Item Checkup
4-6.7.2 User Password........................................................................... 83
4-6.7.3 Change Supervisor Password .................................................. 84
4-6.7.4 Change User Password ............................................................ 85
4-6.7.5 Clear User Password ................................................................ 85
4-6.7.6 Boot Sector Virus Protection ................................................... 86
4-6.8 Save Changes and Exit ............................................................... 86
4-6.9 Discard Changes ( and Exit )..................................................... 87
4-6.10 Load Optimal Defaults ............................................................. 87
4-6.11 Discard Changes ........................................................................ 87
APPENDICES.......................................................... 88
Appendix-1 Identify Mainboard Model Number ................... 89
Appendix-2 Technical Terms ...................................................... 90
• Mainboard
• Multi-lingual Quick Installation Guide
• User Manual (Mainboard)
• Support CD
• Bundled Bonus Pack CD
• Bundled Bonus Pack Manual
• Cable :
ATA66/100 IDE Cable
2 x Serial ATA Cable
FDD Cable
USB Cable (Optional)
8
86SP2 / 86SP2-L
Topics included in this chapter are:
1-1 Mainboard Layout
1-2 Mainboard Specifications**
1-3 Mainboard Specification Table
1-4 Chipset Diagram
Introduction
Chapter 1 Specification
This series of mainboards features an integration of the powerful pro-
cessor Intel Pentium 4 and the single-chip North Bridge Intel
SPRINGDALE-P. The Intel P4 processor is a rapid execution engine
providing 800/533/400MHz system bus, while North Bridge Intel
SPRINGDALE-P is a high performance integrated chipset providing Dual
Channel DDR 333/266 SDRAM memory interface, Hub interface as well
as AGP interface.
Integrated with SPRINGDALE-P, South Bridge Intel ICH5 supports
the LPC I/O, upstream Hub interface, PCI interface, IDE interface, Serial
ATA interface, USB 2.0 interface, AC’97 2.2 (6-channel) Audio interface
and the interrupt control. This chapter is to introduce to users every
advanced function of this high performance integration.
** If any difference is found between the mainboard description
and the Mainboard you are using, please look up the Errata/
Update Slip enclosed inside for the correction or updated
information, or else contact the mainboard Dealer or visit our
Web Site for the latest manual update.
9
Chapter 1 Specification
BIOS
mPGA478B
1
USB3
1
USB2
1
Fan1
+12V Power
AGP 8X/4X
1
IDE1IDE2
1
SPRINGDALE
Intel
ICH5
Intel
Dual Channel DDR 333/266MHz
ATA2
DIMM1
DIMM2
PCI 1
PCI 2
PCI 3
PCI 4
PCI 5
LPT1
COM1
COM2
PS/2 K/B (underside)
PS/2 Mouse
USB1 (underside)
USB0
FD1
1
Main
RTL
Winbond
W83627HF
Fan3
1
JBAT1
1
JKB1
RT2
CD-IN1
1
1
JFSB2
Intel 82865
P
(on top)
650
8101L
JAUD1
Battery
Li
ATA1
Power
HDD IR PWR
1
20
SPK RST
+
-
+
-
PWLED
NJ1
LED
ALC
Fan4
JFSB1
RJ45
(on top)
(middle)
Linein
(ontop)
Mic
(underside)
LineOut
(middle)
USB3 (underside)
USB2 (middle)
Fan2
1
LJP1
1-1 Mainboard Layout
for 86SP2-L only
RJ45
LAN Controller
LJP1 }
10
86SP2 / 86SP2-L
1-2.4 Advanced System Power Management
• ACPI 1.0B compliant (Advanced Configuration and Power Interface),
including ACPI suspend mode support (See ACPI Configuration of
Advanced BIOS Features in BIOS Setup)
• APM V1.2 compliant (Legacy Power Management)
• Keyboard / Mouse Power On/Wake Up(See ACPI Configuration of
Advanced BIOS features in BIOS Setup)
• Supporting Wake-on-LAN
• Real Time Clock (RTC) with date alarm, month alarm, and century
field
1-2 Mainboard Specifications
1-2.1 CPU Socket
CPU Socket 478B on board, supporting Intel®Pentium 4 processors
(including Intel Hyper-Threading CPUs) in 478-pin package for :
-- 800/533/400MHz System Bus;
-- Hyper-pipelined technology;
-- Advanced dynamic execution;
-- Advanced transfer cache;
1-2.2 System Chipsets
North Bridge Intel SPRINGDALE-PE:
• Supporting 533/400MHz Front Side Bus officially
• Supporting 800MHz Front Side Bus by jumper setting
• A high performance integrated chipset providing processor interface
(including Hyper-Threading Technology), Dual channel DDR 333/266
SDRAM memory interface, Hub interface, AGP interface.
