INSTRUCTIONS FOR INSTALLATION AND USE

English

Version 09/23 ID no. 1-041-284

Sauna control unit

Pro D

Pro D2 1-041-288 / PRO-D2

Pro D2 white 1-041-290 / PRO-D2W

D2i 1-041-291 / PRO-D2I

Pro D2i white 1-041-292 / PRO-D2IW

Pro D3 1-041-293 / PRO-D3

Pro D3 white 1-041-294 / PRO-D3W

Pro D3i 1-041-295 / PRO-D3I

Pro D3i white 1-041-296 / PRO-D3IW

Table of Contents

1. About this instruction manual 5

2. Important information for your safety 6

2.1. Intended use 6

2.2. Safety information for the installer 7

2.3. Safety information for the user 8

3. Product description 9

3.1. Scope of delivery 9

3.2. Optional accessories 9

3.3. Product features 10

3.4. Sauna operating modes 12

3.5. Sensor operating modes 12

4. Installation 14

4.1. Installing the power supply unit 14

4.2. Installing the control panel 16

4.3. Installing the heater sensor F1 with overheat cut-out 19

4.4. Installing the bench sensor F2 (optional) 19

4.5. Installing humidity/temperature sensor FTS2 (optional, Pro D3 / Pro

D3i only) 20

4.6. Installing foil sensor FTS2 (optional, Pro D2i / Pro D3i only) 20

5. Electrical connection 21

5.1. Connecting the power supply cable, heater and vaporizer 22

5.2. Connecting the control panel 22

5.3. Connecting the light 22

5.4. Connecting a fan (optional) 23

5.5. Connecting an additional output (optional, Pro D2i / Pro D3i only) 23

5.6. Connecting the power booster (optional) 24

5.7. Connecting the heater sensor F1 24

5.8. Installing bench sensor F2 (optional) 24

5.9. Connecting the humidity/temperature sensor FTS2

(optional, Pro D3 / Pro D3i only) 25

5.10. Connecting the foil sensor (optional, Pro D2i / Pro D3i only) 25

5.11. Connectingthesafetyshut-o󰀨/doorsensor 26

5.12. Remote start 26

5.13. Status output 26

5.14. Finishing the installation 26

6. Testing 27

7. Connection diagram 28

8. Commissioning 29

8.1. Setting the function selection switch 29

8.2. Settings in the technician menu 31

9. Controls 38

9.1. Control panel Pro D2 38

9.2. Control panel Pro D2i 38

9.3. Control panel Pro D3 39

9.4. Control panel Pro D3i 39

9.5. Additional output control panel Pro D (optional) 40

9.6. Power unit 40

10.Operation 41

10.1. Switching on the light on the power unit (cleaning lights) 41

10.2. Switching on the power unit 41

10.3. Activating the control panel 42

10.4. Additional output control panel Pro D (optional) 42

10.5. Starting sauna mode 43

10.6. Switchingo󰀨saunamode 43

10.7. Starting combi mode (Pro D3 / Pro D3i only) 43

10.8. Switchingo󰀨combimode(ProD3/ProD3ionly) 44

10.9. Starting additional output (Pro D2i / Pro D3i only) 45

10.10.Switchingo󰀨additionaloutput(ProD2i/ProD3ionly) 47

10.11.Switching on the light 48

10.12.Switchingo󰀨thelight 48

10.13.Starting the fan 49

10.14.Switchingo󰀨fan 49

10.15.Setting the preset time 50

10.16.Cancelling the preset time feature 50

10.17.Setting the duration 51

10.18.Cancelling the post-drying program (Pro D3 / Pro D3i only) 51

10.19.Activating standby for remote operation 52

10.20.Switchingo󰀨functions 53

10.21.Deactivating the control panel 53

10.22.Switchingo󰀨thepowerunit 53

11.User programs 54

11.1. Preset user programs 54

11.2. Accessing user programs 54

11.3. Creating your own user programs 55

12.The Eco-function 56

13.Cleaning and maintenance 57

13.1. Cleaning 57

13.2. Maintenance 57

14.Disposal 57

15.Troubleshooting 58

15.1. Error messages 58

15.2. Low-water display (Pro D3 / Pro D3i only) 59

15.3. Fuses 59

16.Technical data 60

16.1. Power unit 60

16.2. Control panel Pro D2 / Pro D2i / Pro D3 / Pro D3i 61

16.3. Additional output control panel Pro D (optional) 61

Instructions for installation and use p. 5/31

1.About this instruction manual

Read these installation and operating instructions carefully and keep them within

reach of the sauna control unit. This ensures that you can refer to information on

safety and operation at any time.

Symbols used for warning notices

In these instructions for installation and use, a warning notice located next to

an activity indicates that this activity poses a risk. Always observe the warning

notices. This prevents damage to property and injuries, which in the worst case

may be fatal.

The warning notices contain keywords, which have the following meanings:

DANGER!

Serious or fatal injury will occur if this warning notice is not observed.

WARNING!

Serious or fatal injury can occur if this warning notice is not observed.

CAUTION!

Minor injuries can occur if this warning notice is not observed.

ATTENTION!

