Safety 1st Sky Black Mode d’emploi
IMPORTANT:
RETAIN FOR FUTURE REFERENCE.
20KG0m+
SHUTTLE STROLLER
SKY BLACK
Suitable for newborn to 20KG
Illustrations are representative only.
Design and style may vary.
2#14275-Safety 1st-Shuttle Stroller Sky Black-05-13
Instruction Manual & User Guide
page 3
page 4
page 5
page 6
page 7
page 8
page 9
page 10
page 11
page 12
page 13
page 14
page 15
page 16
• WARNINGS
• Components list
• To unfold the stroller
• To assemble the front wheels
To use the front wheel swivel locks
• To remove the front wheels
• To assemble the rear wheels
To remove the rear wheels
To operate the brakes
• Tottheseat
To remove the seat
To adjust the seat angle
Seat forward facing or rear facing
• Tot&removethebumperbar
Tot&removethecanopy
Tottheraincover
• Totthebootcover
To adjust handle height
• To fold the stroller
• Tosecureyourchild
To use the tether strap
• To attach the One-Safe Infant Carrier to the stroller
• To remove the One-Safe Infant Carrier from the stroller
• Product care and maintenance
Customer service
Table of Contents
Instruction Manual & User Guide
#14275-Safety 1st-Shuttle Stroller Sky Black-05-13 3
These instructions detail the safe use, assembly and maintenance of your product.
Please read these instructions carefully and ensure that they are followed at all times.
Failure to do so could result in serious injury or death.
WARNINGS
• FOLLOWTHEMANUFACTURER’SINSTRUCTIONS.
• PUTONALLTHEBRAKESWHENEVERYOUPARKTHESTROLLER.
• DONOTLEAVECHILDRENUNATTENDED.
• DONOTCARRYEXTRACHILDRENORBAGSONTHISSTROLLER,UNLESSINAN
APPROVEDACCESSORY.
• MAKESURECHILDRENARECLEAROFANYMOVINGPARTSIFYOUAREFOLDING,
UNFOLDINGORADJUSTINGTHEPRAM,OTHERWISETHEYMAYBEINJURED.
• SECURETHECHILDINTHEHARNESSATALLTIMESANDENSURETHATTHE
SAFETYHARNESSISADJUSTEDFIRMLYBUTCOMFORTABLYTOTHECHILD’SBODY.
• Aharnesscanformloopsthatmaybeastrangulationhazard.Neverleaveharness
strapsconnectedwhennotttedtoachildinthestroller.
• Checkthatthestrollerisfullyerectedandallsafetylocksareengagedbeforeplacing
a child in the stroller.
• Donotallowchildrentostandontheseatorfootrest.
• Donotattempttoliftthestrollerbythebumperbarorchildtray,ifithasone.
• Removethechildfromthestrollerbeforegoingupordownstairsorescalators.
• Regularlyinspectthestrollerforanypartsthatareloose,broken,tornormissing.
Attendtotheproblemassoonasitisnoticed.
• UseonlythoseaccessorieswhicharesuppliedbyDorelAustralia,andapprovedforuse
with this stroller.
• Donotrunorjogwiththisstroller.
• Donotusethestrollernearanopenre,barbecueorexposedame.
• Toavoiddangerofsuffocation,keepanyplasticbagsawayfrombabiesandchildren.
• Usethetetherstraptopreventthestrollerrollingaway.
• Keepchildrenawayfromthestrollerwhenunfoldinganddonotletthemplaywiththe
folded stroller.
• Engagefrontwheelswivellock(whereapplicable),tolockfrontwheel(s)whentravelling
onroughorunevensurfaces.
• Thisproductisnotintendedforcommercialuse.
• Neverputhotliquidsinanycupholder(whentted).
• Theweightofthechildshallnotexceed20kg.
Carrybasketcapacity4kg.
4#14275-Safety 1st-Shuttle Stroller Sky Black-05-13
Instruction Manual & User Guide
Components List:
One-SafeInfantCarrier
(soldseparately)
Head pillow
Bootcover Raincover
Carrybasket
Tether
strap
Canopy
Harnessbuckle
Brake
(notshown)
Handle
Seat
Frontwheels
Bumperbar
Swivellocks
Footrest
Legrest
Headpillow
Shoulderpad
Instruction Manual & User Guide
#14275-Safety 1st-Shuttle Stroller Sky Black-05-13 5
Assembling: Shuttle Stroller Sky Black
TO UNFOLD THE STROLLER
Figure1
Figure2
• Removethesecuritytie,ifthestrollerhasone.
• Releasethestoragelatchbypullingthelatchawayfromtheframe,
as per Figure1.
• Graspthefootrestandliftitashighaspossiblesothatit‘clicks’intoplace,
as per Figure2.
Figure3
• Turn assembly upside down, press the white
releasebutton(3A)andliftupthehandlebar
(3B)untilbothframelatches‘click’intothe
lockedposition(3C),asperFigure3.
