SEWOO LK-P43II Manuel utilisateur

J. STEPHEN Co., Ltd.

28-6, Gajangsaneopdong-ro, Osan-si, Gyeonggi-do, 18103, Republic of Korea

TEL : +82-31-8077-5000 FAX : +82-31-459-8880

http://www.miniprinter.com

P43Ⅱ(Non Peeler) Rev. B 10/19

All specifications are subject to change without notice

USER’S MANUAL / Non Peeler

MODEL : LK-P43

Ⅱ

Following information shall be included in the manual

Information to User;

Caution:

the user that changes or modifications not expressly approved by the J. STEPHEN Lab., Ltd.

responsible for compliance could void the user's authority to operate the equipment.

NOTE:

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules.These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment

generates, uses and can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception,

which can be determined by turning the equipment off and on, the user is encouraged to try

to correct the interference by one or more of the following measures:

—Reorient or relocate the receiving antenna.

—Increase the separation between the equipment and receiver.

—Connect the equipment into an outlet on a circuit different from that to which

the receiver is connected.

—Consult the dealer or an experienced radio/TV technician for help

Responsible Party;

The responsible party for Supplier's Declaration of Conformity must be located within

the United States, so you have to include following information in manual.

Company name :

J. STEPHEN Co., Ltd. (Manager : Hong yul Jun)

Address :

20280 S. Vermont Ave. STE 200,Torrance, CA 90502 | USA

TEL / FAX No :

(TEL) +310-561-8030 / (FAX) +82-31-459-8880

Homepage :

http://www.miniprinter.com

Risk of explosion if battery is replaced by an incorrectly type.

Dispose of used battery according to the local disposal instructions.

This device complies with part 15 of the FCC Rules.

Operation is subject to the following two conditions.

1) This device may not cause harmful interference, and

2) This device must accept any interference received,

including interference that may cause undesired operation.

Table of Contents

1. Safety Precautions 4

Unpacking

3. Product Overview 7

4. Installation & Usage 8

4-1. Display 8

4-2. Installing the Battery 9

4-3. Removing the Battery 10

4-4. Charging the Battery 11

4-5. Battery charger usage (Optional) 12

4-6. Car charger usage (Optional) 13

4-7. Belt Clip Usage 14

4-8. Interface Cap Installation 15

4-9. Paper Roll Installation 16

4-10. Install / Uninstall the External Paper Guides 18

4-11. Shoulder Strap Installation (Optional) 20

4-12. Diagnostic Test 21

5. Peripheral Connection 23

5-1. Bluetooth Connection (Optional) 23

5-2. Wi-Fi Connection (Optional) 23

5-3. Interface Cable Connection 24

6. Printer Cleaning 25

6-1. Print-Head Cleaning 25

6-2. Platen Roller Cleaning 26

7. Printer Specication 27

For better safety and reliability, adhere to the following precautionary measures.

Read and follow the instructions carefully before operation of the product.

1. Safety Precautions

WARNING

Failure to follow these instructions could result in re, electric shock, other

injuries, or property damage.

Indication

Prohibition

(Potential risk of electric shock or re)

Must follow

Do not disassemble Unplug the power from the

outlet

Grounding to prevent electric

shock

Do not handle the product

with wet hands

Do not pull or touch the power plug with

wet hands.

Do not bend the wire and do not allow the

wire to be pinched or crushed by heavy

objects.

If a power plug is broken or a plug is cut or

worn, do not use it.

Do not overload an electrical outlet.

WARNING

Failure to follow these instructions could result in re, electric shock, other

injuries, or property damage.

Failure to follow these instructions could result in re, electric shock,

other injuries, or property damage.

(Turn off the power using the power button)

(May cause damage or injury)

(Potential risk of re or unit malfunction)

(Potential risk of re or property damage)

(Potential risk of electric shock or damage)

(Potential risk of malfunction, electric shock,

or re. When the product needs to be repaired,

please contact your reseller)

Dealer

Do not unplug the power cable to turn off

the product.

Do not install the product on an unstable

or inclined surface.

If the product needs to be repaired,

please contact your reseller.

Avoid excessive shock or drops.

Keep product away from the water and

other material.

Do not disassemble, repair or modify the

product.

CAUTION

2. Unpacking

Printer Battery Belt Clip

AC cord

Optional

Standard

USB Cable

Quick Reference

Adaptor

Paper

Shoulder Strap

Serial Cable

Battery Cradle

(Charging Cradle)

Car Adapter 4BC-XX

(Charging Cradle)

ERROR

FULLEMPTYERROR

FULLEMPTY

ERROR

FULLEMPTYERROR

FULLEMPTY

SHOULDER

STRAP RING

3. Product Overview

CHARGER

CONNECTOR

COVER OPEN

BUTTON

Front

Bottom

BATTERY

BELT CLIP

CONNECTOR

SERIAL

USB

DISPLAY
