Rose electronics CrystalLink USB2.0 CATx Manuel utilisateur

CrystalLink USB

2.0 CATx

USB2.0 CATx

Extender

Installation

and

Operation Manual

10707 Stancliff Road

Houston, Texas 77099

Phone: (281) 933-7673

[email protected]

LIMITED WARRANTY

No part of this manual may be reproduced, stored in a retrieval system, or transcribed in any form or any means, electronic or mechanical, including photocopying and

recording, without the prior written permission of Rose Electronics.

manual-crystallink-usb2.0-catx-revb-2018-03-25

Rose Electronics®warrants the CrystalLink USB2.0 CATx Extender to be in good working order for one year

from the date of purchase from Rose Electronics or an authorized dealer. Should this product fail to be in good

working order at any time during this one-year warranty period, Rose Electronics will, at its option, repair or

replace the Unit as set forth below. Repair parts and replacement units will be either reconditioned or new. All

replaced parts become the property of Rose Electronics. This limited warranty does not include service to

repair damage to the Unit resulting from accident, disaster, abuse, or unauthorized modification of the Unit,

including static discharge and power surges.

Limited Warranty service may be obtained by delivering this unit during the one-year warranty period to Rose

Electronics or an authorized repair center providing a proof of purchase date. If this Unit is delivered by mail,

you agree to insure the Unit or assume the risk of loss or damage in transit, to prepay shipping charges to the

warranty service location, and to use the original shipping container or its equivalent. You must call for a return

authorization number first. Under no circumstances will a unit be accepted without a return authorization

number. Contact an authorized repair center or Rose Electronics for further information.

ALL EXPRESS AND IMPLIED WARRANTIES FOR THIS PRODUCT INCLUDING THE WARRANTIES OF

MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED IN DURATION TO A

PERIOD OF ONE YEAR FROM THE DATE OF PURCHASE, AND NO WARRANTIES, WHETHER EXPRESS

OR IMPLIED, WILL APPLY AFTER THIS PERIOD. SOME STATES DO NOT ALLOW LIMITATIONS ON HOW

LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY TO YOU.

IF THIS PRODUCT IS NOT IN GOOD WORKING ORDER AS WARRANTIED ABOVE, YOUR SOLE

REMEDY SHALL BE REPLACEMENT OR REPAIR AS PROVIDED ABOVE. IN NO EVENT WILL ROSE

ELECTRONICS BE LIABLE TO YOU FOR ANY DAMAGES INCLUDING ANY LOST PROFITS, LOST

SAVINGS OR OTHER INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF OR

THE INABILITY TO USE SUCH PRODUCT, EVEN IF ROSE ELECTRONICS OR AN AUTHORIZED DEALER

HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES, OR FOR ANY CLAIM BY ANY OTHER

PARTY.

SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR

CONSEQUENTIAL DAMAGES FOR CONSUMER PRODUCTS, SO THE ABOVE MAY NOT APPLY TO YOU.

THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS AND YOU MAY ALSO HAVE OTHER RIGHTS

WHICH MAY VARY FROM STATE TO STATE.

DECLARATIONS OF CONFORMITY

This is to certify that, when installed and used according to the instructions in this manual, the units listed and

described here are shielded against the generation of radio interferences in accordance with the application of

Council Directives 2014/30/EU and 2014/30/EU, as well as these standards:

■EN 55022: 2010/AC:2011 (Class B)

■EN 55024:2010 + A1:2015

■EN 61000

This equipment has been found to comply with the limits for a Class A digital device, pursuant to Part 15 of the

FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the

equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio

frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful

interference to radio communications. Operation of this equipment in a residential area is likely to cause

harmful interference in which case the user will be required to correct the interference at their own expense.

The product safety of the devices is proven by their compliance with the following standards:

■CAN/CSA-ICES-003 Class B

The manufacturer complies with the EU Directive 2012/19/EU on the prevention of waste electrical and

electronic equipment (WEEE). The device labels carry a respective marking.

These devices comply with Directive 2011/65/EU of the European Parliament and of the council of 8 June

2011 on the restriction of the use of certain hazardous substances in electrical and electronic equipment

(RoHS 2, RoHS II). The device labels carry a respective marking.

