Preface

Properties

Parameters

Diagnostics

Siemens AG

Large Drives Applications

Vogelweiherstr. 1

-15

90441 NÜRNBERG

GERMANY

A5E48281338-AA

Ⓟ

08/2019 Subject to change

Legal information

Warning notice system

This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent

damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert

symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are

graded according to the degree of danger.

DANGER

indicates that death or severe personal injury will result if proper precautions are not taken.

WARNING

indicates that death or severe personal injury may result if proper precautions are not taken.

CAUTION

indicates that minor personal injury can result if proper precautions are not taken.

NOTICE

indicates that property damage can result if proper precautions are not taken.

If more than one degree of danger is present, the warning notice representing the highest degree of danger will

be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to

property damage.

Qualified Personnel

The product/system described in this documentation may be operated only by personnel qualified for the specific

task in accordance with the relevant documentation, in particular its warning notices and safety instructions.

Qualified personnel are those who, based on their training and experience, are capable of identifying risks and

avoiding potential hazards when working with these products/systems.

Proper use of Siemens products

Note the following:

WARNING

Siemens products may only be used for the applications described in the catalog and in the relevant technical

documentation. If products and components from other manufacturers are used, these must be recommended

or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and

maintenance are required to ensure that the products operate safely and without any problems. The permissible

ambient conditions must be complied with. The information in the relevant documentation must be observed.

Trademarks

All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication

may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.

Disclaimer of Liability

We have reviewed the contents of this publication to ensure consistency with the hardware and software

described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the

information in this publication is reviewed regularly and any necessary corrections are included in subsequent

editions.

Digital Electronic Module 2RO NO/NC DC24..48V/5A AC24..230V/5A (6ES7132-4HB13-0AB0)

Manual, 08/2019, A5E48281338-AA 3

Table of contents

1 Preface ...................................................................................................................................................... 4

1.1 Preface......................................................................................................................................4

2 Properties .................................................................................................................................................. 6

2.1 Digital Electronic Module 2RO NO/NC DC24..48V/5A AC24..230V/5A (6ES7132-

4HB13-0AB0)............................................................................................................................6

3 Parameters.............................................................................................................................................. 11

4 Diagnostics.............................................................................................................................................. 12

4.1 Diagnostics using LED display ...............................................................................................12

Digital Electronic Module 2RO NO/NC DC24..48V/5A AC24..230V/5A (6ES7132-4HB13-0AB0)

4Manual, 08/2019, A5E48281338-AA

Preface

1.1 Preface

Purpose of the manual

This manual supplements the

ET 200S Distributed I/O System

Operating Instructions.

Functions which apply to the ET 200S in general are described in the ET 200S operating

instructions on the Internet (https://support.automation.siemens.com/WW/view/en/1144348).

The information in this document along with the operating instructions enables you to

commission the ET 200S.

Basic knowledge requirements

To understand these operating instructions you should have general knowledge of

automation engineering.

Scope of validity of the manual

This manual applies to this ET 200S module. It describes the components that are valid at

the time of publication.

Recycling and disposal

Due to the fact that it is low in contaminants, this ET 200S module is recyclable. For

environmentally compliant recycling and disposal of your electronic waste, please contact a

company certified for the disposal of electronic waste.

Additional support

If you have any questions relating to the use of the products described in this manual and do

not find the answers in this document, please contact your local Siemens representative or

office nearest to you on the Internet (https://www.automation.siemens.com/partner/).

A guide to the technical documentation for the various SIMATIC products and systems is

available on the Internet. (https://www.siemens.com/simatic-tech-doku-portal)

The online catalog and ordering system are available on the Internet

(https://www.siemens.com/automation/mall).

Training center

We offer courses to help you get started with the ET 200S and the SIMATIC S7 automation

system. Please contact your regional training center or the central training center in D-

90327, Nuremberg, Germany on the Internet (https://www.siemens.com/sitrain).

