Racelogic MFD Touch Manuel utilisateur

M D Touch User Manual

•01 Getting Started – M D Touch

•02 Installing M D Touch

•03 Screen Layout - M D Touch

•04 Data Display - M D Touch

•M D Touch - Analogue Gauge Screen

•M D Touch - Bar Graph Screen

•M D Touch - G-Ball Screen

•M D Touch - Numerical Screens

•M D Touch - Target Screen

•05 Settings - M D Touch

•07 - M D Touch Technical Properties

•M D Touch - EC Declaration of Conformity

•M D Touch - PIN OUTS

•M D Touch - Technical Specification

•M D Touch - Updating the irmware

01 Getting Started – M D Touch

Registration

Please register your M D Touch unit so that Racelogic

can continue to provide you with notification of the latest

software releases, firmware upgrades and to offer

technical support.

What is in the box?

Product Code Quantity Description

VBMFDT 1 M D Touch Unit

RLCAB005-C 1 VBOX to VBOX Module Cable (2 m)

RLACS331 1 Swivel Neck Richter Suction Mount

RLACS313 18 GB SD Ultima Pro UHS-1 Memory

Card

https://en.racelogic.support//Product_Info/Displays/M D_Touch/M D_Touch_User_Guide/01_-_M D_Touch_Introduction

Compatible VBOX Products

VBOX 3i / VBOX 3i Dual Antenna /

VBOX 3i RT

VBOX 3iS / VBOX 3iS Dual

Antenna RT VBOX 100 Hz Speed Sensors

Displayed Parameters

Standard parameters used are from the standard Racelogic CAN output from the VBOX.

Decel test parameters are commonly used in brake testing, the majority of which require the use of the VBOX Brake

Trigger Switch or VBOX Pedal Force Sensor and Event Marker Interface.

Standard Parameters Decel Test Parameters Accel Test Parameters

• Speed (km/h or mph)

• Satellite Count

• Heading (degrees north)

• UTC Time

• Height (m or ft)

• Vertical Velocity (km/h or mph)

• Longitudinal Acceleration (g or

m/s²)

• Lateral Acceleration (g or m/s²)

• Max lateral Acceleration (g or

m/s²)

• Average Speed (km/h or mph)

• Distance Travelled (m or ft)

• Longitude (degrees minutes

decimal seconds)

• Deceleration Test Number

• Deceleration Distance (m or ft)

• Deceleration Time (s)

• Deceleration Test Start Speed

(km/h or mph)

• Deceleration AMS Distance (m

or ft)

• Deceleration M DD (g or m/s²)

• Average Deceleration (km/h or

mph)

• Peak Deceleration (km/h or

mph)

• Deceleration Centreline

Deviation (m or ft)

• Trigger Test Number

• Distance from Trigger (m or ft)

• Acceleration Test Number

• Acceleration Time (s)

• Acceleration Distance (m or ft)

• Maximum Speed (km/h or mph)

• Peak Acceleration (km/h or

mph)

• Average Acceleration (km/h or

mph)

• Speed at Distance (km/h or

mph)

https://en.racelogic.support//Product_Info/Displays/M D_Touch/M D_Touch_User_Guide/01_-_M D_Touch_Introduction

Standard Parameters Decel Test Parameters Accel Test Parameters

• Latitude (degrees minutes

decimal seconds)

• Solution Type

• Trigger

• Radius of Turn (m or ft)

• ilename

(VBOX 3i only)

• Logging Status

(VBOX 3i only)

• Memory Used (%)

(VBOX 3i only)

• K Status

(VBOX 3i and VBOX 3iS only)

• Speed Quality (km/h or mph)

• Time from Trigger (s)

• Speed at Trigger (km/h or mph)

• Corrected Trigger Distance (m

or ft)

• Trigger AMS Distance (m or ft)

• Trigger M DD (g or m/s²)

• Trigger Average Deceleration (g

or m/s²)

• Trigger Peak Deceleration (g or

m/s²)

