Ricoh D052 SERIES Instructions d'installation

Ver.1.5 Page 1 of 41 12/12/2008

Subject to change without notice

RICOH Americas Corporation Content ID# rfg032073

Product Support Guide

D052 / D053 / D054

Introduction

Model Type B/W MFP

Launch Date 4/2008

S/N Configuration M92 / M93 / M94

Product Code D052 / D053 / D054

Brand/Model Name

Product Code Gestetner Lanier Ricoh Savin

D052

D053

D054

MP 6000 / 6000SP

MP 7000 / 7000SP

MP 8000 / 8000SP

LD260 / 260SP

LD270 / 270SP

LD280 / 280SP

Aficio MP 6000 / 6000SP

Aficio MP 7000 / 7000SP

Aficio MP 8000 / 8000SP

8060 / 8060sp

8070 / 8070sp

8080 / 8080sp

Product Concept

Provide higher productivity with established superior features for business excellence in an office

environment.

The model MT series has successively established the top position with its excellent features to improve

office efficiency. The B246 series provided the following advanced features:

 Productivity, Usability, Security, Energy-saving

The D052 Series will increase productivity by its cpm speed-up, in addition to the superior features

above.

Product Support Guide

D052 / D053 / D054

Ver. 1.5 Page 2 of 41 12/12/2008

Subject to change without notice

Order Numbers

Main Frame

Name Model EDP Code Lanier ID Notes

Gestetner

MP 6000 / 6000SP

MP 7000 / 7000SP

MP 8000 / 8000SP

414338 / 414340

414341 / 414342

414343 / 414344 N/A -

Lanier LD260 / 260SP

LD270 / 270SP

LD280 / 280SP N/A 479-1946 / 479-1947

479-1948 / 479-1949

479-1950 / 479-1951 -

Ricoh Aficio MP 6000 / 6000SP

Aficio MP 7000 / 7000SP

Aficio MP 8000 / 8000SP

414338 / 414340

414341 / 414342

414343 / 414344 N/A -

Savin 8060 / 8060sp

8070 / 8070sp

8080 / 8080sp

414338 / 414340

414341 / 414342

414343 / 414344 N/A -

Options

Item Description EDP Code Lanier ID Product

Code Common /

Unique

SR970 3000-sheet Finisher

w/50-sheet Stapler 413321 216-1227 B701 Common with

B246 Series

SR4000 2,000-sheet Booklet

Finisher 413319 479-1679 B700 Common with

B246 Series

SR842 3000-sheet Finisher

w/100-sheet Stapler 413310 479-1759 B706 Common with

B246 Series

RT43* Large Capacity Tray 414517 481-7624 B473 Unique to D052

Series

Punch Unit Type 3260

NA 2/3 2/3 Hole Punch for

SR970/SR980/SR4000 412209 216-7116 B702 Common with

B246 Series

Punch Unit Type 1075

NA 2/3 2/3 Hole Punch for

SR842 411198 481-0529 B531 Common with

B246 Series

Cover Interposer Tray

Type 3260 Cover Interposer 412213 216-7118 B704 Common with

B246 Series

Copy Tray Type 2075 Copy Tray 412190 216-7113 B756 Common with

B246 Series

8 1/2" x 14" Paper

Size Tray Type 1075 LG/B4 Option 411187 481-0534 B474 Common with

B246 Series

Key Counter Bracket

Type 1027 Key Counter Bracket 412537 481-0478 B452 Common with

B246 Series

Tab Sheet Holder

Type 3260 Tab Sheet Holder 412203 216-7112 B499 Common with

B246 Series

Product Support Guide

D052 / D053 / D054

Ver. 1.5 Page 3 of 41 12/12/2008

