SMC Networks WUSBS-N2 FICHE Manuel utilisateur

OVERVIEW

The EZ Connect™ N Wireless USB2.0 Adapter (SMCWUSBS-N2) enables Wireless-N connectivity to your

desktop or notebook computer and provides improved throughput and range than existing 802.11g technolo-

gy. Upgrading to Wireless-N is an excellent solution for browsing the Internet and sharing ﬁles such as video,

music and photos. The SMCWUSBS-N2 is Wi-Fi CERTIFIED™ for full compliance with the 802.11n standard, as

well as the popular Wireless-G (802.11g) and Wireless-B (802.11b) standards. This next generation standard

utilizes advanced MIMO (Multiple-In, Multiple-Out) technology to deliver incredible speed and range. With

security being a key consideration, the latest WPA and WPA2 wireless encryption standards are supported,

which prevent unauthorized access to wireless networks and ensure data is secure. Wireless security can

also be set up easily using Wi-Fi Protected Setup™ (WPS) that enables push button or PIN conﬁguration.

Finally the SMCWUSBS-N2 includes an easy installation wizard which guides you step-by-step through the

install process. Once installed the WLAN utility allows you to scan for available wireless networks and man-

age multiple network proﬁles so connecting becomes instantaneous.

www.smc.com

SMCWUSBS-N2

Wireless N USB2.0 Adapter

10G FIBER

1G FIBER

10G COPPER

1G COPPER

10/100

PoE

PHONE CABLES

WIRELESS

LEGEND

10G FIBER

1G FIBER

10G COPPER

1G COPPER

10/100

PoE

WIRELESS

LEGEND











































APPLICATION DIAGRAM

POWER TO CONNECT

KEY FEATURES

New Wireless-N (802.11n ) technology Wi-Fi Protected Set-up™ (WPS)

Delivers improved speed and range than existing 802.11g technol-

ogy while maintaining full backwards compatibility with older Wire-

less-G (802.11g) and Wireless-B (802.11b) standard products.

Makes wireless security setup easy with push button or PIN con-

ﬁguration.

WPA/WPA2 Encryption Installation Wizard

Prevents unauthorized access to your wireless network and in-

sures your data is secure.

Easy software installation with step-by-step guidance.

SWITCHES VDSL WIRELESS VOIP STORAGE BROADBAND ADAPTERS

PHYSICAL

• Link status LED

WIRELESS OPERATING MODES

• Ad-hoc mode

• Infrastructure mode

EASE OF USE

• EZ Installation Wizard

• Wi-Fi Protected Setup™ - PBC and PIN

• Site survey utility

• Proﬁle manager

SECURITY FEATURES

• WEP 64-/128-Bit Encryption

• WPA-/WPA2-PSK (Pre Shared Key)

• WPA/WPA2 Enterprise mode (802.1x)

QUALITY-OF-SERVICE (QoS)

• WMM (Wi-Fi Multimedia)

STANDARDS

• IEEE802.11b, IEEE802.11g, IEEE802.11n

OPERATING FREQUENCY

• USA - FCC: 2412~2462MHz (Ch1~Ch11)

• Canada – IC: 2412~2462MHz (Ch1~Ch11)

• Europe - ETSI: 2412~2472MHz (Ch1~Ch13)

TYPICAL RF OUTPUT POWER

• 11n Mode: 13.5dBm

• 11g Mode: 17dBm

• 11b Mode : 20dBm

TEMPERATURE

• Operating: 0 degrees C to 40 degrees C

• Storage: -10 degrees C to 70 degrees C

HUMIDITY

• Storage: 5% to 90% Non-condensing

• Operating: 0% to 70% Non-condensing

DIMENSIONS

• 92 x 27.08 x 12.30mm

• 3.62 x 1.07 x 0.48 in

WEIGHT

• 0.02Kg

• 0.044Ibs

CERTIFICATIONS

• FCC

• CE

SYSTEM REQUIREMENTS

• 2.4 GHz 802.11n wireless network or 2.4 GHz 802.11b/g wireless

network

• Microsoft Windows 2000 , XP or Vista

• A Notebook or Desktop computer with:

- 300MHz CPU or above

- Available USB2.0 port

- 20MB of available hard disk space

- CD-ROM drive

• We recommend using this product with SMC’s Barricade™ N Routers

WARRANTY

• SMC Limited Lifetime

* The Wi-Fi CERTIFIED Logo is a certiﬁcation mark of the Wi-Fi Alliance

* The Wi-Fi Protected Setup Mark is a mark of the Wi-Fi Alliance

CONTACT

North America

20 Mason

Irvine, CA 92618

1-800-SMC-4YOU

24/7 Technical Support

Europe/Africa

Fructuos Gelabert 6-8

08970 Sant Joan Despí

Barcelona, Spain

Check www.smc.com for your local country contact information

of SMC Networks in the United States or other countries. Other trademarks

or registered trademarks are the property of their respective owners. Infor-

10/2009

www.smc.com

v.1

TECH SPECS - SMCWUSBS-N2
