USER'S GUIDE

LCD PROJECTOR

Connecting the LitePro is summarized on the back of this

card and described in detail in the LitePro 560/570 User’s

Guide.

The User’s Guide contains instructions and illustrations for

connections to all compatible computers. It also describes

the remote control buttons and menu functions.

fold and tear here fold and tear here

QK-START.FRA Page 1 Tuesday, January 28, 1997 9:18 AM

You must install theprojection bulbs

the first time you use the LitePro.

Refer to the “Read Me First” card

or page 40 of the User’s Guide for

instructions.

Place the LitePro on a flat surface

within six feet of your power

source and your computer.

Remove the lens cover.

Plug in the LitePro’s power cord.

Make sure your computer and

monitor are turned off.

Plug the “LCD” end of the LitePro

cable into the “COMPUTER” con-

nector on the side of the LitePro.

If your computer is a Macintosh,

attach the Mac adapters before

doing step 8. Attach one adapter to

the “VGA”end of theLiteProcable.

Attach the other adapter to the

“MONITOR” end of the LitePro

cable.

Locate your computer’s monitor

cable. Unplug it at the computer

end, leaving the monitor end

attached.

Connect the LitePro cable to the

monitor connector on your com-

puter.

If you want to display your presen-

tation on your computer’s monitor

as well as on the projection screen,

attach the “MONITOR” end of the

LitePro cable to the end of the

monitor’s cable.

LP570 only: If you want to connect

your computer’s sound board, a

video player, a speaker system, a

microphone,or a second computer,

refer to the instructions in User’s

Guide.

If you attached your monitor in

Step 8, turn on the monitor.

Press the “|” side of the power

switch to power up the LitePro.

The test pattern will be projected

onto the screen. If necessary, adjust

the height of the LitePro and focus

the lens.

Turn on your computer. The com-

puter image will be projected onto

the screen.

If your computer is... You’ll need...

IBM-compatible desktop or laptop no adapters

Apple Macintosh or PowerBook 2 Mac

adapters

Macintosh PowerBook 1 Mac adapter

and your

video-out cable

QK-START.FRA Page 2 Tuesday, January 28, 1997 9:18 AM

COPY-FCC.FRA Page 1 Tuesday, January 28, 1997 9:27 AM

Certifications

UL 1950, CSA 950, EN 55022, EN 50082-1, EN 60950

FCC Warning

This equipment has been tested and found to comply with the limits for a Class A digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference when the equipment is operated in a commercial environment.

Instructions to User

This equipment generates, uses and can radiate radio frequency energy and, if not installed and

used in accordance with the instructions in this manual, may cause harmful interference to radio

and television reception. Operation of this equipment in a residential area is likely to cause harmful

interference. If this equipment does cause interference to radio or television reception, the user is

required to correct the interference at his/her own expense. The user may try to correct the

interference by one or more of the following measures:

• Reorient the receiving antenna for the radio or television.

• Relocate the equipment with respect to the receiver.

• Plug the equipment into a different outlet so the equipment and receiver are on different branch

circuits.

• Fasten cables using mounting screws to ensure adequate electromagnetic interference controls.

EN 55022 Warning

This product is intended for use in a commercial, industrial, or educational environment. It is not

intended for residential use.

This is a Class A product. In a domestic environment it may cause radio interference, in which case

the user may be required to take adequate measures. The typical use is in a conference room,

meeting room or auditorium.

Wenn das Produkt Lite Pro 560/570 in Deutschland verkauft wird, muss es Umwelt geschuetzt sein.

(Klasse B) Dieses Product muss mit dem Bundesamt fuer Post und Telekommunikation registriert

sein. (BAPT)

Trademarks

All trademarks are the property of their respective owners and are used in this publication for

identification purposes only.

The following are trademarks or registered trademarks of their respective companies:

• IBM and PS/2: International Business Machines, Inc.

• Apple, Macintosh, Mac II,LC, PowerBook, Quadra, Performa, and Power Mac: Apple Computer

Corp.

• LitePro, LiteShow, and IN FOCUS SYSTEMS: In Focus Systems, Inc.