Subject to change without notice

Options

Item Description EDP Code Lanier ID Product

Code Common /

Unique

A3/11"x17" Tray Unit

Type 1075 A3/11"x17" Tray for

Tandem Tray 1 411185 481-0533 B475 Common with

B246 Series

Card Reader Bracket Card Reader Bracket 411203 481-0539 B498 Common with

B246 Series

Output Jogger Unit

Type 3260 Output Jogger for

SR970/SR4000 412212 216-7117 B703 Common with

B246 Series

Output Jogger Unit

Type 1075 Output Jogger for

SR842 411206 481-0538 B513 Common with

B246 Series

File Format Converter

Type C File Format Converter 412823 481-7053 B609 Common with

B246 Series

Copy Connector Kit

Type 7500 Copy Connector Kit 412809 481-7023 B842 Common with

B246 Series

Z-folding Unit ZF4000 Z-Folding Unit 412805 479-1714 B660 Common with

B246 Series

USB Host Interface

Unit Type A USB Host Interface 412867 481-7057 B825 Common with

B246 Series

DataOverwriteSecurity

Unit Type C HDD Data Overwrite

Unit 411989 481-0868 B735 Common with

B246 Series

Type 7500

Removable Hard

Drive Removable Hard Drive 002849MIU 481-7303 - Common with

B246 Series

Type 7500 Additional

Removable Hard

Drive

Additional Removable

Hard Drive 002850MIU 481-7304 - Common with

B246 Series

VM Card Type C Java VM Card 413210 481-7072 B861 Common with

B246 Series

Fax Option Type 7500 Fax Option 413491 481-7190 B819 Common with

B246 Series

G3 Interface Unit

Type 7500 Additional G3 line 413494 481-7191 B820 Common with

B246 Series

32MB Memory

400dpi/SAF Fax SAF Memory 001342MIU 481-0174 - Common with

B246 Series

Printer / Scanner Unit

Type 8000 Printer / Scanner Unit 414367 481-7593 D406 Unique to D052

Series

Printer / Scanner Ricoh Printer/Scanner

Bundle 003445miu - - U

Printer / Scanner Savin Printer/Scanner

Bundle 003446miu - - U

Printer / Scanner Lanier Printer/Scanner

Bundle 003458miu - - U

PostScript 3 Unit Type

7500 PostScript 3 Unit 412916 481-7021 B525 Common with

B246 Series

Copy Data Security

Unit Type C Unauthorized Copy

Control Unit 412808 481-7022 B829 Common with

B246 Series

Product Support Guide

D052 / D053 / D054

Ver. 1.5 Page 4 of 41 12/12/2008

Subject to change without notice

Options

Item Description EDP Code Lanier ID Product

Code Common /

Unique

Browser Unit Type B Web Browser 413083 481-7059 B828 Common with

B246 Series

CS391 9-bin Mailbox 9-bin Mailbox 412191 216-1229 B762 Common with

B246 Series

IEEE 1284 Interface

Board Type A IEEE 1284 Interface

Board 411699 481-0786 B679 Common with

B246 Series

IEEE 1394 Interface

Board Type B IEEE 1394 Interface

Board 412995 481-0683 B581 Common with

B246 Series

IEEE 802.11b

Interface Unit Type N Wireless LAN Interface 414525 481-0907 B736 Unique to D052

Series

Bluetooth Interface

Unit Type 3245 Bluetooth 412866 216-7092 B826

Common with

B246 Series

Gigabit Ethernet Type

7300 1000Base-T Ethernet 402302 481-0893 G381 Common with

