Silvercrest 274299 Manuel utilisateur
TIMER SWITCHES
IAN 274299
ZEITSCHALTUHREN
Bedienungs- und Sicherheitshinweise
TIMER SWITCHES
Operation and Safety Notes
PROGRAMMATEURS
Instructions d‘utilisation et consignes de sécurité
TIJDSCHAKELAAR
Bedienings- en veiligheidsinstructies
GB Operation and Safety Notes Page 5
FR/BE Instructions d‘utilisation et consignes de sécurité Page 17
NL/BE Bedienings- en veiligheidsinstructies Pagina 32
DE/AT/CH Bedienungs- und Sicherheitshinweise Seite 46
Before reading, unfold the page containing the illustrations and familiarise
yourself with all functions of the device.
Avant de lire le mode d‘emploi, ouvrez la page contenant les illustrations
et familiarisez-vous ensuite avec toutes les fonctions de l‘appareil.
Vouw vóór het lezen de pagina met de afbeeldingen open en maak u
vertrouwd met alle functies van het apparaat.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen
Sie sich anschließend mit allen Funktionen des Gerätes vertraut.
B
4
A
5
67
8
1234
5GB
List of pictograms used........Page 6
Introduction
Intended use ........................................Page 7
Control elements..................................Page 8
Technical Data.....................................Page 8
Safety notices ..............................Page 9
Start-up
Setting switching times ........................Page 10
Selecting the operating mode.............Page 12
Adjusting the time ................................Page 13
Cleaning............................................Page 13
Disposal.............................................Page 14
Warranty and Service..........Page 15
Service address ...................................Page 16
Manufacturer.......................................Page 16
6 GB
List of pictograms used:
Observe the warning and
safety instructions!
Attention! Risk of electric shock!
Do not dispose of electric equip-
ment in the household waste!
Use indoors
AC motor
Micro-switch with a contact
opening width of < 3mm
7GB
Timer Switches
Mechanical – for indoors
Introduction
Intended use
This device is intended as a daily timer switch
for enclosed, dry rooms only and designed
for private use. It is not suitable for commer-
cial use. Only operate the device individu-
ally. Do not connect several timer switches in
series. Any other use is considered improper.
The manufacturer is not liable for damages
due to improper use.
Read the entire instructions for use before
using the device. Keep these instructions for
use. Include the instructions for use when
passing the device on.
8 GB
Control elements (Fig. A)
1Clock ring
2Direction of rotation
3Mark
4Switching pins
5Toggle timer /continuous mode
6Status light
7Safety plug (back)
8Isolated ground receptacle with child
protection
Technical Data
Model designation: MZ 20-1 FR
Operating voltage: 220–240V~50Hz
Switched voltage: 220–240V~
16(2)A
Switching capacity: max. 3500 W
Shortest switching time: approx. 15 minutes
9GB
Power reserve: none
Use
indoors:
CE compliant:
Safety notices
Children are not able to understand the
dangers arising from improper use of
electric devices. Never leave children
unsupervised when using electronic
devices.
Only plug the device into conventional
isolated ground receptacles with an
alternating current of 220–240V and
50Hz.
Only connect loads within the specified
capacities of the device.
Do not cover the device. Heat accumu-
lates when covered. There is a fire hazard.
10 GB
Regularly check the device for damage.
Do not replace damaged parts. Contact
the manufacturer or dispose of the device
in an environmentally responsible way.
Do not touch the device with wet hands.
Disconnect the device from the power
mains to de-energise.
Start-up
Setting switching
times (Fig. B)
Use the switching pins 4to set the times
when you wish the timer to switch the con-
nected device on or off. Using a pointy ob-
ject, e.g. pen, push one or several pins down
to lock into place to set the desired switching
time. Every switching pin corresponds to a
switching time of approx. 15 minutes.