COPY-FCC.FRA Page 2 Tuesday, January 28, 1997 9:27 AM

Declaration of Conformity

We, In Focus Systems, Inc., 27700B SW Parkway Ave. Wilsonville, Oregon 97070 USA, declare

under our sole responsibility that the:

LitePro 560 and LitePro 560LS LCD projector

LitePro 570 and LitePro 570LS LCD projector

to which this declaration relates, are in conformity with the following standards:

EN 55022. . . . . . . . . . . . . . . . . . .Information Technology Equipment Emission Standard

EN 50082-1 . . . . . . . . . . . . . . . . .Generic Immunity Standard

EN 60950: 1992+A1+A2: 1993 .Safety of Information Technology Equipment

following the provisions of the following directives:

EMC Directive 89/336/EEC, Amended by 93/68/EEC

Low Voltage Directive 72/23/EEC, Amended by 93/68/EEC

European Office

Planetenweg 91, 2132 HL Hoofddorp, The Netherlands

September, 1995

COPY-FCC.FRA Page 3 Tuesday, January 28, 1997 9:27 AM

LitePro 560/570 User’s Guide i

Contents

Safety Summary iii

Introduction 1

Compatibility 2

Cables and Adapters 2

Remote Control Programmer Kit 3

Usage Guidelines 3

If You Need Assistance 3

Setting Up the LitePro 5

Using the LitePro 17

Basic Image Adjustment 17

Turning the LitePro Off 17

Using the Remote Control 17

Focusing the Image 18

Adjusting the Height 18

Switching to the Spare Lamp 19

Using the Remote Control Buttons 20

Using the Menus 24

Menu 1 Functions 26

Menu 2 Functions 28

Audio Menu Functions 36

Maintenance 39

Cleaning the Lens 39

Replacing the Projection Lamps 40

Replacing Batteries in the Remote Control 42

Replacing the Fuse 43

Troubleshooting 47

Before You Call for Assistance 47

Solutions to Common Problems 48

Appendix 51

Specifications 51

Accessories 53

Cable Connector Pin Assignments 54

Laptop Display Activation Chart 56

Index 59

0060-05.TOC Page i Tuesday, January 28, 1997 9:28 AM

LitePro 560/570 User’s Guide iii

Safety Summary

Please read these instructions before using your LitePro projector.

Failure to comply with these instructions could result in fire,

electrical shock, personal injury or equipment damage.

These graphics are used throughout this manual to draw your atten-

tion to important information about the LitePro:

Information that may be unusual or unexpected.

Information that helps you avoid damage to your

equipment.

Information that helps you avoid personal injury.

These graphics are used on the LitePro:

Attention - Refer to the User’s Guide for important

safety information.

Fuse - Refer to “Replacing the Fuse” on page 43 of

this User’s Guide for important safety information.

Hot Surface - Do not touch untilthe LitePro has

cooled.

Do not look into the lens!

Be very careful not to look into the projection lens when the projector

is turned on. The bright light may harm your eyes. Be especially

careful to keep children from looking into the lens.

Power Source

Use only a three-wire grounding type power source. The power

source should not exceed 250 volts rms between the supply

conductors or between either conductor and the ground.

Power Cord

Use only the power cord that was shipped with the LitePro.

Although other power cords might be similar in appearance, they

SAFETY.FRA Page iii Tuesday, January 28, 1997 9:29 AM

Safety Summary

iv LitePro 560/570 User’s Guide

have not been safety-tested with the LitePro. Never use a power cord

if it has become damaged or frayed. Contact your In Focus dealer or

call In Focus if you need to replace your LitePro power cord.

Grounding

The LitePro is grounded through the grounding conductor on the

power cord. To avoid electric shock, plug the power cord into a

properly wired receptacle. Do not defeat the purpose of the

grounding-type plug.

Fuse

For protection against the risk of fire, use only a fuse of the specified

type. Refer to page 51 for more information about fuse specifications

and to page 43 for instructions on replacing the fuse.

Lamp

To avoid overheating and unacceptable image quality, replace the

projection lamp with a lamp of the specified type. Refer to page 51 for

lamp specifications and to page 40 for instructions on replacing the

lamps.

Hot Surfaces

The rear of the LitePro becomes very hot during operation. Avoid

touching the exhaust grill on the lamp door. Allow the LitePro to

cools for at least 20 minutes before replacing a lamp. When you open

the lamp door, be very careful not to touch the hot surfaces inside.

Ventilation and Overheating

Openings in the LitePro case provide ventilation to protect it from

overheating. Keep loose papers and other objects well away from the

sides and back of the LitePro. Never operate the LitePro when the

lamp door is open; this disrupts the cooling air flow inside and can

cause the LitePro to overheat. Do not place the LitePro on top of or

close to the computer or other heat-producing equipment.

