Table of Contents

1. Parts Identications 3

2. Setting up the printer 4

2.1 Unpacking 4

2.2 Connecting the cables 5

2.2.1 Interface Connector 6

2.2.2 Cash Drawer Connector 7

2.3. Loading the Roll Paper 8

3. Control panel and other functions 11

3.1 Control panel 11

3.2 Error Indicators 11

4. Self Test 12

5. ASCII Print 13

6. Select Baudrate Mode 13

7. Hexadecimal Dump 14

8. Peripherals Connection 15

9. Printer cleaning 16

10. Specications 17

11. Command List 20

12. Utilities 22

13. S/W 23

1. Parts Identications

Features LED indicators

to indicate printer status

and switches to operate

the printer.

CONTROL LABEL

Open this cover to load

or replace paper.

TOP COVER

Used to turn on/o

power to the printer

POWER SWITCH

INTERFACE

CONNECTOR(SERIAL)

INTERFACE

CONNECTOR(USB)

PERIPHERAL DRIVE

CONNECTOR

POWER CONNECTOR

2. Setting Up the Printer

2.1. Unpacking

Your printer box should include these items. If any items are damaged or missing,

please contact your dealer for assistance.

The Printer CD Roll Paper

Adaptor(Optional) Interface Cable(optional)

2.2. Connecting the Cables

You can connect up the cables required for printing to the printer.

They all connect to the connector panel on the back of the printer, which is shown below :

INTERFACE

CONNECTOR(SERIAL)

PERIPHERAL DRIVE

CONNECTOR

POWER CONNECTOR

For connection to a host

computer.

For connection to a host

computer.

For connection of the AC

adapter. Never unplug

the AC adapter while the

printer is on.

Connects to peripheral units

such as cash drawers, etc.

Do not connect this to a

telephone.

INTERFACE

CONNECTOR(USB)

Before connecting any of the cables, make sure that both the printer and the com-

puter are turned o.