Preface

1.1 Preface

Digital Electronic Module 2RO NO/NC DC24..48V/5A AC24..230V/5A (6ES7132-4HB13-0AB0)

Manual, 08/2019, A5E48281338-AA 5

Technical Support

You can reach Technical Support for all industry automation products via the support request

Web form on the Internet (https://www.siemens.com/automation/support-request).

Additional information about Siemens Technical Support is available on the Internet

(https://www.siemens.com/automation/service).

Service & Support on the Internet

In addition to our documentation, we offer a comprehensive knowledge base on the Internet

(https://www.siemens.com/automation/service&support).

There you will find:

●Our Newsletter, which constantly provides you with the latest information about your

products.

●The right documentation for you using our Service & Support search engine.

●The bulletin board, a worldwide knowledge exchange for users and experts.

●Your local contact for Automation & Drives in our contact database.

●Information about on-site services, repairs, spare parts, and lots more.

Digital Electronic Module 2RO NO/NC DC24..48V/5A AC24..230V/5A (6ES7132-4HB13-0AB0)

6Manual, 08/2019, A5E48281338-AA

Properties

2.1 Digital Electronic Module

2RO NO/NC DC24..48V/5A AC24..230V/5A

(6ES7132-4HB13-0AB0)

Properties

●Digital electronic module with two relay outputs

●Output current 5 A per output

●Substitute value

●Suitable for solenoid valves, DC contactors, and indicator lights

●Isolated from the supply voltage

●Normally opened and normally closed contacts

Note

If you connect an extra

-low voltage system (SELV/PELF) on one channel of the relay

subassembly, you can only use an extra

-low voltage system (SELV/PELF) on the other

channel.

General terminal assignment

Note

Terminals 4, 8, A4, A8, A3 and A7 are only available at specified terminal modules.

Pin assignment for 2RO NO/NC DC24..48V/5A AC24..230V/5A (6ES7132-4HB13-0AB0)

Terminal

Assignment

Terminal

Assignment

Notes

Common

•Commonn, NOCnor NCCn, channel n

•n.c.: Not connected (max. 30 VDC can be connected)

•AUX1: Protective-conductor terminal or potential bus (freely

usable up to 230 VAC)

Normally open

contact0

Normally

open contact1

Normally

closed contact0

Normally

closed con-

tact

n.c.

AUX1

Properties

2.1 Digital Electronic Module 2RO NO/NC DC24..48V/5A AC24..230V/5A (6ES7132-4HB13-0AB0)

Digital Electronic Module 2RO NO/NC DC24..48V/5A AC24..230V/5A (6ES7132-4HB13-0AB0)

Manual, 08/2019, A5E48281338-AA 7

Usable terminal modules

Usable terminal modules for 2RO NO/NC DC24..48V/5A AC24..230V/5A (6ES7132-4HB13-0AB0)

TM-E15C26-A1

(6ES7193-4CA50-

0AA0)

TM-E15C24-A1

(6ES7193-4CA30-

0AA0)

TM-E15C24-01

(6ES7193-4CB30-

0AA0)

TM-E15C23-01

(6ES7193-4CB10-

0AA0)

Spring terminal

TM-E15S26-A1

(6ES7193-4CA40-

0AA0)

TM-E15S24-A1

(6ES7193-4CA20-

0AA0)

TM-E15S24-01

(6ES7193-4CB20-

0AA0)

TM-E15S23-01

(6ES7193-4CB00-

0AA0)

Screw-type terminal

TM-E15N26-A1

(6ES7193-4CA80-

0AA0)

TM-E15N24-A1

(6ES7193-4CA70-

0AA0)

TM-E15N24-01

(6ES7193-4CB70-

0AA0)

TM-E15N23-01

(6ES7193-4CB60-

0AA0)

Fast Connect

Block diagram

Figure 2-1 Block diagram of the 2RO NO/NC DC24..48V/5A AC24..230V/5A

Properties

2.1 Digital Electronic Module 2RO NO/NC DC24..48V/5A AC24..230V/5A (6ES7132-4HB13-0AB0)

Digital Electronic Module 2RO NO/NC DC24..48V/5A AC24..230V/5A (6ES7132-4HB13-0AB0)

