Siemens SIMATIC ET 200S Manuel utilisateur

Digital electronic module 2DI AC230V

ST (6ES7131-4FB00- 

0AB0)

_________________

SIMATIC

ET 200S distributed I/O

Digital electronic module 2DI AC230V ST

(6ES7131-4FB00-0AB0)

Manual

10/2010

A5E01077176-02

Preface

Properties

Diagnostics

Legal information

Warning notice system

This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent

damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert

symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are

graded according to the degree of danger.

DANGER

indicates that death or severe personal injury will result if proper precautions are not taken.

WARNING

indicates that death or severe personal injury may result if proper precautions are not taken.

CAUTION

with a safety alert symbol, indicates that minor personal injury can result if proper precautions are not taken.

CAUTION

without a safety alert symbol, indicates that property damage can result if proper precautions are not taken.

NOTICE

indicates that an unintended result or situation can occur if the corresponding information is not taken into

account.

If more than one degree of danger is present, the warning notice representing the highest degree of danger will

be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to

property damage.

Qualified Personnel

The product/system described in this documentation may be operated only by personnel qualified for the specific

task in accordance with the relevant documentation for the specific task, in particular its warning notices and

safety instructions. Qualified personnel are those who, based on their training and experience, are capable of

identifying risks and avoiding potential hazards when working with these products/systems.

Proper use of Siemens products

Note the following:

WARNING

Siemens products may only be used for the applications described in the catalog and in the relevant technical

documentation. If products and components from other manufacturers are used, these must be recommended

or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and

maintenance are required to ensure that the products operate safely and without any problems. The permissible

ambient conditions must be adhered to. The information in the relevant documentation must be observed.

Trademarks

All names identified by ® are registered trademarks of the Siemens AG. The remaining trademarks in this

publication may be trademarks whose use by third parties for their own purposes could violate the rights of the

owner.

Disclaimer of Liability

We have reviewed the contents of this publication to ensure consistency with the hardware and software

described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the

information in this publication is reviewed regularly and any necessary corrections are included in subsequent

editions.

Siemens AG

Industry Sector

Postfach 48 48

90026 NÜRNBERG

GERMANY

A5E01077176-02

Ⓟ 11/2010

Technical data subject to change

Digital electronic module 2DI AC230V ST (6ES7131-4FB00-0AB0)

Manual, 10/2010, A5E01077176-02 3

Preface

Purpose of the manual

This manual supplements the

ET 200S Distributed I/O System

Operating Instructions.

General functions for the ET 200S are described in the ET 200S Distributed I/O System

Operating Instructions (http://support.automation.siemens.com/WW/view/en/1144348).

The information in this document along with the operating instructions enables you to

commission the ET 200S.

Basic knowledge requirements

To understand these operating instructions you should have general knowledge of

automation engineering.

Scope of the manual

This manual applies to this ET 200S module. It describes the components that are valid at

the time of publication.

Recycling and disposal

Thanks to the fact that it is low in contaminants, this ET 200S module is recyclable. For

environmentally compliant recycling and disposal of your electronic waste, please contact a

company certified for the disposal of electronic waste.

Additional support

If you have any questions relating to the products described in this manual and do not find

the answers in this document, please contact your local Siemens representative

(http://www.siemens.com/automation/partners).

A guide to the technical documentation for the various SIMATIC products and systems is

available on the Internet. (http://www.siemens.com/simatic-docu).

The online catalog and ordering systems are available on the Internet

(http://www.siemens.com/automation/mall).

Training center

We offer courses to help you get started with the ET 200S and the SIMATIC S7 automation

system. Please contact your regional training center or the central training center in

D -90327, Nuremberg, Germany (http://www.siemens.com/sitrain).

Preface

Digital electronic module 2DI AC230V ST (6ES7131-4FB00-0AB0)

4 Manual, 10/2010, A5E01077176-02

Technical Support

You can contact Technical Support for all Industry Automation products by means of the

Internet Web form for the Support Request

(http://www.siemens.com/automation/csi_en_WW/support_request).

Additional information about Siemens Technical Support is available on the Internet

(http://www.siemens.com/automation/csi_en_WW/service).

Service & Support on the Internet

In addition to our documentation, we offer a comprehensive knowledge base on the Internet

(http://www.siemens.com/automation/csi_en_WW/support).

There you will find:

● Our Newsletter, which constantly provides you with the latest information about your

products.

● The right documentation for you using our Service & Support search engine.

● The bulletin board, a worldwide knowledge exchange for users and experts.

● Your local contact for Automation & Drives in our contact database.

● Information about on-site services, repairs, spare parts, and lots more.