TABLE OF CONTENTS

Contents

Disclaimer 1

System Introduction 1

Features 1

Package Contents 2

Additional Items Required 2

Application Examples 2

CrystalLink USB2.0 CATx Models 3

Transmitter Unit 3

Receiver Unit 4

Installation Procedure 6

Installation Using Premise Wiring 6

Installing the Transmitter Unit 6

Installing the Receiver Unit 6

Connecting the Transmitter to Receiver 7

Connection Using Surface Cabling 7

Connection Using Premise Cabling 7

Connecting a USB Device 7

Checking the Installation 7

Compatibility 7

Transmitter and Receiver Mounting Options 8

Option 1: CrystalLink USB2.0 CATx Extender Mounting Bracket Kit 8

Option 2: CrystalLink USB2.0 CATx Extender Mounting Plate 8

Troubleshooting Guide 9

Safety 10

Maintenance and Repair 11

Technical Support 11

Figures

Figure 1. Transmitter unit – LED’s and connectors 4

Figure 2. Receiver unit – LED’s and connectors 5

Figure 3. CrystalLink USB2.0 CATx extender – standard installation 6

Figure 4. Chassis mounting options 8

Figure 5. CAT5e/6/7 cable termination pinning 13

Tables

Table 1. Troubleshooting procedures ............................................................................................... 9

Appendices

Appendix A —Specifications 12

Appendix B —CAT5e/6/7 Cable Termination 13

INTRODUCTION

CrystalLink USB2.0 CATx Extender Manual 1

Disclaimer

While every precaution has been taken in the preparation of this manual, the manufacturer assumes no

responsibility for errors or omissions. Neither does the manufacturer assume any liability for damages resulting

from the use of the information contained herein. The manufacturer reserves the right to change the

specifications, functions, circuitry of the product, and manual content at any time without notice.

The manufacturer cannot accept liability for damages due to misuse of the product or other circumstances

outside the manufacturer’s control. The manufacturer will not be responsible for any loss, damage, or injury

arising directly or indirectly from the use of this product (See limited warranty).

System Introduction

Thank you for choosing the Rose Electronics CrystalLink USB2.0 CATx extender.

The CrystalLink USB2.0 CATx has proven to be a valuable investment for any business, big or small, that has

a need to access and extend their USB1.1 or 2.0 peripherals up to 330ft (1200 meters) from a remote location.

The receiver unit’s USB ports connect to your USB peripherals. The number of peripherals can be increased

by using a standard USB hub.

The USB peripherals can be USB1.1 devices (low-speed or full-speed) or USB2.0 high-speed devices

operating up to 480 Mb/s. The receiver unit can supply up to 600ma per USB port for driving high-power USB

devices.

Plug-and-play installation makes the product simple and easy to use. Connect the transmitter to the computers

USB port, connect the USB ports on the receiver to your USB devices, connect the transmitter to the receiver

with up to 330 feet of industry standard CATx cable and power on the system.

The instructions in this manual assume a general knowledge of computer installation procedures, familiarity

with cabling requirements, and some understanding of USB device operation.

Features

■Supports transparent extension of USB 2.0 (high-speed) and USB 1.1 (low and full speed) devices

■Extends USB devices up to 330 feet (100meters) over solid-core CATx cable

■Four-port integrated USB2.0 hub on the receiver unit

■Standard USB hubs can be used to increase the number of connected devices up to 30.

■USB3.0 devices will work at USB2.0 speeds through the extender

■Up to 600ma of power is available at each USB port for high-powered USB devices

■Plug-and-Play installation, no configuration or set-up needed

■Operating system independent and supports all major operating systems

CrystalLink USB2.0 CATx Extender Manual 2

Package Contents

The package contents consist of the following:

■Transmitter unit

■Receiver unit

■USB2.0 cable

■24V DC Power Adapter (1) and AC power cable (1)

■Manual

Additional Items Required

■USB compatible computer (host computer) with a USB compliant operating system

■USB compatible device(s) for remote-end connection

■Solid-core CATx Unshielded Twisted Pair (UTP) cable or shielded (STP) cable up to a maximum of 330ft

(100meters).

■For optimum performance, the CATx cable should be run straight and not coiled, and not routed close to

electrical cables or radio interference. Terminate the cables according to T568A/T568B.

