RTW TouchMonitor TMR7 Manuel utilisateur
TouchMonitor TMR7 | TMR7OEM
Software Version 8-03 and higher | 01.2020
Quick Start Guide
EN
TouchMonitor TMR7 | TMR7OEMEN-2 Manual | TouchMonitor TMR7 | TMR7OEM
Please note:
The external power supply is UL Listed for CAN/US, model
ATS 065T-P/A240, manufactured by Adapter Technology Co Ltd.
(RTW 1178-R), Class II double insulated, rated:
Input: 100 - 240 V, 47 - 63 Hz, 1 A max.
Output: 24 Vd.c., 2.71 A, 65 W
The figures in this operating manual are carefully created and are
used to illustrate the descriptions. However, they may differ a little bit
from the displays of your unit.
The current version of this manual and the available firmware/firmware
updates can be found under Audio Monitors/TouchMonitor TMR7 in
the download area of our web site:
https://www.rtw.com/en/support/manuals-software.html.
The package contains a USB flash device source by a third party com-
pany. The device is certified to be CE conform and RoHS compliant.
A detailed RoHS declaration of conformity about TouchMonitor
TMR7 and TMR7OEM will be found in the appendix.
Quick Start Guide
for
RTW TouchMonitor TMR7 | TMR7OEM
Manual Version: 3.1
Issued: 18.03.2020
Software Version: 8-03 and higher (01.2020)
© 03/2020 | Technical changes without prior notice!
RTW GmbH & Co. KG
Am Wassermann 25 | 50829 Köln | Germany
Fon +49 221. 70 913-0 | Fax +49 221. 70 913-32
rtw@rtw.com | www.rtw.com
WEEE Reg.-no.: DE 90666819
RoHS Conformity: These instruments comply with and fall under cate-
gory 9 Monitoring and control equipment of the regu-
lations of the Directive 2011/65/EU on the restric-
tion of the use of certain hazardous substances in
electrical and electronic equipment of the European
Parliament and Council from June 8th, 2011.
Please carefully read the safety instructions, understand
them and act as requested to prevent any hazards or not
to violate any laws.
EN-3Manual | TouchMonitor 7“/9“ Series common Safety Instructions
EN
Safety Instructions
The following symbols may be marked on the panels or covers of
equipment or module and are used in this manuals with these terms:
WARNING!
This symbol alerts you to a potentially hazardous condition, such as
the presence of dangerous voltage that could pose a risk of electrical
shock. Refer to the accompanying Warning Label or Tag, and exercise
extreme caution.
ATTENTION!
This symbol alerts you to important operating considerations or a po-
tential operating condition that could damage equipment. If you see
this marked on equipment, consult the operating manual for precauti-
onary instructions.
NOTE
This symbol points your attention to specific characteristics that are
no malfunctions.
Important Safety Instructions
• Read these instructions. Study carefully and understand all safety
and operating instructions before you install and operate the unit!
• Keep these instructions. Keep all safety and operating instructions
for future reference!
• Heed all warnings on the unit and in the safety and operating inst-
ructions before you install and operate the unit!
• Follow all instructions to ensure against injury to yourself and da-
mage to the unit or other objects connected to the unit.
To prevent possible electrical shock, death, fire, injuries and malfunc-
tions, use this product only as specified.
Only use attachments and accessories specified by the manufacturer.
The units of the TouchMonitor series are designed for indoor use only
and may only be operated with a power supply unit provided for it.
Safety InstructionsEN-4 Manual | TouchMonitor 7“/9“ Series common
WARNING!
Always follow the safety precautions below to avoid the possibility of serious injury or even death from electrical shock, short-circuiting, dama-
ges, fire, or other hazards. These precautions include, but are not limited to, the following:
• Do not apply a potential to any terminal that exceeds the maxi-
mum rating of that terminal.
• Avoid exposed circuitry. Do not touch exposed connections and
components when power is present.
• Turn off and disconnect the power supply immediately it the unit
produces unusual smells, noises or smoke, or if foreign substan-
ces (e. g. liquids) or foreign objects enter the unit.
• Because of the installed battery the unit shall not be exposed to
excessive heat such as sunshine, fire, or similar.