B246 Series

BK5010 Plockmatic

Booklet Maker Plockmatic

Bookletmaker 413101 479-1720 - -

CF5010 Cover Feeder Plockmatic Cover

Feeder 413102 481-7078 - -

TR5010 Trimmer Plockmatic Trimmer 413103 481-7076 - -

BF5010 Book Folder

(requires Trimmer) Plockmatic Book

Folder 413104 481-7077 - -

BK5010 Rail Unit Plockmatic Rail Unit 413105 481-7079 - -

GBC StreamPunch III GBC StreamPunch III 414387 479-1745 - -

GBC Die Set 3 Hole

(Ring Binder) Die Set 001450MIU 481-0736 - -

GBC Die Set 11 Hole

(Velobind) Die Set 001451MIU 481-0737 - -

GBC Die Set 19 Hole

(Cerlox) Die Set 001452MIU 481-0738 - -

GBC Die Set 21 Hole

(Twin Loop Wire 2:1) Die Set 001453MIU 481-0739 - -

GBC Die Set 32 Hole

(Twin Loop Wire 3:1) Die Set 001454MIU 481-0740 - -

GBC Die Set 44 Hole

(Color Coil) Die Set 001455MIU 481-0741 - -

GBC Die Set 32 Hole

(Pro Click) Die Set 002493MIU 481-7066 - -

* RT43 LCT has been modified slightly to accommodate 80ppm model.

Product Support Guide

D052 / D053 / D054

Ver. 1.5 Page 5 of 41 12/12/2008

Subject to change without notice

Supplies/Yields

Name/Description Ricoh

Product

Code

Savin

Product

Code

Lanier

Product

Code

Gestetner

Product

Code

Packaging

Yield

(CTN)

Toner Type 6110D (Black) 885400 4 x 1,100 g./Btl. 172,000*

Toner Type 6075 (Black) 9883 4 x 1,100 g./Btl. 172,000*

Toner 6002/7502 (Black) 89883 4 x 1,100 g./Btl. 172,000*

Toner (Black) 480-0089 4 x 1,100 g./Btl. 172,000*

Developer Type 24 (Black) **B0649645 480-0090 1-Each 350,000

Developer Type 6075 (Black) **B0649645 1-Each 350,000

Developer Type DD9 (Black) **B0649645 1-Each 350,000

Staple Type H for SR842 410508 9849 1 x 5,000/Ctn. 5,000

Staple Refill Type H for SR842 410509 9850 5 x 5,000/ Ctn. 25,000

Staple CSC810A for SR842 89849 1 x 5,000/ Ctn. 5,000

Staple Refill CSC810B for SR842 89850 5 x 5,000/ Ctn. 25,000

Staple Type H SC585 for SR842 117-0334 1 x 5,000/ Ctn. 5,000

Staple Refill Type H SC585 for SR842 117-0332 5 x 5,000/ Ctn. 25,000

Staple Type K for SR970/SR4000 410801 9858 1 x 5,000/ Ctn. 5,000

Staple Refill Type K for SR970/SR4000 410802 9859 3 x 5,000/ Ctn. 15,000

Staple CSC760A for SR970/SR4000 89858 1 x 5,000/ Ctn. 5,000

Staple Refill CSC760B for SR970/SR4000 89859 3 x 5,000/ Ctn. 15,000

Staple Type K SC645 480-0063 1 x 5,000/ Ctn. 5,000

Staple Refill Type K SC645 480-0062 3 x 5,000/ Ctn. 15,000

Staple Type L for SR4000 (Saddle Stitch) 411240 9885 1 x 2,000/ Ctn. 2,000

Staple Refill Type L for SR4000

(Saddle Stitch) 411241 9886 4 x 2,000/ Ctn. 8,000

Staple CSC860A for SR4000

(Saddle Stitch) 89885 1 x 2,000/ Ctn. 2,000

Staple Refill CSC860B for SR4000

(Saddle Stitch) 89886 4 x 2,000/ Ctn. 8,000

Staple Type L for SR4000 (Saddle Stitch) 480-0091 1 x 2,000/ Ctn. 2,000

Staple Refill Type L for SR4000

(Saddle Stitch) 480-0092 4 x 2,000/ Ctn. 8,000

NOTE: *A4, 6% chart is used to measure the above yield. Storage period for toner is max. 1 year.

