SICK I110P Manuel utilisateur

OPERATING INSTRUCTIONS

i110P, i110R

Safety position switch

Described product

i110P, i110R

Manufacturer

SICK AG

Erwin-Sick-Str. 1

79183 Waldkirch

Germany

Legal information

This work is protected by copyright. Any rights derived from the copyright shall be

reserved for SICK AG. Reproduction of this document or parts of this document is

only permissible within the limits of the legal determination of Copyright Law. Any modi‐

fication, abridgment or translation of this document is prohibited without the express

written permission of SICK AG.

The trademarks stated in this document are the property of their respective owner.

Original document

This document is an original document of SICK AG.

2O P E R A T I N G I N S T R U C T I O N S | i110P, i110R 8027232/1CY6/2022-09-14 | SICK

Subject to change without notice

Contents

1 Scope.................................................................................................. 4

2 On safety............................................................................................. 5

2.1 Qualified safety personnel....................................................................... 5

2.2 Applications of the safety switches......................................................... 5

2.3 Correct use................................................................................................ 5

2.4 General protective notes and protective measures............................... 6

3 Mounting............................................................................................. 7

3.1 Change actuator entry direction.............................................................. 8

3.2 Protection against surroundings.............................................................. 9

4 Electrical installation........................................................................ 10

5 Commissioning.................................................................................. 12

5.1 Tests before the first commissioning...................................................... 12

5.2 Periodic technical inspections................................................................. 12

6 Disposal.............................................................................................. 13

7 Technical specifications................................................................... 14

7.1 General system data................................................................................ 14

7.2 Dimensional drawings.............................................................................. 15

8 Conformities and certificates.......................................................... 16

8.1 EU declaration of conformity.................................................................... 16

8.2 UK declaration of conformity................................................................... 16

CONTENTS

8027232/1CY6/2022-09-14 | SICK O P E R A T I N G I N S T R U C T I O N S | i110P, i110R 3

Subject to change without notice

1 Scope

These operating instructions are applicable to the i110R and i110P safety position

switches.

These operating instructions are original operating instructions.

1 SCOPE

4O P E R A T I N G I N S T R U C T I O N S | i110P, i110R 8027232/1CY6/2022-09-14 | SICK

Subject to change without notice

2 On safety

This chapter deals with your own safety and the safety of the equipment operators.

bThese operating instructions are applicable to the i110R and i110P safety position

switches.

The national/international rules and regulations apply to the installation, commission‐

ing, use and periodic technical inspections of the safety switches, in particular

•the Machinery Directive,

•the Low Voltage Directive,

•the Work Equipment Directive,

•the safety regulations as well as

•the work safety regulations/safety rules.

Manufacturers and operators of the machine on which the protective devices are used

are responsible for obtaining and observing all applicable safety regulations and rules.

2.1 Qualified safety personnel

Only qualified safety personnel are authorised to mount, install and commission the

safety position switch i110R/i110P. Qualified safety personnel are defined as persons

who

•have undergone the appropriate technical training

and

•have been instructed by the responsible machine owner in the operation of the

machine and the current valid safety guidelines

and

•who have access to these operating instructions.

2.2 Applications of the safety switches

Safety position switches of type series i110R/i110P are position switches with forced

opening that are activated by roller levers (R) or roller tappets (P). They meet the

requirements according to EN 60947-5-1.

•the dangerous state of the machine can only be switched on when the guard is

closed,

•a STOP command is triggered if the protective device is opened while the machine

is operating.

For the control this means that

•activation commands that cause dangerous conditions, may only become active

when the guard is in the protective position and the dangerous conditions have

been terminated before the protective position is cancelled.

Prior to the use of safety switches, a risk assessment must be performed on the

machine.

2.3 Correct use

Safety position switch i110R/i110P must only be applied as defined in section 2.2

“Applications of the safety position switch”. The safety position switch must only be

used on the machine where it has been fitted, installed and by qualified safety person‐

nel and in compliance with these operating instructions.

ON SAFETY 2

8027232/1CY6/2022-09-14 | SICK O P E R A T I N G I N S T R U C T I O N S | i110P, i110R 5

Subject to change without notice

If the device is used for any other purposes or modified in any way – also during

mounting and installation – any warranty claim against SICK AG shall become void.

The correct use includes the regular inspection of the protective device by qualified

safety personnel in accordance with section 5.2.

2.4 General protective notes and protective measures

Safety position switches serve the purpose of protecting individuals. Tampering or

incorrect installation may result in severe personal injury.

WARNING

Do not override safety position switches (by bridging contacts), turn them from their

protective position, remove them or defeat them in any other way.

2 ON SAFETY

6O P E R A T I N G I N S T R U C T I O N S | i110P, i110R 8027232/1CY6/2022-09-14 | SICK

Subject to change without notice

3 Mounting

WARNING

Mounting is only allowed to be performed by qualified safety personnel.

bPay attention to EN ISO 14119 on mounting the safety switch.

Mount the safety position switch such that

•It is difficult to access by operating personnel when the protective equipment is

open.

•it can be inspected and replaced.

WARNING

Do not use the safety position switch as a mechanical stop.

WARNING

The safety position switch must be adequately secured against movement.

In order to meet these requirements,

•the mounting components must be reliable and require a tool to be released,

•the use of elongated holes must be restricted to the initial settings,

•the roller lever must be mounted on the motor shaft with a positive fit.

bAssemble safety switch with 2 bolts M4 and tighten screws at 2.5–3 Nm.

bTake note of the data in the switch-path diagram when mounting the radial cam.

MOUNTING 3

8027232/1CY6/2022-09-14 | SICK O P E R A T I N G I N S T R U C T I O N S | i110P, i110R 7

Subject to change without notice

Contacts open Contacts closed

Idle position

End

position

Figure 1: Switching position diagram (RA = roller lever, PA = roller tappet)

3.1 Change actuator entry direction

1. Undo screws on actuating head.

2. Set direction required (4 × 90°).

3. Tighten screws to 1.2 Nm.

3 MOUNTING

8O P E R A T I N G I N S T R U C T I O N S | i110P, i110R 8027232/1CY6/2022-09-14 | SICK

Subject to change without notice

3.2 Protection against surroundings

A precondition for a durable and perfect safety function is the protection of the

actuating head against penetration by foreign matter such as shavings, sand, abrasive

materials etc.

Cover the control slot, the actuator and the type label when painting.

MOUNTING 3

8027232/1CY6/2022-09-14 | SICK O P E R A T I N G I N S T R U C T I O N S | i110P, i110R 9

Subject to change without notice

4 Electrical installation

DANGER

The electrical connection is only allowed to be made by qualified safety personnel.

bInstall cable connector M20 with the required IP protection.

bConnection see figure 2

bOperate all contact pairs within the same voltage range.

bConnect all live parts on one side of the contact block.

bTighten clamping screws to 0.9 ... 1.0 Nm.

bCheck sealing at conduit entry.

bClose switch lid and tighten screws.

4 ELECTRICAL INSTALLATION

10 O P E R A T I N G I N S T R U C T I O N S | i110P, i110R 8027232/1CY6/2022-09-14 | SICK

Subject to change without notice