This keyword is a warning that damage to property can occur.

Other symbols

This symbol indicates tips and useful information.

These installation and operating instructions can also be found in the

downloads section of our website: www.sentiotec.com/downloads.

Instructions for installation and use p. 6/31

2.Important information for your safety

The sauna control units of the Pro D series have been produced

in accordance with the applicable safety rules and regulations.

However, hazards may arise during use. Therefore adhere to the

followingsafetyinformationandthespecicwarningnoticesin

the individual chapters. Also observe the safety information for the

devices connected.

2.1. Intended use

The sauna control units of the Pro D series are used exclusively for

operating and controlling the sauna functions in accordance with

the technical data.

The sauna control units of the Pro D series may only be used for

operatingandcontrollingasaunaheaterwhichhasbeencertied

as satisfying the combustion test described in paragraph 19.101 of

EN 60335-2-53. If the heater does not meet this requirement, an

appropriate safety precaution must be taken (for example: safety

shut-o󰀨/doorsensor,see5.11onpage26).

The sauna control units of the Pro D series may only be used for

operating and controlling 3 heating circuits with a maximum heat-

ing capacity of 3.5 kW per heating circuit. The maximum vaporizer

output is 3.5 kW. The maximum additional output totals 3.5 kW.

Any use exceeding this scope is considered improper use. Improper

use can result in damage to the product, severe injuries or death.

Instructions for installation and use p. 7/31

2.2. Safety information for the installer

●Installationmayonlybeperformedbyaqualiedelectricianor

similarlyqualiedperson.

●Work on the sauna control unit may only be performed when the

power has been disconnected.

●A fully disconnecting all-pole isolating device compliant with

overvoltagecategoryIIImustbettedonsite.

●The sauna control unit must be installed outside the sauna cabin

at a height of approx. 1.70 m or in accordance with the rec-

ommendation issued by the sauna manufacturer. The ambient

temperature must be within a range spanning -10 °C to +40 °C.

●The heater sensor must be installed in such a way that it is not

a󰀨ectedbyinowingair.

●The heater supply cable must have a minimum cross-sectional

area of 2.5 mm2and be temperature-resistant up to 150 °C.

●Also comply with the regulations applicable at the installation

location.

●For your own safety, consult your supplier in the event of prob-

lemsthatarenotexplainedinsu󰀩cientdetailintheinstallation

instructions.

Instructions for installation and use p. 8/31

2.3. Safety information for the user

●The sauna control unit must not be used by children under 8 years

of age.

●The sauna control unit may be used by children over 8 years of

age, by persons with limited psychological, sensory or mental

capabilities or by persons with lack of experience/knowledge,

but only if:

– They are supervised.

– They have been shown how to use the device safely and

are aware of the hazards that could occur.

●Children must not play with the sauna control unit.

●Children under 14 years of age may only clean the sauna control

unit if they are supervised.

● Forhealthreasons,donotusethesaunawhenundertheinu-

ence of alcohol, medication or drugs.

● Makesurethatnoammableobjectshavebeenplacedonthe

sauna heater before the sauna control unit is switched on.

● Makesurethatnoammableobjectshavebeenplacedonthe

sauna heater before activating the preset time function or the

standby mode for remote start.

●Makesurethatnoammableobjectshavebeenplacedonor

in front of the infrared heater before the sauna control unit is

switched on.

●Makesurethatnoammableobjectshavebeenplacedonor

in front of the infrared heater before activating the preset time

function or the stand-by mode for the remote start.

●For your own safety, consult your supplier in the event of prob-

lemsthatarenotdescribedinsu󰀩cientdetailintheoperating

instructions.

Instructions for installation and use p. 9/31

3.Product description

3.1. Scope of delivery

●Control panel (depending on version Pro D2 / D2i / D3 / D3i)

●Power unit

●Heater sensor with integrated overheat cut-out

●Sensor cables

●Installation material

●Wire jumper for bridging terminals V1 and Wm for combi heaters without

low-watershut-o󰀨

3.2. Optional accessories

●Bench sensor (1-009-231 / O-F2)

●Humidity/temperature sensor (1-010-081 / O-FTS2)

●Foil sensor (1-014-445 / P-ISX-FF)

●Power booster (1-008-779 / O-S2-18, 1-009-280 / O-S2-30)

●Safety shutdown (SFE-xxxxx)

●Home door sensor (1-052-723 / SAB00103)

●Control panel Pro D2 (1-040-159/PRO-D2-CU)

●Control panel Pro D2 white (1-040-161 / PRO-D2W-CU)

●Control panel Pro D2i (1-040-163 / PRO-D2I-CU)

●Control panel Pro D2i white (1-040-165 / PRO-D2IW-CU)

●Control panel Pro D3 (1-040-167 / PRO-D3-CU)

●Control panel Pro D3 white (1-040-169 / PRO-D3W-CU)

●Control panel Pro D3i (1-1040-173 / PRO-D3I-CU)

●Control panel Pro D3i white (1-1-040-173 /PRO-D3IW-CU)

●Additional output control panel Pro D (1-040-174 / PRO-DA-CU)

●Additional output control panel Pro D white (1-040-175 / PRO-DAW-CU)

●Pro D BUS converter RS485 (1-053-348 / BUS-CON-D)

● MySentioWi(1-053-313/S-WIFI01)

●MySentio Remote (1-053-314 / S-WIFI02)

Instructions for installation and use p. 10/31

3.3. Product features

Pro D2 / Pro D2 white

The sauna control unit Pro D2 / Pro D2 white features the following functions:

●Regulation of sauna heaters with a heating output of up to 10.5 kW in the

temperature range spanning 30 °C to 110 °C.