• Caution: Danger of explosion if battery is incorrectly replaced. Re-
place only with the same or equivalent type.
• Do not cover the unit and do not place any objects or anything
containing liquids on it.
• Do not insert your fingers or any other objects into the housing.
• Do not operate without cover plates or panels.
• Do not operate with suspected failures. If you suspect there is da-
mage to the unit, have it inspected by qualified service personnel.
• Do not use this apparatus near water.
• Do not operate in wet/damp conditions.
• Do not operate in explosive atmosphere.
• Do not operate in dusty environments.
• Do not open the housing. Inside, there are no user-serviceable
parts. Any necessary servicing shall be performed by a properly
qualified technician.
• Do not attempt to repair any part of the unit. Repairs shall only be
carried out by qualified personnel.
• Never remove any parts from the unit and do not make any modi-
fications to the unit without the express written consent of RTW.
Modifications can cause both safety hazards and affect the unit’s
conformity and certifications.
• Only use the power cord and power supply specified for this pro-
duct and certified for the country of use.
• Use with power supply model ATS 065T-P/A240, manufactured
by Adapter Technology Co Ltd. (RTW 1178-R).
• The power cord of the external power supply disconnects the pro-
duct from the power source. Do not block the power cord or power
supply; it must remain accessible to the user at any time.
• Connect and disconnect properly. Use only connectors specified
for this product and fix them tight before use.
• Observe all terminal ratings and markings on the product. Consult
the operating manual for further ratings information before making
connections to this product.
EN-5Manual | TouchMonitor 7“/9“ Series common Safety Instructions
EN
ATTENTION!
Always follow the safety precautions below to avoid the possibility of physical injury to you or others, or damage to the unit or other property.
These precautions include, but are not limited to, the following:
• Do not block any ventilation openings. Install in accordance with
the manufacturer‘s instructions to prevent the internal temperature
from becoming too high.
• Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including amplifiers) that produce heat.
• Also keep away the unit from direct incident solar radiation.
• Keep product surfaces clean and dry. Clean only with dry cloth.
• Never use any solvent based liquids for cleaning the housing
surfaces and the display.
• Do not place the unit in an unstable position where it might
accidently fall over.
• Before connecting any devices to the unit make sure that the
power supply is disconnected.
• Protect the power cord from being walked on or pinched particu-
larly at plugs, convenience receptacles, and the point where they
exit from the apparatus.
• Unplug this apparatus during lightning storms or when unused for
long periods of time.
• Before moving the unit, remove all connected cables.
• When transporting or moving the unit, always take care not to
scratch or damage the housing surfaces and the display.
• Refer all servicing to qualified service personnel. Servicing is re-
quired when the apparatus has been damaged in any way, such as
power-supply cord or plug is damaged, liquid has been spilled or
objects have fallen into the apparatus, the apparatus has been ex-
posed to rain or moisture, does not operate normally, or has been
dropped.
Information on installed battery
The pcb features a battery socket with a 3 V Li/Mn coin cell battery, type CR 1225. It must be inserted from the side with its positive pole on
top and its negative pole towards the pcb surface.
Environmental ConsiderationsEN-6 Manual | TouchMonitor 7“/9“ Series common
Environmental Considerations
Observe the following information about the environmental impact
of the product and the following guidelines when recycling an instru-
ment or component (product end-of-life handling):
• Equipment Recycling
Production of this equipment required the extraction and use of
natural resources. The equipment may contain substances that
could be harmful to the environment or human health if improperly
handled at the product’s end of life. In order to avoid release of
such substances into the environment and to reduce the use of
natural resources, we encourage you to recycle this product in an
appropriate system that will ensure that most of the materials are
reused or recycled appropriately.
• Battery Recycling
This product contains a lithium manganese dioxide (Li/Mn) bat-
tery, which must be recycled or disposed of properly according to
your local government regulations.
• Restriction of Hazardous Substances
These instruments comply with and fall under category 9 Moni-
toring and control equipment of the regulations of the Directive
2011/65/EU on the restriction of the use of certain hazardous
substances in electrical and electronic equipment of the European
Parliament and Council from June 8th, 2011. This product may
contain lead, cadmium and/or mercury in slight quantities. Please
dispose of or recycle the electronic parts or devices according to
your local government regulations.
