Product Overview

SMCFS5

EZ Switch 10/100

5-port Fast Ethernet Desktop Switch

The EZ Switch™ 10/100 (SMCFS5) is a Fast Ethernet desktop

switch that is easy to install and improves network performance

by offering speeds up to 200Mbps per port. Designed for easy

integration with any home or small office network, the SMCFS5

contains added features like Store-and-Forward Switching and

Flow Control to ensure data delivery and network integrity. The

Green Saving feature automatically powers down ports that are

not in use to help saving on energy costs and to make the

network more eco-friendly.

Key Features and Benefits

Store-and-forward Technology

Flow Control and Store-and-Forward Switching with

wire-speed filtering and forwarding rates

ensure data delivery and network integrity.

Easy-to-read LED Indicators

At-a-glance LED indicators per port simplify network

troubleshooting.

Auto MDI/MDI-X on each port to simplify

integration into a network

The switch automatically detects the cable and port

configuration of the opposite connection. No cross-

over cables required, pure plug-and-play.

Green Saving

Green Saving technology allows home and

business users to save on energy costs, conserve

energy and protect our environment.

Features

PHYSICAL PORTS

5 x 10/100Mbps Nway ports (RJ-45)

DC power socket

COMPATIBILITY

10Base-T (IEEE802.3)

100Base-TX (IEEE802.3u)

Full Duplex Flow Control (IEEE802.3x)

SWITCHING DATABASE

1K MAC address entries

BUFFER MEMORY

512Kb per device

PERFORMANCE

Aggregated Bandwidth: 1.0Gbps

Throughput: 0.7Mpps

FEATURES

Supports NWay protocol for speed (10/100Mbps) and

duplex mode (Half/Full) auto-detection

Wire-speed packet filtering and forwarding rate

Store-and-forward architecture filters fragment & CRC

error packets

Green Saving technology to reduce power consumption

LEDS

System: Power

Port: Link/Activity

POWER REQUIREMENTS

Input : 100~240V, 50/60Hz 0.2A

Output : 5V/600mA

WEIGHT & DIMENSIONS

133g

150 x 80 x 30 mm

EMISSIONS

FCC Class B

CE

VCCI Class B

TEMPERATURE

Operating: 0~400C (32~980F)

WARRANTY

Please check

Contact

North America

20 Mason, Irvine,

CA 92618, U.S.A

1-800-SMC-4YOU

24/7 Technical Support

Europe/Africa

Fructuos Gelabert 6-8

08970 Sant Joan Despi

Barcelona, Spain

Check www.smc.com for your local country contact information

Networks. Other trademarks or registered trademarks are the

property of their respective owners. Information is subject to

www.smc.com for the warranty terms in your

country.

Optional Accessories
