User Manual

ITM-5117 Series

17" Industrial LED Touch

Monitor

The documentation and the software included with this product are copyrighted 2012

by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right

to make improvements in the products described in this manual at any time without

notice. No part of this manual may be reproduced, copied, translated or transmitted

in any form or by any means without the prior written permission of Advantech Co.,

Ltd. Information provided in this manual is intended to be accurate and reliable. How-

ever, Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringe-

ments of the rights of third parties, which may result from its use.

Acknowledgements

Intel and Pentium are trademarks of Intel Corporation.

Microsoft Windows and MS-DOS are registered trademarks of Microsoft Corp.

All other product names or trademarks are properties of their respective owners.

Product Warranty (2 years)

Advantech warrants to you, t he original purchaser, that each of its products will be

free from defects in materials and workmanship for two years from the da te of pur-

chase.

This warranty does not apply to any products which have been repaired or altered by

persons other than repair personnel authorized by Advantech, or which have been

subject to misuse, abuse, accident or improper installation. Advantech assumes no

liability under the terms of this warranty as a consequence of such events.

Because of Advantech’s high quality-control standards and rigorous testing, most of

our customers never need to use our repair service. If an Advantech product is defec-

tive, it will be rep aired or replaced at no charge during the warranty period. For out-

of-warranty repairs, you will be billed according to the cost of replacement materials,

service time and freight. Please consult your dealer for more details.

If you think you have a defective product, follow these steps:

1. Collect all the information about the problem encountered. (For example, CPU

speed, Advantech products used, other hardware and software used, etc.) Note

anything abnormal and list any onscreen messages you get when the problem

occurs.

2. Call your dealer and describe the problem. Please have your manual, product,

and any helpful information readily available.

3. If your product is diagnosed as defective, obtain an RMA (return merchandize

authorization) number from your dealer. This allows us to process your return

more quickly.

4. Carefully pack the defective product, a fully-completed Repair and Replacement

Order Card and a photocopy proof of purchase date (such as your sales receipt)

in a shippable container. A product returned without proof of the purchase date

is not eligible for warranty service.

5. Write the RMA number visibly on the outside of the package and ship it prepaid

to your dealer.

Declaration of Conformity

This product has passed the CE test for env ironmental specifications when shielded

cables are used for external wiring. We recommend the use of shielded cables. This

kind of cable is a vailable from Advantec h. Please contact your local supplier for

ordering information.

This product has passed the CE test for environmental specifications. Test conditions

for passing included the equipment being operated within an industrial enclosure. In

order to protect the product from being damaged by ESD (Electrostatic Discharge)

and EMI leakage, we strongly recommend the use of CE-compliant indu strial enclo-

sure products.

FCC Class A

Note: This equipment has been tested and found to comply with the limits for a Class

A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interfere nce when the eq uipment is

operated in a commercial environment. This equipment generates, uses, and can

radiate radio frequency energy and, if not installed and used in accordance with the

instruction manual, may cause harmful interference to radio communications. Opera-

tion of this equipment in a residential area is likely to cause harmful interference in

which case the user will be required to correct the interference at his own expense.

This equipment has passed the FM certification. According to the National Fire Pro-

tection Association, work sites are classi fied into different classes, divisions and

groups, based on hazard considerations. This equipment is compliant with the speci-

fications of Class I, Division 2, Groups A, B, C and D indoor hazards.

Technical Support and Assistance

1. Visit the Advantech website at http://support.advantech.com where you can find

the latest information about the product.

2. Contact your distributor, sales representative, or Advantech's customer service

center for technical support if you need additional assistance. Please have the

following information ready before you call:

–Product name and serial number

–Description of your peripheral attachments

–Description of your software (operating system, version, application software,

etc.)

–A complete description of the problem

–The exact wording of any error messages

Warnings, Cautions and Notes

Document Feedback

To assist us in making improvements to this manual, we would welcome comment s

and constructive criticism. Please send all such - in writing to: sup port@advan-

tech.com

Warning! Warnings indicate conditions, which if not observed, can cause personal

injury!

Caution! Cautions are included to help you avoid damaging hardware or losing

data. e.g.

There is a danger of a new battery exploding if it is incorrectly installed.

Do not attempt to recharge, force open, or heat the battery. Replace the

battery only with the same or equivalent type recommended by the man-

ufacturer. Discard used batteries according to the manufacturer's

instructions.

Note! Notes provide optional additional information.

