Safety 1st WANDERER X Manuel utilisateur
17KG0m+
3 WHEEL STROLLER
WANDERER X
Suitable for newborn to 17kg
Illustration and designs may vary.
2
017002 - 017003 - Wanderer X Stroller - 01 - 16
CONTENTS
Warnings ......................................................................................................... 3
Components list ........................................................................................ 4 - 5
ASSEMBLING THE STROLLER
Opening Stroller ............................................................................................. 6
Wheel Assembly ......................................................................................... 7 - 8
Fitting Seat ...................................................................................................... 9
Bumper Bar ................................................................................................... 10
USING THE STROLLER
Canopy .......................................................................................................... 11
Front Swivel Wheel ....................................................................................... 12
Operating Brakes ......................................................................................... 13
Adjusting Handle / Backrest / Legrest .................................................. 14 - 15
Securing your Child ........................................................................................ 16
Adjusting Harness Height / Tether Strap ....................................................... 17
Folding / Unfolding / Carrying Stroller ................................................... 18 - 19
BASSINETTE AND INFANT CARRIER
Install and Use Bassinette .................................................................... 20 - 22
Install and Use Infant Carrier ................................................................ 23 - 24
CARE AND MAINTENANCE
Care and Maintenance ................................................................................. 25
Notes ..................................................................................................... 26 - 27
CONTACTS
Customer Service ....................................................................................... 28
3
017002 - 017003 - Wanderer X Stroller - 01 - 16
ALWAYS APPLY THE BRAKES WHENEVER THE STROLLER IS
STATIONARY.
• DO NOT LEAVE CHILDREN UNATTENDED.
• DO NOT CARRY EXTRA CHILDREN OR BAGS ON THIS
STROLLER.
• MAKE SURE CHILDREN ARE CLEAR OF ANY MOVING PARTS
IF YOU ADJUST THE STROLLER, OTHERWISE THEY MAY BE
INJURED.
• SECURE THE CHILD IN THE HARNESS AT ALL TIMES AND
ENSURE THAT THE SAFETY HARNESS IS ADJUSTED FIRMLY
BUT COMFORTABLY TO THE CHILD’S BODY.
• A harness can form loops that may be a strangulation hazard, never
leave harness straps connected when not fitted to a child in the stroller.
• Use the tether strap to prevent the stroller rolling away.
• Do not allow children to stand on the seat or footrest.
• Do not attempt to lift the stroller by the bumper bar.
• Remove the child from the stroller before going up or down stairs
or escalators.
• Engage front wheel swivel locks when travelling on rough or uneven
surfaces.
• Regularly inspect the stroller for any parts that are loose, broken, torn
or missing. Attend to the problem as soon as it is noticed.
• Use only those accessories which are supplied by Dorel Australia and
approved for use with this stroller.
• Do not use the stroller near an open fire, barbecue or exposed flame.
• This product is not intended for commercial use.
• Do not run or jog with this stroller.
• This product is tested to AS/NZ 2088:2013
WARNING TO AVOID INJURY OR DEATH:
These instructions detail the safe use, assembly and maintenance of your
product. Please read these instructions carefully and ensure that they are
followed at all times. Failure to do so could result in serious injury or death.
4
017002 - 017003 - Wanderer X Stroller - 01 - 16
Maxi-Cosi Infant Carrier Wanderer Bassinette
Note:
• The weight of the child using this stroller should not be more than 17kg.
• Total weight for the shopping basket should not be more than 4kg.
• The weight of the child using the Infant Carrier should not be more
than 9kg.
• The weight of the child using the Bassinette should not be more
than 9kg.
• Please refer to instruction manuals of the Maxi-Cosi Infant Carrier
& Wanderer Bassinette for full weight and height specifications.
Components Sold Separately
Maxi-Cosi Infant
Carrier Adaptors x2
Safety 1st
Universal Raincover
5
017002 - 017003 - Wanderer X Stroller - 01 - 16
Component List
1
2
4
5
7
8
6
3
16
15
9
11
12
13
14
10
1. Handle Height Adjustment
2. Tether Strap
3. Folding Lock (both sides)
4. Storage Latch
5. Shopping Basket
6. Brake Lever (both sides)
7. Rear Wheels Assembly
8. Never Flat Tyres (x3)
9. Canopy
10. Marle Seat Pad
11. Bumper Bar
12. Harness Pads
13. Safety Harness
14. Adjustable Legrest
15. Swivel Wheel Lock
16. Front Wheel
6
017002 - 017003 - Wanderer X Stroller - 01 - 16
OPENING STROLLER
• If the stroller has a security tie, please remove it.
• Lift storage latch to release, as per Figure 1a.
• Unfold stroller by lifting handle as per Figure 1b until the locking
mechanism engages, as per Figure 1c.
Assembling: Wanderer Stroller
Lift
Storage Latch
1a
1b
1c
Lift
Note:
• Folding strollers and accessories will always have the potential
to trap fingers or parts of the body between moving parts, causing
injuries. Care should be taken while folding or unfolding.
• This vehicle is designed for use on flat or gently sloping surfaces
and may be unstable on higher sloping and uneven surfaces.
You should always be aware of the possibility of the stroller
tipping on uneven or higher sloping surfaces.
7
017002 - 017003 - Wanderer X Stroller - 01 - 16
Assembling: Wanderer Stroller
TO FIT REAR WHEELS
• Slide rear wheel onto the wheel hub, as per Figure 2a.
• Repeat for other side.
TO REMOVE REAR WHEELS
• Push and hold metal tab, as per Figure 2b.
• Pull rear wheel from the hub, as per Figure 2c.
• Repeat on other side.
Push
Push
Push
Assembling: Wanderer Stroller
2a
2c
2b
Note:
Never Flat tyres do not require air.
The tyres are maintenance free.
8
017002 - 017003 - Wanderer X Stroller - 01 - 16
TO FIT FRONT WHEEL
• Lift the front of the stroller and push the shaft into the front wheel hub, as per
Figure 3a.
• Listen for ‘CLICK’ to confirm locking position.
TO REMOVE FRONT WHEEL
• Slide the plastic button while pulling the front wheel off the front hub, as per
Figure 3b.
Assembling: Wanderer Stroller
Push
Pull
Click!
3a 3b
Slide
9
017002 - 017003 - Wanderer X Stroller - 01 - 16
TO FIT THE SEAT
• The seat can be positioned in either the forward facing Figure 4a or
rearward facing Figure 4c configuration. Insert the seat onto the frame by
lowering the seat into the frame, as per Figure 4b.
• Listen for ‘CLICK’.
TO REMOVE THE SEAT
• Slide and hold down button (A) with one hand and press button (B) with the
other hand, as per Figure 4d.
• Then press button (C) and lift out the seat, as per Figure 4e.
Assembling: Wanderer StrollerAssembling: Wanderer Stroller
Push
Press (B)
Slide (A)
Click!
Do not use this seat with any other models of stroller.
WARNING
Press (C)
Opposite side
Lift
4e
4a
4c
4b
4d
10
017002 - 017003 - Wanderer X Stroller - 01 - 16
TO FIT BUMPER BAR
• Align bumper bar mounting slider with the mounting brackets, as per
Figure 5a and slide down until it locks into place.
• Repeat on other side.
TO REMOVE BUMPER BAR
• Remove bumper bar from frame.
• Press the plastic button and slide bumper bar upwards, as per Figure 5b
&Figure 5c.
Using: Wanderer Stroller
Slide
Push
Slide
5a 5b
5c
