Reed Instruments R9905 Manuel utilisateur
Instruction
Manual
R9905
Data Logging
Indoor Air
Quality Meter
REED Instruments
2
Table of Contents
Introduction ................................................................................................ 3
Product Quality........................................................................................... 4
Safety ......................................................................................................... 4
Features...................................................................................................... 4
Included...................................................................................................... 5
Specications..........................................................................................5-6
Instrument Description............................................................................... 7
Display Description .................................................................................... 8
Operating Instructions...........................................................................9-16
Power ON/OFF...................................................................................... 9
Taking Measurements............................................................................ 9
Unit of Measurement Selection (°C/°F) ................................................. 9
Data Hold............................................................................................... 9
Min/Max and Average Readings.......................................................... 10
Backlight.............................................................................................. 11
Setup Mode......................................................................................... 11
Setting the Data Logging Sampling Rate .......................................11-12
Setting the Relative Humidity/Temperature Offset .............................. 12
Setting the CO2Offset......................................................................... 12
Setting Altitude Compensation ......................................................12-13
Set CO2Alarm Values (Hi/Lo).........................................................13-14
Setting the Auto-Power Off Time ........................................................ 14
Setting the Time and Date................................................................... 15
Data Logging ....................................................................................... 16
Upload Recorded Data to PC.............................................................. 16
Software Installation ............................................................................ 16
Clearing Stored Data ........................................................................... 16
continued...
REED Instruments
3
Calibration Mode.................................................................................17-19
CO2Calibration...............................................................................17-18
Humidity/Temperature Calibration..................................................18-19
Calibrating Hi RH .......................................................................18-20
Calibrating Lo RH............................................................................ 18
Calibrating Hi Temp......................................................................... 19
Calibrating Lo Temp...................................................................19-20
Battery Replacement................................................................................ 20
Applications.............................................................................................. 20
Accessories and Replacement Parts ....................................................... 20
Appendix A – Recommended Guidelines................................................. 21
NIOSH Recommendations .................................................................. 21
ASHRAE Standard 62 to 1989: 1000ppm........................................... 21
Building Bulletin 101 (BB101): 1500ppm ............................................ 21
OSHA: 5000ppm ................................................................................. 21
Germany, Japan, Australia: 5000ppm.................................................. 21
Product Care ............................................................................................ 21
Product Warranty ..................................................................................... 22
Product Disposal and Recycling .............................................................. 22
Product Support....................................................................................... 22
Introduction
Thank you for purchasing your REED R9905 Data Logging Indoor Air
Quality Meter. Please read the following instructions carefully before using
your instrument. By following the steps outlined in this manual your meter
will provide years of reliable service.
REED Instruments
4
Product Quality
This product has been manufactured in an ISO9001 facility and has been
calibrated during the manufacturing process to meet stated product
specications. If a certicate of calibration is required please contact the
nearest authorized REED distributor or authorized Service Center. Please
note an additional fee for this service will apply.
Safety
• Never attempt to repair or modify your instrument. Dismantling your
product, other than for the purpose of replacing batteries, may cause
damage that will not be covered under the manufacturer's warranty.
Servicing should only be provided by an authorized service center.
• Avoid condensation on CO2sensor.
• Do not hold the meter in close proximity to your mouth as exhalation
affects CO2levels.
• Do not calibrate the meter in the air with unknown CO2concentration.
Features
• Triple LCD display simultaneously monitors carbon dioxide (CO2),
temperature and relative humidity
• Calculates time-weighted average (TWA) and short-term exposure
limit (STEL)
• Low-drift NDIR CO2sensor for stable and accurate readings
• Temperature and relative humidity measurements help determine
thermal comfort
• Easy-to-read backlit LCD display
• User adjustable audible alarm
• Data hold, Max/Min and Average functions
• Record up to 32,000 datapoints and keep track with internal time and
date stamp
• User selectable sampling rate from 1 to 60 mins
• Low battery indicator and auto shut-off
REED Instruments
5
Included
• USB Cable
• Hard Carrying Case
• Batteries
Specifications
Temperature
Measuring Range: -4 to 140°F (-20 to 60°C)
Accuracy: ±1.5°F (±0.8°C)
Resolution: 0.1°F/°C
Humidity
Measuring Range: 0 to 100% RH
Accuracy: 10 to 90% RH: ±3%
<10% & >90% RH: ±5%
Resolution: 0.1% RH
CO2(Carbon Dioxide)
Sensor Type: Nondispersive Infrared (NDIR)
Measuring Range: 0 to 30,000ppm
Accuracy: 0 to 5000ppm: ±(75ppm + 3% rdg.)
