SMART Board E70 Manuel d'utilisation

SMARTBoard® E70

SETUP AND MAINTENANCE GUIDE

FOR MODEL SPNL-4070

smarttech.com/kb/170534

Product registration

If you register your SMART product, we’ll notify you of new features and software upgrades.

Keep the following information available in case you need to contact SMARTSupport.

Serial number:

Date of purchase:

Licenses

The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI logo are trademarks or registered trademarks of HDMI Licensing LLC in the United

States and other countries

FCC warning

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses and

can radiate radio frequency energy and, if not installed and used in accordance with the manufacturer’s instructions, may cause harmful interference to radio

communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the

interference at his own expense.

Trademark notice

SMARTBoard, SMARTNotebook, smarttech, the SMART logo and all SMART taglines are trademarks or registered trademarks of SMARTTechnologiesULC in

the U.S. and/or other countries. Windows is either a registered trademark or a trademark of Microsoft Corporation in the U.S. and/or other countries. All other

third-party product and company names may be trademarks of their respective owners.

or translated into any language in any form by any means without the prior written consent of SMARTTechnologiesULC. Information in this manual is subject to

change without notice and does not represent a commitment on the part of SMART.

This product and/or use thereof covered by one or more of the following U.S. patents.

www.smarttech.com/patents

10/2016

i smarttech.com/kb/170534

Important information

WARNING

lFailure to follow the installation instructions shipped with theSMART product could result in

personal injury and product damage which may not be covered by the warranty.

lDo not open or disassemble the SMART product. You risk electrical shock from the high

voltage inside the casing. Opening the casing also voids the warranty.

lDo not stand (or allow children to stand) on a chair to touch the surface of the SMART

product. Rather, mount the product at the appropriate height.

lTo reduce the risk of fire or electric shock, do not expose the SMART product to rain or

moisture.

lIf the SMART product requires replacement parts, make sure the service technician uses

replacement parts specified by SMARTTechnologies or parts with the same characteristics

as the original.

lEnsure that any cables that cross the floor to the SMART product are properly bundled and

marked to avoid a trip hazard.

lUseonly extension cords and outlets that can fully accommodate this product’s polarized

plug.

lUse the power cable provided with this product. If a power cable is not supplied with this

product, please contact your supplier. Use only power cables that match the AC voltage of

the power outlet and that comply with your country’s safety standards.

lIf the glass is broken, do not touch the liquid crystal. To prevent injury, handle glass

fragments with care when disposing of them.

lUse only VESA®-approved mounting hardware.

lDo not insert objects inside the cabinet ventilation holes, because they could touch

dangerous voltage points and cause electric shock, fire or product damage which may not

be covered by the warranty.

lDo not place any heavy objects on the power cable. Damage to the cable could cause

shock, fire or product damage which may not be covered by the warranty.

IMPORTANT INFORMATION

ii smarttech.com/kb/170534

lDisconnect all the interactive flat panel's power cables from the wall outlet and seek

assistance from qualified service personnel if any of the following occurs:

oThe power cable or plug is damaged

oLiquid is spilled into the interactive flat panel

oObjects fall into the interactive flat panel

oThe interactive flat panel is dropped

oStructural damage, such as cracking, occurs

oThe interactive flat panel behaves unexpectedly when you follow operating

instructions

iii smarttech.com/kb/170534

Contents

Important information i

Chapter 1: About your interactive flat panel 1

Feature highlights 1

Included accessories 2

Chapter 2: Mounting your interactive flat panel 3

Choosing a mounting location 4

Choosing a mounting height 4

Cable management 4

Connecting your interactive flat panel 5

Configuring your computer’s screen resolution 6

Chapter 3: Using your interactive flat panel 9

Using the remote control 9

Using the control panel 12

On-screen display menu 13

Multi Media mode 14

Cleaning the interactive flat panel 16

Chapter 4: Troubleshooting your interactive flat panel 19

Locating the serial number 19

Resolving common touch control and resolution issues with Windows and Mac operating

systems 20

Resolving image issues 22

Appendix A: Configuring and calibrating your SMARTBoard E70 interactive flat panel with

Windows 23

Configuring your touch and display settings for the SMARTBoard E70 23

Appendix B: Calibrating your interactive flat panel with MacOSX 31

Calibrating your SMARTBoard E70 31

Appendix C: Hardware environmental compliance 33

Waste Electrical and Electronic Equipment and Battery regulations (WEEE and

BatteryDirectives) 33

Batteries 33

More information 33

Index 35

Chapter 1

1 smarttech.com/kb/170534

Chapter 1: About your interactive flat panel

Feature highlights 1

Included accessories 2

Pen and pen tray 2

Remote control 2

Included cables 2

This chapter describes the features of your SMARTBoard® E70 interactive flat panel and provides

information about product parts and accessories.

