SEWOO LK-B10 Manuel utilisateur

All specifications are subject to change without notice

4” DESKTOP LABEL PRINTER

MODEL : LK-B10

1

A software tool is available to configure the printer settings on AURES technical

website: www.aures-support.fr

2

Table of Contents

1. Unpacking 3

2. Inspecting the printer 4

3. Attaching Power Supply 6

4. Hooking Up the printer and Computer 7

5. Loading the Paper 8

6. Loading Ribbon 10

7. Self Test 12

8. Interface 13

9. Media Roll Size 15

10. Labels 16

11. Tags and Strip with Slots 17

12. Tags and Strip with Black Marks 18

13. Plain Continuous Stock 19

14. Specications 20

15. Command List 22

3

1. Unpacking

Printer Power Cord(1EA)

Power Supply

Sample LabelsSample Ribbon

Ribbon Spindle (2EA) Paper Spindle Core

Manual

4

2. Inspecting the printer

Power Supply

Printer Head

Head Release Lever

Paper Sensor

Bottom Cover

Button

Interface Connectors Power Switch

Paper width Guide

Upper Cover Knob

5

Open the upper cover by pushing the knob in

the direction of the arrow

Make sure to be careful of the HOT head

Make sure you hear the closing sound of the

paper upper guide.

Close the upper cover and make sure you hear

the closing sound of the upper cover.

Opening the printer

Closing the paper upper guide Closing the upper cover

6

1 2

34

Check the specification of the AC power cord

if it is correct with your power system

Turn off the power of the printer and connect

the power supply to the printer

Connect the AC power cord to the power supply Insert a plug into the outlet

3. Attaching Power Supply

220VAC

115VAC

7

Make sure the printer is turned off then connect the printer to the PC

4. Hooking Up the printer and computer

USB(Option)

Serial

Parallel

-Computer-

-Printer-

8

1 2

34

Turn off the printer and open the upper cover by

pushing the in the direction of the arrow.

Open the paper width guide by pushing it to the

right & left sides.

5. Loading the Paper

Rise up the paper upper guide by pulling the

head release lever

Pull out one of the adjustable width tabs.

Insert a paper roll replace the tab and center.

Paper Fixing Tap

9

5 6

78

Adjust the paper width guide to meet the paper

width

Close the upper cover and make sure you hear

the closing sound of the upper cover.

Insert paper roll into the printer

Make sure you hear the closing sound of the

paper upper guide.
