Rigol RSA Series Manuel utilisateur

User Guide

Vector Network Analyzer

Applicable to RSA5000N/RSA3000N

Jul. 2020

RIGOL TECHNOLOGIES CO., LTD.

RIGOL

VNA User Guide I

Guaranty and Declaration

Trademark Information

RIGOL®is the trademark of RIGOL TECHNOLOGIES CO., LTD.

Publication Number

UGD24100-1110

Software Version

00.03.00

Software upgrade might change or add product features. Please acquire the latest

version of the manual from RIGOL website or contact RIGOL to upgrade the

software.

Notices

⚫RIGOL products are covered by P.R.C. and foreign patents, issued and pending.

⚫RIGOL reserves the right to modify or change parts of or all the specifications

and pricing policies at the company’s sole decision.

⚫Information in this publication replaces all previously released materials.

⚫Information in this publication is subject to change without notice.

⚫RIGOL shall not be liable for either incidental or consequential losses in

connection with the furnishing, use, or performance of this manual, as well as

any information contained.

⚫Any part of this document is forbidden to be copied, photocopied, or rearranged

without prior written approval of RIGOL.

Product Certification

RIGOL guarantees that this product conforms to the national and industrial

standards in China as well as the ISO9001:2015 standard and the ISO14001:2015

standard. Other international standard conformance certifications are in progress.

If you have any problem or requirement when using our products or this manual,

please contact RIGOL.

E-mail: servi[email protected]m

Website: www.rigol.com

RIGOL

II VNA User Guide

Safety Requirement

General Safety Summary

Please review the following safety precautions carefully before putting the

instrument into operation so as to avoid any personal injury or damage to the

instrument and any product connected to it. To prevent potential hazards, please

follow the instructions specified in this manual to use the instrument properly.

Use Proper Power Cord.

Only the exclusive power cord designed for the instrument and authorized for use

within the local country could be used.

Ground the Instrument.

The instrument is grounded through the Protective Earth lead of the power cord. To

avoid electric shock, connect the earth terminal of the power cord to the Protective

Earth terminal before connecting any input or output terminals.

Connect the Probe Correctly.

If a probe is used, the probe ground lead must be connected to earth ground. Do not

connect the ground lead to high voltage. Improper way of connection could result in

dangerous voltages being present on the connectors, controls or other surfaces of

the oscilloscope and probes, which will cause potential hazards for operators.

Observe All Terminal Ratings.

To avoid fire or shock hazard, observe all ratings and markers on the instrument and

check your manual for more information about ratings before connecting the

instrument.

Use Proper Overvoltage Protection.

Ensure that no overvoltage (such as that caused by a bolt of lightning) can reach the

product. Otherwise, the operator might be exposed to the danger of an electric

shock.

Do Not Operate Without Covers.

Do not operate the instrument with covers or panels removed.

Do Not Insert Objects into the Air Outlet.

Do not insert objects into the air outlet, as doing so may cause damage to the

instrument.

Use Proper Fuse.

Please use the specified fuses.

RIGOL

VNA User Guide III

Avoid Circuit or Wire Exposure.

Do not touch exposed junctions and components when the unit is powered on.

Do Not Operate with Suspected Failures.

If you suspect that any damage may occur to the instrument, have it inspected by

RIGOL authorized personnel before further operations. Any maintenance,

adjustment or replacement especially to circuits or accessories must be performed

by RIGOL authorized personnel.

Provide Adequate Ventilation.

Inadequate ventilation may cause an increase of temperature in the instrument,

which would cause damage to the instrument. So please keep the instrument well

ventilated and inspect the air outlet and the fan regularly.

Do Not Operate in Wet Conditions.

To avoid short circuit inside the instrument or electric shock, never operate the

instrument in a humid environment.

Do Not Operate in an Explosive Atmosphere.

To avoid personal injuries or damage to the instrument, never operate the

instrument in an explosive atmosphere.

Keep Product Surfaces Clean and Dry.

To avoid dust or moisture from affecting the performance of the instrument, keep the

surfaces of the instrument clean and dry.

Prevent Electrostatic Impact.

Operate the instrument in an electrostatic discharge protective environment to avoid

damage induced by static discharges. Always ground both the internal and external

conductors of cables to release static before making connections.

Use the Battery Properly.

Do not expose the battery (if available) to high temperature or fire. Keep it out of the

reach of children. Improper change of a battery (lithium battery) may cause an

explosion. Use the RIGOL specified battery only.

Handle with Caution.