NOTE: ** Part Number

Product Support Guide

D052 / D053 / D054

Ver. 1.5 Page 6 of 41 12/12/2008

Subject to change without notice

Option Compatibility

1.DTL/A3 Tray

2.Tab Sheet Holder

3.LCT

4.LCT LG Unit

5.Copy Tray

6.50sheet staple Finisher-A

7.Saddle Stitch Finisher-B

8.100sheet Staple Finisher-C

9.Punch Units for Fin-A & B

10.Punch Unit for Fin-C

11.9-bin Mailbox

12.Cover Interposer

13.Jogger Unit for Fin-A & B

14.Jogger Unit for Fin-C

15.Z-folding unit

16.Printer / Scanner Unit

17. PS3

18. IEEE1394

19. IEEE1284 Centro

20. Wireless LAN

21.Bluetooth

22.1000Base T Ethernet

23. USB Host I/F

24. Unauthorized Copy Control Unit

25 .DOS Unit

26. VM Card

27. Copy Connector

28. File Format Converter

29. Fax Option

30.G3 Interface Unit

1.DTL/A3 Tray

2.Tab Sheet Holder

3.LCT

4.LCT LG Unit M

5.Copy Tray XXXXXXXXX

6.50sheet staple Finisher-A X X X X X

7.Saddle Stitch Finisher-B X X X X X

8.100sheet Staple Finisher-C X X X X X X

9.Punch Units for Fin-A & B X 1 1 X X X

10.Punch Unit for Fin-C X X X M X X X

11.9-bin Mailbox X 1 1 X X X X

12.Cover Interposer X X

13.Jogger Unit for Fin-A & B X 1 1 X X X

14.Jogger Unit for Fin-C X X X M X X X

15.Z-folding unit 11

16.Printer / Scanner Unit

17. PS3

18. IEEE1394 X X X

19. IEEE1284 Centro X X X

20. Wireless LAN X X X

21. Bluetooth XXX

22. 1000Base T Ethernet

23. USB Host I/F

24. Unauthorized Copy Control

Unit

25. DOS Unit

26. VM Card

27. Copy Connector

28. File Format Converter

29. Fax Option M

30. G3 Interface Unit M

X: Cannot be installed together

M: Must be installed together in RAC Market

1: Must be select one of these two options & installed together

Product Support Guide

D052 / D053 / D054

Ver. 1.5 Page 7 of 41 12/12/2008

Subject to change without notice

Branding Information

Branding is required as the machines are shipped as a generic version.

Ricoh version machines: You must attach the model label (provided) to the front cover.

Savin/Lanier: You must attach the model label (provided) to the front cover and set the Plug and Play name with

SP 5-907.

Configuration

Main Frame Configuration

Punch Unit NA 3/2

Punch Unit EU 2/4

Punch Unit Scandinavian 4

Punch Unit NA 3/2

Punch Unit EU 2/4

Punch Unit Scandinavian 4

2,000sheet

Saddle Stitch Finisher 3,000sheet_50sheet Staple

Finisher

3,000sheet_100sheet

Staple Finisher

Cover

Interposer Model MT-C3.5 Base-unit

ARDF

1,550sheet Tandem Tray x 1

550sheet Tray x 2

100sheet Bypass Tray

LCT

9-bin

Mailbox

LCT LG Unit

Jogger Unit

DLT/A3 Tray Unit

Tab Sheet Holder

Printer/Scanner Unit

Copy Connector

File Format Converter

IEEE1394 Unit

Wireless LAN Unit

Bluetooth Unit

IEEE1284 Centro Unit

PS3 Program

DataOverwriteSecurity Unit

Copy Tray

Key Counter Bracket

Key Card Bracket

VM Card

Z-folding

unit

Unauthorized Copy Control Unit

USB Hosts

Gigabite Ethernet

Product Support Guide

D052 / D053 / D054

Ver. 1.5 Page 8 of 41 12/12/2008

Subject to change without notice

MFP Option Board Slot / SD Card Assignments

This machine has built in standard 10/100BaseT Network Interface Board (NIB) and USB2.0.

