SMC Networks 6709L2 Manuel utilisateur

TigerSwitch 10/100

Standalone 8+2 10/100 Port

Managed Switch

◆ 8 10/100BASE-TX ports, 1 1000BASE-T port

◆ Optional 100BASE-FX or 1000BASE-X modules

◆ Switch Fabric Bandwidth of 3.8 Gbps

◆ Non-blocking switching architecture

◆ Up to four port trunks (static or dynamic)

◆ Spanning Tree Protocol

◆ QoS support for two-level priority

◆ Security filtering based on MAC

◆ Full support for VLANs with GVRP

◆ IGMP multicast filtering and snooping

◆ Manageable via console, Telnet, SNMP/RMON

Installation Guide

SMC6709L2

38 Tesla

Irvine, CA 92618

Phone: (949) 679-8000

TigerSwitch 10/100

Installation Guide

From SMC’s Tiger line of feature-rich workgroup LAN solutions

March 2003

150200003000B