• Trigger Centreline Deviation (m

or ft)

CAN Parameters

When you connect M D Touch to a VBOX data logger (CAN data source is not available with VBOX Speed

Sensors) and have configured the CAN channels you want to capture, the VBOX CAN button will become visible on the

Select Data Source screen.

https://en.racelogic.support//Product_Info/Displays/M D_Touch/M D_Touch_User_Guide/01_-_M D_Touch_Introduction

VBOX CAN data source is available Example of CAN channels available from an IMU04

or a CAN channel to be available for selection, it must be selected to log by the VBOX unit via the VBOX Setup

software, and it must be compatible with the display element on M D Touch.

IMPORTANT

If you configure the VBOX to log 32 or more CAN channels, you may witness some erroneous behaviour where

selected CAN parameters change on the MFD Touch display.

https://en.racelogic.support//Product_Info/Displays/M D_Touch/M D_Touch_User_Guide/01_-_M D_Touch_Introduction

02 Installing M D Touch

Connectors

You can find more detailed connector information on the PIN OUTS page.

Left Side

SD Card

The unit uses an SD card to save and load settings, save test results and update the firmware. You can find more

information here.

https://en.racelogic.support//Product_Info/Displays/M D_Touch/M D_Touch_User_Guide/02_-_M D_Touch_Getting_Started

Right Side

CAN Input

The bottom M D Touch Lemo port is for connecting CAN to the VBOX using the supplied RLCAB005-C cable. CAN

Output is also available on this port by using an RLVBACS024 CAN splitter. You can find more information here.

CAN Output / RACELOGIC Module Connection

The top M D Touch Lemo port is for CAN Output. More information on this is available here.

You can use M D Touch as part of a daisy chain with additional Racelogic modules connected to the VBOX.

Connection to VBOX 3i / VBOX 3i Dual Antenna / VBOX 3i RTK

M D Touch connects to VBOX 3i with the supplied RLCAB005-C cable, from the Bottom CAN socket on the M D

Touch to the CAN port on the VBOX 3i.

https://en.racelogic.support//Product_Info/Displays/M D_Touch/M D_Touch_User_Guide/02_-_M D_Touch_Getting_Started

If you are using a CAN Hub, you connect M D Touch with the supplied RLCAB005-C cable from the the

Bottom CAN socket on M D Touch to the MFD port on the CAN Hub.

You can use M D Touch as part of a daisy chain with additional Racelogic modules connected to VBOX 3i.

Connection to VBOX 3iS / VBOX 3iS Dual Antenna RTK

When connecting M D Touch to a VBOX 3iS/3iSR, you must connect the cable labelled "CAN OUT + POWER" to the

bottom port on the M D Touch.

If you are using a wiring loom, you must identify and connect the connector labelled "CAN OUT + POWER" to the

bottom port on the M D Touch. If you need help identifying the connector, you can find the relevant cable drawing here.

https://en.racelogic.support//Product_Info/Displays/M D_Touch/M D_Touch_User_Guide/02_-_M D_Touch_Getting_Started

Connection to VBOX 100 Hz Speed Sensor

When connecting M D Touch to a VBOX 100 Hz Speed Sensor, you must connect the cable labelled "CAN OUT" to the

bottom port on the M D Touch.

If you are using a wiring loom, you must identify the CAN Out connector and connect it to the bottom port on the M D

Touch. If you need help identifying the connector, you can find the relevant cable drawing here.

https://en.racelogic.support//Product_Info/Displays/M D_Touch/M D_Touch_User_Guide/02_-_M D_Touch_Getting_Started

Power

The M D Touch display powers via the connection to the VBOX unit. On boot up, the M D Touch displays a splash

screen. As M D Touch boots up quicker than the VBOX, it will display 'Waiting for VBOX' with a scrolling progress bar

until the VBOX is fully booted up.

https://en.racelogic.support//Product_Info/Displays/M D_Touch/M D_Touch_User_Guide/02_-_M D_Touch_Getting_Started
