Position TVs less than an inch from the wall and offer up to 10° of tilt

Ideal for accentuating the look of ultra-thin LCD, plasma and LED TVs,

SANUS’ new Super Slim VLT14 and VMT14 tilting mounts sit less than

an inch from the wall and offer up to 10° of smooth tilting capability with

fingertip tilt. In addition, these mounts offer the innovative ClickStand™

mechanism, so it’s easy to access cables behind the TV. Simply pull

down on the quick-release tabs to unlock the TV from the wall plate

and the ClickStand™feature holds the TV away from the wall for

hands-free cable management.

Convenient quick-release tabs

on mounting brackets stay

hidden, but easily pull down

to unlock TV from wall plate

for cable access

Super Slim tilting mount sits

less than an inch from wall to

complement the sleek look of

ultra-thin TVs

Innovative ClickStand™mechanism

holds TV away from wall for easy

cable access

VLT14-B1 shown

MODEL VLT14-B1

MODEL VMT14-B1

MODEL VLT14-B1

www.sanus.com • 800.359.5520

Fingertip tilt allows easy

TV angle adjustments with

the touch of a finger

Wall plate mounting holes

designed to accommodate

16" or 24" on-center studs

(model VLT14 only)

Tilting

NEW visioNmouNt®

Super Slim Tilting Mounts

MODEL VLT14 Tilting Mount for 37" – 65" TVs

MODEL VMT14 Tilting Mount for 26" – 42" TVs

PRODUCT DIMENSIONS (w x d x h)

31.4" x .9" x 17.3"

79.8 x 2.2 x 43.8 cm

PACKAGE DIMENSIONS (w x d x h)

32" x 2.6" x 8.7"

81.3 x 6.5 x 22.1 cm

PACKAGE WEIGHT

11.4 lbs / 5.2 kg

TV SIZE/WEIGHT CAPACITY

37" – 65" / 130 lbs

94 – 165 cm / 49 kg

PROFILE

.87" / 2.2 cm

FINISH

Black – VLT14

•Super Slim tilting mount sits less than an inch from the wall to complement the

sleek look of ultra-thin TVs

• Fingertip tilt allows easy TV angle adjustments with the touch of a finger

•Innovative ClickStand™mechanism holds TV away from wall for easy cable access

•Convenient quick-release tabs on mounting brackets stay hidden, but easily pull

down to unlock TV from wall plate for cable access

•Wall plate mounting holes designed to accommodate 16" or 24" on-center studs

PRODUCT DIMENSIONS (w x d x h)

23.6" x .8" x 17.3"

60.1 x 2 x 43.8 cm

PACKAGE DIMENSIONS (w x d x h)

23.6" x 2.6" x 8.7"

60 x 6.5 x 22.1 cm

PACKAGE WEIGHT

7.5 lbs / 3.4 kg

TV SIZE/WEIGHT CAPACITY

26" – 42" / 80 lbs

66 – 107 cm / 36.3 kg

PROFILE

.8" / 2 cm

FINISH

Black – VMT14

•Super Slim tilting mount sits less than an inch from wall to complement the sleek look

of ultra-thin TVs

•Fingertip tilt allows easy TV angle adjustments with the touch of a finger

•Innovative ClickStand™mechanism holds TV away from wall for easy cable access

•Convenient quick-release tabs on mounting brackets stay hidden, but easily pull down

to unlock TV from wall plate for cable access

MASTER PACK QUANTITY

MASTER PACK DIMENSIONS

(w x d x h)

35.4" x 16.7" x 9.1"

90 x 42.5 x 23 cm

MASTER PACK WEIGHT

36.5 lbs / 16.6 kg

LIST PRICE

$169.99

AVAILABLE

August 27, 2010

UPC

793795521934

MASTER PACK QUANTITY

MASTER PACK DIMENSIONS

(w x d x h)

25" x 16.73" x 9.1"

63.5 x 42.5 x 23 cm

MASTER PACK WEIGHT

31.7 lbs / 14.4 kg

LIST PRICE

$119.99

AVAILABLE

August 27, 2010

UPC

793795521941

www.sanus.com • 800.359.5520

VLT14-B1 SHOWN

VMT14-B1 SHOWN

NEW visioNmouNt®

Super Slim Tilting Mounts

MOUNTING PATTERN 100x100

200x100

200x200

300x200

400x200

500x200

300x300

400x300

400x400

500x400

600x400

800x400

Universal » Width: 100 – 804 mm

  a a a a a a a a a a a a a 

Height: 25 – 410 mm

MOUNTING PATTERN 100x100

200x100

200x200

300x200

400x200

500x200

400x300

400x400

600x400

800x400

800x500

Universal » Width: 147 – 571.5 mm

  a a a a a a a a    a

Height: 15 – 410 mm
