Silvercrest 285220 Manuel utilisateur

TIMER SWITCHES

IAN 285220

TIMER SWITCHES

Operation and Safety Notes

TIJDSCHAKELAAR

Bedienings- en veiligheidsinstructies

ZEITSCHALTUHREN

Bedienungs- und Sicherheitshinweise

PROGRAMMATEURS

Instructions d‘utilisation et consignes de sécurité

285220_A_Zeitschaltuhren_mechanisch_cover_BE.indd 2 01.08.17 07:30

GB/IE/NI Operation and Safety Notes Page 5

FR/BE Instructions d‘utilisation et consignes de sécurité Page 19

NL/BE Bedienings- en veiligheidsinstructies Pagina 35

DE/AT / CH Bedienungs- und Sicherheitshinweise Seite 51

Before reading, unfold the page containing the illustrations and familiarise

yourself with all functions of the device.

Avant de lire le mode d‘emploi, ouvrez la page contenant les illustrations

et familiarisez-vous ensuite avec toutes les fonctions de l‘appareil.

Vouw vóór het lezen de pagina met de afbeeldingen open en maak u

vertrouwd met alle functies van het apparaat.

Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und

machen Sie sich anschließend mit allen Funktionen des Gerätes vertraut.

285220_A_Zeitschaltuhren_mechanisch_cover_BE.indd 3 01.08.17 07:30

1 2 3 4

285220_A_Zeitschaltuhren_mechanisch_cover_BE.indd 4 01.08.17 07:30

5GB/IE/NI

List of pictograms used........Page 6

Introduction...................................Page 7

Intended use ........................................Page 7

Control elements..................................Page 8

Technical Data.....................................Page 8

Safety notices ..............................Page 9

Start-up..............................................Page 10

Setting switching times ........................Page 10

Selecting the operating mode.............Page 12

Adjusting the time ................................Page 13

Cleaning............................................Page 13

Disposal.............................................Page 14

Warranty and Service..........Page 15

Service address ...................................Page 16

Manufacturer.......................................Page 17

6 GB/IE/NI

List of pictograms used:

Observe the warning and

safety instructions!

Attention! Risk of electric shock!

Do not dispose of electric equip-

ment in the household waste!

Use indoors

AC motor

Micro-switch with a contact

opening width of < 3mm

7GB/IE/NI

Timer Switches

Mechanical – for indoors

Introduction

Intended use

This device is intended as a daily timer switch

for enclosed, dry rooms only and designed

for private use. It is not suitable for commer-

cial use. Only operate the device individu-

ally. Do not connect several timer switches in

series. Any other use is considered improper.

The manufacturer is not liable for damages

due to improper use.

Read the entire instructions for use before

using the device. Keep these instructions for

use. Include the instructions for use when

passing the device on.

8 GB/IE/NI

Control elements (Fig. A)

1Clock ring

2Direction of rotation

3Mark

4Switching pins

5Toggle timer / continuous mode

6Safety plug (back)

7Isolated ground receptacle with child

protection

Technical Data

Model designation: MZK 20-A FR 3655

Operating voltage: 230V~50Hz

Switched voltage: 230V~16(2)A

Switching capacity: max. 3500W

Shortest switching time: approx. 15 minutes

Power reserve: none

9GB/IE/NI

Use

indoors:

EU compliant:

Safety notices

Children are not able to understand the

dangers arising from improper use of

electric devices. Never leave children

unsupervised when using electronic

devices.

Only plug the device into conventional

isolated ground receptacles with an

alternating current of 230V and 50Hz.

Only connect loads within the speciﬁed

capacities of the device.

Do not cover the device. Heat accumu-

lates when covered. There is a ﬁre hazard.

Regularly check the device for damage.

Do not replace damaged parts. Contact

10 GB/IE/NI

the manufacturer or dispose of the device

in an environmentally responsible way.

Do not touch the device with wet hands.

Disconnect the device from the power

mains to de-energise.

Do not connect devices from which

hazards could arise during unsupervised

operation (i.e. heaters).

This device is child-proofed. Both pins of

the plug must be inserted into the socket

at the same time.

Start-up

Setting switching

times (Fig. B)

Use the switching pins 4to set the times

when you wish the timer to switch the con-

nected device on or oﬀ. Using a pointy ob-

ject, e.g. pen, push one or several pins down

11GB/IE/NI

to lock into place to set the desired switching

time. Every switching pin corresponds to a

switching time of approx. 15 minutes.

Device for private use, set times may be oﬀ-

set. Not suitable for applications requiring

precise and accurate switching.

In ﬁgure B the grey pins mark a switching

time of 8:30 pm to 10:30 pm. A load is

switched on during the time from 8:30 pm

to 10:30 pm.

Setting the switching time

Push down the respective number of

switching pins 4.

Disabling switching time

Push the switching pins 4up again.