●A power booster allows the maximum switching capacity to be increased from

10.5 kW to 18 kW or 30 kW.

●Optional dimming or switching of a cabin light (up to 100 W)

●Optional modulation or switching of a fan (up to 100 W)

●Remote start function

●Door monitoring system

●Status output

●Preset time function

The maximum heating period can be set to 6 h, 12 h, 18 h or 24 h.

●User programs

The user programs enable favourite sauna settings to be saved and accessed

again.Thereare5presetuserprogramsavailablewhichcanbemodied

according to user requirements.

●Automatic heating time limit

The sauna control unit shuts down automatically after the maximum heating

time for safety reasons. The maximum heating period can be set to 6 h, 12 h,

18 h or 24 h.

●Overheat cut-out

The overheat cut-out is installed in the housing for the heater sensor. If a

defect causes the sauna heater to continue heating after reaching the pre-

ferredtemperature,theoverheatcut-outswitchesthesaunaheatero󰀨ata

temperature of around 139 °C.

PRO D3 / PRO D3 white

Same functional scope as the Pro D2 / Pro D2 white, with the following additional

features:

●Regulation of combi-model sauna heaters with a heating output of up to 10.5 kW

and vaporizer output of up to 3.5 kW in the temperature range spanning 30 °C

to 110 °C and a humidity range spanning 0% to 100%.

●Post-drying program

After operation in combined mode, the post-drying program starts automat-

ically to prevent mould or rot from forming in the sauna cabin. This involves

heating the sauna cabin to 80°C with the fan running.

The duration can be set from OFF - 60 minutes.

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels Sentiotec Unité de contrôle

Sentiotec

Sentiotec Pro-C2 Manuel utilisateur

Sentiotec

Sentiotec Pro B2 Manuel utilisateur

Sentiotec

Sentiotec Karibu Modern FinnischPlug'n'Play Manuel utilisateur

Sentiotec

Sentiotec A2 Manuel utilisateur

Sentiotec

Sentiotec Pro D2 Manuel utilisateur

Sentiotec

Sentiotec K1 Next Manuel utilisateur

Sentiotec

Sentiotec Pro B3 Manuel utilisateur

Sentiotec

Sentiotec Pro C2 Manuel utilisateur

Sentiotec

Sentiotec IS1 P-IS1-T Manuel utilisateur

Sentiotec

Sentiotec A2 Manuel utilisateur

Sentiotec

Sentiotec just sauna combi series Manuel utilisateur

Sentiotec

Sentiotec just sauna combi Manuel utilisateur

Sentiotec

Sentiotec Pro B2 Manuel utilisateur

Sentiotec

Sentiotec IS2 Manuel utilisateur

Sentiotec

Sentiotec IHS 1 Manuel de la liste des pièces

Sentiotec

Sentiotec CV 41 Manuel de l'opérateur

Sentiotec

Sentiotec CK 41 Manuel utilisateur

Sentiotec

Sentiotec CK 31 Manuel utilisateur

Sentiotec

Sentiotec Pro B Manuel utilisateur

Sentiotec

Sentiotec wave.com4 touch Manuel utilisateur

Sentiotec

Sentiotec K4 NEXT Manuel utilisateur

Sentiotec

Sentiotec Just Sauna Fin Series Manuel utilisateur

Sentiotec

Sentiotec just sauna fin Manuel utilisateur

Sentiotec

Sentiotec A2-15 Manuel utilisateur

Manuels Unité de contrôle populaires d'autres marques

Festo

Festo Compact Performance CP-FB6-E Manuel de la liste des pièces

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manuel utilisateur

JS Automation

JS Automation MPC3034A Manuel utilisateur

JAUDT

JAUDT SW GII 6406 Series Guide rapide

Spektrum

Spektrum Air Module System Manuel utilisateur

BOC Edwards

BOC Edwards Q Series Manuel utilisateur

KHADAS

KHADAS BT Magic Manuel utilisateur

Etherma

Etherma eNEXHO-IL Manuel utilisateur

PMFoundations

PMFoundations Attenuverter Manuel utilisateur

GEA

GEA VARIVENT Manuel utilisateur

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manuel utilisateur

Altronix

Altronix LINQ8PD Instructions de montage

Eaton

Eaton Powerware Series Manuel utilisateur

WAGO

WAGO 750-407/040-000 Manuel utilisateur

Sony

Sony CCU-590 Manuel utilisateur

Graco

Graco 25D614 Manuel utilisateur

Task Force Tips

Task Force Tips YE-RF-900 Manuel de programmation

Shini

Shini SPV-U Series Manuel utilisateur