5001 to 30,000ppm: ±(150 ppm +5% rdg.)
Resolution: 1ppm
Warm-up Time: 20 seconds
Sampling Rate: 2 seconds
General Specifications
Display: LCD
Backlit Display: Yes
Data Hold: Yes
Min, Max, Avg Functions: Yes
CO2Short Term
Exposure Limit (STEL): Yes (15 minutes)
continued...
REED Instruments
6
CO2Time Weighted
Average (TWA): Yes (8 hours)
Datalogging Capabilities: Yes
Real-Time Clock and
Date Stamp: Yes
Selectable Sampling Rate: Yes (between 1s and 60m59s)
Internal Memory: Yes (32,000 datapoints)
Alarm: Yes (Low and High)
Auto Shut-off: Yes (adjustable)
Kick Stand: Yes
Low Battery Indicator: Yes
Power Supply: 9V battery
Battery Life: Approx. 10 hours (continuous use)
PC Connectivity: USB
Software OS Compatibility: Windows 7/8/10
Product Certications: CE
Operating Temperature: 32 to 122°F (0 to 50°C)
Storage Temperature: -4 to 140°F (-20 to 60°C)
Operating Humidity Range: 0 to 90%
Storage Humidity Range: 10 to 75%
Maximum Operating Altitude: 6561' (2000m)
Dimensions: 11.2 x 2.6 x 1.5" (284 x 65 x 39mm)
Weight: 10.7oz (304g)
REED Instruments
7
Instrument Description
R9905
Indoor Air Quality Meter
1
10
3
4
6
812
13
2
511
7
9
1. Temp/Humidity Probe
2. CO2Sensor
3. LCD Display
4. Power and Backlight Button
5. MIN MAX AVG Button
6. SETUP Button
7. DATA HOLD Button
8. REC Button
9. °C/°F Button
10. CO2Calibration Inlet
11. USB Interface
12. Tilt Stand
13. Battery Compartment
REED Instruments
8
Display Description
CALAVGMAXMIN
FULLRECSTELTWA
%
RH
ppm
m
CO2
SET ALARM HiLo HOLD
1234 5 6 7 8
129
10
11
13
14
15
16
222120191817
1. Setup Indicator
2. Time Weighted
Average Indicator
3. CO2Alarm Indicator
4. Short-term Exposure
Limit Indicator
5. Hi CO2Alarm Indicator
6. Lo CO2Alarm Indicator
7. Recording Data Logger
Indicator
8. Data Hold Indicator
9. CO2Measurement Indicator
10. CO2Reading
11. Relative Humidity/
Temperature Reading
12. Memory Full Indicator
13. Altitude Measurement Unit
14. CO2Measurement Unit
15. Relative Humidity
Measurement Unit
16. Temperature Measurement
Unit
17. Auto Power Off
Enabled Indicator
18. Battery Status Indicator
19. Minimum Indicator
20. Maximum Indicator
21. Average Indicator
22. Calibration Mode
REED Instruments
9
Operating Instructions
Power ON/OFF
Turn the meter on by pressing the button. To turn the meter off, press
and hold the button for 3 seconds.
Taking Measurements
The meter starts taking measurements when powered on and updates
readings every 2 seconds.
Note: Make sure the CO2sensor is switched to "MEAS" position and not
the "CAL" position.
Rapid environment changes (i.e., moving your meter from indoors
to outdoors) may cause inaccurate readings, therefore,it is always
recommended to allow your meter to get acclimated to its new
environment (approx. 10 to 15 minutes). Do not
hold the meter close to your mouth or any other source of CO2.
