SMC Networks EZ Connect SMC2670W Manuel utilisateur

0101001100100100010010110010101010011010010

SMC2670W

Model Number::

Features

•Plug-and-Play, no drivers needed

•IEEE 802.11b Compliant

•Up to 11 Mbps wireless LAN

•Up to 825 feet operating range

•2.4GHz frequency band, Direct

Sequence Spread Spectrum (DSSS)

•64-bit or 128-bit WEP encryption

•Weband Windows-based config-

uration and management for

advanced configuration

Benefits

•Instant access for any Ethernet network device

to obtain shared information without the need

to plug in

•IEEE 802.11b compliant ensure seamless

interoperability among multiple vendors

•11 Mbps performance meets most foreseeable

networking needs

•High security with 64/128-bit WEP encryption to

protect your information and to ensure secure

data transmissions

•Simple and easy installation by using the con-

venient web or windows-based configuration utility

•Wireless LANs are tremendously convenient, help

to enhance productivity, and provide a real cost

benefit over traditional wired networks (no instal-

lation or maintenance expenses)

Compatibility

•IEEE 802.3

•IEEE 802.11b

•Windows

98/ME/NT/2000/XP

EZ ConnectTM

2.4GHz 11 Mbps Wireless Ethernet Adapter

Overview

wireless

The EZ Connect™ 2.4GHz 11 Mbps Wireless Ethernet

Adapter (SMC2670W) converts any Ethernet device in

your home and/or office to become wireless device in

minutes. The new product transforms any Ethernet-

equipped device, such as a gaming console, printer,

set-top box, point-of-sale terminal, desktop or laptop

computer into wireless network device instantaneously.

Using the standard IEEE 802.11b technology, this

Wireless Ethernet Adapter supports transfer speeds up

to 11 Mbps with a maximum operating range up to

825 feet. It is the ultimate convenient way to expand

your wireless local area network.

The new SMC2670W Wireless Ethernet Adapter is easy

and simple to install. It is Plug-and-PlayTM and does not

require installing any drivers. Simply plug it into your

Ethernet device and your Ethernet device will become

wireless! This means now you can have the freedom of

placing your printer anywhere in the home or office or

play games with multiple players over a wireless

connection without the constraint of messy cabling.

To ensure secure transmission across wireless network,

users can use the Web-based interface or Windows

Utility program to configure the 64-bit or 128-bit WEP

encryption. In addition, the EZ Connect Wireless

Ethernet Adapter offers an auto-fallback feature that

provides connectivity at 11, 5.5, 2, and 11 Mbps under

noisy environments and enables a larger wireless

operating range. Combine these features and you

have a flexible and high performance solution for any

of your wireless network needs.

38 Tesla

Irvine, CA 92618

1-800-SMC-4YOU

www.smc.com

3-click

SPECIFICATIONS

0101001100100100010010110010101010011010010

Product Description

EZ Connect 2.4GHz 11 Mbps Wireless Ethernet Adapter

SMC2670W

wireless

Standards

•IEEE802.11b

•IEEE802.3 (10BaseTX)

Management

•Windows-Based

•Web-Based

Security

•64-bit/128-bit WEP encryption

LAN

•1*10BaseT RJ-45 LAN port

LED

•Power

•Wireless

•Ethernet

Power Supply

•DC5V

Operating Frequency

•America/FCC: 2.412~2.462 GHz (11 channels)

•Europe CE/ETSI: 2.412~2.472 GHz (13 channels)

•Japan: 2.412~2.484 GHz (14 channels)

•France: 2.457~2.472 GHz (4 channels)

•Spain: 2.457~2.462 GHz (2 channels)

RF Power Output

•20 dBm (typical)

Data Rate

•11Mbps / 5.5 Mbps / 2Mbps /

1 Mbps Auto Fallback

Operating Range

•Up to 825 ft

Sensitivity

•-75 dBm @11Mbps, PER<8

Power Consumption

•Transmission: 800mA

•Receiving: 350mA

Network Configuration

•Infrastructure

Operating Temperature

•-10~65ºC

Storage Temperature

•-30~70ºC

Humidity (non-condensing)

•5~95%

Antenna

•ExternalDipole Antenna

Dimension

•117mm*62mm*22mm

Weight

•<75g

Warranty

•Limited Lifetime

EZ ConnectTM

2.4GHz 11 Mbps Wireless Ethernet Adapter

SMC2670W
