REED R8002 Manuel utilisateur

reedinstruments

www com

Model R8002

Laser Distance Meter

Instruction

Manual

Pantone 534 Blue

Pantone 123 Yellow

Pantone 485 Red

Pantone 123 Yellow

Pantone 534 Blue

Black Rich Black -

20/20/20/100

Blue - 100/80/30/5

Yellow - 0/27/100/0

Red - 10/100/100/5

Yellow - 0/27/100/0

Blue - 100/80/30/5

Only if you REALLY need them:

Pantone 534 Blue - 100/80/30/5

Pantone 485 Red - 10/100/100/5

Pantone 123 Yellow - 0/27/100/

www.reedinstruments.com

1-877-849-2127 | [email protected]

reedinstruments

www com

Pantone 534 Blue

Pantone 123 Yellow

Pantone 485 Red

Pantone 123 Yellow

Pantone 534 Blue

Black Rich Black -

20/20/20/100

Blue - 100/80/30/5

Yellow - 0/27/100/0

Red - 10/100/100/5

Yellow - 0/27/100/0

Blue - 100/80/30/5

Only if you REALLY need them:

Pantone 534 Blue - 100/80/30/5

Pantone 485 Red - 10/100/100/5

Pantone 123 Yellow - 0/27/100/

Table of Contents

Features......................................................................................... 3

Specications................................................................................ 3

Instrument Description.................................................................. 4

Operating Instructions................................................................5-7

Setting the Reference Point......................................................... 5

Area Measurements.................................................................... 5

Volume Measurements ............................................................... 6

2-Point Indirect Measurements ................................................... 6

3-Point Indirect Measurements ................................................... 6

Continuous, Max/Min Measurement ........................................... 7

Data Records.............................................................................. 7

Battery Replacement..................................................................... 7

Troubleshooting............................................................................. 8

www.reedinstruments.com

1-877-849-2127 | [email protected]

reedinstruments

www com

Pantone 534 Blue

Pantone 123 Yellow

Pantone 485 Red

Pantone 123 Yellow

Pantone 534 Blue

Black Rich Black -

20/20/20/100

Blue - 100/80/30/5

Yellow - 0/27/100/0

Red - 10/100/100/5

Yellow - 0/27/100/0

Blue - 100/80/30/5

Only if you REALLY need them:

Pantone 534 Blue - 100/80/30/5

Pantone 485 Red - 10/100/100/5

Pantone 123 Yellow - 0/27/100/

Features

• Measures Distance, Area, and Volume

• Indirect measurement using Pythagoras

• Max/Min Measurements

• Continuous Measurements

• Reference Setting

• Saves the last 10 measured records

Specifications

Measuring Range: 0.05 to 45m

Measuring Accuracy: Within 10m: ±2.00mm;

< 10m: ±2mm ± 0.05 x (Distance in Meters - 10)

Measuring Units: m, ft, in

Laser Type: Class II, < 1mW, 620 to 690nm

Measurement Time: 0.25 to 4 seconds

Operating Temperature: 0 to 40°C

Storage Temperature: -20 to 65°C

Power Supply: 2 x AAA Batteries

Weight: 120g

Dimensions: 112 x 48 x 25mm

www.reedinstruments.com

1-877-849-2127 | [email protected]

reedinstruments

www com

Pantone 534 Blue

Pantone 123 Yellow

Pantone 485 Red

Pantone 123 Yellow

Pantone 534 Blue

Black Rich Black -

20/20/20/100

Blue - 100/80/30/5

Yellow - 0/27/100/0

Red - 10/100/100/5

Yellow - 0/27/100/0

Blue - 100/80/30/5

Only if you REALLY need them:

Pantone 534 Blue - 100/80/30/5

Pantone 485 Red - 10/100/100/5

Pantone 123 Yellow - 0/27/100/

Instrument Description

1. On/Measure Button

2. Function Button

3. Unit/Backlight Button

4. Reference Set Button

5. Clear/Off Button

Display Description

1. Signal Strength

2. Laser Icon

3. Reference Point

4. Max/Min Icon

5. Measurement Type

6. Battery Indicator

7. Record Number

8. Continuous Measurement

9. Hardware Error

10. Measurement Result

11. Unit of Measurement

www.reedinstruments.com

1-877-849-2127 | [email protected]

reedinstruments

www com

Pantone 534 Blue

Pantone 123 Yellow

Pantone 485 Red

Pantone 123 Yellow

Pantone 534 Blue

Black Rich Black -

20/20/20/100

Blue - 100/80/30/5

Yellow - 0/27/100/0

Red - 10/100/100/5

Yellow - 0/27/100/0

Blue - 100/80/30/5

Only if you REALLY need them:

Pantone 534 Blue - 100/80/30/5

Pantone 485 Red - 10/100/100/5

Pantone 123 Yellow - 0/27/100/

Operating Instructions

Press the On button to turn the meter on. Press the Off button to turn the

meter off. The meter will automatically turn off after 3 minutes of inactivity.

Press the Measure button to activate the laser. Press the Measure button

again to take the measurement. While taking any measurement, press the

Clear button to cancel.

Press the Backlight button to turn the backlight on and off.