Feature highlights

Designed specifically for classrooms, the

SMARTBoard E70 interactive flat panel combines a

premium touch experience with the power of

SMARTNotebook® collaborative learning software

on a 70" display.

The high-definition, shadow-free 70" (177.8 cm) LED

display features low friction coated glass that

enables fingers to glide smoothly over the surface,

facilitating a natural touch experience. The interactive

flat panel also virtually eliminates glare and provides

an optimal view from any angle in the classroom,

delivering an unparalleled viewing and writing

experience to offer the best value for classrooms.

The multitouch interactive flat panel features freestyle multi-user interaction anywhere on the

display with Windows®7 or Windows8 operating systems, enabling students to collaborate

without limitations.

CHAPTER 1

ABOUT YOUR INTERACTIVE FLAT PANEL

2 smarttech.com/kb/170534

Included accessories

The following accessories are included with your interactive flat panel:

Pen and pen tray

Two pens are included with your interactive flat panel.

Remote control

The remote control enables you to access the on-screen menus and to change the display and

input settings.

Included cables

VGA - RGB video input

Power cable - AU/NZ, NA, UK and EU

USB cable - touch interface

Chapter 2

3 smarttech.com/kb/170534

Chapter 2: Mounting your interactive flat panel

Choosing a mounting location 4

Choosing a mounting height 4

Cable management 4

Connecting your interactive flat panel 5

Configuring your computer’s screen resolution 6

Recommended computer screen resolution 6

Windows 7 and Windows 8 operating systems 7

MacOSX operating system software 8

WARNING

The weight of the interactive flat panel is 169.8 lb. (77 kg), refer to your local building code to

ensure the wall and the mount being used can support this installation. Use appropriating

hardware in accordance to building code and always use 3 or more people to lift and install E70

interactive flat panel.

Model Weight (lb.) Weight (kg)

SPNL-4055 116 lb 13 oz 53 kg

SPNL-4065 153 lb 69.4 kg

Model Mounting plate

SPNL-4055 600 mm × 400 mm

SPNL-4065 600 mm × 400 mm

Model Screw length Fasten force

SPNL-

4055

25 mm where the total wall mount bracket and washer

thickness is less than 7 mm.

97.36–177.01 in-lb.

(11–20 N·m)

SPNL-

4065

30 mm where the total wall mount bracket and washer

thickness is less than 7 mm.

97.36–177.01 in-lb.

(11–20 N·m)

CHAPTER 2

MOUNTING YOUR INTERACTIVE FLAT PANEL

4 smarttech.com/kb/170534

Choosing a mounting location

Consider the following when you select a location for the interactive flat panel:

lThe wall must be strong enough to support the interactive flat panel and the mounting

equipment. The interactive flat panel weighs 169.8 lb. (77 kg).

lSelect a wall with a flat, regular surface and sufficient clearance to accommodate your

interactive flat panel. Mount the interactive flat panel in a location that’s central to your

audience’s viewing direction.

lChoose a location for the interactive flat panel that’s far from bright light sources, such as

windows and strong overhead lighting. IR lighting can cause issues with the performance of

the cameras and can lead to unintentional or missed touches.

For mobile or adjustable installation options, contact your authorized SMART reseller

(smarttech.com/where).

Choosing a mounting height

Consider the general height of the user community when you choose the height for the interactive

flat panel.

The flat panel height is based on the midpoint between the reach of the students and the teacher.

Cable management

When you connect cables to the interactive flat panel from a computer and other peripheral

devices, ensure that the cables aren’t a trip hazard. Use channels and raceways to safely secure

and hide cables. Contact your authorized SMART reseller for these accessories.
