SilverStone MMS01 Manuel utilisateur

MMS01

Mammoth Series

Military-grade IP65 water resistant and dust proof

external 2.5” drive enclosure with USB 3.0

MS0

ter resistant and dust proo

Specifications

Mammoth Series

The MMS01 is a military-grade external 2.5” drive enclosure with USB 3.0 capability. Its thick, protective enclosure is certified for IP65 standard

so it is dust proof and water resistant. Under multiple testing regime based on US military standard, the MMS01 has also proven to be immune

or resistant to rapid temperature change, vibration, 1.2 meter drop, salt spray, sand, and fungal growth. Despite the extraordinary durability,

there are no sacrifices in performance as the MMS01 supports UASP in addition to its already speedy USB 3.0 interface. If you are looking for

an enclosure that can protect your drive in the harshest environment possible, the MMS01 is the one to get.

Model No

Enclosure material

Color

Military Standard

Ingress protection

HDD size support

HDD interface

Enclosure interface

Transfer speed

Support OS

Extra function

Environment

Net Weight

Dimension

SST-MMS01B

ABS with silicone sleeve

Black

MIL-STD-810G, Method 503.5 (thermal shock)

MIL-STD-810G, Method 507.5 (humidity)

MIL-STD-810G, Method 508.6 (fungus)

MIL-STD-810G, Method 509.5 (salt spray)

MIL-STD-810G, Method 510.5, Procedure I (sand and dust)

MIL-STD-810G, Method 514.6 (vibration)

MIL-STD-810G, Method 516.6 (shock)

IP6X

Dustproof: No ingress of dust; complete protection against contact (dust tight)

IPX5

Water resistant: Water projected by a nozzle (6.3 mm) against enclosure from any direction shall have no harmful effects

7mm or 9.5mm 2.5” SATA HDD/SSD

SATA III / II / I

Micro USB 3.0 type B (compatible with USB 2.0/USB 1.1)

Max. 5Gbps

Microsoft Windows 10/8.1/8/7/VISTA (32 and 64 bit) or future release versions

Mac OS 10.6 or future release versions

UASP

Operating Temperature: 5°C ~ 35°C

Operating Humidity: 20%RH ~ 80%RH

Storage Temperature: -20°C ~ 50°C

Storage Humidity: 20%RH ~ 80%RH

280g ± 20g

100mm (W) x 20mm (H) x 135 mm (D) (without silicone sleeve)

MMS01

Introduction

Product Overview

suppor

UASP

n a

dditi

s a

hest environment

pos

sible, the MM

Application for 2.5”SATA HDD/SSD( SATAIII 6Gbps /SATA II 3.0Gbps /SATA I 1.5Gbps)

■

This product is designed for SATA HDD/SSD only and is not applicable for PATA(IDE) based HDD.

■

This product can support hard drives with more than 4TB capacity.

■

Windows XP operating system limits HDD capacity to 2TB.

■

Loading / Removing hard drive may cause slight scratching.

The following USB Host controller models have been validated.

■

Intel H87 chipset USB 3.0 Host controller

■

ETron EJ168 USB 3.0 Host controller

■

Intel Z77 chipset USB 3.0 Host controller

■

ASMedia ASM1042 USB 3.0 Host controller

■

Frescologic FL1100 USB 3.0 Host controller

■

ASMedia ASM1142 USB 3.1 Host controller

■

FL1100 USB 3.0 Host controller

※Please update each host controller (adapter) driver to the latest version.

Package Content

Product Description

Appearance

User manual

MMS01B enclosure

Anti-vibration pad

Protective sleeve

Micro USB3.0 cableSix hand corner

Back

Latch

Screw

Protective sleeve

Micro USB 3.0

connector

MMS01

Instruction

Mammoth Series

■When mounting a hard drive, please be mindful of static electricity as it can cause device malfunction. Please touch other metal objects to

discharge or wear antistatic gloves before handling hard drive.

■If hard drive already contains data, please backup it up before installation to prevent data loss.

1.Open the latch

2.Using included hex key to remove the hex screws for opening the MMS01 enclosure

3.Install HDD or SSD into MMS01 enclosure

Package Content

Instruction

Installation Guide

Mammoth Series

MMS01

6. Slip the protective sleeve over the enclosure

5. Reinstall all hex screws

4. Drive securely seated

4.1 Installation the crash pad

Anti-vibration pad

＊If 7mm thick 2.5” HDD/SSD is installed, please place the anti-vibration pad on it. For 9.5mm thick 2.5” HDD/SSD, it is not necessary to

use the anti-vibration pad.

Instruction

MMS01

Mammoth Series

Caution

7. Connect MMS01 to your computer

Mammoth Series

MMS01

If a suspected case of failure occurs, please check for the following:

■My device is recognized as USB 2.0, not USB 3.0?