EN-7Manual | TouchMonitor TMR7 | TMR7OEM Index of Content
EN
Index of Content
Safety Instructions 3
Important Safety Instructions 3
Warning! 4
Attention! 5
Environmental Considerations 6
Index of Content 7
Before You Begin 8
Introduction 8
Scope of Delivery 10
Installation 11
Connection 12
Pin Assignment 13
Getting Started 15
System Start-up 15
Adapt the TouchMonitor to your Audio System 16
Create Your Own Preset 18
Working with Instruments and Presets 23
Delivered Presets 25
Software Modules (Licences Handling) 42
Software Update 46
Specifications (Extract) 48
EC Declaration of Conformity 50
RoHS Declaration of Conformity 51
CE and RoHS of Third Party Components 52
Licenses of the Implemented Software 53
Before You Begin | IntroductionEN-8 Manual | TouchMonitor TMR7 | TMR7OEM
Before You Begin
Introduction
Thank you for purchasing a TouchMonitor TMR7 or TMR7OEM.
Loudness, true peak, PPM, audio vectorscope, moving-coil instru-
ments, RTA, and correlation: The TMR7 TouchMonitor 4-channel
solutions featuring 7“ touchscreen and the unique TouchMonitor ope-
rating concept integrate all metering options required in radio broad-
casting to a solution made to measure.
EN-9Manual | TouchMonitor TMR7 | TMR7OEM Before You Begin | Introduction
EN
Simple and flexible
The graphical user interface used in the TouchMonitor range is con-
trolled simply by using your finger or a mouse. Instruments can be
scaled, randomly positioned and combined in almost every way for
optimized use of available screen space. Even multiple instruments of
the same type, assigned to different input channels and configurations,
can be displayed simultaneously. A context-sensitive, on-screen help
feature and the intuitive operatable menu system supports the user,
allowing him to make setup changes with ease.
Audio I/O interface
TMR7‘s hardware and software are perfectly adjusted to radio-broad-
cast requirements and easily integrates into any studio environments.
The four audio inputs provided by the two AES3 XLR ports are flexib-
ly configurable for mono, stereo, or multichannel sources, providing
separate instruments for each source. So TMR7 allows parallel moni-
toring of the on-air signal and a PFL source.
Licences
A totally modular software concept means that you only have to
purchase features that you actually require. This puts you in control,
defining the functionality of a TouchMonitor that suits your needs
best. New instruments and functions can be added as software
modules to the device at any time. Simply purchase and activate the
corresponding licence.
Many display functions are available to choose from: the Real-Time
Analyzer (RTA), loudness meters compliant to all relevant loudness
standards, LRA and Chart, and the Premium PPM including Audio
Vectorscope and Moving Coil instruments.
Before You Begin | Scope of DeliveryEN-10 Manual | TouchMonitor TMR7 | TMR7OEM
Scope of Delivery
Unpack the instrument, find your version below, and check, if you received all items listed. If components are missing, please contact your
dealer. Recommended accessories, options and software licences are also listed.
TouchMonitor TMR7 | TMR7OEM
Table-top unit TMR7
OEM version TMR7OEM
Power supply Quick Start Guide
>
>
>
>
with Audio Interface Software Licence, if ordered
> >
USB stick
Quick Start Guide
USB stick
Loudness and
SPL display
SW20002
RTA - Real Time
Analyzer
SW20003
Premium PPM
+ Moving Coil
SW20006
2 x AES3 In
2 x AES3 Out
Timecode
Reader
SW20008
Logging Data
Server (+Chart)
SW20014
Ce manuel convient aux modèles suivants
1
Table des matières
Autres manuels RTW écran tactile
Manuels écran tactile populaires d'autres marques
Elecro Engineering
Elecro Engineering Poolsmart Plus Instructions d'installation
Johnson Controls
Johnson Controls IQ4 HUB Manuel utilisateur
Elo TouchSystems
Elo TouchSystems ET2270L Manuel utilisateur
Elo TouchSystems
Elo TouchSystems ET1002L Manuel utilisateur
Elo TouchSystems
Elo TouchSystems 3201L Manuel utilisateur
Duratec
Duratec S15 Manuel utilisateur