In addition to them, the customer can select 1000 Base-T Ethernet, Wireless LAN Interface (IEEE802.11b, WPA

support), IEEE1394, Bluetooth or IEEE 1284 (Parallel port).

For 3rd vender IC CARD Authentication, USB Host interface is available.

PCI I/F 1

Printer/Scanne

SD card

IEEE1284

IEEE1394

Wireless

LAN

Bluetooth

USB Host

PCI I/F3

SD Card Slot

PCI I/F 2

1000 Base T

& USB2.0 *2

(Option)

10/100BaseT

& USB2.0

(Standard)

Main (GW) Controller

SD card

Service Use

only

Post Script 3

SD card

*1. Only one out of IEEE1394, IEEE1394, Wireless LAN or Bluetooth can be installed.

*2. PCI I/F for 1000 Base T& USB2.0 and 10/100BaseT & USB2.0 cannot be selected together.

Product Support Guide

D052 / D053 / D054

Ver. 1.5 Page 9 of 41 12/12/2008

Feature Comparison To Previous Version

Items D052 Series

(New Model) Improvement B246 Series

(Previous Model)

CPM 60/70/80cpm X 55/65/75cpm

Resolution 1,200dpi 1,200dpi

HDD 80GB 80GB

Operational Panel Large WVGA Large WVGA

Preview/Thumbnail Display Yes Yes

Duty 300K 300K

Life 9,000K 9,000K

MCBC 100K X 75K

Drum Yield 1,200K 1,200K

Warm up Time (sec.) 30/30/60 30 sec.

Recovery time from Off mode (sec.) 30/30/60 30 sec.

Recovery time from Low power mode 10 sec. 10 sec.

Dual sided scanning Yes Yes

Paper capacity (Standard) 4,300 sheets 4,300 sheets

Paper capacity (Maximum) 8,300 sheets 8,300 sheets

Z-folding Yes Yes

Booklet Yes Yes

Cover Interposer Yes Yes

9 bin Mailbox Yes Yes

First Copy Time (seconds) 4.2/3.5/3.5 4.2/3.5/3.5

Scan to E-mail Yes Yes

Scan to Folder Yes Yes

LDAP Yes Yes

IP v6 Printing Yes Yes

PDF Direct Print Yes Yes

Web Image Monitor Yes Yes

NRS Yes Yes

Windows Authentication Yes Yes

DOS Unit Yes Yes

Unauthorized Copy Control Yes Yes

Subject to change without notice

Product Support Guide

D052 / D053 / D054

Ver. 1.5 Page 10 of 41 12/12/2008

Feature Comparison To Previous version (GW Controller)

Item Printer Controller for D052 Series

(New Model) Printer Controller for B246 Series

(Previous Model)

Print speed 60 / 70 / 80 ppm 55 / 65 / 75 ppm

Type Embedded Embedded

CPU Intel Celeron LV 866MHz Intel Celeron LV 866MHz

Interface

USB2.0

Ethernet 100/10 base TX

1. IEEE 1394

2. Wireless LAN (IEEE802.11b)

3. Bluetooth

4. IEEE 1284 Type C

5. USB Host

6. 1000Base T Ethernet

USB2.0

Ethernet 100/10 base TX

1. IEEE 1394

2. Wireless LAN (IEEE802.11b)

3. Bluetooth

4. IEEE 1284 Type C

5. USB Host

6. 1000Base T Ethernet

Network

protocol TCP/IP, IPX/SPX, EtherTalk, SMB TCP/IP, IPX/SPX, EtherTalk, SMB

language

RPCS, PCL5e / 6

Adobe PostScript 3

RPCS, PCL5e / 6

Adobe PostScript 3

Resolution

RPCS: 300/600/1200dpi

PCL5e: 300/600dpi

PCL6: 600/1200dpi

PS3: 300/600/1200dpi

RPCS: 300/600/1200dpi

PCL5e: 300/600dpi

PCL6: 600/1200dpi

PS3: 300/600/1200dpi

Memory MAX: 512MB

(Standard 256MB Memory) MAX: 512MB

(Standard 256MB Memory)