All references to CAT5e/6/7 cable in this document refer to solid-core cable and represent the minimum

CAT5e/6//7 specification requirements. Use of UTP or STP patch-cables may reduce the recommended cable

extension distances.

Application Examples

The CrystalLink USB2.0 CATx extender is ideal for use with any USB2.0 device in an office, computer room

or industrial environment where USB devices need to be connected remotely from a host PC.

■Industrial control

■Interactive whiteboard

■Connection to network attached devices

■Boardroom and conferencing presentations.

■Extension of multiple USB devices including hard drivers, printer, scanner, camera control, touchscreens

Figure 1. CrystalLink USB2.0 CATX Extender – front and back panels

MODELS

CrystalLink USB2.0 CATx Extender Manual 3

CrystalLink USB2.0 CATx Models

The CrystalLink USB2.0 CATx enables users to extend beyond the standard 15ft (5.0 meter) cable limit for

USB peripherals by locating high-speed USB device(s) up to 330 feet (100 meters) from the computer.

Transmitter Unit

The transmitter connects to the host device using the supplied USB cable. Power for the transmitter is provided

by the host computer. Power and status LED’s are conveniently located on the front panel for user reference.

Transmitter unit – front panel view

Transmitter unit – rear panel view

Item Type Description

Power LED (Blue) LED turns on when power is supplied.

LED is off when no power is supplied by the host computer.

Link LED (Green)

Indicates a valid USB link is established between the local and remote

extenders.

LED turns on when link between local and remote extender is established.

LED is off when there is no link between local and remote extenders.

LED is slow blinking when the unit is attempting to establish a link

Host LED (Green) LED turns on when the extender system is properly enumerated on the

host computer.

LED blinks when in a suspended state.

Activity LED (Amber)

Indicates data transmission is occurring between local and remote

extenders.

LED blinks intermittently with or without a USB device connected. When

the local and remote extenders are in suspend mode, the LED is off.

CrystalLink USB2.0 CATx Extender Manual 4

2 Config Reserved for engineering use

3 Mode Reserved for engineering use

4 USB Host Port

Used to connect the local extender unit to the host computer. Accepts Type

B connector into the local extender unit.

5 Link Port (RJ45) Accepts RJ45 connector for CAT5e/6/7 cabling to connect the local

extender unit to the remote extender unit.

Figure 2. Transmitter unit – LED’s and connectors

Receiver Unit

The receiver has four USB Type-A ports for connecting up to four USB devices. Additional devices may be

connected by attaching a USB hub to the receiver unit. The receiver is powered directly by the included 24V

power supply, delivering 600mA of current per USB port.

Receiver unit – front panel view

Receiver unit – rear panel view

Item Type Description

1 USB Device Ports Accepts USB device(s) using Type A connectors

Power LED (Blue) LED turns on when power is supplied, off when no power is supplied.

Link LED (Green)

Indicates a valid USB link is established between the local and remote

extenders.

LED turns on when link between local and remote extenders is established.

LED is off when there is no link between local and remote extenders.

Host LED (Green) Indicates that the RG2304 system is properly enumerated on the host

computer. The LED blinks when in a suspended state.

Activity LED (Amber)

Indicates data transmission is occurring between local and remote

extenders. LED blinks intermittently with or without a USB device

connected. When the local and remote extenders are in suspend mode,

the LED is off.

CrystalLink USB2.0 CATx Extender Manual 5

3 DC Power Port Connects to the AC power supply. Required at the remote extender for

proper operation.

4 Config Reserved for manufacturer use.

5 Mode Reserved for manufacturer use.

6 Link Port (RJ45) Accepts RJ45 connector for CAT 5e/6/7 cabling to connect the local

extender to the remote extender unit

Figure 3. Receiver unit – LED’s and connectors

INSTALLATION

CrystalLink USB2.0 CATx Extender Manual 6

Installation Procedure

Before beginning an installation, ensure you have all products and components ready for the installation

Figure 4. CrystalLink USB2.0 CATx extender – standard installation



Determine where the computer is to be located and set up the computer.



Determine where you want to locate the remote USB device(s).



Remember the product supports a maximum distance of 330ft (100m) for transparent USB devices. If

using patch (stranded) cables or premise wiring, the achievable extension distance may be less.



Avoid potential sources of interference such as electrical wiring, fluorescent lighting and radio

communications equipment.



