Siemens SINAMICS G120P Manuel utilisateur

dV/dt filter plus Voltage Peak Limiter

___________________

SINAMICS

SINAMICS G120P

dV/dt filter plus Voltage Peak

Limiter

Operating Instructions

Control version V4.6

04/2014

A5E32847105B AB

Safety information

General

Mechanical installation

Electrical installation

Maintenance and servicing

Technical specifications

Siemens AG

Industry Sector

Postfach 48 48

90026 NÜRNBERG

GERMANY

A5E32847105B AB

Ⓟ

03/2014 Subject to change

Legal information

Warning notice system

This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent

damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert

symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are

graded according to the degree of danger.

DANGER

indicates that death or severe personal injury will result if proper precautions are not taken.

WARNING

indicates that death or severe personal injury may result if proper precautions are not taken.

CAUTION

indicates that minor personal injury can result if proper precautions are not taken.

NOTICE

indicates that property damage can result if proper precautions are not taken.

If more than one degree of danger is present, the warning notice representing the highest degree of danger will

be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to

property damage.

Qualified Personnel

The product/system described in this documentation may be operated only by

personnel qualified

for the specific

task in accordance with the relevant documentation, in particular its warning notices and safety instructions.

Qualified personnel are those who, based on their training and experience, are capable of identifying risks and

avoiding potential hazards when working with these products/systems.

Proper use of Siemens products

Note the following:

WARNING

Siemens products may only be used for the applications described in the catalog and in the relevant technical

documentation. If products and components from other manufacturers are used, these must be recommended

or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and

mai

ntenance are required to ensure that the products operate safely and without any problems. The permissible

ambient conditions must be complied with. The information in the relevant documentation must be observed.

Trademarks

All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication

may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.

Disclaimer of Liability

We have reviewed the contents of this publication to ensure consistency with the hardware and software

described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the

information in this publication is reviewed regularly and any necessary corrections are included in subsequent

editions.

dV/dt filter plus Voltage Peak Limiter

Operating Instructions, 04/2014, A5E32847105B AB 5

Table of contents

1 Safety information ................................................................................................................................... 7

1.1 Warnings ........................................................................................................................................7

1.2 Components that can be destroyed by electrostatic discharge (ESD) ..........................................9

2 General................................................................................................................................................. 11

3 Mechanical installation .......................................................................................................................... 15

4 Electrical installation.............................................................................................................................. 19

5 Maintenance and servicing.................................................................................................................... 23

6 Technical specifications ........................................................................................................................ 25

Table of contents

dV/dt filter plus Voltage Peak Limiter

6Operating Instructions, 04/2014, A5E32847105B AB

dV/dt filter plus Voltage Peak Limiter

Operating Instructions, 04/2014, A5E32847105B AB 7

Safety information

1.1

Warnings

WARNING

Danger to life if the fundamental safety instructions and remaining risks are not carefully

observed

Non-compliance with the fundamental safety instructions and residual risks stated in

Chapter 1 of the Installation Manual for PM330 Power Modules can result in accidents with

severe injuries or death.

•Adhere to the fundamental safety instructions.

•When assessing the risk, take into account residual risks.

Note

Use of copper cables for a UL-approved system

For a UL

-approved system use 60/75°C copper conductors only.

Preconditions

The persons responsible for the safety of the plant or system must ensure that the following

conditions are met:

●Basic planning work for the system and all work relating to transportation, assembly,

installation, commissioning, maintenance and repairs is carried out by qualified personnel

and checked by responsible, suitably skilled personnel.

●The Operating Instructions and machine documentation are always available.

●The technical specifications regarding the applicable installation, connection,

environmental, and operating conditions are always observed.

●The plant-specific assembly and safety guidelines are observed and personal protection

equipment is used.

●Unqualified personnel are forbidden from using these machines and working near them.

These Operating Instructions are intended for qualified personnel and only contain

information and notes relating to the intended purpose of the machines.

The Operating Instructions and machine documentation are written in different languages as

specified in the delivery contracts.

Safety information

1.1 Warnings

dV/dt filter plus Voltage Peak Limiter

8Operating Instructions, 04/2014, A5E32847105B AB

Note

Support by SIEMENS service centers

We recommend engaging the support and services of your loc

al Siemens service center for

all planning, installation, commissioning and maintenance work.

Safety information

1.2 Components that can be destroyed by electrostatic discharge (ESD)

dV/dt filter plus Voltage Peak Limiter

Operating Instructions, 04/2014, A5E32847105B AB 9

1.2

Components that can be destroyed by electrostatic discharge (ESD)

CAUTION

Components sensitive to electrostatic charge

The board contains components that can be destroyed by electrostatic discharge. These

components can be easily destroyed if not handled properly. If you do have to use

electronic boards, however, please observe the following:

•You should only touch electronic boards if absolutely necessary.

•When you touch boards, however, your body must be electrically discharged

beforehand.

•Boards must not come into contact with highly insulating materials (such as plastic

parts, insulated desktops, articles of clothing manufactured from man-made fibers).

•Boards must only be placed on conductive surfaces.

•Boards and components should only be stored and transported in conductive packaging

(such as metalized plastic boxes or metal containers).

•If the packaging material is not conductive, the boards must be wrapped with a

conductive packaging material (such as conductive foam rubber or household aluminum

foil).

The necessary ESD protective measures are clearly illustrated in the following diagram:

●a = conductive floor surface

●b = ESD table

●c = ESD shoes

●d = ESD overall

●e = ESD wristband

●f = cabinet ground connection

●g = contact with conductive flooring

Figure 1-1 ESD protective measures

Safety information

1.2 Components that can be destroyed by electrostatic discharge (ESD)

dV/dt filter plus Voltage Peak Limiter

10 Operating Instructions, 04/2014, A5E32847105B AB
