Silvercrest 298849 Manuel utilisateur
TIMER SWITCHES
TIMER SWITCHES
Operation and Safety Notes
TIJDSCHAKELAAR
Bedienings- en veiligheidsinstructies
ZEITSCHALTUHREN
Bedienungs- und Sicherheitshinweise
IAN 298849
GB / IE / NI Operation and Safety Notes Page 5
NL Bedienings- en veiligheidsinstructies Pagina 19
DE / AT / CH Bedienungs- und Sicherheitshinweise Seite 33
Before reading, unfold the page containing the illustrations and familiarise
yourself with all functions of the device.
Vouw vóór het lezen de pagina met de afbeeldingen open en maak u
vertrouwd met alle functies van het apparaat.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen
Sie sich anschließend mit allen Funktionen des Gerätes vertraut.
1
A
B
5
7
6
8
4
1 2 3 4
3
5GB/IE/NI
List of pictograms used......... Page 6
Introduction.................................... Page 7
Intended use ......................................... Page 7
Control elements................................... Page 8
Technical data ...................................... Page 8
Safety notices ............................... Page 9
Start-up............................................... Page 10
Setting switching times ......................... Page 10
Selecting the operating mode.............. Page 12
Adjusting the time ................................. Page 13
Cleaning............................................. Page 13
Disposal.............................................. Page 14
Warranty and Service........... Page 15
Service address .................................... Page 16
Manufacturer ........................................ Page 17
6 GB/IE/NI
List of pictograms used
Observe the warning and
safety instructions!
Attention! Risk of electric shock!
Do not dispose of electric equip-
ment in the household waste!
Use indoors
AC motor
Micro-switch with a contact
opening width of < 3 mm
7GB/IE/NI
Timer Switches
Mechanical – for indoors
Introduction
Intended use
This device is intended as a daily timer switch
for enclosed, dry rooms only and designed
for private use. It is not suitable for commer-
cial use. Only operate the device individually.
Do not connect several timer switches in se-
ries. Any other use is considered improper.
The manufacturer is not liable for damages
due to improper use. Read the entire instruc-
tions for use before using the device. Keep
these instructions for use. Include the instruc-
tions for use when passing the device on.
8 GB/IE/NI
Control elements (Fig. A)
1Clock ring
2Direction of rotation
3Mark
4Switching pins
5Toggle timer / continuous mode
6Safety plug (back)
7Status light
8Isolated ground receptacle with child
protection
Technical data
Model designation:
MZK 20-A DE 3655
Operating voltage: 220–240V~50Hz
Switched voltage: 220–240 V~
16(2) A
Switching capacity: max. 3500 W
Shortest switching time: approx. 15 minutes
9GB/IE/NI
Power reserve: none
Use
indoors:
EU compliant:
Safety notices
Children are not able to understand the
dangers arising from improper use of
electric devices. Never leave children
unsupervised when using electronic
devices.
Only plug the device into conventional
isolated ground receptacles with an
alternating current of 220–240 V and
50 Hz.
Only connect loads within the specified
capacities of the device.
Do not cover the device. Heat accumu-
lates when covered. There is a fire hazard.
10 GB/IE/NI
Regularly check the device for damage.
Do not replace damaged parts. Contact
the manufacturer or dispose of the device
in an environmentally responsible way.
Do not touch the device with wet hands.
Disconnect the device from the power
mains to de-energise.
Do not connect devices from which
hazards could arise during unsupervised
operation (i.e. heaters).
This device is child-proofed. Both pins of
the plug must be inserted into the socket
at the same time.
Start-up
Setting switching
times (Fig. B)
Use the switching pins 4to set the times
when you wish the timer to switch the