8Manual, 08/2019, A5E48281338-AA

Technical specifications 2RO NO/NC DC24..48V/5A AC24..230V/5A (6ES7132-4HB13-0AB0)

Dimensions and weight

Width (mm)

Weight

Approx. 50 g

Module-specific data

Supports isochronous operation No

Number of outputs

Cable length

•Unshielded Max. 600 m

•Shielded Max. 1000 m

Parameter length

3 bytes

Address space

1 byte

Address space (packed)

2 bits

Voltages, currents, potentials

Rated supply voltage L+ (from the power module)

24 V DC

Reverse polarity protection Current per channel

Yes

•Up to 50°C Max. 5 A

•Up to 60°C Max. 4 A

Electrical isolation

•Between the channels Yes

•Between channels and backplane bus Yes

•Between channels and supply voltage Yes

•Between the supply voltage and backplane

bus

Yes

Permissible potential difference

•Between channels and backplane bus 240 VAC

•Between channels and supply voltage 240 VAC

Insulation tested

•Between the supply voltage and backplane

bus

500 VDC

•Between channels and backplane bus 2500 VDC

•Between channels and supply voltage 2500 VDC

Current consumption

•From the power supply L+ max. 30 mA

•From backplane bus max. 10 mA

Power dissipation of the module

Typically 0.6 W

Properties

2.1 Digital Electronic Module 2RO NO/NC DC24..48V/5A AC24..230V/5A (6ES7132-4HB13-0AB0)

Digital Electronic Module 2RO NO/NC DC24..48V/5A AC24..230V/5A (6ES7132-4HB13-0AB0)

Manual, 08/2019, A5E48281338-AA 9

Dimensions and weight

Status, interrupts, diagnostics

Status display

Green LED per channel

Diagnostics functions

Status, interrupts, diagnostics

Status display

Green LED per channel

Diagnostics functions

Data for selecting an actuator

Output current

•Continuous thermal current Max. 5 A

•Minimum load current 8 mA

Connecting two outputs in parallel

•For redundant control of a load No

•To increase performance No

Control of a digital input

Yes

Switch rate

•For resistive load 2 Hz

•On inductive load 0.5 Hz

•For lamp load 2 Hz

Limitation (internal) of the voltage induced on

circuit interruption

Short-circuit protection of the output

1The relay outputs must be fused externally with 6 A. For installation in a hazardous area as speci-

fied by the National Electric Code (NEC) the fuse must only be removed with a suitable tool if the

subassembly is not in an explosive area.

Properties

2.1 Digital Electronic Module 2RO NO/NC DC24..48V/5A AC24..230V/5A (6ES7132-4HB13-0AB0)

Digital Electronic Module 2RO NO/NC DC24..48V/5A AC24..230V/5A (6ES7132-4HB13-0AB0)

10 Manual, 08/2019, A5E48281338-AA

Switching capacity and lifetime of the contacts

With an external protective circuit, the contacts will last longer than specified in the following

table.

The normally open and normally closed contacts of the relay have a different lifetime. The

table shows the switching capacity and lifetime of the contacts.

Table 2- 1 Switching capacity and lifetime of the contacts

Resistive load

Voltage

Current

Duty cycles (typ.)

Normally open con-

tact

Duty cycles (typ.)