• Showing Hyper-Threading Logo when booting with a Hyper-thread-
ing CPU.
South Bridge Intel ICH5:
• Supporting the LPC I/O, upstream Hub interface, PCI interface, IDE
interface, Serial ATA interface, USB 2.0 interface, AC’97 2.2 (6-
channel) Audio interface and the interrupt control.
1-2.3 Memory
2 DDR DIMM 184-pin slots on board :
• Supporting unregistered, non-ECC Dual-channel DDR 333/266
SDRAM up to 2GBs
• DIMMs to be populated in identical pairs for Dual-channel operation
• SPD (Serial Presence Detect) Scheme for DIMM Detection supported
11
Chapter 1 Specification
1-2.7 Multi-I/O Functions :
• Serial ATA Controller integrated in ICH5, supporting:
-- 2x Serial ATA connectors supporting up to 150MByte/s transfer rate
• PCI EIDE Controller, supporting:
-- 2x UATA100/66/33 IDE connectors supporting up to 4 IDE devices
• Dedicated IR Functions:
-- Third serial port dedicated to IR function either through the two
complete serial ports or the third dedicated port Infrared-IrDA (HPSIR)
and ASK (Amplitude Shift Keyed) IR
• Multi-mode Parallel Data Transfer:
-- Standard mode, high speed mode ECP and enhanced mode EPP
• Floppy Disk Connector:
-- One FDD connector supporting 2 floppy drives with drive swap support
• Universal Serial Bus Transfer Mode:
-- USB V2.0 compliant; 480Mb/s USB Bus, supporting Windows 2000 or
later operating system (no support for Windows 9X/ME)
-- 4 built-in USB connectors and 2 USB Headers which require 2 additional
USB cables to provide 4 more optional USB ports
• PS/2 Keyboard and PS/2 Mouse
• UARTs (Universal Asynchronous Receiver / Transmitter):
-- Two serial ports (COM1 & COM2) on board
1-2.5 Accelerated Graphics Port (AGP) Interface
AGP Controller embedded on board, supporting:
• 1.5V (4x/8x) power mode only
• 8x 66MHz AD and SBA signalling, AGP pipelined split-transection
longburst transfers up to 2GB/sec
• AGP 8X/4X supported, AGP V3.0 compliant
1-2.6 AMI BIOS
Flash Memory for easy upgrade, supporting BIOS Writing Protection,
Year 2000 compliant, and supporting various hardware configuration
during booting system (See Chapter 4 BIOS Setup):
• Standard BIOS Features(Times, Date, System Information etc.)
• Advanced BIOS Features (CPU,IDE, Floppy, SuperIO, Hardware
Health, ACPI, USB, and Frequency/Voltage Control)
• Advanced Chipset Features (NorthBridge, SouthBridge Configuration)
• PCI/PNP Resource Management (IRQ Settings, Latency Timers etc.)
• Boot Configuration Setup (Boot Settings, Boot Device Priority etc.)
• BIOS Security Features (Supervisor Password, User Password)
12
86SP2 / 86SP2-L
1-2.11 AC’97 Audio Codec on board
AC’97 Audio Codec 2.2 compliant on board
• Supporting 6-channel display of PCM audio output
• 6 channel audio consists of Front Left, Front Right, Back Left, Back
Right, Center and Subwoofer for complete surround sound effect
• AC’97 Audio Codec Driver enclosed in Support CD for user’s
installation.
1-2.9 LAN on board (for 86SP2-L only)
PCI local bus single-chip Fast Ethernet Controller RTL8101L on board:
• Supporting 10/100Mb data transfer
• Supporting Wake On LAN function through the on-board RJ45 LAN
Connector
• LAN Driver enclosed in Support CD for user’s installation.