Digital electronic module 2DI AC230V ST (6ES7131-4FB00-0AB0)

Manual, 10/2010, A5E01077176-02 5

Table of contents

Preface ...................................................................................................................................................... 3

1 Properties .................................................................................................................................................. 7

1.1 Digital electronic module 2DI AC230V ST (6ES7131-4FB00-0AB0).............................................7

2 Diagnostics.............................................................................................................................................. 11

2.1 Diagnostics using LED display.....................................................................................................11

Table of contents

Digital electronic module 2DI AC230V ST (6ES7131-4FB00-0AB0)

6 Manual, 10/2010, A5E01077176-02

Digital electronic module 2DI AC230V ST (6ES7131-4FB00-0AB0)

Manual, 10/2010, A5E01077176-02 7

Properties 1

1.1 Digital electronic module 2DI AC230V ST (6ES7131-4FB00-0AB0)

Properties

● Digital electronic module with two inputs

● Rated input voltage 230 VAC

● Suitable for switches

General terminal assignment

Note

Terminals 4, 8, A4, A8, A3 and A7 are only available at specified terminal modules.

Terminal assignment for 2DI AC230V ST (6ES7131-4FB00-0AB0)

Terminal Assignment Terminal Assignment Notes

1 DI

0 5 DI

2 L1 6 L1

3 N 7 N

4 n.c. 8 n.c.

A4 AUX1 A8 AUX1

A3 AUX1 A7 AUX1

DIn: Input signal, Channel n

L1: Sensor power supply 230 VAC

N: Neutral conductor

n.c.: Not connected (max. 30 V DC can be connected)

AUX1: Protective-conductor terminal or potential bus (freely usable

up to 230 VAC)

Properties

1.1 Digital electronic module 2DI AC230V ST (6ES7131-4FB00-0AB0)

Digital electronic module 2DI AC230V ST (6ES7131-4FB00-0AB0)

8 Manual, 10/2010, A5E01077176-02

Usable terminal modules

Usable terminal modules for 2DI AC230V ST (6ES7131-4FB00-0AB0)

TM-E15C26-A1

(6ES7193-4CA50-

0AA0)

TM-E15C24-A1

(6ES7193-4CA30-

0AA0)

TM-E15C24-01

(6ES7193-4CB30-

0AA0)

TM-E15C23-01

(6ES7193-4CB10-

0AA0)

Spring terminal

TM-E15S26-A1

(6ES7193-4CA40-

0AA0)

TM-E15S24-A1

(6ES7193-4CA20-

0AA0)

TM-E15S24-01

(6ES7193-4CB20-

0AA0)

TM-E15S23-01

(6ES7193-4CB00-

0AA0)

Screw-type terminal

TM-E15N26-A1

(6ES7193-4CA80-

0AA0)

TM-E15N24-A1

(6ES7193-4CA70-

0AA0)

TM-E15N24-01

(6ES7193-4CB70-

0AA0)

TM-E15N23-01

(6ES7193-4CB60-

0AA0)

Fast Connect



$8;



































8;





























', ', ',

/ /

/

3($8;

ZLUH ZLUH ZLUH

&RQQHFWLRQH[DPSOHV

Block diagram

3 1













/

3

(76

EDFNSODQH

EXV

&RQQHFWLRQ

%DFNSODQHEXV

Figure 1-1 Block diagram of the 2DI AC230V ST

Properties

1.1 Digital electronic module 2DI AC230V ST (6ES7131-4FB00-0AB0)

Digital electronic module 2DI AC230V ST (6ES7131-4FB00-0AB0)

Manual, 10/2010, A5E01077176-02 9

Technical data 2DI AC230V ST (6ES7131-4FB00-0AB0)

Dimensions and weight

Width (mm) 15

Weight Approx. 31 g

Module-specific data

Supports isochronous operation No

Number of inputs 2

Length of cable

Unshielded Max. 600 m

Shielded Max. 1,000 m

Parameter length 3 bytes

Address space 1 byte

Address space (packed) 2 bits

Voltages, currents, potentials

Supply voltage (from the power module) 230 VAC

Frequency 47 Hz to 63 Hz

Electrical isolation

Between the channels No

Between the channels and backplane bus Yes

Permissible potential difference

between M internal and inputs 1500 VAC

Insulation test voltage 2500 V DC

Power dissipation of the module Typically 0.7 W

Status, interrupts, diagnostics

Status display Green LED per channel

Diagnostics function No

Data for selecting a sensor

Input voltage

Rated value 230 VAC

For signal "1" 164 to 264 VAC

For signal "0" 0 VAC to 40 VAC

Input current

At signal "1"

5 mA to 15 mA

Input delay

At "0" to "1" 15 ms

At "1" to "0" 45 ms

Input characteristic curve According to IEC 61131, Type 1

Connection of 2-wire BEROs No

Permitted quiescent current Max. 2 mA

Properties

1.1 Digital electronic module 2DI AC230V ST (6ES7131-4FB00-0AB0)

Digital electronic module 2DI AC230V ST (6ES7131-4FB00-0AB0)

10 Manual, 10/2010, A5E01077176-02