Press and hold the Unit button to change the measuring units.

Different measuring functions will be displayed as symbols on the LCD.

Setting the Reference Point

The default reference point is from the back of the meter. Press the

Reference Set button to switch between the front, back, or rear. The LCD

will display where the reference point with the below icons.

Area Measurements

1. While the meter is on, press the Function button till the Area

symbol appears on the LCD.

2. Press the Measure button to take the rst measurement.

Press the Measure button to take the second measurement.

3. The Area will be automatically calculated and displayed on the

LCD.

Area: Volume: 2-Point: 3-Point:

Front Back Rear

www.reedinstruments.com

1-877-849-2127 | [email protected]

reedinstruments

www com

Pantone 534 Blue

Pantone 123 Yellow

Pantone 485 Red

Pantone 123 Yellow

Pantone 534 Blue

Black Rich Black -

20/20/20/100

Blue - 100/80/30/5

Yellow - 0/27/100/0

Red - 10/100/100/5

Yellow - 0/27/100/0

Blue - 100/80/30/5

Only if you REALLY need them:

Pantone 534 Blue - 100/80/30/5

Pantone 485 Red - 10/100/100/5

Pantone 123 Yellow - 0/27/100/

Volume Measurements

1. While the meter is on, press the Function button till the Volume

symbol appears on the LCD.

2. Press the Measure button to take the rst measurement.

Press the Measure button to take the second measurement.

Press the Measure button to take the third measurement.

3. The Volume will be automatically calculated and displayed on the

LCD.

2-Point Indirect Measurements

1. While the meter is on, press the Function button till the 2-Point

symbol appears on the LCD.

2. Aim at the top measurement point and press the Measure button

to take the rst measurement.

3. Turn the meter horizontal and press the Measure button to take

the second measurement.

4. Press the Measurement button again to display the result on the

LCD. Press the Clear button to return to single measurements.

3-Point Indirect Measurements

1. While the meter is on, press the Function button till the 3-Point

symbol appears on the LCD.

2. Aim at the top measurement point and press the Measure button

to take the rst measurement.

3. Turn the meter horizontal and press the Measure button to take

the second measurement.

4. Point the meter to the bottom of the measurement point and press

the Measure button to take the third measurement.

5. Press the Measurement button again to display the result on the

LCD. Press the Clear button to return to single measurements.

www.reedinstruments.com

1-877-849-2127 | [email protected]

reedinstruments

www com

Pantone 534 Blue

Pantone 123 Yellow

Pantone 485 Red

Pantone 123 Yellow

Pantone 534 Blue

Black Rich Black -

20/20/20/100

Blue - 100/80/30/5

Yellow - 0/27/100/0

Red - 10/100/100/5

Yellow - 0/27/100/0

Blue - 100/80/30/5

Only if you REALLY need them:

Pantone 534 Blue - 100/80/30/5

Pantone 485 Red - 10/100/100/5

Pantone 123 Yellow - 0/27/100/

Continuous, Max/Min Measurement

1. While the meter is on, press and hold the Measure button to start

Continuous Measurement.

2. While measuring the Maximum and Minimum measurements will

appear on the rst and second rows on the LCD.

3. Press the Measure button to stop taking measurements.

The meter will automatically stop after taking 100 continuous

measurements.

Data Records

1. Press and hold the Feature button to access the last 10 recorded

measurements. The Record Number icon will appear on the LCD.

2. The records will appear in reverse order from the time they were

taken. Press the Function button to scroll through them.

3. Press the Measure or Clear button to return to single

measurements.

Battery Replacement

When the Battery Indicator is ashing you will need to replace the

batteries.

1. Turn the meter off and remove the battery compartment door on

the back of the meter.

2. Insert new batteries observing correct polarity.

3. Close the battery compartment door.

www.reedinstruments.com

1-877-849-2127 | [email protected]

reedinstruments

www com

Pantone 534 Blue

Pantone 123 Yellow

Pantone 485 Red

Pantone 123 Yellow

Pantone 534 Blue

Black Rich Black -

20/20/20/100

Blue - 100/80/30/5

Yellow - 0/27/100/0

Red - 10/100/100/5

Yellow - 0/27/100/0

Blue - 100/80/30/5

Only if you REALLY need them:

Pantone 534 Blue - 100/80/30/5

Pantone 485 Red - 10/100/100/5

Pantone 123 Yellow - 0/27/100/

Troubleshooting

Error messages are displayed by a number code on the LCD.

When the Hardware Error icon appears on the LCD, turn the meter on and

off several times. If the symbol still appears contact REED Instruments at

info@reedinstruments.com for repair.

Be sure to take care with the meter’s mirror. Avoid dirt, scratches, and

solvents. These may affect the accuracy and precision of the meter.

Code Cause Remedy

101 Battery too low Change batteries

104 Calculation Error Repeat procedure

152 Temperature too high Cool down the meter

153 Temperature too low Warm up the meter

154 Out of range Put target between 0.05 & 45m

155 Signal too weak Ensure surface is at and

large enough

156 Signal too strong

157 Measure error or background

brightness Darken or change target

160 Too much shaking Stabilize the meter