1-2.10 Hardware Monitor on board
• Hardware Monitor supported by W83627HF, providing monitoring and
alarm for flexible desktop management of hardware voltage, tempera-
tures and fan speeds.
• Utility Software Soltek Hardware Monitor for displaying system status
is enclosed in Support CD for user’s installation.
1-2.12 Form Factor
• ATX Form Factor, ATX Power Supply, version 2.03 compliant, sup-
ported by one Main Power Connector, one +12V Power Connector.
• Mainboard size: 305mm x 210mm
1-2.8 Expansion Slots
• 5 PCI Bus Master slots
• 1 AGP slot
• 2 DDR SDRAM DIMM slots
13
Chapter 1 Specification
1-3 Mainboard Specification Table
CPU
North Bridge
South Bridge
BIOS
Memory
I/O Chip
AGP interface
Audio
IDE Interface
SATA Interface
PCI Slots
I/O Connectors
Networking
Other common
features
Socket 478B for P4 CPU( HT CPU included)
Intel SPRINGDALE-P,supporting 533/400MHz
FSB
Intel ICH5
AMI BIOS
Supporting Dual-channel DDR 333/266 SDRAM,
up to 2GB in 2 DIMM slots
W83627HF, with Hardware Monitor
AGP8X/4X Mode only; 1 AGP Slot on board
AC’97 Audio 2.2 compliant, 6 channel audio
2 UATA 66/100 IDE ports
2 Serial ATA connectors
5 PCI Master slots on board
8 USB V2.0, 1 FDD port, 2 COM ports, 1 LPT,
1 IrDA, 1 PS/2 K/B, 1 PS/2 Mouse
LAN Controller RTL8101L and Connector RJ45
(for 86SP2-L only)
PS/2 Keyboard/Mouse Power On / Wake Up
ATX 2.03 Power Supply
ATX Form Factor
86SP2/86SP2-L Specifications and Features
86SP2 86SP2-L
No Yes
LAN Controller
on board
Optional
Features
Models
Ce manuel convient aux modèles suivants
2
Table des matières
Autres manuels SOLTEK Carte mère
SOLTEK
SOLTEK 86SP3 Manuel utilisateur
SOLTEK
SOLTEK 85MR3-R Manuel utilisateur
SOLTEK
SOLTEK 75FRN Series Manuel utilisateur
SOLTEK
SOLTEK SL-85MIR3 Manuel utilisateur
SOLTEK
SOLTEK SL-75KIV Manuel utilisateur
SOLTEK
SOLTEK 75DRV Manuel utilisateur
SOLTEK
SOLTEK SL-75DRV-X Manuel utilisateur
SOLTEK
SOLTEK SL-63AV Manuel d'utilisation et d'entretien
SOLTEK
SOLTEK SL-75KAV Manuel utilisateur
SOLTEK
SOLTEK SL-65MIE Manuel utilisateur
SOLTEK
SOLTEK SL-65F+ Manuel utilisateur
SOLTEK
SOLTEK SL-75KAV Manuel utilisateur
SOLTEK
SOLTEK KT400 Manuel utilisateur
SOLTEK
SOLTEK SL-67EZ Manuel d'utilisation et d'entretien
SOLTEK
SOLTEK KT400-R Manuel utilisateur
SOLTEK
SOLTEK SL-85DIV Manuel utilisateur
SOLTEK
SOLTEK SL-85DR-C Manuel utilisateur
SOLTEK
SOLTEK NF4-754RL Manuel utilisateur
SOLTEK
SOLTEK SL-85ERV4-R Manuel utilisateur
SOLTEK
SOLTEK SL-54A2 Manuel utilisateur
Manuels Carte mère populaires d'autres marques
Telit Wireless Solutions
Telit Wireless Solutions SL869-3DR Manuel utilisateur
Gigabyte
Gigabyte GA-9IVDT Manuel utilisateur
Texas Instruments
Texas Instruments ADS8372EVM Manuel utilisateur
Commell
Commell MS-C73 Manuel utilisateur
IBT Technologies
IBT Technologies MB860 Manuel utilisateur
Nvidia
Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur
