SilverStone PM01 Manuel utilisateur

Primera Series PM01

Pioneering computer case with exceptional style and functionality

The following manual and guides were carefully prepared by the SilverStone engineering team to

help you maximize the potential of your SilverStone product. Please keep this manual for future

reference when upgrading or performing maintenance on your system.Acopy of this manual can also

be downloaded from our website at:

Warranty Information

Installation and system optimization guide:

Product Overview

Specification

Disassemble Chart

Installation Chart

Top Cover Removed Guide

Connector Definition

Componet Size Limitations

Upqrade And Mainterance

P.1

P.2

P.4

P.14

P.15

P.18

P.22

Product Overview

Primera Series PM01

Specifications

Primera is the Spanish word for “first” or “first class.” Cases in

this series are designed for those seeking to build PCs with rich

feature set and trend-setting aesthetics.

The Primera PM01 is an incredible computer case that fuses

eye-catching styling and functionality in a package rarely seen in the

PC world. It utilizes high quality, piano-like finish with oversized

intake mesh panel inspired by sports car intake grill for unusually

sleek exterior. Paired with an elaborate lighting system consists of

LED fans and built-in adjustable LED strips, the PM01 can project

the feel of a luxurious supercar on a highly customizable computer

case. The roomy interior layout supports a variety of large, high end

components that are designed to be cooled efficiently and quietly

bytheincludedthree140mmLEDintakefansandan140mmexhaust

fan. True to SilverStone tradition, the PM01 also has excellent dust

protection thanks to implementation of easily removable filters and

positive pressure airflow setup. Novice users will find this case a

pleasure to build with and maintain while advanced users will find

details such as support for two 360mm radiator mounting positions

andwatertankmountingholestobehighlyusefulforbuildingbeautiful

liquid cooled PCs.

Model No.

Material

Motherboard

Drive Bay

Cooling System

Radiator Support

Expansion Slot

Front I/O Port

Power Supply

Expansion Card

Limitation of CPU cooler

Limitation of PSU

Dimension

SST-PM01BR-W (black with red LED + window)

SST-PM01CR-W (matte black with red LED + window)

SST-PM01WA-W (white with blue LED + window)

Plastic outer shell steel body

ATX (up to 12" x 10.7"), MicroATX

External

Internal

Front

Rear

Top

Front

Rear

Top

USB 2.0 x 2, USB 3.0 x 2,Audio x 1, MIC x 1

Standard PS2 (ATX)

Support graphics card up to 16.5", width restriction - 6.88"

180mm

240mm

220mm (W) x 571mm (H) x 560mm (D), 70.3 liters

None

2.5" or 3.5" x 4, 2.5" x 5

3 x 120mm / 140mm fan slot (includes 3 x 140mm LED fan)

1 x 120mm / 140mm fan slot (includes 1 x 140mm fan)

3 x 120mm fan slot or 2 x 140mm fan slot

240mm / 280mm / 360mm x 1

120mm / 140mm x 1

Introduction

Cases in

with rich

at fuse

en in the

versi

zed

nusuall

nsists of

oje

omputer

h end

d quietl

exhaust

llent d

ust

lters and

s case a

will find

positions

beautiful

Disassemble Chart

Primera Series PM01

Picture Item

ScrewA#6-32 X6.6

*Four modes: full brightness, half brightness, breathing pattern, and off

Screw C #6-32 X5

Screw D #6-32 X15-D=10

Screw B M3 X5

Screw M3-4

Bag 120 x 90MM

Manual 205 x 150MM

Motherboard Standoff

Secure Motherboard, PSU, 3.5” HDD

Secure 3.5” HDD

Secure 2.5” HDD

Secured HDD tray

Packing all screws

Bag 170 x 240MM

Fan-Cable-Extension

Purpose

TOP COVER

ATX MB (OPTION)

LEFT-SIDE-PANEL

FRONT-FILTER

LED FAN X3

USB 3.0 X2, USB 2.0 X2

Audio & MIC port

LED BUTTON *

POWER BUTTON 2.5” HDD X2

2.5” HDD X3

RIGHT-SIDE-PANEL

2.5” or 3.5” HDD X3

2.5” or 3.5” HDD X1

Disassemble Chart

Primera Series PM01

LEFT SIDE

TOP REAR RIGHT 3/4REAR LEFT 3/4

TOP RIGHTTOP LEFT

FRONT

REAR

RIGHT SIDE

Installation Guide

Primera Series PM01

Have all components collected.

Check that all components do not have compatibility problems with each other or with the case.

If possible, assemble the components outside the case first to make sure they are working.

Keep the motherboard manual ready for reference during installation.

Prepare a Philips screwdriver.

Before you begin, please make sure that you

Lösen Sie die beiden Schrauben an den linken und rechten Seitenwänden, nehmen Sie die Seitenwände ab.

Desatornille dos tornillos de los paneles izquierdo y derecho para quitarlos.

Per rimuovere i pannelli laterali allentare, per entrambi, le due viti di serraggio.

Loosen two screws from both left and right side panels to remove them.

Отвинтите по два винта, крепящих левую иправую боковых панели, иснимите панели.

왼쪽과 오른쪽 사이드 패널에서 두 개씩 나사를 풀어 사이드 패널을 제거합니다.

取下左右側板各兩顆螺絲,卸下側板。

取下左右侧板各两颗螺丝,卸下侧板。

両方の左右パネルからネジ2本を緩めて、取り外します。

Desserrez les vis des deux panneaux latéraux pour les retirer.

Installation Guide

Primera Series PM01

Installieren Sie das hintere I/O-Blech im Gehäuse.

Instale la placa trasera de E/S de la placa base en la carcasa.

Installare la placca I/O della scheda madre nella sede preposta.

Insert the I/O shield included with your motherboard.

Установите вкорпус заднюю панель ввода-вывода материнской платы.

메인보드 후방 I/O 판을 케이스에 장착합니다.

將I/O彈片裝上機殼。

将I/O弹片装上机箱。

ケース内にマザーボード後部I/Oプレートをインストールします。

Installez la plaque arrière de la carte mère dans le boîtier.

Installation Guide

Primera Series PM01

Stecken Sie die Abstandshalter wie für Ihr Motherboard erforderlich in die entsprechenden Befestigungsbohrungen. Installieren Sie

dann das Motherboard.

Inserte los soportes según sea necesario para su placa base en los agujeros de montaje correspondientes, luego instale la placa base.

Inserire nei corrispondenti fori di fissaggio i distanziatori, come richiesto dalla scheda madre, quindi installare la scheda madre.

Insert standoffs as required by your motherboard in corresponding mounting holes, then install motherboard.

Принеобходимостиустановите опорныестойкидлясистемной платывсоответствующие крепежныеотверстия, затем

установитесистемнуюплату.

메인보드에서 필요한 경우 해당 장착 구멍에 스탠드오프를 삽입한 후 메인보드를 설치합니다.

請依需求安裝主機板螺柱,安裝主機板。

请依需求安装主板螺柱,安装主板。

マザーボードに応じて、必要な孔にスペーサーを取り付けてからマザーボードを取り付けます。

Insérez les entretoises comme requis par votre carte mère dans les trous de montage correspondant, puis installez la carte mère.

Installation Guide

Primera Series PM01

Entfernen Sie Steckplatzabdeckungen, installieren Sie die gewünschten Erweiterungskarten.

Quite las cubiertas de los zócalos de expansión para instalar las tarjetas de expansión necesarias.

Rimuovere i cover degli slot di espansione per installare le schede.

Remove expansion slot covers to install required expansion cards.

Снимите крышки слотов расширения для установки необходимых плат расширения.

확장슬롯 커버를 제거한 후, 필요한 확장카드를 설치 합니다.

移除擴充槽檔片並安裝擴充卡。

移除扩充槽档片并安装扩充卡。

拡張スロットカバーを取り外して、必要な拡張カードを装着します。

Retirez les équerres pour installer vos cartes d'extension.

Installation Guide

Primera Series PM01

Positionieren Sie Ihre Festplatte am Einschub und sichern Sie sie mit den mitgelieferten Schrauben. Achtung: Die Befestigung des

Festplatteneinschubs sollte auf der Seite erfolgen, auf der sich auch der Festplattenanschluss befindet.

Coloque su disco duro en la bandeja y fíjelo con los tornillos incluidos. Aviso: el disco duro montado en la bandeja debería situarse en

el mismo lado de su conector para disco duro.

Collocare il disco rigido nel cassetto e fissarlo utilizzando le viti fornite in dotazione . Attenzione: la parte con le prese del cassetto

contenente il disco rigido deve essere collocata sullo stesso lato del connettore del disco rigido.

Place your hard drive on the tray and secure with included screws. Caution: the secure with mount of hard drive tray should be place

at the same side with your hard drive connector jack.

Поместите жесткий диск влоток изакрепите его винтами из комплекта . Внимание! Крепление лотка выполняется

стой же стороны, где расположен соединительный разъем для жесткого диска.

하드 드라이브를 트레이에 올려 놓고 제 공된 나사를 사용하여 고정합니 다. 주의: 하드 드라이브 트레이는 하드 드라이브 커넥터

잭과 동 일한 면에 놓고 장착해야 합니다.

請將您的硬碟安裝置硬碟托盤中,並以內附螺絲鎖固後,請注意鎖固硬碟托盤的方向必須與硬碟連接線接頭一致。

请将您的硬盘安装置硬盘托盘中,并以内附螺丝锁固后,请注意锁固硬盘托盘的方向必须与硬盘连接线接头一致。

ハードディスクをトレイに置き、付属のネジで固定します。注意： ハードディスクドライブトレイは、ハードディスクコネクタジャックと同じ

向きに設置してください。

Placez votre disque dur sur le plateau et fixez-le avec les vis fournies. Attention : le support du plateau de disque dur doit être du

même côté que la prise du connecteur de disque dur.