HDD <Standard>

80.0GB <Standard>

80.0GB

Utility

software

SmartDeviceMonitor for Admin

Printer Utility for Mac,

DeskTopBinder Lite

SmartDeviceMonitor for Admin

Printer Utility for Mac,

DeskTopBinder Lite

Localization

for

Printer Driver

RPCS/PCL: 18 Languages

PS3: 12 Languages RPCS/PCL: 18 Languages

PS3: 12 Languages

Subject to change without notice

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Ricoh Imprimante tout-en-un

Ricoh

Ricoh Pro 8120s Manuel utilisateur

Ricoh

Ricoh Aficio MP C305 Manuel utilisateur

Ricoh

Ricoh Aficio DSc432 Manuel de service

Ricoh

Ricoh Aficio 2022 Manuel utilisateur

Ricoh

Ricoh Aficio MP 9002 Manuel utilisateur

Ricoh

Ricoh M0A0 Manuel utilisateur

Ricoh

Ricoh TC-IIR Manuel utilisateur

Ricoh

Ricoh 8016 Manuel utilisateur

Ricoh

Ricoh Aficio MP 1350 Manuel de service

Ricoh

Ricoh InfoPrint 4247 Manuel utilisateur

Ricoh

Ricoh Aficio MP C2030 Manuel de service

Ricoh

Ricoh C220S - Aficio SP Color Laser Mode d’emploi

Ricoh

Ricoh Aficio 240W Manuel utilisateur

Ricoh

Ricoh Toscana-P1 Manuel utilisateur

Ricoh

Ricoh A292 Manuel utilisateur

Ricoh

Ricoh Sirius-SC1fn Manuel utilisateur

Ricoh

Ricoh MP C6502SP Manuel utilisateur

Ricoh

Ricoh C221SF - Aficio SP Color Laser Instructions d'installation

Ricoh

Ricoh Aficio SP C242SF Manuel d'installation

Ricoh

Ricoh IM 2702 Manuel utilisateur

Ricoh

Ricoh MP C3003 Manuel utilisateur

Ricoh

Ricoh Mv106 Manuel utilisateur

Ricoh

Ricoh Aficio SP 100SF e Manuel utilisateur

Ricoh

Ricoh Aficio SG 3100SNw Manuel d'utilisation et d'entretien

Manuels Imprimante tout-en-un populaires d'autres marques

Triumph Adler

Triumph Adler DC 2016 Manuel

Epson

Epson WorkForce WF-2510 Guide de l'utilisateur

Epson

Epson Stylus Scan 2000 Manuel d'installation et d'exploitation

Epson

Epson PictureMate Snap PM 240 Mode d’emploi

Konica Minolta

Konica Minolta bizhub C35 Manuel utilisateur

Brother

Brother MFC-J430w Manuel utilisateur

Konica Minolta

Konica Minolta BIZHUB 558 Manuel utilisateur

Lexmark

Lexmark MX710 Series Manuel

Brother

Brother MFC-9760 Manuel utilisateur

Lexmark

Lexmark XC8155 Manuel utilisateur

Lexmark

Lexmark X642E Manuel utilisateur

Sharp

Sharp MX-2310U Mode d’emploi

Aficio

Aficio 200 Manuel utilisateur

Canon

Canon ImageCLASS 2300 Manuel

Lexmark

Lexmark X925 Manuel utilisateur

Brother

Brother Business Smart MFC-J4510dw Manuel utilisateur

Epson

Epson Stylus CX8400 Series Manuel utilisateur

Oce

Oce VarioLink 5022 Manuel utilisateur