Ensure that the CATx cable is terminated with matching connectors. For example, a CAT6 cable should

be terminated with compatible CAT6 connectors.

Installation Using Premise Wiring

If you are using premise cabling, ensure CATx cabling is installed between the two locations, with CATx

premise outlets located near both the computer and the USB device(s), and the total length, including patch

cords is not more than 330ft (100m).

Installing the Transmitter Unit



Place the transmitter unit near the computer.



Install the supplied USB cable between the transmitter and USB port on the host computer.

Installing the Receiver Unit

Place the receiver unit near the USB device(s) in the desired remote location.

USB Host

TX Unit

RX Unit

CATx Cable

330ft (100m)

USB2.0

Devices

Autres manuels pour CrystalLink USB2.0 CATx

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Rose electronics Extenseur

Rose electronics

Rose electronics CRYSTALVIEW USB 1.1 Manuel utilisateur

Rose electronics

Rose electronics CrystalLink USB-3-2-1 Fiber Manuel utilisateur

Rose electronics

Rose electronics CLK-4U2FM-500M Manuel utilisateur

Rose electronics

Rose electronics CrystalLink USB2.0 CATx Manuel utilisateur

Rose electronics

Rose electronics CrystalView DVI CAT Series Manuel utilisateur

Rose electronics

Rose electronics CrystalView DVI EX Manuel utilisateur

Rose electronics

Rose electronics CrystalView Micro LT Manuel utilisateur

Rose electronics

Rose electronics CrystalView DVI Quad Guide de configuration

Rose electronics

Rose electronics CrystalView DVI CATx CRK-2DTXPD1D Manuel utilisateur

Rose electronics

Rose electronics CrystalView EX5 Manuel utilisateur

Rose electronics

Rose electronics Cybernetech CLK-2U2TP-100M Manuel utilisateur

Rose electronics

Rose electronics VideoSplitter CAT5 Manuel utilisateur

Rose electronics

Rose electronics CRK-2DTPPDVI Manuel utilisateur

Rose electronics

Rose electronics CrystalView DVI Plus Manuel utilisateur

Rose electronics

Rose electronics CrystalView Rack CRV-12SLP Manuel du propriétaire

Rose electronics

Rose electronics CrystalView HDT Manuel utilisateur

Rose electronics

Rose electronics CrystalLink CAT5 Serial Manuel utilisateur

Rose electronics

Rose electronics ViewLink Coax Manuel utilisateur

Rose electronics

Rose electronics AUTO EQUALIZATION Manuel utilisateur

Rose electronics

Rose electronics CrystalLink USB2.0 CATx Manuel utilisateur

Rose electronics

Rose electronics CLK-4U2TP-100M Manuel utilisateur

Rose electronics

Rose electronics CrystalLink USB Fiber Manuel utilisateur

Rose electronics

Rose electronics CrystalLink USB-3-2-1 Fiber Manuel utilisateur

Rose electronics

Rose electronics CrystalView EX DVI Multi CRK-1DTXT2DM-2T-EX6 Manuel utilisateur

Manuels Extenseur populaires d'autres marques

SY HDBT-60T Manuel utilisateur

Appsys ProAudio

Appsys ProAudio ADX-16 Manuel utilisateur

Atlona

Atlona RS232 Manuel utilisateur

IDK

IDK OPF-TH1000-A Manuel utilisateur

Enable-IT

Enable-IT 824WP Manuel utilisateur

Worx

Worx Landroid RadioLink WA0864 Fiche technique

TP-Link

TP-Link TL-WA730RE Manuel utilisateur

Camplex

Camplex CMX-HDMI-SFPL Manuel utilisateur

SC&T

SC&T HE03-4K Manuel utilisateur

Marmitek

Marmitek MegaView70 Manuel utilisateur

Samsung

Samsung SCS-26UC4 Manuel utilisateur

Foxun

Foxun SX-GES24 Manuel utilisateur

MuxLab

MuxLab 500771 Manuel utilisateur

foxunhd

foxunhd SX-AEX01 Manuel utilisateur

TERK Technologies

TERK Technologies LFIRX2 Manuel utilisateur

Devolo

Devolo Audio Extender Manuel

Edimax

Edimax EW-7438RPn V2 Manuel utilisateur

Shinybow USA

Shinybow USA SB-6335T5 Manuel utilisateur