Safety Instructions

1. Read these safety instructions carefully.

2. Keep this User Manual for later reference.

3. Disconnect this equipment from any AC outlet before cleaning. Use a damp

cloth. Do not use liquid or spray detergents for cleaning.

4. For plug-in equipment, the power outlet socket must be located near the equip-

ment and must be easily accessible.

5. Keep this equipment away from humidity.

6. Put this equipment on a reliable surface during installation. Dropping it or letting

it fall may cause damage.

7. The openings on the enclosure are for air convection. Protect the equipment

from overheating. DO NOT COVER THE OPENINGS.

8. Make sure the voltage of the power source is correct before connecting the

equipment to the power outlet.

9. Position the power cord so that people cannot step on it. Do not place anything

over the power cord.

10. All cautions and warnings on the equipment should be noted.

11. If the equipment is not used for a long time, disconnect it from the power source

to avoid damage by transient overvoltage.

12. Never pour any liquid into an opening. This may cause fire or electrical shock.

13. Never open the equipment. For safety reasons, the equipment should be

opened only by qualified service personnel.

14. If one of the following situations arises, get the equipment checked by service

personnel:

 The power cord or plug is damaged.

 Liquid has penetrated into the equipment.

 The equipment has been exposed to moisture.

 The equipment does not work well, or you cannot get it to work according to

the user's manual.

 The equipment has been dropped and damaged.

 The equipment has obvious signs of breakage.

15. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT WHERE THE

STORAGE TEMPERATURE MAY GO BELOW -20° C (-4° F) OR ABOVE 60° C

(140° F). THIS COULD DAMAGE THE EQUIPMENT. THE EQUIPMENT

SHOULD BE IN A CONTROLLED ENVIRONMENT.

16. CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY

REPLACED. REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE

RECOMMENDED BY THE MANUFACTURER, DISCARD USED BATTERIES

ACCORDING TO THE MANUFACTURER'S INSTRUCTIONS.

The sound pressure level at the operator's position according to IEC 704-1:1982 is

no more than 70 dB (A).

DISCLAIMER: This set of instructions is given accord ing to IEC 704-1. Advantech

disclaims all responsibility for the accuracy of any statements contained herein.

Caution! For power adapter selection: the information about the adapter output

rating (12 Vdc, 5 A min, or 18 W min) is provided in the user manual for

user's selection if the power adapter is not shipped with the unit

Chapter 1

1Overview

Sections include:

Introduction

Features

Applications

Naming Rule

1.1 Introduction

The Advantech ITM-5117 is a brand new Industrial Touch Monitor, designed to meet

the needs of custome rs who wan t quick and easy integrations with Advantech

Embedded Box Computers, like ARK, and DSA. Advantech offers four different types

of ITM-5117 to meet customer's demands. In this manual Advantech will be introducing

ITM-5117R-MA1E (Standalone Monitor series)

1.2 Features

17'' SXGA LED backlight panel which provides 20 ~ 30% power saving

Special easy to clean design of 5-wire resistive plane touch window

All new frame rail design provides a variety of connectors for peripheral devices

Simple & elegant ID design with IP54 front panel protection

Panel with BOX PC combination provides more flexibility for applications

Stable Industrial grade rugged aluminum holder to adjust monitor angle

Long time industrial component support

Combo RS-232 & USB interface for touchscreen function

1.3 Applications

Application scenarios - self-service applications:

KIOSK / POI machine

Transportation machine

Ticketing machine

Financial ATM

Entertainment / Gaming / Slot machine

HMI (Human-Machine Interface) equipment controller monitor

Public communication machine

Public advertisement machine

1.4 Naming Rule

ITM-5117R-MA1E

12 3 4 5 6 78

Code 1 Integration Level

ITM-5 Panel Mount LCD

Monitor

ITM-6 Sunlight Readable

Monitor

Code 5 SKU

M Monitor

P Pluggable

with ARK

L I-Panel link

with ARK

C All-in-one

Code 2 Type

1 4:3

2 16:9

Code 3 LCD Size

19 19”

17 17”

15 15”

12 12”

10 10”

08 8”

Code 4 Touchscreen

G Glass

R Resistive

P Projected

Capacitive

Code 7 Revision

Change

(minor)

1 1

2 2

Code 8 Standard

E RoHS

Code 6 Revision

Change

(critical)

A A

B B

6.4”

Chapter 2

2System Setup

Sections include:

Specifications

Dimensions

Panel Mount Assembling SOP

Cable Clamp

Accessory Packing

2.1 Specifications

Note! The ITM-511series offers the following features and meets precise

specifications.