Liquid Spills

Do not set drinks on top of the LitePro. Spilled liquids canflow inside

and damage the LitePro.

Do Not Disassemble

The only user-serviceable parts on the LitePro are inside the lamp

door at the rear. Do not open any other part of the LitePro. Opening

the LitePro case will expose you to electric shock hazard. All service

must be performed by an authorized In Focus service center.

SAFETY.FRA Page iv Tuesday, January 28, 1997 9:29 AM

LitePro 560/570 User’s Guide 1

Introduction

The In Focus Systems LitePro 560 and 570 LCD projectors provide

640x480 resolution with compatibility up to 800x600. The LitePro’s

active matrix liquid crystal display (LCD) is based on Thin Film

Transistor (TFT™) technology. It can display up to 16.7 million colors.

The LitePro is ideal for high-performance business, CAD and

imaging applications that demand high resolution and exceptional

color quality.

Figure 1. Shipping Box Contents

1. LitePro 560/570 LCD projector not shown:

2. power cord 2 Fuses, 2 Projection Lamps,

3. audio/video cable Soft Carrying Case, Lens

4. Macintosh adapters (2) Cover, Read Me First card,

5. LiteShow diskettes (LP 560LS & LP 570LS) LiteShow User’s Guide (LP

6. LitePro cable 560LS & LP 570LS), Remote

7. remote control units (2) Control Programmer Kit

8. LitePro 560/570 User’s Guide

INTRO.FRA Page 1 Tuesday, January 28, 1997 9:30 AM

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels InFocus Projecteur

InFocus

InFocus in5316HD Manuel utilisateur

InFocus

InFocus Proxima DP6870 Manuel utilisateur

InFocus

InFocus LP 240 Manuel utilisateur

InFocus

InFocus IN3114 Manuel utilisateur

InFocus

InFocus IN5555L Manuel utilisateur

InFocus

InFocus LitePro 580 Manuel utilisateur

InFocus

InFocus LitePro 610 Manuel utilisateur

InFocus

InFocus IN2136 Manuel utilisateur

InFocus

InFocus X16 Manuel utilisateur

InFocus

InFocus LitePro Manuel utilisateur

InFocus

InFocus LP280 Manuel d'utilisation et d'entretien

InFocus

InFocus LightPro IN1004 Manuel utilisateur

InFocus

InFocus LiteBoard IN3902LB Manuel utilisateur

InFocus

InFocus LP 725 Manuel utilisateur

InFocus

InFocus LP 840 Guide de configuration rapide

InFocus

InFocus ScreenPlay 7210 Manuel utilisateur

InFocus

InFocus IN3916 Manuel utilisateur

InFocus

InFocus SP4800 Manuel utilisateur

InFocus

InFocus in122st Manuel utilisateur

InFocus

InFocus in5300 series Manuel utilisateur

InFocus

InFocus SP4805 Manuel utilisateur

InFocus

InFocus IN5132 Mode d’emploi

InFocus

InFocus LP 740 LiteMount Manuel utilisateur

InFocus

InFocus LitePro Manuel utilisateur

Manuels Projecteur populaires d'autres marques

iEmmet

iEmmet MP-312 Manuel utilisateur

Epson

Epson VS400 Manuel utilisateur

Sony

Sony VPL-HS10 Marketing Specifications & Features Manuel utilisateur

Sony

Sony VPL-HW65ES Manuel de service

Toshiba

Toshiba TLP-791U Manuel utilisateur

Philips

Philips LC1341 Guide de référence

Panasonic

Panasonic PTL735NTU - LCD PROJECTOR-NETWORK IB Manuel utilisateur

NEC

NEC NP600S EDU Manuel utilisateur

BenQ

BenQ SH753P Manuel utilisateur

Eiki

Eiki EK-623U series Manuel utilisateur

Epson

Epson PowerLite Pro Cinema 6020UB Manuel utilisateur

Epson

Epson PowerLite Home Cinema 705HD Manuel utilisateur

Christie

Christie LHD700 Manuel utilisateur

Navitar

Navitar FX Manuel utilisateur

Sony

Sony SRX-R815P Manuel utilisateur

Vivitar

Vivitar DP1500 X Manuel utilisateur

Acer

Acer C20 Series Manuel utilisateur

Asus

Asus ZenBeam Latte Manuel utilisateur