Checkthattheframeislockedopenby
pushingdownwardonthehandle.
Figure3
6#14275-Safety 1st-Shuttle Stroller Sky Black-05-13
Instruction Manual & User Guide
Assembling: Shuttle Stroller Sky Black (cont)
• Alignthepinsonthetopsofthefrontwheelswith
theholesintheundersideofthewheelhousings,
as per Figure4(A).
• Firmlypushthepinsintothehousinguntilthey
‘click’intoplace,asperFigure4(B).
TO ASSEMBLE THE FRONT WHEELS
Checkthewheelsareattachedbyattempt-
ingtopullthemoutagain.
Figure4
• Slide the slider in the middle of the unit up or
down as the case may be in each wheel, to lock
or unlock the wheel, as per Figure5.
Figure5
TO USE THE FRONT WHEEL SWIVEL LOCKS
Unlockfrontwheelswivellockswhenon
roughorunevensurfaces.
Instruction Manual & User Guide
#14275-Safety 1st-Shuttle Stroller Sky Black-05-13 7
Assembling: Shuttle Stroller Sky Black (cont)
TO REMOVE THE FRONT WHEELS
Laystrollerontheothersideandrepeatthestepabovetoremove
the opposite wheel assembly.
• Lay stroller on its side, as per Figure6.
• Aligntheswivellocksliderwiththeslotverticallyandensurethelockingbutton
isvisibleinsidetheholelocatedontheinsideofthefrontswivelwheelvertical
shafthousing.
• Oncevisible,pressonthetabwiththescrewdriverandpullonthewheel
assemblytoremove.
Should only be performed by an adult.
Figure6
8#14275-Safety 1st-Shuttle Stroller Sky Black-05-13
Instruction Manual & User Guide
Assembling: Shuttle Stroller Sky Black (cont)
Figure7
• Push each wheel into position, as per Figure7.
TO ASSEMBLE THE REAR WHEELS
• PressthemetallicreleasebuttonFigure8(A),
locatedontherearaxleinwardsandpullthe
wheel Figure8(B)outwards.Repeatsame
step for other wheel.
Figure8
TO REMOVE THE REAR WHEELS
TO OPERATE THE BRAKES
• PushdownontheRed pedal located on the
centreoftherearwheelaxletosetthe
park brake, as per Figure9.
Figure9
Torelease,pushdownonthepedalagain.
Checkthatbothwheelsareproperlyattached
byattemptingtopullthemout.
Instruction Manual & User Guide
#14275-Safety 1st-Shuttle Stroller Sky Black-05-13 9
Using: Shuttle Stroller Sky Black (cont)
• The seat is suitable for newborn. If your child is
not able to sit up unassisted, use the fully
reclined position only.
Placingtheseatintoposition.
• Lowertheseatontotheframeuntilit‘clicks’,
as per Figure10.
TO REMOVE THE SEAT
• Press(RedButton)oneachsideoftheseat
mount and lift seat clear,as per Figure10(A).
TO FIT THE SEAT
Figure10
• Theseatcanbeadjustedto3positions:
• Asittingpositionand2recliningpositions.
• Pushtheadjustmentbuttons(A)onboth
sides and tilt the seat into the desired
position(B),asperFigure11.
Figure11
TO ADJUSTING THE SEAT ANGLE
SEAT FORWARD FACING OR REAR FACING
• Pushthereleasebutton(A)on
both sides inwards and lift the seat
from the frame.
• Turntheseatineitherfacingforward
orfacingyoupositionandlowerthe
seatontotheframeagainuntilit
‘clicks’,asperFigure12.
Figure12
Whenpositioningandadjustingtheseat,checkthattheadjustment/
release buttons are locked on both sides.
A
B
A
10 #14275-Safety 1st-Shuttle Stroller Sky Black-05-13
Instruction Manual & User Guide
Using: Shuttle Stroller Sky Black (cont)
TO FIT & REMOVE THE BUMPER BAR
• ToFit.
Alignandinsertthelocatorpins
intothemountingholesonthe
armrestsuntilthey‘click’andlockin
place at both ends,
as per Figure13(1).
• ToRemove.
Pressbutton(A)located
on each side of the bumper bar and pull
it clear of the stroller,
as per Figure13(2).
Figure13
TO FIT & REMOVE THE CANOPY
• ToFit.
Attachcanopytoseatframebyclosingtheclips,
as perFigure14(1).
• ToRemove.
Removecanopybyreleasingtheclips,
as per Figure14(2).
Figure14
TO FIT THE RAINCOVER
• Alignthezipperontheraincovertothezipper
ontherightendofthecanopy,asperFigure15(A).
• Ziptheraincovertothecanopycompletelyandhook
theotherendoftheraincovertotheundersideof
the footrest, as per Figure15(B).
Figure15
1
2
1
2
