Silvercrest STK 17 A1 Caractéristiques techniques

IAN 321204_1901

OWIM GmbH & Co. KG

Stiftsbergstraße 1

DE-74167 Neckarsulm

GERMANY

Model no.: HG04522A/HG04522B

Version: 06/2019

Last Information Update · Tietojen tila

Informationsstatus · Stan informacji

Informacijos pobūdis · Stand

der Informationen: 06/2019

Ident.-No.: HG04522A/B062019-3

IAN 321204_1901

WIRELESS DOORBELL STK 17 A1

TRÅDLÖS DÖRRKLOCKA

Asennus-, käyttö- ja turvallisuusohjeet

DZWONEK DO DRZWI

STEROWANY RADIOWO

Wskazówki montażu, obsługi i bezpieczeństwa

BELAIDIS DURŲ SKAMBUTIS

Nurodymai dėl montavimo, naudojimo ir saugumo

FUNK-TÜRKLINGEL

Montage-, Bedienungs- und Sicherheitshinweise

OVIKELLO

Asennus-, käyttö- ja turvallisuusohjeet

WIRELESS DOORBELL

Assembly, operating and safety instructions

WIRELESS DOORBELL STK 17 A1

GB Assembly, operating and

safety instructions Page 5

FI Asennus-, käyttö- ja

turvallisuusohjeet Sivu 29

SE Monterings-, bruks- och

säkerhetsanvisningar Sidan 52

PL Wskazówki montażu, obsługi i

bezpieczeństwa Strona 74

LT Nurodymai dėl montavimo,

naudojimo ir saugumo Puslapis 99

DE/AT/ CH Montage-, Bedienungs- und

Sicherheitshinweise Seite 122

You need · Tarvitset · Du behöver

Wymagane · Jums reikės · Sie benötigen:

ø 6mm

GB 5

Introduction...................................... Page 6

Intended use........................................ Page 6

Technical data..................................... Page 7

Included items ..................................... Page 8

Parts and features ............................... Page 8

Safety................................................... Page 9

General safety information................. Page 10

Safety instructions for batteries/

rechargeable batteries ....................... Page 12

Assembly............................................ Page 15

Preparing for use ......................... Page 16

Inserting/replacing the batteries....... Page 16

Operation.......................................... Page 17

Synchronising transmitter /receiver ... Page 17

Setting the signal type ........................ Page 19

Setting the volume............................... Page 20

Selecting the chime............................. Page 20

Troubleshooting................................... Page 21

Cleaning and maintenance.... Page 22

Disposal .............................................. Page 22

Simplified EU declaration

of conformity................................... Page 25

Warranty ........................................... Page 25

Warranty claim procedure................. Page 27

Service................................................. Page 28

GB6

Wireless Doorbell

Introduction

We congratulate you on the

purchase of your new product.

You have chosen a high quality

product. The instructions for use are part

of the product. They contain important

information concerning safety, use and

disposal. Before using the product, please

familiarise yourself with all of the safety in-

formation and instructions for use. Only

use the product as described and for the

speciﬁed applications. If you pass the

product on to anyone else, please ensure

that you also pass on all the documentation

with it.

Intended use

This product is intended for the wireless

transmission of the doorbell chime. The

product is not intended for commercial

use.

GB 7

Technical data

Range: 100m (unobstructed

area)

Frequency band: 433MHz

Max. transmitted

power: <10dBm

Battery types: Receiver: 2 x

1.5V (direct

current) (type AA /

LR6),

Transmitter: 1 x

3V (direct

current) (type

CR2032)

Receiver: Audible signal vol-

ume (at maximum

volume setting):

min. 73dB (at a

distance of 1m

from the device)

Transmitter: IP rating: IPX4

GB8

Included items

1 Transmitter

1 Receiver

2 Batteries 1.5V (direct current),

type AA (receiver)

1 Battery 3V (direct current), type

CR2032 (transmitter)

3 Long screws (for mounting transmitter

and receiver on a wall)

1 Short screw (for transmitter)

3 Dowels

5 Exchangeable name plates (for the

doorbell)

1 Doorbell cover

1 Operating instructions

Parts and features

Receiver (Figs. A/B):

1Signal indicator

2Melody selection button

3Volume/Synchronisation button

4Signal type selector button

(acoustic, optical, optical and

acoustic signal)

GB 9

5Speaker

6Hanger

7Battery compartment cover

8Battery compartment

Transmitter (Figs. C/D):

9Signal indicator

10 Name plate

11 Chime button

12 Battery compartment

13 Holder (for wall mounting)

Mounting (Figs. E/ F):

14 Long screw

15 Dowel

16 Short screw (for transmitter)

Safety

Read all safety

information and instructions. Failure to

comply with the safety information and

GB10

instructions may cause ﬁre and/or serious

injury.

YOU SHOULD STORE ALL SAFETY IN-

FORMATION AND INSTRUCTIONS

IN A SAFE PLACE IN CASE YOU NEED

TO REFER TO THEM AGAIN IN THE

FUTURE!

General safety

information

DANGEROUS TO LIFE

AND RISK OF ACCI-

DENTS FOR TODDLERS AND

CHILDREN! Never leave children

alone and unsupervised with the

packaging material. There is a risk

of suﬀocation from the packaging

material. Children often underestimate

risks. Always keep children away

from the product. This is not a toy.
