Samsung SP-A8000 Manuel utilisateur

SP-A8000

DLP Projector

Owner’s Instructions

The color and the appearance of the product may differ

from the illustrations in this manual. The specifications are

subject to change without prior notice to improve

performance.

Table Of Contents

MAJOR SAFETY PRECAUTIONS

Before You Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1

Care and Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

INSTALLATION AND CONNECTION

Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1

Installing the Projector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2

Leveling with Adjustable Feet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3

Zoom and Focus Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4

Adjusting the Lens Position Moving Dial . . . . . . . . . . . . . . . . . . . . . . . 2-5

Screen Size and Projection Distance . . . . . . . . . . . . . . . . . . . . . . . . . 2-6

Lamp Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7

Supported Display Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8

Connecting the Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9

Connecting a DVD player/Cable Box/Satellite Box to HDMI/DVI . . . 2-10

Connecting a DVD player/Cable Box/Satellite Box via Component 2-11

Connecting to VCR/Camcorder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-12

Connecting with a PC and Setting up the PC . . . . . . . . . . . . . . . . . . 2-13

The 3D IR Emitters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-14

USING

Product Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1

Front, Upper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2

Rear Side . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3

Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4

LED Indications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5

Using the Screen Adjustment Menu (OSD: On Screen Display) . . . . 3-6

Read Before Watching 3D Picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-7

TROUBLESHOOTING

Before Requesting Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1

MORE INFORMATION

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1

RS232C Command Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2

Contact SAMSUNG WORLDWIDE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3

Correct Disposal - Europe only . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4

1 Major Safety Precautions

1-1 Before You Start

Icons used in this manual

Using this Manual

• The contents of this manual are subject to change without prior notice for performance improvement.

• Make yourself fully aware of the safety precautions before using this product.

• If a problem occurs, refer to the 'Troubleshooting' section.

The copyright of this manual is reserved by Samsung Electronics, Co., Ltd.

The contents of this manual may not be partially or in whole reproduced, distributed or used in any form without the written

permission of Samsung Electronics, Co., Ltd.

ICON NAME MEANING

Caution Indicates cases where the function may not work or the setting may be canceled.

Note Indicates a hint or tip to operate a function.

An administration fee may be charged if either.

(a) An engineer is called out at your request and there is no defect in the product.

(i.e. where you have failed to read this user manual).

(b) You bring the unit to a repair centre and there is no defect in the product.

(i.e. where you have failed to read this user manual).

The amount of such administration charge will be advised to you before any work or home visit is carried out.

1-2 Care and Maintenance

Cleaning the Surface and the Lens

Cleaning Inside the Projector

Clean the projector using a soft dry cloth.

• Do not clean the product with a flammable substance such as

benzene or thinner.

• Avoid scratching the lens with your fingernails or a sharp object.

This may result in scratches or damage to the product.

• Avoid cleaning the product with a wet cloth or by directly

spraying water onto the product.

If water enters the product, it may result in fire, electric shock, or

a problem with the product.

• A white stain may appear on the surface of the projector if water

gets on it.

The appearance and the color may differ depending on the

model.

For cleaning the interior of the projector, contact an authorized

Samsung Service Center.

• Contact a Service Center if dust or other substances are inside

the projector.

Major Safety Precautions 1-3

1-3 Safety Precautions

Icons used for safety precautions

Meaning of Signs

Power Related

The following images are for your reference and may differ depending on models and countries.

The appearance and the color may differ depending on models.

Warning

ICON NAME MEANING

Warning Failing to follow the precautions marked with this sign may result in a serious injury or

death.

Caution Failing to follow the precautions marked with this sign may result in a personal injury or

property damage.

Do not perform. Must be followed.

Plug the power plug in firmly.

• Doing otherwise may result in fire.

Avoid connecting multiple electric appli-

ances to a single wall outlet.

• Doing otherwise may result in fire due

to overheating of the wall outlet.

Avoid using a damaged power cord or plug

or a loose power outlet.