Unless otherwise noted, all the information listed below is subject to

change without prior notification.

Display

Size 17“ LED backlight panel

Resolution 1280 x 1024 (SXGA)

Viewing Angle 85°/85°/85°/85°

Brightness 350 (cd/m2)

Support Color 16.7 M / 262K colors

Contrast Ratio 1000

Response Time 30 [msec]

Lamp Life (hrs) 50,000 hrs

Touch

T/S Type 5-Wire Resistive Touch Window

Surface

Hardness 3 H

Durability 36 millions times with a silicone rubber.

Hit rate is by 250 g at 2 times per second.

Environment

Operating

Temperature -20 ~ + 60° C

Storage

Temperature -30 ~ + 70° C

Humidity 5 ~ 95% @ 40° C, non-condensing

Shock 10G peak acceleration (11 ms duration)

Front panel IP54

System

IO (M series) VGA x 1; DVI-D x 1; 12 VDC Jack x 1; USB x1; RS-232X1

(USB & RS-232 are only for touch screen function)

OSD (M series)

Keys: Menu, Up, Down, Enter, Monitor power on/off

Menu Functions: Brightness, Volume, Contrast, Clock

Phase, Horizontal Position, Vertical Position and Sharp-

ness

Power 60 W power adapter, with AC 100 ~ 240 V input and DC

+12 V @ 5 A output

EMC

Compliance CE/FCC/CCC/BSMI

Safety UL/CB/CCC /BSMI

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Advantech écran tactile

Advantech

Advantech UTC-320 Manuel utilisateur

Advantech

Advantech TPC-660E Manuel utilisateur

Advantech

Advantech ProFlat IDP-31150 Manuel utilisateur

Advantech

Advantech POC-W242 Manuel utilisateur

Advantech

Advantech FPM-3159 Series Manuel utilisateur

Advantech

Advantech IDP31-156W Series Manuel utilisateur

Advantech

Advantech UTC-520A Manuel utilisateur

Advantech

Advantech IDP31-150 Series Manuel utilisateur

Advantech

Advantech IDK-1119R-35SXA1E Manuel utilisateur

Advantech

Advantech IDP31-215W Series Manuel utilisateur

Advantech

Advantech FPM-5151 Series Manuel utilisateur

Advantech

Advantech UPOS-M15 Series Manuel d'installation et d'exploitation

Advantech

Advantech TPC-660G Manuel utilisateur

Advantech

Advantech IDP31-156WP Series Manuel utilisateur

Advantech

Advantech ProFlat IDP-31156W Manuel utilisateur

Advantech

Advantech ProFlat IDP-31230W Manuel utilisateur

Advantech

Advantech ProFlat IDP-31320W Manuel utilisateur

Advantech

Advantech HIT-W121 Manuel utilisateur

Advantech

Advantech TPC-662G-B1E Manuel utilisateur

Advantech

Advantech TPC-31 Manuel utilisateur

Advantech

Advantech ProFlat IDP-31190 Manuel utilisateur

Advantech

Advantech TPC-1071H Manuel utilisateur

Manuels écran tactile populaires d'autres marques

Elecro Engineering

Elecro Engineering Poolsmart Plus Instructions d'installation

Johnson Controls

Johnson Controls IQ4 HUB Manuel utilisateur

Elo TouchSystems

Elo TouchSystems ET2270L Manuel utilisateur

Elo TouchSystems

Elo TouchSystems ET1002L Manuel utilisateur

Elo TouchSystems

Elo TouchSystems 3201L Manuel utilisateur

Duratec

Duratec S15 Manuel utilisateur

Crestron

Crestron TPMC-3SM Manuel utilisateur

Racelogic

Racelogic MFD Touch Manuel utilisateur

J2 580 Guide de l'utilisateur

HAI

HAI OmniTouch 10p Manuel utilisateur

panel

panel PC PSR108-FM Series Manuel utilisateur

Tipro

Tipro FREE+ Manuel utilisateur

Systemline

Systemline Commander Manuel utilisateur

Interactive Technologies

Interactive Technologies Insite Manuel utilisateur

GVision

GVision Legacy Manuel utilisateur

BeiJer

BeiJer T21C-C24 Manuel utilisateur

Edge

Edge CS Manuel utilisateur

Elo TouchSystems

Elo TouchSystems WALLABY PRO Manuel utilisateur