Please handle with care during transportation to avoid damage to keys, knobs,

interfaces, and other parts on the panels.

RIGOL

IV VNA User Guide

Safety Notices and Symbols

Safety Notices in this Manual:

WARNING

Indicates a potentially hazardous situation or practice which, if not

avoided, will result in serious injury or death.

CAUTION

Indicates a potentially hazardous situation or practice which, if not

avoided, could result in damage to the product or loss of important data.

Safety Terms on the Product:

DANGER

It calls attention to an operation, if not correctly performed, could

result in injury or hazard immediately.

WARNING

It calls attention to an operation, if not correctly performed, could

result in potential injury or hazard.

CAUTION

It calls attention to an operation, if not correctly performed, could

result in damage to the product or other devices connected to the

product.

Safety Symbols on the Product:

Hazardous

Voltage

Safety Warning

Protective Earth

Terminal

Chassis Ground

Test Ground

RIGOL

VNA User Guide V

Care and Cleaning

Care

Do not store or leave the instrument where it may be exposed to direct sunlight for

long periods of time.

Cleaning

Clean the instrument regularly according to its operating conditions.

1. Disconnect the instrument from all power sources.

2. Clean the external surfaces of the instrument with a soft cloth dampened with

mild detergent or water. When cleaning the LCD, take care to avoid scarifying it.

CAUTION

To avoid damage to the instrument, do not expose it to caustic liquids.

WARNING

To avoid short-circuit resulting from moisture or personal injuries, ensure

that the instrument is completely dry before connecting it to the power

supply.

Environmental Considerations

The following symbol indicates that this product complies with the WEEE Directive

2002/96/EC.

Product End-of-Life Handling

The equipment may contain substances that could be harmful to the environment or

human health. To avoid the release of such substances into the environment and

avoid harm to human health, we recommend you to recycle this product

appropriately to ensure that most materials are reused or recycled properly. Please

contact your local authorities for disposal or recycling information.

You can click on the following link https://int.rigol.com/services/declaration.html to

download the latest version of the RoHS&WEEE certification file.

RIGOL

VI VNA User Guide

RSA Series Overview

RSA series is a new generation of cost-efficient real-time spectrum analyzer with high

performance. With superb performance specifications and the clear user interface,

the RSA series allows you to operate it through various ways, such as pressing keys

on the front panel, using the touch screen, connecting the mouse and the keyboard.

Remote communication interfaces are also available. The instrument can be widely

used in education science, corporate R&D, industrial production, and other fields.

RIGOL

VNA User Guide VII

Document Overview

Topics in this manual:

Chapter 1 Quick Start

This chapter introduces the front/rear panel and user interface as well as

announcements during first use of the analyzer.

Chapter 2 Functions of the Front Panel

This chapter gives detailed function descriptions of the front panel keys in VNA

mode.

Chapter 3 Appendix

This chapter lists the options and accessories that can be ordered along with your

analyzer as well as the service and support information.

Format Conventions in this Manual:

1. Keys:

The keys on the front panel are usually denoted by the format of "Key Name

(Bold) + Text Box". For example, FREQ denotes the FREQ key.

2. Menu Keys:

The menu softkeys are usually denoted by the format of "Menu Word (Bold) +

Character Shading". For example, Center Freq denotes the center frequency

menu item under the FREQ function key.

3. Connectors:

The connectors on the front or rear panel are usually denoted by the format of

"Connector Name (Bold) + Square Brackets (Bold)". For example, [Gen Output

50Ω].

4. Operation Procedures:

"→" represents the next step of operation. For example, FREQ →Center Freq

indicates pressing FREQ on the front panel and then pressing the menu softkey

Center Freq.

Content Conventions in this Manual:

The RSA series spectrum analyzer that supports VNA includes the following models.

This manual takes RSA5065N as an example.

Model

Frequency Range

VNA Frequency Range

RSA5065N

9 kHz to 6.5 GHz

100 kHz to 6.5 GHz

RSA5032N

9 kHz to 3.2 GHz

100 kHz to 3.2 GHz

RSA3045N

9 kHz to 4.5 GHz

100 kHz to 4.5 GHz

RSA3030N

9 kHz to 3 GHz

100 kHz to 3 GHz

RSA3015N

9 kHz to 1.5 GHz

100 kHz to 1.5 GHz

RIGOL

VIII VNA User Guide

User Manuals of this Product:

Quick Guide, User Guide, Programming Guide, Data sheet, etc. For the desired

manual, please download it from www.rigol.com.
