REED K4010 Manuel utilisateur

reedinstruments

www com

Model K4010

Photo-Contact

Tachometer

Instruction

Manual

Pantone 534 Blue

Pantone 123 Yellow

Pantone 485 Red

Pantone 123 Yellow

Pantone 534 Blue

Black Rich Black -

20/20/20/100

Blue - 100/80/30/5

Yellow - 0/27/100/0

Red - 10/100/100/5

Yellow - 0/27/100/0

Blue - 100/80/30/5

Only if you REALLY need them:

Pantone 534 Blue - 100/80/30/5

Pantone 485 Red - 10/100/100/5

Pantone 123 Yellow - 0/27/100/

1.888.610.7664info@REED-Direct.com REED-Direct.com

reedinstruments

www com

Pantone 534 Blue

Pantone 123 Yellow

Pantone 485 Red

Pantone 123 Yellow

Pantone 534 Blue

Black Rich Black -

20/20/20/100

Blue - 100/80/30/5

Yellow - 0/27/100/0

Red - 10/100/100/5

Yellow - 0/27/100/0

Blue - 100/80/30/5

Only if you REALLY need them:

Pantone 534 Blue - 100/80/30/5

Pantone 485 Red - 10/100/100/5

Pantone 123 Yellow - 0/27/100/

Table of Contents

Features......................................................................................... 2

Specications................................................................................ 3

Instrument Description .................................................................. 4

Operating Procedures ................................................................4-5

Photo Tachometer Measurement ................................................ 4

Contact RPM Measurement........................................................ 5

Contact Surface Speed Measurement ........................................ 5

Memory Call Button Operation.................................................... 5

Battery Replacement..................................................................... 6

Features

• Automatically holds last reading for 5 minutes and recalls minimum

and maximum readings

• Characters on the 5-digit display reverse direction depending on

which measurement mode you are in

• Microcomputer LSI circuitry provides accuracy to 0.05% and permits

readings to a resolution of 0.1 RPM in either photo or contact mode

• ABS plastic housing assures years of maintenance free performance

• Designed to t comfortably in either hand

For service on this or any other REED product or information on other

REED products, contact REED Instruments at [email protected]

1.888.610.7664info@REED-Direct.com REED-Direct.com

reedinstruments

www com

Pantone 534 Blue

Pantone 123 Yellow

Pantone 485 Red

Pantone 123 Yellow

Pantone 534 Blue

Black Rich Black -

20/20/20/100

Blue - 100/80/30/5

Yellow - 0/27/100/0

Red - 10/100/100/5

Yellow - 0/27/100/0

Blue - 100/80/30/5

Only if you REALLY need them:

Pantone 534 Blue - 100/80/30/5

Pantone 485 Red - 10/100/100/5

Pantone 123 Yellow - 0/27/100/

Specifications

Range: Photo: 5 to 99,999 tr/min;

Contact: 0.5 to 20,000 tr/min;

Surface Speed: 0.05 to 1,999.9 mpmin/

0.2 to 6,560 fpm

Resolution: 0.1rpm < 999.9 tr/min, 1 rpm > 1000rpm;

0.1 mpm < 99.99 mpm;

0.1 fpm < 99.99 fpm, 1 fpm >1000 fpm

Accuracy: ±(0.5% + 1 digit)

Sampling Time: Photo: 1 sec. > 6 rpm;

Contact: 1 sec. > 60 tr/min

Detecting Distance: 50 to 150 mm (2” to 6”) typically;

300 mm (12”) max.

Operating temperature: 0 - 50°C (32 - 122°F)

Display: 5 digit LCD 10 mm high

Power Supply: (4) 1.5V L “AA” batteries

Dimensions: 215 x 65 x 38 mm

(8.5 x 2.6 x 1.5”)

Weight: 10.6 oz (300g)

Includes: 3 contact adapters (2 cones, 1 funnel),

surface speed wheel, reective tape,

batteries and hard carrying case

Optional accessories: Replacement Measuring Wheel (AS-35C)

Replacement Cone Tip (CONE)

Replacement Funnel Tip (FUNNEL)

Replacement extension Shaft (EXT-SHAFT)

Reective Tape (RT100)

1.888.610.7664info@REED-Direct.com REED-Direct.com

reedinstruments

www com

Pantone 534 Blue

Pantone 123 Yellow

Pantone 485 Red

Pantone 123 Yellow

Pantone 534 Blue

Black Rich Black -

20/20/20/100

Blue - 100/80/30/5

Yellow - 0/27/100/0

Red - 10/100/100/5

Yellow - 0/27/100/0

Blue - 100/80/30/5

Only if you REALLY need them:

Pantone 534 Blue - 100/80/30/5

Pantone 485 Red - 10/100/100/5

Pantone 123 Yellow - 0/27/100/

Instrument Description

1. Reective mark

2. Signal light beam

3. Monitor indicator

4. Display

5. Measure button

6. Memory call button

7. Function select switch

8. Rotating ring

9. Circumferential speed ring

10. Battery Compartment

Operating Procedures

Photo Tachometer Measurement

1. Slide the Function switch to the RPM (Photo) position

2. Place the reective marking (tape) to the object being measured

3. Press the Measure button and align the visible light beam with the

reective mark

4. Ensure that the Monitor indicator lights when the target passes

through the light beam

5. Release the Measure button when the reading stabilizes

(about 2 seconds)

In order to obtain greater accuracy for measurement of less than 50 RPM,

use 2 or 3 pieces of reective tape and then divide the reading with the

number of pieces used to calculate the nal gure.

1.888.610.7664info@REED-Direct.com REED-Direct.com

reedinstruments

www com

Pantone 534 Blue

Pantone 123 Yellow

Pantone 485 Red

Pantone 123 Yellow

Pantone 534 Blue

Black Rich Black -

20/20/20/100

Blue - 100/80/30/5

Yellow - 0/27/100/0

Red - 10/100/100/5

Yellow - 0/27/100/0

Blue - 100/80/30/5

Only if you REALLY need them:

Pantone 534 Blue - 100/80/30/5

Pantone 485 Red - 10/100/100/5

Pantone 123 Yellow - 0/27/100/

Contact RPM Measurement

1. Slide the Function switch to RPM (Contact) position

2. Press the Measure button while lightly pressing the rotating

device

3. Release the Measure button when the reading stabilizes (approx.

2 seconds)

Contact Surface Speed Measurement

1. Slide the Function switch to m/min. (Surface Speed) or ft/min.

(Surface Speed)

2. Press the Measure button and simply attach the surface speed

test wheel to the detector

3. Release the Measure button when the reading stabilizes

Memory Call Button Operation

The minimum, maximum and the last (nal) readings are automatically

stored during measurement. These values can be recalled anytime by

pressing the Memory Call buttonTo recall the stored value, follow these

procedures:

1. Press the Memory Call button once to display the last reading.

The symbol “LA” will appear on the display.

2. Press the Memory Call button once again to display the

maximum value. The symbol “UP” will appear on the display.

3. Press the Memory Call button once more to display the minimum

value. The symbol “DN” will appear on the display.

Max Value

Last Value

Min Value

Display

reading

Measuring Time

1.888.610.7664info@REED-Direct.com REED-Direct.com