→Try to power off your computer and connect the cable again.

■Only 2TB capacity can be identified when using a drive over 2TB (Windows Vista/7/8/10)?

→Please use GPT format for over 2TB capacity.

■When connected as a USB 3.0 device, my system cannot recognize it after a period of time?

→Please update the USB 3.0 driver.

■Why some drives don’t show up in “My Computer” (Windows) ?

→Make sure the hard disk letter is assigned in C ~ Z range.

■When using a new drive, it cannot be recognized by my OS?

→Please format the drive.

■When using a 2TB drive, the capacity in the OS only shows 1.8TB?

→Most hard drive manufacturers use decimal, but the OS uses binary to calculate drive capacity.

Due to different calculation methods, you will see 200GB less capacity on a 2TB drive.

Package Content

Troubleshooting

Caution

Q：Can I use drives that already have existing data?

A：Mostly yes, but depending on the environment in which the drive was previously used, there may be incompatibility,

so to avoid unpredictable data loss, please backup first before using it in MMS01B.

Q：What kinds of hard drives are supported？

A：The product can support 2.5” SATA HDD/SSD, but not IDE, SAS, SCSI HDD.

Q：How many drive insertion cycles can MMS01B withstand?

A：This product’s SATAconnector durability is rated up to 10,000 cycles.

Q：Why does disk format take so much time in Windows?

A：You can select quick format when performing the format function.

Q：Why can’t my drive access S.M.A.R.T information?

A：This product does not support S.M.A.R.T function.

Q：Does MMS01B support USAP function?

A：Yes, but your system also needs to support USAP for it to work.

FAQ

MMS01

Mammoth Series

Einleitung

Mammoth Series

MMS01

Unterstützt 2,5-Zoll-SATA-Festplatten/-SSDs (SATA III, 6 Gb/s /SATAII, 3,0 Gb/s /SATAI, 1,5 Gb/s)

■

Dieses Produkt wurde nur für SATA-Festplatten/-SSDs entwickelt und unterstützt keine PATA-

(IDE-)basierten Datenträger.

■

Dieses Produkt kann Datenträger mit mehr als 4 TB unterstützen.

■

Das Windows XP-Betriebssystem beschränkt die Laufwerkskapazität auf 2 TB.

■

Beim Installieren/Entfernen eines Datenträgers kann dieser leicht am Produkt kratzen.

Folgende USB-Host-Controller-Modelle wurden überprüft.

■

USB 3.0-Host-Controller mit Intel H87-Chipsatz

■

USB 3.0-Host-Controller ETron EJ168

■

USB 3.0-Host-Controller mit Intel Z77-Chipsatz

■

USB 3.0-Host-Controller ASMediaASM1042

■

USB 3.0-Host-Controller Frescologic FL1100

■

USB 3.1-Host-Controller ASMediaASM1142

■

USB 3.0-Host-Controller FL1100

*Bitte aktualisieren Sie den Treiber des jeweiligen Host-Controllers (Adapters) auf die neueste Version.

Zurück

Riegel

Sechskantschrauben

Protective sleeve

Micro USB 3.0-Kabel

Lieferumfang

Produktbeschreibung

Appearance

Bedienungsanleitung

MMS01B-Gehäuse

Vibrationsdämpfendes Polster

Protective sleeve

Micro USB 3.0-KabelSix hand corner

Einleitung

Mammoth Series

■Bitte ergreifen Sie bei der Installation eines Datenträgers entsprechende Maßnahmen aufgrund statischer Elektrizität, da diese das Gerät

beschädigen kann. Berühren Sie zum Entladen andere metallische Objekte oder legen Sie ein Antistatik-Armband an, bevor Sie den

Datenträger installieren.

■Falls der Datenträger bereits Daten enthält, sichern Sie diese zur Vermeidung von Datenverlust bitte vor der Installation.

1. Riegel öffnen

2.Mit dem mitgelieferten Sechskantschlüssel Sechskantschrauben zum Öffnen des MMS01-Gehäuses entfernen

3. Festplatte oder SSD in MMS01-Gehäuse installieren

Package Content

Installationsanleitung

MMS01

Einleitung

Mammoth Series

MMS01

6. Schutzhülle über das Gehäuse schieben

5. Alle Sechskantschrauben wieder installieren

4.Laufwerk sicher installiert

4.1 Vibrationsdämpfendes Polster installieren

Vibrationsdämpfendes Polster

＊Falls eine 7 mm dicke 2,5-Zoll-Festplatte/-SSD installiert wird, platzieren Sie bitte das vibrationsdämpfende Polster darauf. Bei einer

9,5 mm dicken 2,5-Zoll-Festplatte/-SSD muss das vibrationsdämpfende Polster nicht verwendet werden.