Normally closed

contact

For resistive load

24 V DC

5.0 A

0.1 million

0.15 million

4.0 A

0.2 million

0.175 million

2.0 A

0.45 million

0.3 million

0.5 A

1.4 million

1.1 million

0.1 A

1.5 million

48 VDC

2.0 A

0.15 million

0.11 million

1.0 A

0.3 million

0.2 million

0.5 A

0.6 million

0.1 A

0.8 million

0.6 million

48 VAC

2.0 A

0.45 million

0.35 million

60 VAC

2.0 A

0.45 million

0.35 million

120 VAC

5.0 A

0.1 million

3.0 A

0.2 million

2.0 A

0.4 million

0.3 million

1.0 A

0.8 million

0.6 million

0.5 A

1.5 million

1.0 million

230 VAC

5.0 A

0.1 million

3.0 A

0.2 million

2.0 A

0.4 million

0.3 million

1.0 A

0.8 million

0.6 million

0.5 A

1.5 million

1.0 million

For inductive load in

accordance with IEC

947-5-1 DC 13/ AC

24 V DC

2.0 A

0.1 million

1.0 A

0.2 million

0.5 A

0.5 million

48 VDC

2.0 A

0.07 million

0.05 million

1.0 A

0.15 million

0.1 million

0.5 A

0.4 million

0.25 million

48 VAC

1.0 A

0.5 million

0.3 million

60 VAC

1.0 A

0.5 million

0.3 million

120 VAC

2.0 A

0.1 million

1.0 A

0.3 million

0.1 million

0.5 A

0.9 million

0.6 million

0.1 A

1.5 million

1.0 million

230 VAC

2.0 A

0.1 million

1.0 A

0.5 million

0.3 million

0.5 A

0.9 million

0.6 million

0.1 A

1.0 million

Autres manuels pour SIMATIC ET 200S

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Siemens Unité de contrôle

Siemens

Siemens SIMATIC ET 200SP Manuel utilisateur

Siemens

Siemens SINUMERIK 808D Guide d'installation

Siemens

Siemens SINUMERIK 802D Guide d'installation

Siemens

Siemens SINAMICS G120 Manuel utilisateur

Siemens

Siemens WF 723 C Mode d'emploi

Siemens

Siemens SINAMICS G120P CU230P-2 Guide de l'administrateur

Siemens

Siemens OMM-1 Manuel utilisateur

Siemens

Siemens ECOFAST 3RK1911-4AA Series Manuel utilisateur

Siemens

Siemens SIMATIC ET 200SP Manuel utilisateur

Siemens

Siemens SIMATIC ET 200S Manuel utilisateur

Siemens

Siemens SIWAREX MS Manuel utilisateur

Siemens

Siemens SINUMERIK 808D Manuel utilisateur

Siemens

Siemens SIMOCODE pro Manuel utilisateur

Siemens

Siemens 3VL92 Series Manuel utilisateur

Siemens

Siemens SIRIUS 3RA2711-DB0 Series Manuel utilisateur

Siemens

Siemens simatic ET 200MP Manuel utilisateur

Siemens

Siemens SIMATIC NET 6GK1110-1AA00 Manuel utilisateur

Siemens

Siemens PS-35 Manuel utilisateur

Siemens

Siemens ACVATIX VPF43 Series Manuel utilisateur

Siemens

Siemens SIRIUS ACT 3SU14 Manuel utilisateur

Siemens

Siemens Simatic S7-1500 Manuel de la liste des pièces

Siemens

Siemens SIMATIC IM 151/CPU Manuel utilisateur

Siemens

Siemens FDK:521H1134 Manuel utilisateur

Siemens

Siemens WF 705 Instructions d'utilisation et d'installation

Manuels Unité de contrôle populaires d'autres marques

Festo

Festo Compact Performance CP-FB6-E Manuel de la liste des pièces

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manuel utilisateur

JS Automation

JS Automation MPC3034A Manuel utilisateur

JAUDT

JAUDT SW GII 6406 Series Guide rapide

Spektrum

Spektrum Air Module System Manuel utilisateur

BOC Edwards

BOC Edwards Q Series Manuel utilisateur

KHADAS

KHADAS BT Magic Manuel utilisateur

Etherma

Etherma eNEXHO-IL Manuel utilisateur

PMFoundations

PMFoundations Attenuverter Manuel utilisateur

GEA

GEA VARIVENT Manuel utilisateur

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manuel utilisateur

Altronix

Altronix LINQ8PD Instructions de montage

Eaton

Eaton Powerware Series Manuel utilisateur

WAGO

WAGO 750-407/040-000 Manuel utilisateur

Sony

Sony CCU-590 Manuel utilisateur

Graco

Graco 25D614 Manuel utilisateur

Task Force Tips

Task Force Tips YE-RF-900 Manuel de programmation

Shini

Shini SPV-U Series Manuel utilisateur