Unit of Measurement Selection (°C/°F)
When the meter is powered on press the button to
toggle between Celsius and Fahrenheit.
Note: The default unit of measurement is Celsius (°C).
The meter will automatically save the last selected unit of
measure when turned off.
Data Hold
Press the button to freeze the current reading on the display.
Press the button again to resume normal operation.
Note: When the Data Hold function is enabled the , and
buttons are disabled.
continued...
REED Instruments
10
Min/Max and Average Readings
When in this mode, the unit simultaneously monitors and stores the
minimum, maximum and average values into the internal memory while
continuously updating/refreshing the measurement values.
1. Press the button once, the MIN indicator will appear on the LCD
display. The minimum values (CO2, humidity and temperature) are
displayed and will automatically update when new minimum data
values are measured.
2. Press the button again and the MAX indicator will appear on the
LCD display. The maximum values (CO2, humidity and temperature)
are displayed and will automatically update when new maximum
data values are measured.
3. Press the button a third time and the short-term exposure limit
(STEL) indicator will now appear on the LCD display. The STEL
average limit for the past 15 minutes will be displayed and will
automatically be updated every minute.
4. Press the button a fourth time and the time weight average
(TWA) indicator will now appear on the LCD display. The TWA limit
for the past 8 hours will be displayed and will automatically be
updated every 10 minutes.
If the meter has been powered on for less than
15 minutes, the STEL and TWA values will only reflect the
weighted average of readings taken since it was powered on.
If the meter does not have enough data to display STEL
and TWA, "----" will appear on LCD display.
5. Press the button a fth time and the "MAX, MIN, STEL and
TWA" indicators will blink simultaneously while continuing to update
the readings in memory and can be viewed by returning to the
appropriate function. While in this function, the meter is displaying
the current measurement values only.
6. Press and hold the button for 2 seconds to exit MAX/MIN/AVG
mode and resume normal operation.
continued...
REED Instruments
Ce manuel convient aux modèles suivants
1
Table des matières
Autres manuels Reed Instruments Instrument de mesure
Reed Instruments
Reed Instruments R1620 Manuel utilisateur
Reed Instruments
Reed Instruments SMART Series Manuel utilisateur
Reed Instruments
Reed Instruments SMART Series Manuel utilisateur
Reed Instruments
Reed Instruments R8130 Manuel utilisateur
Reed Instruments
Reed Instruments LM-81AM Manuel utilisateur
Reed Instruments
Reed Instruments R3500 Manuel utilisateur
Reed Instruments
Reed Instruments R5090 Manuel utilisateur
Reed Instruments
Reed Instruments Smart Series Manuel utilisateur
Reed Instruments
Reed Instruments R3525 Manuel utilisateur
Reed Instruments
Reed Instruments R7050 Manuel utilisateur
Reed Instruments
Reed Instruments R8050 Manuel utilisateur
Reed Instruments
Reed Instruments Smart R1610 Manuel utilisateur
Reed Instruments
Reed Instruments R8008 Manuel utilisateur
Reed Instruments
Reed Instruments R8140 Manuel utilisateur
Reed Instruments
Reed Instruments R1600 Manuel utilisateur
Reed Instruments
Reed Instruments R4700SD Manuel utilisateur
Reed Instruments
Reed Instruments HT-6510A Manuel utilisateur
Reed Instruments
Reed Instruments R5020 Manuel utilisateur
Reed Instruments
Reed Instruments R7700 Manuel utilisateur
Reed Instruments
Reed Instruments R9920 Manuel utilisateur
Manuels Instrument de mesure populaires d'autres marques
Endress+Hauser
Endress+Hauser Proline Promag 50 Caractéristiques techniques
Siemens
Siemens SITRANS F Coriolis FCT030 Manuel de la liste des pièces
KLINGER
KLINGER CMF V Series Manuel utilisateur
EXFO
EXFO FTB-2 Manuel d'exploitation et d'entretien
Keysight
Keysight M8290A Manuel utilisateur
ADTEK
ADTEK MW-5 Manuel utilisateur
