus Pack CD

====Bundled Bonus Pack Manual

====Temperature Sensor Cable (Optional)

====ATA66/100/133 DE Cable

====RS232 Cable

FDD Cable

IT M LIST CH CKUP

75ERV

This chapter contains the following topics :

1-1 Mainboard Specification

1-2 Mainboard Layout

1-3 Chipset Diagram

• This chapter briefly introduces the characteristics of the mainboards. t includes

the information regarding the chipset, CPU types, built-in functions and layout.

Users will have more ideas about mainboards after reading this chapter.

Chaper 1 Introduction

Chapter 1 Introduction

1-1 Mainboard Specification

1-1.1 Processor

• Supporting AMD Athlon™ Thunderbird processor up to 1.5GHz or above.

• Supporting AMD Duron™ processor up to 1.2GHz or above.

• Supporting 200MHz & 266MHz FSB bus.

• Supporting Processor V D(voltage D) and F D(Frequency D) auto

detection.

• Supporting Atholon™ XP Processors.

1-1.2 Chipset

• V A VT8366A DDR V-Link Host North Bridge.

• V A VT8233A V-Link Client South Bridge.

• TE 8705 LPC /O.

1-1.3 AWARD BIOS V6.0 Supporting

• Plug & Play V1.0.

• Flash Memory for easy upgrade.

• Year 2000 compliant.

• B OS writing protection.

• SmartDOC Anti-Burn shield.

1-1.4 Sound Controller

• SoundBlaster Pro Hardware and Direct Sound Ready AC97 Digital Audio

Controller with Codec onboard.

1-1.5 Power Management

• ACP 1.0 compliant (Advanced Configuration and Power nterface).

• APM V1.2 compliant (legacy power management).

• Supporting ACP suspend STR mode (Suspend To RAM) and POS mode

(Power On Suspend).

• System event monitoring with two event classes.

• Supporting PS/2 Keyboard & Mouse power on.

• Supporting Wake On LAN (WOL) & Wake On Ring.

• Supporting Real Time Clock (RTC) with date alarm, month alarm, and

century field.

• USB boot-up Function.

75ERV

1-1.6 Full Featured Accelerated Graphics Ports (AGP)

Controller

• AGP v2.0 compliant.

• Supports Side Band Addressing(SBA) mode (non-multiplexed address /

data).

• Supporting 66MHz 1x, 2x, and 4x modes for AD and SBA signaling.

1-1.7 Multi-I/O Function

• Two UltraDMA-33/66/100/133 Master Mode PC E DE ports.

• Two UARTs for complete Serial Ports.

• One dedicated R connector:

--At third serial port dedicated to R function either through the two complete serial

ports or the third dedicated port nfrared- rDA (HPS R) and ASK( Amplitude Shift

Keyed) R.

• Multi-mode parallel connector supporting:

--Standard mode, ECP and EPP.

• Floppy Disk connector supporting:

--One FDD with drive swap function.

• Universal Serial Bus connector supporting:

-- USB v1.1 and ntel Universal HC v1.1 compatible.

-- 2 built-in USB connectors, in addition to one internal USB header which requires

a USB cable to support 2 more optional USB ports.

• PS/2 keyboard connector.

• PS/2 Mouse connector.

1-1.8 xpansion Slots

• Six PC bus Master slots.

• One CNR slot.

• One AGP 4x mode slot.

• Three 184-pin D MM slots.

1-1.9 Advanced High Performance SDR/DDR DRAM Controller

• Supporting memory size up to 3GB.

• Supporting 184-pin DDR SDRAM type only.

• Supporting PC1600 and PC2100 DDR SDRAM.

Table des matières

Autres manuels SOLTEK Carte mère

SOLTEK

SOLTEK 65kv Manuel utilisateur

SOLTEK

SOLTEK SL-85DIR3 Manuel utilisateur

SOLTEK

SOLTEK SL-75DRV-X Manuel utilisateur

SOLTEK

SOLTEK SL-65ME-T Manuel utilisateur

SOLTEK

SOLTEK 75FRN Series Manuel utilisateur

SOLTEK

SOLTEK SL-PT880E-R Manuel utilisateur

SOLTEK

SOLTEK SL-55F5 Manuel utilisateur

SOLTEK

SOLTEK SL-75KV Manuel utilisateur

SOLTEK

SOLTEK SL-53D5-S Manuel d'utilisation et d'entretien

SOLTEK

SOLTEK SL-52D2 Manuel utilisateur

SOLTEK

SOLTEK SL-75MIV Manuel utilisateur

SOLTEK

SOLTEK SL-65MV Manuel d'utilisation et d'entretien

SOLTEK

SOLTEK SL-845GVI Manuel utilisateur

SOLTEK

SOLTEK SL-65GS Manuel utilisateur

SOLTEK

SOLTEK B9A-FGR Manuel utilisateur

SOLTEK

SOLTEK SL-65LIV-T Manuel utilisateur

SOLTEK

SOLTEK 85ERV Manuel utilisateur

SOLTEK

SOLTEK SL-85SID Manuel utilisateur

SOLTEK

SOLTEK SL-B8D-F Manuel utilisateur

SOLTEK

SOLTEK SL-65LIV Manuel utilisateur

SOLTEK

SOLTEK SL-54U5 Manuel d'utilisation et d'entretien

SOLTEK

SOLTEK SL-55D5 Manuel d'utilisation et d'entretien

SOLTEK

SOLTEK B7A-F Manuel utilisateur

SOLTEK

SOLTEK 85MR3 Manuel utilisateur

Manuels Carte mère populaires d'autres marques

DFI

DFI SD170 Manuel utilisateur

ASROCK

ASROCK ROMED8-2T Manuel utilisateur

Asus

Asus P2L97A Manuel utilisateur

Winmate

Winmate IC70 Manuel utilisateur

Asus

Asus MES-B Manuel utilisateur

Grantech

Grantech SYS8F377VGGA-3OMN Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuel utilisateur

Gigabyte

Gigabyte GA-9IVDT Manuel utilisateur

Texas Instruments

Texas Instruments ADS8372EVM Manuel utilisateur

Commell

Commell MS-C73 Manuel utilisateur

IBT Technologies

IBT Technologies MB860 Manuel utilisateur

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur

Biostar

Biostar M7VIT Bravo Instructions d'utilisation et d'installation

Intel

Intel D33217CK Manuel utilisateur

Asus

Asus F1A55-M LX PLUS R2.0 Manuel utilisateur

EPC

EPC EPC9147C Manuel utilisateur

Asus

Asus EX-B760M-V5 D4 Manuel utilisateur

EPOX

EPOX MU-8KHA0010 Manuel utilisateur
