SMC Networks 2870W - annexe 1 Manuel utilisateur

38 Tesla

Irvine, CA 92618

Phone: (949) 679-8000

EZ Connect™ g 2.4GHz 54 Mbps

Wireless Ethernet Adapter

User Guide

October 2003

Revision Number: 1.0

Information furnished by SMC Networks, Inc. (SMC) is believed to be accurate and reliable.

However, no responsibility is assumed by SMC for its use, nor for any infringements of patents

or other rights of third parties which may result from its use. No license is granted by

implication or otherwise under any patent or patent rights of SMC. SMC reserves the right to

change specifications at any time without notice.

SMC Networks, Inc.

38 Tesla

Irvine, CA 92618

Trademarks:

SMC® is a registered trademark; and EZ-Stream, EZ Connect, Barricade and EZ Hub are

trademarks of SMC Networks, Inc. Other product and company names are trademarks or

registered trademarks of their respective holders.

COMPLIANCES

FCC - Class B

The Federal Communication Commission Radio Frequency Interference

Statement includes the following paragraph:

The equipment has been tested and found to comply with the limits for a Class B

Digital Device, pursuant to part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instruction, may

cause harmful interference to radio communication. However, there is no

guarantee that interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television reception, which

can be determined by turning the equipment off and on, the user is encouraged to

try to overcome the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

The equipment is for home or office use.

FCC ID INFORMATION

The product contains an approved FCC module ID: “QDWWN360G”.

CAUTION STATEMENT:

FCC Radiation Exposure Statement

FCC RF Radiation Exposure Statement: This equipment complies with FCC RF

radiation exposure limits set forth for an uncontrolled environment. This

equipment should be installed and operated with a minimum distance of 20cm

between the antenna and your body and must not be co-located or operating in

conjunction with any other antenna or transmitter.

Caution: Changes or modifications not expressly approved by the party

responsible for compliance could void the user's authority to operate the

equipment.

Industry Canada - Class B

This digital apparatus does not exceed the Class B limits for radio noise emissions

from digital apparatus as set out in the interference-causing equipment standard

entitled "Digital Apparatus", ICES-003 of Industry Canada.

Cet appareil numerique respecte les limites de bruits radioelectriques applicables

aux appareils numeriques de Classe B prescrites dans la norme sur le material

brouilleur: "Appareils Numeriques," NMB-003 edictee par l'Industrie.

COMPLIANCES

Low Power License-Exempt Radio communication Devices

(RSS-210)

Warning Note:

operation is subject to the following two conditions: (1) this device

may not cause interference, and (2) this device must accept any

interference, including interference that may cause undesired

operation of the device.

2. Operation in 2.4GHz band: To prevent radio interference to the licensed service, this

device is intended to be operated indoors and away from windows to provide

maximum shielding. Equipment (or its transmit antenna) that is installed outdoors

is subject to licensing.

Exposure of Humans to RF Fields for Mobile Radios Equip-

ment (RSS-102)

1. Mobile radios that are not body worn (e.g. mounted on vehicles or placed on desks,

shelves, etc.) and operated such that humans are normally separated from their

radiating element by at least 20cm are not subject to SAR tests, but must have an

RF evaluation

by the certification applicant, based on the calculated or measured field strength

value. SAR evaluation can be used if so desired in lieu of a RF evaluation of field

strength limits.

2. Exposures produced by such radios shall not exceed the exposure limits specified

in Health Canada's Safety Code 6. Health Canada’ s address is:

775 Brookfield Road, Ottawa, Ontario

Canada K1A 1C1; Tel: (613) 954 -6699 / Fax:(613) 941-1734 ;

e-mail: [email protected].

EC Conformance Declaration - Class B

SMC contact for these products in Europe is:

SMC Networks Europe,

Edificio Conata II,

Calle Fructuós Gelabert 6-8, 2o, 4a,

08970 - Sant Joan Despí,

Barcelona, Spain.

This RF product complies with all the requirements of the Directive 1999/5/EC of

the European parliament and the council of 9 March 1999 on radio equipment and

telecommunication terminal Equipment and the mutual recognition of their

conformity(R&TTE).

The R&TTE Directive repeals and replaces in the directive 98/13/EEC. As of April

8, 2000.

OMPLIANCES

iii

Important Safety Notices

• Unplug this product from the AC power before cleaning. Do not use liquid clean-

ers or aerosol cleaners. Use a dry cloth for cleaning.

• Route the power supply cords so that they are not likely to be walked on or

pinched by items placed upon or against them. Pay particular attention to cords

at plugs, convenience receptacles, and the point where they exit from the prod-

uct.

• Situate the product away from heat sources such as radiators, heat registers,

stoves, and other products that produce heat.

• To prevent fire or shock hazard, do not expose this unit to rain or moisture. Do

not allow water or any foreign objects to enter the interior. This may cause a fire

or electric shock. In the event that water or other foreign objects get into the

product, immediately unplug the AC adapter from the electrical outlet and con-

tact Customer Service for inspection and/or repair/replacement options.

• Do not take apart the equipment. This may cause fire, electric shock or other in-

juries.

• Do not overload wall outlets and extension cords as this can result in a fire or

electric shock.

• This product is for use with the AC adapter that comes with it. Use with anyother

ACpoweris stronglydiscouragedasitmay causefire, electric shock,or damage

to the equipment.

ABLE

ONTENTS

2.4GHz 54 Mbps Wireless Ethernet Bridge. . . . .1

System Requirements.................................................1

Equipment Checklist....................................................1

Hardware Description. . . . . . . . . . . . . . . . . . . . . . 3

Applications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Understanding Wireless Security . . . . . . . . . . . .8

Hardware Installation . . . . . . . . . . . . . . . . . . . . .10

Using the EZ Installation Wizard . . . . . . . . . . . . 11

Configuring Your Computer. . . . . . . . . . . . . . . . 20

Using IPCONFIG.......................................................20

Configuring Your IP Address.....................................21

Advanced Web Configuration (Wireless Bridge

mode) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

Browser Configuration...............................................29

Internet Explorer in Windows ....................................29

Internet Explorer in Macintosh...................................30

Advanced Web Configuration (Access Point

mode) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38

Browser Configuration...............................................38

Advanced Telnet Configuration. . . . . . . . . . . . .51

Maximum Distance Table . . . . . . . . . . . . . . . . . 53

Important Notice ....................................................... 53

Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . 55

Technical Specification. . . . . . . . . . . . . . . . . . . 57

Terminology . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
